BEJTM910BTri-Mode Dual-Band Analog/PCS Phone

TM910B User Guide S/W Development Group 5 Part CDMA HANDSETS LAB. For more information about RF exposure, please visit the FCC website at www.fcc.gov FCC RF EXPOSURE INFORMATION In August 1996 the Federal Communications Commission (FCC) of the United States with its action in Report and Order FCC 96-326 adopted an updated safety standard for human exposure to radio frequency electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. The design of this phone complies with the FCC guidelines and these international standards. Use only the supplied or an approved antenna. Unauthorized antennas, modifications, or attachments could impair call quality, damage the phone, or result in violation of FCC regulations. Do not use the phone with a damaged antenna. If a damaged antenna comes into contact with the skin, a minor burn may result. Please contact your local dealer for replacement antenna. Body-worn Operation This device was tested for typical body-worn operations with the back of the phone kept 2.0 cm. from the body. To maintain compliance with FCC RF exposure compliance requirements, use only belt-clips, holsters or similar accessories that maintain a 2.0 cm. separation distance between the user’s body and the back of the phone, including the antenna, whether extended or retracted. The use of third-party belt-clips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with FCC RF exposure compliance requirements, and should be avoided. WARNING! Read this information before using your phone TM910B User Guide LG Electronics Proprietary Contents Part 1. Overview....................................................................................................................................6 Chapter 1. Getting Started...............................................................................................................6 Front View of Phone – Flip Closed..........................................................................................6 Front View of Phone – Flip Open............................................................................................7 LCD Icons..............................................................................................................................8 Icons.......................................................................................................................................8 Descriptions............................................................................................................................8 Using the Phone Menu ..........................................................................................................9 Common Function of PIM mode ...........................................................................................9 Turning Your Phone On and Off............................................................................................10 Using the Battery Part 2. Phone Mode..............................................................................................................................13 Chapter 2. Basic Functions............................................................................................................13 Making a Call.......................................................................................................................13 Correcting Dialing Mistakes.................................................................................................. 13 Receiving Calls.....................................................................................................................14 Using Quick Mode................................................................................................................14 Responding to Call Waiting................................................................................................... 15 Using 3-Way Call..................................................................................................................15 Mute.....................................................................................................................................16 Redialing Calls......................................................................................................................16 Pause Feature........................................................................................................................16 Adjusting the Volumes..........................................................................................................17 Power Save Mode.................................................................................................................17 Emergency Dialing................................................................................................................17 Speed Dialing.......................................................................................................................17 Chapter 3. Managing Call History ...............................................................................................19 Viewing the Call History List ..............................................................................................19 Viewing Call Details.............................................................................................................19 Making a Call from the Recent Call History List....................................................................20 Connect to the Internal Phone Book.......................................................................................19 Erasing a Call History Entry ................................................................................................19 Viewing the Air Time ..................................................…

Text truncated - open the document above for the full version.

TM910B User Guide LG Electronics Proprietary Labeling requirements: This device shall bear the following statement in a conspicuous location on the device.

@ LG Electronics Inc.& May 11, 2001 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 U.S.A. To whom it may concern: We, the undersigned, hereby authorize PCTEST Engineering Laboratory, Inc., to act on our behalf in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by PCTEST Engineering Laboratory, Inc. on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to the application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, General Manager of New York Office LG Electronics Inc. LGE LG Electronics Inc.& 459-9,Kasan-dong,Kemchun-ku Seoul 153-023,Korea Tel: 82-2-850-3861 Fax:82-2-850-3861 E-mail :[email protected] October 2, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: LG Information & Communications, Ltd. FCC ID: BEJTM910B FCC E911 Requirements Per S22.921 Gentlemen: LG Information & Communications, Ltd. hereby certifies that the analog cellular telephone (FCC ID:BEJTM910B, using the Automatic A/B Roaming - Intelligent Retry method, meets the E911 requirements specified in Section 22.921 of the FCC Rules. This procedure recognizes when a "9-l-l" call is made and, at such time, will override any programming in the mobile unit that determines the handling of a non-911 call and permit the call to be handled by other analog carriers. Should you have any questions or comments concerning the above, please contact the undersigned. E.S.Park Research Engineer Communication Terminal Research Lab LG Electronics Inc. AFFIDAVIT FOR ESN PROTECTION OF CELLULAR MOBILE TELEPHONES We hereby certify that the LGE Handheld Portable Cellular Telephone(FCC ID: BEJTM910B) is so designed that it complies with all the requirements for ESN protection specified in section 22.919 of the FCC Rules. A) The transmitter in service has a unique ESN. B) The ESN host component is permanently attached to a main circuit board of the mobile transmitter and the integrity of the unit operating software cannot be altered. The ESN is plated from fraudulent contact and tampering. The ESN is encoded using multiplication by a polynomial and the ESN data programmed in the memory with other information. C) The ESN is factory-set and cannot be altered, transferred, removed or otherwise able to be manipulated. Cellular mobile equipment is specifically designed such that any attempt to remove, tamper with, or change the ESN chip, its logic system, or firmware originally programmed by the manufacturer will render the mobile transmitter inoperative. Sincerely, E.S.Park Research Engineer CDMA Handset Lab LG Electronics Inc. Tel : 82-2-850-3850 Fax : 82-2-850-3861 http://[email protected] 459-9, Kasan-dong,Kemchun-ku Seoul 153-023, Korea LG Electronics Inc. LGE October 2, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: LG ELECTRONICS INC. FCC ID: BEJTM910B Users Manual RF Exposure Warning Statement Gentlemen: LG Electronics Inc. hereby confirms that the attached RF exposure warning page will be readily visible to the user, and will be placed at a prominent location in the front section of the users manual. If you have any further questions regarding this matter, please do not hesitate to contact me or PCTEST Lab at (410) 290-6652. Sincerely, E.S. Park Research Engineer CDMA Handset Lab. LG Electronics Inc. 459-9 Kasan-dong Kumchun-gu Seoul 153-023 Korea Tel : 82-2-850-3861 Fax : 82-2-850-3856 E_mail : [email protected] LGE LG Electronics Inc.

October 2. 2001 Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 In re : LG Electronics Inc.. FCC ID: BEJTM910B Tri - Mode Cellular Phone (CDMA & AMPS) Part 22, 24 Certification Request for Confidentiality Gentlemen: In accordance with 0.459 of CFR 47, LG Electronics, Inc. hereby requests confidentiality of the Block Diagrams attachment, Schematic Diagrams & Circuit Description attachment, Operational Description attachment, and Parts List/Tune-Up Procedure attachment for the above-referenced Type Acceptance application. These documents contain detailed system and equipment description and related information about the product which LG Electronics Inc. Considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, LG Electronics Inc. considers this information to be of benefit to its competitors, such that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, E.S.Park Research Engineer CDMA Handset Lab LG Electronics Inc. Tel : 82-2-850-3850 Fax : 82-2-850-3861 http://[email protected] 459-9, Kasan-dong,Kemchun-ku Seoul 153-023, Korea LG Electronics Inc. LGE

September 28, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: LG Electronics Inc. FCC ID: BEJTM910B Part 22/24 Certification Gentlemen: Submitted herewith, on behalf of LG Electronics Inc., is an application for Part 22/24 Certification of the following Tri-Mode Cellular Phone: FCC ID: BEJTM910B TRADE/MODEL(s): LGE LG-TM910B EUT TYPE: Tri-Mode Dual-Band Analog/PCS Cellular Phone (AMPS/CDMA) Tx Freq. Range(s): 824.04 — 848.97 MHz (AMPS) / 824.70 — 848.31 MHz (CDMA) 1851.25 — 1908.75 MHz (PCS CDMA) Max. RF Output Power: 0.534 W ERP AMPS (27.279 dBm) / 0.399W ERP CDMA (25.999 dBm) 0.252 W EIRP PCS CDMA (24.016 dBm) Max. SAR Measurement: 1.29 mW/g (1g) AMPS Head SAR; 0.915 mW/g (1g) CDMA Head SAR; 1.33 mW/g (1g) PCS CDMA Head SAR 0.472 mW/g (1g) AMPS Body SAR; 0.355 mW/g (1g) CDMA Body SAR; 0.527 mW/g (1g) PCS CDMA Body SAR 1.74 mW/g (10g) AMPS Hand SAR; 1.24 mW/g (10g) CDMA Hand SAR; 1.33 mW/g (10g) PCS CDMA Hand SAR Attached is the applicant’s Letter of Authorization, Confidentiality Request, ESN Affidavit, E911 compliance statement, measurement report test data and plots, RF Exposure measurement report and data, FCC ID label and location, test setup photographs, internal and external photographs, block diagram (confidential), circuit diagrams & description (confidential), operational description (confidential), parts list & tune-up procedure (confidential), and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc: Mr. Harris Ahn Principal Engineer Communication Terminal Research Lab, LGE

November 5, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Steve Dayhoff SUBJECT: LG Electronics Inc. FCC ID: BEJTM910B 731 Confirmation No.: EA102702 Correspondence Reference No.: 21100 Request for Tech. Info.: 10/31/2001 Dear Steve: Transmitted herewith, on behalf of LG Electronics Inc., is an amendment provided in response to the request for technical information dated October 31, 2001. 1. Please find attached an explanation of the basic function of the Bluetooth. 2. Please find attached the Block Diagram and antenna diagram confirming there is a separate internal antenna for the Bluetooth transmission. We trust this information is sufficient to issue the grant as soon as possible. If you have any further questions, please do not hesitate to contact us.

January 3, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Linda Eillott SUBJECT: LG Electronics Inc. FCC ID: BEJTM910B 731 Confirmation No.: EA102702 Correspondence Reference No.: 21529 Request for Tech. Info.: 12/19/2001 Dear Linda: Transmitted herewith, on behalf of LG Electronics Inc., is an amendment provided in response to the request for technical information dated December 19, 2001. 1. Please find attached the revised users manual which describes where the compliance statement will be placed on the device. 2. We would like to confirm that we have submitted the payment for the confidentiality fee of $145.00. We trust this information is sufficient to issue the grant as soon as possible. If you have any further questions, please do not hesitate to contact us.

January 3, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Linda Eillott SUBJECT: LG Electronics Inc. FCC ID: BEJTM910B 731 Confirmation No.: EA102702 Correspondence Reference No.: 21529 Request for Tech. Info.: 12/19/2001 Dear Linda: Transmitted herewith, on behalf of LG Electronics Inc., is an amendment provided in response to the request for technical information dated December 19, 2001. 1. Please find attached the revised users manual which describes where the compliance statement will be placed on the device. 2. We would like to confirm that we have submitted the payment for the confidentiality fee of $145.00. We trust this information is sufficient to issue the grant as soon as possible. If you have any further questions, please do not hesitate to contact us.

© 2001 PCTEST Lab FCC ID: BEJTM910B (Model: LG-TM910B) NVLAP Lab Code: 100431-0 LGE Tri-Mode Dual-Band Analog/PCS Phone © 2001 PCTEST Lab FCC ID: BEJTM910B (Model: LG-TM910B) NVLAP Lab Code: 100431-0 LGE Tri-Mode Dual-Band Analog/PCS Phone © 2001 PCTEST Lab FCC ID: BEJTM910B (Model: LG-TM910B) NVLAP Lab Code: 100431-0 LGE Tri-Mode Dual-Band Analog/PCS Phone © 2001 PCTEST Lab FCC ID: BEJTM910B (Model: LG-TM910B) NVLAP Lab Code: 100431-0 LGE Tri-Mode Dual-Band Analog/PCS Phone © 2001 PCTEST Lab FCC ID: BEJTM910B (Model: LG-TM910B) NVLAP Lab Code: 100431-0 LGE Tri-Mode Dual-Band Analog/PCS Phone © 2001 PCTEST Lab FCC ID: BEJTM910B (Model: LG-TM910B) NVLAP Lab Code: 100431-0 LGE Tri-Mode Dual-Band Analog/PCS Phone © 2001 PCTEST Lab FCC ID: BEJTM910B (Model: LG-TM910B) NVLAP Lab Code: 100431-0 LGE Tri-Mode Dual-Band Analog/PCS Phone

© 2001 PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE) LG Electronics Inc. 2. 983 (f) Equipment Identification: LG Electronics Inc. LGE Model No. : LG-TM910B FCC ID : BEJTM910B S/N : Made in Korea

© 2001 PCTEST Lab FCC ID: BEJTM910B (Model: LG-TM910B) NVLAP Lab Code: 100431-0 LGE Tri-Mode Dual-Band Analog/PCS Phone © 2001 PCTEST Lab FCC ID: BEJTM910B (Model: LG-TM910B) NVLAP Lab Code: 100431-0 LGE Tri-Mode Dual-Band Analog/PCS Phone © 2001 PCTEST Lab FCC ID: BEJTM910B (Model: LG-TM910B) NVLAP Lab Code: 100431-0 LGE Tri-Mode Dual-Band Analog/PCS Phone © 2001 PCTEST Lab FCC ID: BEJTM910B (Model: LG-TM910B) NVLAP Lab Code: 100431-0 LGE Tri-Mode Dual-Band Analog/PCS Phone © 2001 PCTEST Lab FCC ID: BEJTM910B (Model: LG-TM910B) NVLAP Lab Code: 100431-0 LGE Tri-Mode Dual-Band Analog/PCS Phone © 2001 PCTEST Lab FCC ID: BEJTM910B (Model: LG-TM910B) NVLAP Lab Code: 100431-0 LGE Tri-Mode Dual-Band Analog/PCS Phone © 2001 PCTEST Lab FCC ID: BEJTM910B (Model: LG-TM910B) NVLAP Lab Code: 100431-0 LGE Tri-Mode Dual-Band Analog/PCS Phone © 2001 PCTEST Lab FCC ID: BEJTM910B (Model: LG-TM910B) NVLAP Lab Code: 100431-0 LGE Tri-Mode Dual-Band Analog/PCS Phone © 2001 PCTEST Lab FCC ID: BEJTM910B (Model: LG-TM910B) NVLAP Lab Code: 100431-0 LGE Tri-Mode Dual-Band Analog/PCS Phone

LGE FCC ID:BEJTM910B -- FM Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Brain: σ = 0.90 mho/m ε r = 41.5 ρ = 1.00 g/cm 3 ; Antenna Position -- In; Crest Factor 1.0 SAR (1g): 0.321 mW/g, SAR (10g): 0.219 mW/g LGE TriMode Phone Model:LG-TM910B FM Mode, Ch.0991[824.04MHz]; Flip = Closed Conducted Power = 26.0dBM; BlueTooth = 2.5mW Test Date -- 09/24/2001 SAR Tot [mW/g] 3.14E-2 9.26E-2 1.57E-1 2.22E-1 2.79E-1 PCTEST Engineering Laboratory, Inc. LGE FCC ID:BEJTM910B -- FM Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Brain: σ = 0.90 mho/m ε r = 41.5 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.977 mW/g, SAR (10g): 0.702 mW/g LGE TriMode Phone Model:LG-TM910B FM Mode, Ch.0991 [824.04MHz]; Flip = Closed Conducted Power = 26.0dBM; BlueTooth = 2.5mW Test Date -- 09/24/2001 SAR Tot [mW/g] 9.66E-2 2.93E-1 4.81E-1 6.88E-1 8.74E-1 PCTEST Engineering Laboratory, Inc. LGE FCC ID:BEJTM910B -- FM Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Brain: σ = 0.90 mho/m ε r = 41.5 ρ = 1.00 g/cm 3 ; Antenna Position -- In; Crest Factor 1.0 SAR (1g): 0.509 mW/g, SAR (10g): 0.348 mW/g LGE TriMode Phone Model:LG-TM910B FM Mode, Ch.0383 [836.49MHz]; Flip = Closed Conducted Power = 26.0dBM; BlueTooth = 2.5mW Test Date -- 09/24/2001 SAR Tot [mW/g] 5.19E-2 1.58E-1 2.55E-1 3.69E-1 4.55E-1 PCTEST Engineering Laboratory, Inc. LGE FCC ID:BEJTM910B -- FM Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Brain: σ = 0.90 mho/m ε r = 41.5 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 1.29 mW/g, SAR (10g): 0.899 mW/g LGE TriMode Phone Model:LG-TM910B FM Mode, Ch.0383 [836.49MHz]; Flip = Closed Conducted Power = 26.0dBM; BlueTooth = 2.5mW Test Date -- 09/24/2001 SAR Tot [mW/g] 1.04E-1 3.12E-1 5.20E-1 7.35E-1 9.43E-1 PCTEST Engineering Laboratory, Inc. LGE FCC ID:BEJTM910B -- FM Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Brain: σ = 0.90 mho/m ε r = 41.5 ρ = 1.00 g/cm 3 ; Antenna Position -- In; Crest Factor 1.0 SAR (1g): 0.459 mW/g, SAR (10g): 0.324 mW/g LGE TriMode Phone Model:LG-TM910B FM Mode, Ch.0799 [848.97MHz]; Flip = Closed Conducted Power = 26.0dBM; BlueTooth = 2.5mW Test Date -- 09/24/2001 SAR Tot [mW/g] 4.62E-2 1.39E-1 2.26E-1 3.21E-1 4.10E-1 PCTEST Engineering Laboratory, Inc. LGE FCC ID:BEJTM910B -- FM Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Brain: σ = 0.90 mho/m ε r = 41.5 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 1.12 mW/g, SAR (10g): 0.771 mW/g LGE TriMode Phone Model:LG-TM910B FM Mode, Ch.0799 [848.97MHz]; Flip = Closed Conducted Power = 26.0dBM; BlueTooth = 2.5mW Test Date -- 09/24/2001 SAR Tot [mW/g] 1.08E-1 3.19E-1 5.24E-1 7.43E-1 9.60E-1 PCTEST Engineering Laboratory, Inc. LGE FCC ID:BEJTM910B -- Cellular CDMA Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Brain: σ = 0.90 mho/m ε r = 41.5 ρ = 1.00 g/cm 3 ; Antenna Position -- In; Crest Factor 1.0 SAR (1g): 0.409 mW/g, SAR (10g): 0.285 mW/g LGE TriMode Phone Model:LG-TM910B Cellular CDMA Mode, Ch.0363 [835.89MHz]; Flip = Closed Conducted Power = 25.0dBM; BlueTooth = 2.5mW Test Date -- 09/24/2001 SAR Tot [mW/g] 4.06E-2 1.14E-1 2.08E-1 2.84E-1 3.65E-1 PCTEST Engineering Laboratory, Inc. LGE FCC ID:BEJTM910B -- Cellular CDMA Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Brain: σ = 0.90 mho/m ε r = 41.5 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.915 mW/g, SAR (10g): 0.657 mW/g LGE TriMode Phone Model:LG-TM910B Cellular CDMA Mode, Ch.0363 [835.89MHz]; Flip = Closed Conducted Power = 25.0dBM; BlueTooth = 2.5mW Test Date -- 09/24/2001 SAR Tot [mW/g] 9.18E-2 2.66E-1 4.47E-1 6.39E-1 8.14E-1 PCTEST Engineering Laboratory, Inc. LGE FCC ID:BEJTM910B -- PCS CDMA Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 1900 MHz Brain: σ = 1.62 mho/m ε r = 40.0 ρ = 1.00 g/cm 3 ; Antenna Position -- In; Crest Factor 1.0 SAR (1g): 0.945 mW/g, SAR (10g): 0.512 mW/g LGE TriMode Phone Model:LG-TM910B PCS CDMA Mode, Ch.0025 [1851.25MHz]; Flip = Closed Conducted Power = 23.0dBM; BlueTooth = 2.5mW Test Date -- 09/25/2001 SAR Tot [mW/g] 8.45E-2 2.51E-1 4.30E-1 5.83E-1 7.64E-1 PCTEST Engineering Laboratory, Inc. LGE FCC ID:BEJTM910B -- PCS CDMA Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 1900 MHz Brain: σ = 1.62 mho/m ε r = 40.0 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.314 mW/g, SAR (10g): 0.169 mW/g LGE TriMode Phone Model:LG-TM910B PCS CDMA Mode, Ch.0025 [1851.25MHz]; Flip = Closed Conducted Power = 23.0dBM; BlueTooth = 2.5mW Test Date -- 09/25/2001 SAR Tot [mW/g] 2.79E-2 8.54E-2 1.55E-1 1.82E-1 2.62E-1 PCTEST Engineering Laboratory, Inc. LGE FCC ID:BEJTM910B -- PCS CDMA Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 1900 MHz Brain: σ = 1.62 mho/m ε r = 40.0 ρ = 1.00 g/cm 3 ; Antenna Position -- In; Crest Factor 1.0 SAR (1g): 1.33 mW/g, SAR (10g): 0.691 mW/g LGE TriMode Phone Model:LG-TM910B PCS CDMA Mode, Ch.0600 [1880.00MHz]; Flip = Closed Conducted Power = 23.0dBM; BlueTooth = 2.5mW Test Date -- 09/25/2001 SAR Tot [mW/g] 8.70E-2 2.69E-1 4.41E-1 6.03E-1 7.90E-1 PCTEST Engineering Laboratory, Inc. LGE FCC ID:BEJTM910B -- PCS CDMA Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. …

Text truncated - open the document above for the full version.

© 2001 PCTEST Lab FCC ID: BEJTM910B (Model: LG-TM910B) NVLAP Lab Code: 100431-0 LGE Tri-Mode Dual-Band Analog/PCS Phone © 2001 PCTEST Lab FCC ID: BEJTM910B (Model: LG-TM910B) NVLAP Lab Code: 100431-0 LGE Tri-Mode Dual-Band Analog/PCS Phone © 2001 PCTEST Lab FCC ID: BEJTM910B (Model: LG-TM910B) NVLAP Lab Code: 100431-0 LGE Tri-Mode Dual-Band Analog/PCS Phone © 2001 PCTEST Lab FCC ID: BEJTM910B (Model: LG-TM910B) NVLAP Lab Code: 100431-0 LGE Tri-Mode Dual-Band Analog/PCS Phone © 2001 PCTEST Lab FCC ID: BEJTM910B (Model: LG-TM910B) NVLAP Lab Code: 100431-0 LGE Tri-Mode Dual-Band Analog/PCS Phone © 2001 PCTEST Lab FCC ID: BEJTM910B (Model: LG-TM910B) NVLAP Lab Code: 100431-0 LGE Tri-Mode Dual-Band Analog/PCS Phone © 2001 PCTEST Lab FCC ID: BEJTM910B (Model: LG-TM910B) NVLAP Lab Code: 100431-0 LGE Tri-Mode Dual-Band Analog/PCS Phone © 2001 PCTEST Lab FCC ID: BEJTM910B (Model: LG-TM910B) NVLAP Lab Code: 100431-0 LGE Tri-Mode Dual-Band Analog/PCS Phone © 2001 PCTEST Lab FCC ID: BEJTM910B (Model: LG-TM910B) NVLAP Lab Code: 100431-0 LGE Tri-Mode Dual-Band Analog/PCS Phone

© 2001 PCTEST Engineering Lab., Inc. PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE (SAR EVALUATION) LG Electronics Inc. Dates of Tests: Sept. 19-21, 2001 Communication Terminal Research Lab Test Report S/N: SAR.210827555.CKL 459-9, Kasan-dong, Keumchun-Ku Test Site: PCTEST Lab, Columbia, MD USA Seoul 153-023, Korea Attn: Haris Ahn, Principal Engineer FCC ID BEJTM910B APPLICANT LG ELECTRONICS INC. EUT Type: Tri-Mode Dual-Band Analog/PCS Phone (AMPS/CDMA) Tx Frequency: 824.04 — 848.97 MHz (AMPS) / 824.70 — 848.31 MHz (CDMA) 1851.25 — 1908.75 MHz (PCS CDMA) Rx Frequency: 869.04 — 893.97 MHz (AMPS) / 869.70 — 893.31 MHz (CDMA) 1931.25 — 1988.75 MHz (PCS CDMA) Max. RF Output Power: 0.534 W ERP AMPS (27.279 dBm) / 0.399 W ERP CDMA (25.999 dBm) 0.252 W EIRP (24.016 dBm) Max. SAR Measurement: 1.29mW/g AMPS Head SAR; 0.472mW/g AMPS Body SAR; 1.74mW/g AMPS Hand SAR 0.915mW/g CDMA Head SAR; 0.355mW/g CDMA Body SAR; 1.24mW/g CDMA Hand SAR 1 .33mW/g PCS Head SAR; 0.527mW/g PCS Body SAR; 1.33mW/g PCS Hand SAR Trade Name/Model(s): LG-TM910B FCC Classification: Licensed Portable Transmitter Held to Ear (PCE) FCC Rule Part(s): §2.1093; ET Docket 96.326 Application Type: Certification Antenna Manufacturer: GALTRONICS Model No.: 02-4128-75-952 Antenna Dimensions: Length = 10.29 cm. [Helical / Whip] This wireless portable device has been shown to be capable of continued compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in ANSI/IEEE Std. C95.3-1992. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. NVLAP accreditation does not constitute any product endorsement by NVLAP or any agency of the United States Government. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. 210511292.BEJ SAR Measurement Report FCC Part 24/22 Certification © 2001 PCTEST Lab i Table of Contents 1.1 SCOPE 1 2.1 INTRODUCTION / SAR DEFINITION 2 3.1 SAR MEASUREMENT SET-UP 3 4.1 E-FIELD PROBE SYSTEM 4 5.1 E-FIELD PROBE CALIBRATION PROCESS 5-6 6.1 PHANTOM, HOLDER, & EQUIVALENT TISSUE 7 7.1 SYSTEM SPECIFICATIONS 8 8.1 MEASUREMENT PROCESS 9 9.1 TEST POSITION OF THE PHONE 10 10.1 BODY SAR TEST SETUP 11 11.1 ANSI/IEEE C95.1 RF EXPOSURE LIMITS 12 12.1 MEASUREMENT UNCERTAINTIES 13 13.1 TEST DATA SUMMARY 14-22 14.1 SAR TEST EQUIPMENT LIST 23 15.1 CONCLUSION 24 16.1 REFERENCES 25 Test Report S/N: SAR.210827555.BEJ SAR Measurement Report Test Date(s): Sept. 19-21, 2001 FCC Part 24/22 Certification © 2001 PCTEST Lab LGE FCC ID: BEJTM910B (Model: LG-TM910B) 1 Tri-Mode Dual-Band Analog/PCS Phone (AMPS/CDMA) SAR MEASUREMENT REPORT 1.1 Scope Environmental evaluation measurements of specific absorption rate 1 (SAR) distributions in simulated human head and body tissues exposed to radiofrequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 2 Company Name: LG ELECTRONICS INC. Address: Communication Terminal Research Lab 459-9, Kasan-dong, Keumchun-Ku Attention: Seoul 153-023, Korea Harris Ahn, Principal Engineer • EUT Type: Tri-Mode Dual-Band Analog/PCS Phone • Trade Name / Model: LG-TM910B • FCC IDENTIFIER: BEJTM910B • Tx Frequency: 824.04 — 848.97 MHz (AMPS) 824.70 — 848.31 MHz (CDMA) 1851.25 — 1908.75 MHz (PCS CDMA) • Rx Frequency: 869.04 — 893.97 MHz (AMPS) 869.70 — 893.31 MHz (CDMA) 1931.25 — 1988.75 MHz (PCS CDMA) • FCC Classification: Licensed Portable Transmitter Held to Ear (PCE) • Modulation(s): AMPS / CDMA • FCC Rule Part(s): §2.1093, Docket 96-326 • Max. RF Output Power: 0.534 W ERP - AMPS (27.279 dBm) 0.399 W ERP - CDMA (25.999 dBm) 0.252 W EIRP - PCS CDMA (24.016 dBm) • Max SAR Measurement: 1.29mW/g AMPS Head SAR; 0.472mW/g AMPS Body SAR; 1.74mW/g AMPS Hand SAR 0.915mW/g CDMA Head SAR; 0.355mW/g CDMA Body SAR; 1.24mW/g CDMA Hand SAR 1.33mW/g PCS Head SAR; 0.527mW/g PCS Body SAR; 1.33mW/g PCS Hand SAR • Application Type: Certification • Dates of Tests: Sept. 19-21, 2001 Place of Tests: PCTEST Engineering Lab. Columbia, MD, U.S.A. • Report Serial No.: SAR.210827555.BEJ 1 Specific Absorption Rate (SAR) is a measure of the rate of energy absorption due to exposure to an RF transmitting source (wireless portable device). 2 IEEE/ANSI Std. C95.1-1992 limits are used to determine compliance with FCC ET Docket 93-62. Fig. 1 SAR Test Setup Test Report S/N: SAR.210827555.BEJ SAR Measurement Report Test Date(s): Sept. 19-21, 2001 FCC Part 24/22 Certification © 2001 PCTEST Lab LGE FCC ID: BEJTM…
