BEJTM910Tri-Mode Dual-Band Analog/PCS Phone

LG Electronics USA, Inc.

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: Jul 12, 2001
Application Purpose: Original Equipment
Date of Application: May 23, 2001
Equipment Note: Tri-Mode Dual-Band Analog/PCS Phone
Frequency Range: 1851.25000000 - 1908.75000000
Company: LG Electronics USA, Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

TM910 User Guide S/W Development Group 5 Part CDMA HANDSETS LAB. For more information about RF exposure, please visit the FCC website at www.fcc.gov FCC RF EXPOSURE INFORMATION In August 1996 the Federal Communications Commission (FCC) of the United States with its action in Report and Order FCC 96-326 adopted an updated safety standard for human exposure to radio frequency electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. The design of this phone complies with the FCC guidelines and these international standards. Use only the supplied or an approved antenna. Unauthorized antennas, modifications, or attachments could impair call quality, damage the phone, or result in violation of FCC regulations. Do not use the phone with a damaged antenna. If a damaged antenna comes into contact with the skin, a minor burn may result. Please contact your local dealer for replacement antenna. Body-worn Operation This device was tested for typical body-worn operations with the back of the phone kept 2.0 cm. from the body. To maintain compliance with FCC RF exposure compliance requirements, use only belt-clips, holsters or similar accessories that maintain a 2.0 cm. separation distance between the user’s body and the back of the phone, including the antenna, whether extended or retracted. The use of third-party belt-clips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with FCC RF exposure compliance requirements, and should be avoided. WARNING! Read this information before using your phone TM910 User Guide LG Electronics Proprietary Contents Part 1. Overview....................................................................................................................................6 Chapter 1. Getting Started...............................................................................................................6 Front View of Phone – Flip Closed..........................................................................................6 Front View of Phone – Flip Open............................................................................................7 LCD Icons..............................................................................................................................8 Icons.......................................................................................................................................8 Descriptions............................................................................................................................8 Using the Phone Menu ..........................................................................................................9 Common Function of PIM mode ...........................................................................................9 Turning Your Phone On and Off............................................................................................10 Using the Battery Part 2. Phone Mode..............................................................................................................................13 Chapter 2. Basic Functions............................................................................................................13 Making a Call.......................................................................................................................13 Correcting Dialing Mistakes..................................................................................................13 Receiving Calls.....................................................................................................................14 Using Quick Mode................................................................................................................14 Responding to Call Waiting...................................................................................................15 Using 3-Way Call..................................................................................................................15 Mute.....................................................................................................................................16 Redialing Calls......................................................................................................................16 Pause Feature........................................................................................................................16 Adjusting the Volumes..........................................................................................................17 Power Save Mode.................................................................................................................17 Emergency Dialing................................................................................................................17 Speed Dialing.......................................................................................................................17 Chapter 3. Managing Call History ...............................................................................................19 Viewing the Call History List ..............................................................................................19 Viewing Call Details.............................................................................................................19 Making a Call from the Recent Call History List....................................................................20 Connect to the Internal Phone Book.......................................................................................19 Erasing a Call History Entry ................................................................................................19 Viewing the Air Time ......................................................…

Text truncated - open the document above for the full version.

Attestation Statements

@ LG Electronics Inc.& May 11, 2001 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 U.S.A. To whom it may concern: We, the undersigned, hereby authorize PCTEST Engineering Laboratory, Inc., to act on our behalf in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by PCTEST Engineering Laboratory, Inc. on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to the application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, General Manager of New York Office LG Electronics Inc. May 07. 2001 Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 In re : LG Electronics Inc.. FCC ID: BEJTM910 Tri - Mode Cellular Phone (CDMA & AMPS) Part 22, 24 Certification Request for Confidentiality Gentlemen: In accordance with 0.459 of CFR 47, LG Electronics, Inc. hereby requests confidentiality of the Block Diagrams attachment, Schematic Diagrams & Circuit Description attachment, Operational Description attachment, and Parts List/Tune-Up Procedure attachment for the above-referenced Type Acceptance application. These documents contain detailed system and equipment description and related information about the product which LG Electronics Inc. Considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, LG Electronics Inc. considers this information to be of benefit to its competitors, such that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, E.S.Park Research Engineer CDMA Handset Lab LG Electronics Inc. Tel : 82-2-850-3850 Fax : 82-2-850-3861 http://[email protected] 459-9, Kasan-dong,Kemchun-ku Seoul 153-023, Korea LG Electronics Inc. LGE LGE LG Electronics Inc.& 459-9,Kasan-dong,Kemchun-ku Seoul 153-023,Korea Tel: 82-2-850-3861 Fax:82-2-850-3861 E-mail :[email protected] May 6, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: LG Information & Communications, Ltd. FCC ID: BEJTM910 FCC E911 Requirements Per S22.921 Gentlemen: LG Information & Communications, Ltd. hereby certifies that the analog cellular telephone (FCC ID:BEJTM910, using the Automatic A/B Roaming - Intelligent Retry method, meets the E911 requirements specified in Section 22.921 of the FCC Rules. This procedure recognizes when a "9-l-l" call is made and, at such time, will override any programming in the mobile unit that determines the handling of a non-911 call and permit the call to be handled by other analog carriers. Should you have any questions or comments concerning the above, please contact the undersigned. E.S.Park Research Engineer Communication Terminal Research Lab LG Electronics Inc. AFFIDAVIT FOR ESN PROTECTION OF CELLULAR MOBILE TELEPHONES We hereby certify that the LGE Handheld Portable Cellular Telephone(FCC ID: BEJTM910) is so designed that it complies with all the requirements for ESN protection specified in section 22.919 of the FCC Rules. A) The transmitter in service has a unique ESN. B) The ESN host component is permanently attached to a main circuit board of the mobile transmitter and the integrity of the unit operating software cannot be altered. The ESN is plated from fraudulent contact and tampering. The ESN is encoded using multiplication by a polynomial and the ESN data programmed in the memory with other information. C) The ESN is factory-set and cannot be altered, transferred, removed or otherwise able to be manipulated. Cellular mobile equipment is specifically designed such that any attempt to remove, tamper with, or change the ESN chip, its logic system, or firmware originally programmed by the manufacturer will render the mobile transmitter inoperative. Sincerely, E.S.Park Research Engineer CDMA Handset Lab LG Electronics Inc. Tel : 82-2-850-3850 Fax : 82-2-850-3861 http://[email protected] 459-9, Kasan-dong,Kemchun-ku Seoul 153-023, Korea LG Electronics Inc. LGE May 06, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: LG ELECTRONICS INC. FCC ID: BEJTM910 Users Manual RF Exposure Warning Statement Gentlemen: LG Electronics Inc. hereby confirms that the attached RF exposure warning page will be readily visible to the user, and will be placed at a prominent location in the front section of the users manual. If you have any further questions regarding this matter, please do not hesitate to contact me or PCTEST Lab at (410) 290-6652. Sincerely, E.S. Park Research Engineer CDMA Handset Lab. LG Electronics Inc. 459-9 Kasan-dong Kumchun-gu Seoul 153-023 Korea Tel : 82-2-850-3861 Fax : 82-2-850-3856 E_mail : [email protected] LGE LG Electronics Inc.

Cover Letter(s)

May 16, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: LG Electronics Inc. FCC ID: BEJTM910 Part 22/24 Certification Gentlemen: Submitted herewith, on behalf of LG Electronics Inc., is an application for Part 22/24 Certification of the following Tri-Mode Cellular Phone: FCC ID: BEJTM910 TRADE/MODEL(s): LGE LG-TM910 EUT TYPE: Tril-Mode Cellular Phone (AMPS/CDMA) Tx Freq. Range(s): 824.04 — 848.97 MHz (AMPS) / 824.70 — 848.31 MHz (CDMA) 1851.25 — 1908.75 MHz (PCS CDMA) Max. RF Output Power: 0.502 W ERP AMPS (27.007 dBm) / 0.398 W ERP CDMA (25.984 dBm) 0.252 W EIRP PCS CDMA (24.010 dBm) Max. SAR Measurement: 1.260 mW/g (1g) AMPS Head SAR; 0.991 mW/g (1g) CDMA Head SAR; 1.280 mW/g (1g) PCS CDMA Head SAR 0.463 mW/g (1g) AMPS Body SAR; 0.363 mW/g (1g) CDMA Body SAR; 0.523 mW/g (1g) PCS CDMA Body SAR 1.690 mW/g (10g) AMPS Hand SAR; 1.180 mW/g (10g) CDMA Hand SAR; 1.310 mW/g (10g) PCS CDMA Hand SAR Attached is the applicant’s Letter of Authorization, Confidentiality Request, ESN Affidavit, E911 compliance statement, measurement report test data and plots, RF Exposure measurement report and data, FCC ID label and location, test setup photographs, internal and external photographs, block diagram (confidential), circuit diagrams & description (confidential), operational description (confidential), parts list & tune-up procedure (confidential), and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc: Mr. Harris Ahn Principal Engineer Communication Terminal Research Lab, LGE

Cover Letter(s)

June 21, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Frank Coperich SUBJECT: LG Electronics Inc. FCC ID: BEJTM910 731 Confirmation No.: EA101122 Correspondence Reference No.: 19662 Request for Tech. Info.: 06/18/2001 Dear Frank: Transmitted herewith, on behalf of LG Electronics Inc., is an amendment provided in response to the request for technical information dated June 18, 2001. 1. Please find attached the revised test data. 2. We would like to confirm that the justification for the reported mixture is that it will lead to an overestimation of the SAR measurement value. This takes into account the measurement error and uncertainty for demonstrating compliance. We trust this information is sufficient to issue the grant as soon as possible. If you have any further questions, please do not hesitate to contact us. cc: LG Electronics Inc.

Cover Letter(s)

June 26, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Frank Coperich SUBJECT: LG Electronics Inc. FCC ID: BEJTM910 731 Confirmation No.: EA101122 Correspondence Reference No.: 19662 Request for Tech. Info.: 06/26/2001 Dear Frank: Transmitted herewith, on behalf of LG Electronics Inc., is an amendment provided in response to the request for technical information dated June 26, 2001. 1. Please find attached the confidential letter per your request. We trust this information is sufficient to issue the grant as soon as possible. If you have any further questions, please do not hesitate to contact us. cc: LG Electronics Inc.
