BEJTP200Touch Pen

[KOREA] LG Touch Pen User Information (Model Name: AN-TP200) 목 차 1. LG Touch Pen 의 개요 및 제원 (1) 개 요 (2) 제 원 2. 주의 사항 3. 고객지원 4. User notice (1) 개 요 이 LG Touch Pen 는 사용자가 가정이나 사무실에서 PDP TV 에 직접 글이나 그림을 나타낼 수 있으며, 2.4GHz 대역의 무 선방식을 LG Pentouch Dongle 과 연동하여 PDP 화면을 제어 하는 송신부 제품입니다. (2) 제 원 구 분 내 용 모 델 명 AN-TP200 주파수 대역 2402MHz ~ 2480MHz 채 널 79EA 송신 출력 0 dBm 수신 감도 -82dBm 크 기 폭 17 x 두께 18.5 x 길이 196.8 (공차 ± 1mm) 무 게 36.34g 전 원 3.7V (Lithium ion Battery) 동작 온도 0°C ~ + 40 °C 1. LG Touch Pen 의 개요 및 제원 2. 주의 사항 (1) LG Touch Pen 구입 후 제품 사용법에 따라 페어링 후에 사용 하세요 . (2) LG Touch Pen 의 밧데리는 교체할 수 없으며, 수시로 USB를 통해 충전하여 사용하세요. (3) 제품을 분해하거나, 열을 가해서는 안됩니다. (4) 케이스가 손상될 정도로 극심한 충격을 줘서는 안됩니다. (5) 제품을 물에 넣어서는 안됩니다. 3. 고객 지원 (1) TV 매뉴얼의 서비스 연락처를 참조하세요. (2) 보증기간 : 1년 보증 기간 중에 정상적인 사용 중에 기술상의 결함이나 문제가 나타났을 때, 구입처를 방문하세요. 이 보증은 제품을 구매한 그 지역의 구매자에게만 적용됩니다. (3) KCC 인증 마크 및 인증번호 KCC-CRM-LGE-EBX615087 기자재의 명칭 (모델명) : 특정소출력무선 기기 (무선데이터 통신 시스템용 무선기기)/AN-TP200 상호명 : 엘지전자(주) 제조자 /제조국가: 엘지전자(주)/대한민국 제조년월: . . [ENGLISH] Contents 1. Overview and Specifications of LG Touch Pen (1) Overview (2) Specifications 2. Cautions 3. Customer Support 4. User Notice (1) Overview The LG Touch Pen allows you to type text or draw a picture directly on the PDP TV at home or in the office. It is a transmitter that controls the PDP screen by working with the LG Pentouch Dongle using the 2.4 GHz wireless band. (2) Specifications Item Description Model Name AN-TP200 Frequency band 2402 MHz to 2480 MHz Channels 79 Tx power 0 dBm Reception sensitivity -82 dBm Size 17 x 18.5 x 196.8 (Tolerance ± 1 mm) Weight 36.34 g Power supply 3.7 V (lithium ion battery) Operating temperature 0°C to +40°C 1. Overview and Specifications of LG Touch Pen 2. Cautions (1) Start using the LG Touch Pen by first pairing it with the TV, as instructed in the user manual. (2) The battery of the LG Touch Pen cannot be replaced, but it can be charged through a USB port. (3) Do not disassemble or heat the product. (4) Avoid extreme shocks or impacts that can damage the case. (5) Do not put the product in water. 3. Customer Support (1) See the service contact in the TV manual. (2) Warranty period: 1 year If you find a technical defect or problem in the course of normal use during the warranty period, please contact your dealer. This warranty applies only to the purchaser in the region where the product is purchased. [GERMAN] Inhalt 1. Überblick und Spezifikationen des LG Touch Pen (1) Überblick (2) Spezifikationen 2. Warnhinweise 3. Kundendienst 4. Hinweis für Benutzer (1) Überblick Mit dem LG Touch Pen können Sie auf Ihrem PDP-Fernseher zu Hause oder im Büro direkt Text eingeben oder zeichnen. Es handelt sich um einen Sender, der den PDP-Bildschirm steuert. Dies geschieht im Zusammenspiel mit dem LG Pentouch Dongle über die Drahtlosfrequenz 2,4 GHz. (2) Spezifikationen Element Beschreibung Modellname AN-TP200 Frequenzband 2.402 bis 2.480 MHz Kanäle 79 TX Power 0 dBm Empfängerempfindlichkeit -82 dBm Größe 17 x 18,5 x 196,8 (Toleranz ± 1 mm) Gewicht 36,34 g Stromversorgung 3,7 V (Lithium-Ionen-Akku) Betriebstemperatur 0°C bis +40°C 1. Überblick und Spezifikationen des LG Touch Pen 2. Warnhinweise (1) Wenn Sie den LG Touch Pen zum ersten Mal verwenden, koppeln Sie ihn mit Ihrem Fernsehgerät wie in der Bedienungsanleitung beschrieben. (2) Der Akku des LG Touch Pen lässt sich nicht austauschen, kann aber über einen USB-Anschluss aufgeladen werden. (3) Bauen Sie das Produkt nicht auseinander, und erhitzen Sie es nicht. (4) Vermeiden Sie extreme Stöße und Erschütterungen, die das Gehäuse beschädigen können. (5) Bringen Sie das Produkt nicht mit Wasser in Berührung. 3. Kundendienst (1) Siehe Service-Kontakt in der Bedienungsanleitung Ihres Fernsehgeräts. (2) Garantiezeitraum: 1 Jahr Sollte bei normaler Verwendung während des Garantiezeitraums ein Defekt oder sonstiges Problem auftreten, wenden Sie sich an Ihren Fachhändler. Diese Garantie gilt nur für den Käufer in der Region, wo das Produkt gekauft wurde. [FRENCH] Sommaire 1. Présentation et spécifications du stylet LG Touch Pen (1) Présentation (2) Spécifications 2. Précautions 3. Support technique 4. Avertissement utilisateur (1) Présentation Le stylet LG Touch Pen vous permet de saisir un texte ou de dessiner une image directement sur un téléviseur PDP à la maison ou au bureau. Il s'agit d'un transmetteur qui contrôle l'écran PDP grâce à une interaction avec le module de sécurité LG Pentouch Dongle via une bande sans fil de 2,4 GHz. (2) Spécifications Élément Description Nom du modèle AN-TP200 Bande de fréquence De 2 402 à 2 480 MHz Canaux 79 Puissance d'émission 0 dBm Sensibilité de réception - 82 dBm Taille 17 x 18,5 x 196,8 (Tolérance ± 1 mm) Poids 36,34 g Alimentation électrique 3,7 V (batterie Lithium-ion) Température de fonctionnement De 0°C à + 40°C 1. Présentation et spécifications du stylet LG Touch Pen 2. Précautions (1) Utilisez tout d'abord le stylet LG Touch Pen en association avec votre téléviseur en suivant les instructions du guide de l'utilisateur. (2) La batterie du stylet LG Touch Pen ne peut être remplacée et doit être chargée via un port USB. (3) N'essayez pas de désassembler ni de faire chauffer le produit. (4) Évitez tout choc violent avec le produit. Cela pourrait endommager le boitier. (5) N'immergez pas le produit dans l'eau. 3. Support technique (1) Consultez le guide d'utilisation du téléviseur pour connaître les coordonnées du support technique. (2) Durée de la garantie : 1 an Si vous constatez un défaut ou un problème technique lors de l'utilisation normale du produit et que la garantie est toujours valable, contactez votre revendeur. Cette garantie n'est valable qu'auprès des revendeurs de la région où le produit a été acheté. [PORTUGUESE] Sumário 1. Visão geral e especificações da LG Touch Pen (1) Visão geral (2) Especificações 2. Cuidados 3. Apoio ao cliente 4. Aviso aos usuários (1) Visão geral A LG Touch Pen permite que você digite ou desenhe diretamente na TV PDP em casa ou no escritório. É um…

Text truncated - open the document above for the full version.

LG Electronics USA. 1000 Sylvan Avenue Englewood Cliffs, New Jersey, United States Date: March 24, 2011 Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Ms. Claire Hoque/Application Examiner of Compliance Engineering Services, Inc., d.b.a. Compliance Certification Services and hereafter referred to as CCS, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Ms. Claire Hoque of CCS on our behalf shall have the same effect as acts of our own. In authorizing CCS as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards;

LG Electronics USA. 1000 Sylvan Avenue Englewood Cliffs, New Jersey, United States Date: March 24, 2011 Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA RE: Request of Confidentiality for FCCID: BEJTP200 To Whom It may Concern: Pursuant to Sections 0.457 and 0.459 of the Commission`s Rules(CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, LG Electronics USA. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give LG Electronics USA. temporary confidentiality of commercially sensitive information prior to product release. The requested permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT & SHORT-TERM CONFIDENTIAL LIST Exhibit Description File name PERMANENT 1 Block Diagram Block Diagram_BEJTP200.pdf 2 Operational Description Operational Description_BEJTP200.pdf 3 Schematics Schematic_BEJTP200.pdf 4 Part Lists Part List_BEJTP200.pdf SHORT-TERM 5 External Photos Ext Photo_BEJTP200.pdf 6 Internal Photos Int Photo_BEJTP200.pdf 7 Test-Setup Photos Test Photo_BEJTP200.pdf 8 Users Manual User Manual_BEJTP200.pdf Note: The pictures on the label location do not require any long term or short term confidentiality. The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be public before the date of the Grant for this application. Sincerely, Christopher Johnson Sr. Manager, Standards & Compliance

LG Electronics USA. 1000 Sylvan Avenue Englewood Cliffs, New Jersey, United States Date: March 24, 2011 Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA LETTER OF AUTHORIZATION We, the undersigned, hereby authorize Harvey Sung of Digital EMC Co., Ltd. to act on our behalf in all manners relating to application for equipment authorization for FCC ID: BEJTP200 including signing of all documents relating to these matters. Any and all acts carried out by Harvey Sung of Digital EMC Co., Ltd. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from LG Electronics USA. Sincerely, Christopher Johnson Sr. Manager, Standards & Compliance

FCCID: BEJTP200 Copyright Ⓒ 2011, Digital EMC Co., Ltd. View 1 FCCID: BEJTP200 Copyright Ⓒ 2011, Digital EMC Co., Ltd. View 2 FCCID: BEJTP200 Copyright Ⓒ 2011, Digital EMC Co., Ltd. View 3

FCC ID: BEJTP200 Copyright Ⓒ 2011, Digital EMC Co., Ltd. FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase - The FCC label shown is representative of the label that will appear on the radio when in production. Other information may also be included on this label. - The device is so small that it is not practicable to place the statement specified under 15.19 statement request, the information required by this paragraph shall be placed in a prominent location in the user's manual.

FCCID: BEJTP200 Copyright Ⓒ 2011, Digital EMC Co., Ltd. Page1 / 4 View 1 FCCID: BEJTP200 Copyright Ⓒ 2011, Digital EMC Co., Ltd. Page2 / 4 View 2 FCCID: BEJTP200 Copyright Ⓒ 2011, Digital EMC Co., Ltd. Page3 / 4 View 3 FCCID: BEJTP200 Copyright Ⓒ 2011, Digital EMC Co., Ltd. Page4 / 4 View 4

1103-00271 DRTFCC1103-0147 TRF-RF-215(00)110331 Page 2 / 17 Copyright ○ C 2011, Digital EMC Co., Ltd. CONTENTS 1. Equipment information .............................................................. 3 1.1 Equipment description ............................................................. 3 1.2 Ancillary equipment ................................................................. 3 2. Information about test items ..................................................... 4 2.1 Test mode ................................................................................ 4 2.2 Auxiliary equipment ................................................................. 4 2.3 Tested frequency ..................................................................... 4 2.4 Tested environment ................................................................. 4 2.5 EMI Suppression Device(s)/Modifications ............................... 4 3. Test Report ................................................................................. 5 3.1 Summary of tests .................................................................... 5 3.2 Transmitter requirements ........................................................ 6 3.2.1 AC Conducted Emissions .................................................... 6 3.2.2 Radiated Emission .............................................................. 9 3.2.3 Antenna Requirements ..................................................... 13 APPENDIX..................................................................................... 14 1103-00271 DRTFCC1103-0147 TRF-RF-215(00)110331 Page 3 / 17 Copyright ○ C 2011, Digital EMC Co., Ltd. 1. Equipment information 1.1 Equipment description FCC Equipment Class Part 15 Low Power Communication Device Transmitter Equipment type Touch Pen Equipment model name AN-TP200 Equipment add model name N/A Equipment serial no. Identical prototype Frequency band 2402 ~ 2480MHz Power DC 3.7 V Antenna type Internal Type: Chip Antenna (Max. peak gain: 1.99dBi) 1.2 Ancillary equipment Equipment Model No. Serial No. Manufacturer Note USB Cable - - - 100cm - - - - - 1103-00271 DRTFCC1103-0147 TRF-RF-215(00)110331 Page 4 / 17 Copyright ○ C 2011, Digital EMC Co., Ltd. 2. Information about test items 2.1 Test mode This device was tested in maximum duty mode at maximum power. Test Case 1 EUT Test Case 2 EUT + Notebook Test Case 3 - 2.2 Auxiliary equipment Equipment Model No. Serial No. Manufacturer Note Notebook X51RL 85N0AS318314227 ASUS - - - - - - 2.3 Tested frequency TX Frequency (MHz) RX Frequency (MHz) Lowest Channel 2402 2402 Middle Channel 2439 2439 Highest Channel 2480 2480 2.4 Tested environment Temperature : 21 ~ 23 o C Relative humidity content : 36 ~ 55 % R.H. Details of power supply :DC 3.7 V 2.5 EMI Suppression Device(s)/Modifications EMI suppression device(s) added and/or modifications made during testing → None 1103-00271 DRTFCC1103-0147 TRF-RF-215(00)110331 Page 5 / 17 Copyright ○ C 2011, Digital EMC Co., Ltd. 3. Test Report 3.1 Summary of tests FCC Part Section(s) Parameter Limit (Using in 2400 ~ 2483.5MHz) Test Condition Status Note 1 I. Transmit mode (Tx) 15.249 (a) Field Strength Limits Refer to the FCC 15.249(a) Radiated C Note.2 15.205, 15.209 General Field Strength Limits (Restricted Bands and Radiated Emission Limits) < FCC 15.209 limits Radiated C Note.2 15.207 AC Conducted Emissions < FCC 15.207 limits Line Conducted C Note.3 Note 1: C=Comply NC=Not Comply NT=Not Tested NA=Not Applicable Note 2: Both test case1 and test case 2 were performed and the worst case data was reported. Note 3: This test item was performed at test case2 only. The sample was tested according to the following specification: ANSI C-63.4-2003 1103-00271 DRTFCC1103-0147 TRF-RF-215(00)110331 Page 6 / 17 Copyright ○ C 2011, Digital EMC Co., Ltd. 3.2 Transmitter requirements 3.2.1 AC Conducted Emissions - Procedure: The conducted emissions are measured in the shielded room with a spectrum analyzer in peak hold. While the measurement, EUT had its hopping function disabled at the middle channels in line with Section 15.31(m). Emissions closest to the limit are measured in the quasi-peak and average detector mode with the tuned receiver using a bandwidth of 9 kHz. The emissions are maximized further by cable manipulation and Exerciser operation. The highest emissions relative to the limit are listed. - Measurement Data: Comply Minimum Standard: FCC Part 15.207(a) Frequency Range (MHz) Conducted Limit (dBuV) Quasi-Peak Average 0.15 ~ 0.5 66 to 56 * 56 to 46 * 0.5 ~ 5 56 46 5 ~ 30 60 50 * Decreases with the logarithm of the frequency 1103-00271 DRTFCC1103-0147 TRF-RF-215(00)110331 Page 7 / 17 Copyright ○ C 2011, Digital EMC Co., Ltd. AC Line Conducted Emissions (Graph) 1103-00271 DRTFCC1103-0147 TRF-RF-215(00)110331 Page 8 / 17 Copyright ○ C 2011, Digital EMC Co., Ltd. AC Line Conducted Emissions (Data List) 1103-00271 DRTFCC1103-0147 TRF-RF-215(00)110331 Page 9 / 17 Copyright ○ C 2011, Digital EMC Co., Ltd. 3.2.2 Radiated Emission - Procedure: The EUT was placed on a 0.8m high wooden table inside a semi anechoic chamber. An antenna was placed at 3m distance from the EUT. Measurements of frequencies and amplitudes of field strengths were recorded for reference during final measurements. For final radiated testing, measurements were performed on OATS. Measurements were performed with the EUT oriented in 3 orthogonal axis and rotated 360 degrees to determine worst-case orientation for maximum emissions The spectrum analyzer is set to: Frequency Range = 30 MHz ~ 10 th harmonic. RBW = 100 kHz ( 30MHz ~ 1 GHz) = 1 MHz (1 GHz ~ 10 th harmonic ) VBW ≥ RBW Distance = 3m Detector function = peak Trace = max hold Sweep = auto Measurement Data: Comply Note 1: See next pages for actual measured spectrum plots and data. Fundamental / Harmonics emission: FCC Part 15.249(a) Frequency (MHz) Limit @ 3m Fundamental (mV/m) Harmonics (uV/m) 2400 ~ 2483.5 50 500 General Standard: FCC Part 15.209(a) Frequ…

Text truncated - open the document above for the full version.

FCC ID: BEJTP200 Copyright Ⓒ 2011, Digital EMC Co., Ltd. Tested EUT Position EUT position: X axis EUT position: Y axis EUT position: Z axis FCC ID: BEJTP200 Copyright Ⓒ 2011, Digital EMC Co., Ltd. View 1 FCC ID: BEJTP200 Copyright Ⓒ 2011, Digital EMC Co., Ltd. View 2 FCC ID: BEJTP200 Copyright Ⓒ 2011, Digital EMC Co., Ltd. View 3
