BEJVX7000Dual-Band CDMA Phone (PCS)

LG-VX7000 User Guide Dual-band CDMA w/GPS [PCS/Cellular CDMA/GPS] CDMA Mobile Phone For more information about RF exposure, please visit the FCC website at www.fcc.gov FCC RF EXPOSURE INFORMATION In August 1996 the Federal Communications Commission (FCC) of the United States with its action in Report and Order FCC 96-326 adopted an updated safety standard for human exposure to radio frequency electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. The design of this phone complies with the FCC guidelines and these international standards. Use only the supplied or an approved antenna. Unauthorized antennas, modifications, or attachments could impair call quality, damage the phone, or result in violation of FCC regulations. Do not use the phone with a damaged antenna. If a damaged antenna comes into contact with the skin, a minor burn may result. Please contact your local dealer for replacement antenna. Body-worn Operation This device was tested for typical body-worn operations with the back of the phone kept 1.5 cm. from the body. To maintain compliance with FCC RF exposure requirements, use only belt-clips, holsters or similar accessories that maintain a 1.5 cm. separation distance between the user’s body and the back of the phone, including the antenna, whether extended or retracted. The use of belt-clips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with FCC RF exposure requirements, and should be avoided. WARNING! Read this information before using your phone Contents Introduction Highlights Important Information Check Accessories Before You Start FCC RF EXPOSURE INFORMATION Chapter 1. Getting Started Cautions Phone Overview On screen Icons Chapter 2. Basic Functions Turning the Phone On and Off Making a Call Correcting Dialing Mistakes Receiving Calls Using Quick Mode Call Waiting Mute Redialing Calls Adjusting the Volume Power Save Mode Signal Strength Emergency Dialing Mini Display Speed Dialing Caller ID Phone Book Features Chapter 3. Menu Features General Guidelines to MENU Access and Settings Sound Display System Features Utility Security Voice Services Browser Start Chapter 4. Book Features Call History Phone Book Function of Scheduler General Guidelines to Scheduler Access and Settings Scheduler Item Descriptions Schedule Wake Up Viewing Your Telephone Number Chapter 5. Message Features Voice Send Msg New Text Old Text Erase All Setting Chapter 6. Functions used during a call Mute Memo Recording Key Tone Voice Privacy Chapter 7. Accessories Chapter 1. Getting Started Cautions ??Using the phone in proximity to receiving equipment (i.e., TV or radio) may cause interference. ??Keep your phone in a safe place when not in use. ??Only use the batteries, antennas, and chargers provided by LG. Using the wrong accessories could void your warranty. ??Only authorized personnel should service the phone and its accessories. Faulty installation or service may result in accidents and consequently invalidate the warranty. ??Do not hold the antenna while the phone is in use. ??Do not use the phone in designated “no cellular phone use” areas. ??Do not expose the phone to high temperature or humidity. ??Avoid getting your phone wet. If the phone gets wet, turn the power off immediately and remove the battery pack. If the phone is mal-functional, return it to the dealer for service. ??Avoid shock or impact on the phone. Phone Overview Function Key Descriptions Lamp The red light goes on when you use the power key to turn on the phone and when there are incoming calls and messages. LCD screen Displays messages & indicator icons. END/PWR Used to turn power on/off. This key disconnects a call. Using this key, you can also exit out of a menu back to the phone’s standby display without changing the setting. SEND Allows user to place or answer calls. Mouse Key This mouse key allows quick access to text and voice mail notification messages. calendar, outgoing call log, phonebook Find name. Cellcase Close the active cellcase to the terminate a call in progress. Open the active cellcase to answer an incoming call. Soft Keys The current operation of a soft key is defined by the word at the bottom of the display. Soft Keys 2 : If you press this key once in a menu, you can go back one level and if you press and hold the key in a menu, you can go back to the standby display. Side Keys These keys enable you to adjust keybeep volume (in standby mode) and earpiece volume (in a call status). Scroll Keys These keys are used to scroll through the memory locations and menu items. - In the standby status, set the manner mode by pressing the button. (for 2 seconds) - In the standby status, set the lock function by pressing the button. (for 2 seconds) Alphanumeric Keypad These keys enable you to enter numbers and characters and choose menu items. Clear Key On screen Icons The phone screen displays several onscreen icons and onscreen icons appears when the phone is power on. Icons Descriptions Displays the strength of the signal received by the phone and current signal strength is indicated as the number of bars displayed on the screen. No service The phone is not receiving a system signal. In use A call is in progress. No icon indicates the phone is in standby mode. Digital indicator Digital service is available. Indicates that a text message or voice mail has been received Roaming The phone is outside of its home service area. Charge level Indicates battery charge level. Chapter 2. Basic Functions Turning the Phone On and Off Turning the Phone On 1. Install a charged battery pack or connect the phone to an external power source such as the cigarette lighter adapter or car kit. 2. Press [END/PWR] for a few seconds until the red light on the top of the phone flashes. ??Fully e…

Text truncated - open the document above for the full version.

October 27. 2003 Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 In re : LG Electronics Inc.. Tri-band Tri-mode CDMA Phone (Cellular/PCS/GPS) Part 22, 24 Certification Request for Confidentiality Gentlemen: In accordance with 0.459 of CFR 47, LG Electronics, Inc. hereby requests confidentiality of the Block Diagrams attachment, Schematic Diagrams & Circuit Description attachment, Operational Description attachment, and Parts List/Tune-Up Procedure attachment for the above-referenced Type Acceptance application. These documents contain detailed system and equipment description and related information about the product which LG Electronics Inc. Considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, LG Electronics Inc. considers this information to be of benefit to its competitors, such that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, E.S.Park Research Engineer CDMA Handset Lab LG Electronics Inc. Tel : 82-2-850-3850 Fax : 82-2-850-3861 [email protected] 459-9, Kasan-dong,Kemchun-ku Seoul 153-023, Korea LG Electronics Inc. LGE

AFFIDAVIT FOR ESN PROTECTION OF CELLULAR MOBILE TELEPHONES We hereby certify that the LGE Handheld Portable Cellular Telephone(FCC ID: BEJVX7000) is so designed that it complies with all the requirements for ESN protection specified in section 22.919 of the FCC Rules. A) The transmitter in service has a unique ESN. B) The ESN host component is permanently attached to a main circuit board of the mobile transmitter and the integrity of the unit operating software cannot be altered. The ESN is plated from fraudulent contact and tampering. The ESN is encoded using multiplication by a polynomial and the ESN data programmed in the memory with other information. C) The ESN is factory-set and cannot be altered, transferred, removed or otherwise able to be manipulated. Cellular mobile equipment is specifically designed such that any attempt to remove, tamper with, or change the ESN chip, its logic system, or firmware originally programmed by the manufacturer will render the mobile transmitter inoperative. Sincerely, E.S.Park Research Engineer CDMA Handset Lab LG Electronics Inc. Tel : 82-2-850-3850 Fax : 82-2-850-3861 [email protected] 459-9, Kasan-dong,Kemchun-ku Seoul 153-023, Korea LG Electronics Inc. LGE Tel : 82-2-850-3850 Fax : 82-2-850-3861 [email protected] 459-9, Kasan-dong,Kemchun-ku Seoul 153-023, Korea LG Electronics Inc. LGE October 27. 2003 Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Subject : LG Electronics Inc.. FCC ID: BEJVX7000 User’ s Manual RF Exposure Warning Statement Gentlemen: LG Electronics, Inc. hereby conforms that the attached RF exposure warning page will be ready visible to the user, and will be placed at a prominent location in the front of user’ s manual. If you have any questions or comments concerned the above, please do not hesitate to contact PCTEST Lab. or me at (410)290-6652 Sincerely, E.S.Park Research Engineer CDMA Handset Lab LG Electronics Inc.

November 26, 2003 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: LG Electronics, Inc. FCC ID: BEJVX7000 Part 22/24 Certification Gentlemen: Submitted herewith, on behalf of LG Electronics, Inc., is an application for Part 22/24 Certification of the Tri-Mode Dual-Band Analog/PCS Phone (AMPS/CDMA). Attached is the applicant’s Letter of Authorization, Confidentiality Request, measurement report test data and plots, RF Exposure measurement report and data, FCC ID label and location, test setup photographs, internal and external photographs, block diagram (confidential), circuit diagrams & description (confidential), operational description (confidential), parts list & tune-up procedure (confidential), and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc: LG Electronics, Inc.

LGE FCC ID: BEJVX7000 EUT Photographs © 2003 PCTEST Lab. Dual-Band CDMA Phone NVLAP Lab Code: 100431-0 LGE FCC ID: BEJVX7000 EUT Photographs © 2003 PCTEST Lab. Dual-Band CDMA Phone NVLAP Lab Code: 100431-0 LGE FCC ID: BEJVX7000 EUT Photographs © 2003 PCTEST Lab. Dual-Band CDMA Phone NVLAP Lab Code: 100431-0 LGE FCC ID: BEJVX7000 EUT Photographs © 2003 PCTEST Lab. Dual-Band CDMA Phone NVLAP Lab Code: 100431-0 LGE FCC ID: BEJVX7000 EUT Photographs © 2003 PCTEST Lab. Dual-Band CDMA Phone NVLAP Lab Code: 100431-0 LGE FCC ID: BEJVX7000 EUT Photographs © 2003 PCTEST Lab. Dual-Band CDMA Phone NVLAP Lab Code: 100431-0 LGE FCC ID: BEJVX7000 EUT Photographs © 2003 PCTEST Lab. Dual-Band CDMA Phone NVLAP Lab Code: 100431-0

© 2003 PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE) LG Electronics Inc. 12 03-3-7 12/12 2.983 (e) Standard Test Conditions: 2. 983 (f) Equipment Identification: 2. 983 (g) Photograph : “Refer to additional documents” 2. 985 RF Power Output: “Refer to additional documents” 2. 987 Modulation Characteristics: “Refer to additional documents” 2. 989 Occupied Bandwidth “Refer to additional documents” 2. 991 Spurious Emissions at Antenna Terminals: “Refer to additional documents” 2. 993 Field Strength of Spurious Radiation: “Refer to additional documents” 2. 995 Frequency stability: “Refer to additional documents” 2. 997 Frequency spectrum to be investigated “Refer to additional documents” LG Electronics Inc. LGE Model No . VX7000 FCC ID : BEJVX7000 S/N : Made in Korea

LGE FCC ID: BEJVX7000 EUT Photographs © 2003 PCTEST Lab. Dual-Band CDMA Phone NVLAP Lab Code: 100431-0 LGE FCC ID: BEJVX7000 EUT Photographs © 2003 PCTEST Lab. Dual-Band CDMA Phone NVLAP Lab Code: 100431-0 LGE FCC ID: BEJVX7000 EUT Photographs © 2003 PCTEST Lab. Dual-Band CDMA Phone NVLAP Lab Code: 100431-0 LGE FCC ID: BEJVX7000 EUT Photographs © 2003 PCTEST Lab. Dual-Band CDMA Phone NVLAP Lab Code: 100431-0 LGE FCC ID: BEJVX7000 EUT Photographs © 2003 PCTEST Lab. Dual-Band CDMA Phone NVLAP Lab Code: 100431-0 LGE FCC ID: BEJVX7000 EUT Photographs © 2003 PCTEST Lab. Dual-Band CDMA Phone NVLAP Lab Code: 100431-0 LGE FCC ID: BEJVX7000 EUT Photographs © 2003 PCTEST Lab. Dual-Band CDMA Phone NVLAP Lab Code: 100431-0 LGE FCC ID: BEJVX7000 EUT Photographs © 2003 PCTEST Lab. Dual-Band CDMA Phone NVLAP Lab Code: 100431-0 LGE FCC ID: BEJVX7000 EUT Photographs © 2003 PCTEST Lab. Dual-Band CDMA Phone NVLAP Lab Code: 100431-0 LGE FCC ID: BEJVX7000 EUT Photographs © 2003 PCTEST Lab. Dual-Band CDMA Phone NVLAP Lab Code: 100431-0

PCTEST ENGINEERING LABORATORY, INC. 6660 – B Dobbin Road • Columbia, MD 21045 • USA Telephone 410.290.6652 / Fax 410.290.6654 http://www.pctestlab.com (email: [email protected]) CERTIFICATE OF COMPLIANCE (SAR EVALUATION) PCTEST SAR REPORT FCC Measurement Report Reviewed by: Quality Manager SAR Filename: SAR-231027526.BEJ Test Dates: November 3-5, 2003 Phone Type: Dual-Band Phone FCC ID: BEJVX7000 Page 1 of 30 © 2003 PCTEST Engineering Laboratory, Inc APPLICANT NAME & ADDRESS: DATE & LOCATION OF TESTING: LG ELECTRONICS, INC. Dates of Tests: November 3-5, 2003 Communication Terminal Research Lab Test Report S/N: 22/24.231027526.BEJ 459-9, Kasan-dong, Keumchun-Ku Test Site: PCTEST Lab, Columbia MD Seoul, KOREA 153-023 FCC ID: BEJVX7000 APPLICANT: LG ELECTRONICS, INC. EUT Type: Dual-Band PCS Phone (CDMA) Tx Frequency: 824.70 – 848.31 MHz (CDMA)/ 1851.25 – 1908.75 MHz (PCS CDMA) Rx Frequency: 869.70 – 893.31 MHz (CDMA)/ 1931.25 – 1988.75 MHz (PCS CDMA) Max. RF Output Power: 0.253 W ERP CDMA (24.033 dBm)/ 24.0 dBm Conducted 0.392 W EIRP PCS CDMA (25.921 dBm) / 24.0 dBm Conducted Max. SAR Measurement: 0.519 W/kg CDMA Head SAR; 0.637 W/kg CDMA Body SAR; 0.565 W/kg PCS CDMA Head SAR; 0.491 W/kg PCS CDMA Body SAR Trade Name/Model(s): VX7000 FCC Classification: Licensed Portable Transmitter Held to Ear (PCE) FCC Rule Part(s): §2.1093; FCC/OET Bulletin 65 Supplement C [July 2001] Application Type: Certification Test Device Serial No.: identical prototype [S/N: 1] with EMW Antenna This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001) and IEEE Std. P1528 D1.2 (April 2003). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Grant Conditions: Power output listed is ERP for Part 22 and EIRP for Part 24. SAR compliance for body- worn operating configuration is based on a separation distance of 1.5 cm between the back of the unit and the body of the user. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. Belt clips or holsters may not contain metallic components. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST SAR REPORT FCC Measurement Report Reviewed by: Quality Manager SAR Filename: SAR-231027526.BEJ Test Dates: November 3-5, 2003 Phone Type: Dual-Band Phone FCC ID: BEJVX7000 Page 2 of 30 © 2003 PCTEST Engineering Laboratory, Inc TABLE OF CONTENTS 1. INTRODUCTION / SAR DEFINITION.................................................................................3 2. SAR MEASUREMENT SETUP..............................................................................................4 3. DASY4 E-FIELD PROBE SYSTEM........................................................................................5 4. Probe Calibration Process..................................................................................................6 5. PHANTOM & EQUIVALENT TISSUES.................................................................................7 6. TEST SYSTEM SPECIFICATIONS.........................................................................................8 7. DOSIMETRIC ASSESSMENT & PHANTOM SPECS................................................................9 8. DEFINITION OF REFERENCE POINTS..............................................................................10 9. TEST CONFIGURATION POSITIONS...............................................................................11 10. ANSI/IEEE C95.1 - 1992 RF EXPOSURE LIMITS.................................................................14 11. MEASUREMENT UNCERTAINTIES...................................................................................15 12. SYSTEM VERIFICATION..................................................................................................16 13. SAR TEST DATA SUMMARY............................................................................................17 16. CONCLUSION...............................................................................................................29 17. REFERENCES..................................................................................................................30 PCTEST SAR REPORT FCC Measurement Report Reviewed by: Quality Manager SAR Filename: SAR-231027526.BEJ Test Dates: November 3-5, 2003 Phone Type: Dual-Band Phone FCC ID: BEJVX7000 Page 3 of 30 © 2003 PCTEST Engineering Laboratory, Inc 1. INTRODUCTION / SAR DEFINITION The FCC has adopted the guidelines for evaluating the environmental effects of radiofrequency radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-1992 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. (c) 1992 by the Institute of Electrical and Electronics Engineers, Inc., New York, New York 10017.[2] The measurement procedure described in IEEE/ANSI C95.3-1992 Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields - RF and Microwave[3] is used for guidance in measuring SAR due to the RF radiation exposure from the…
