BEJWCD100Wireless Charger

Rev 1.0 EU All rights reserved. LG Electronics Inc., 2014 LG Electronics, Inc Wireless Charging Cradle WCD-100 User Manual www.lg.com Contact office for compliance of this product : LG Electronics Inc. EU Representative, Krijgsman 1, 1186 DM Amstelveen, The Netherlands English Français Español Deutsch Русский LG Electronics, Inc Wireless Charging Cradle WCD-100 User Manual All rights reserved. LG Electronics Inc., 2014 Note: For optimal performance and to prevent any damage to, or misuse of the WCD-100, please read all of the information carefully before using the WCD-100. Any modifications or changes to this manual due to typographical errors or inaccuracies of stated information shall only be made by LG Electronics Inc.. ENG ENG 2 Included in the Package WCD-100 (Wireless Charger) * Power Adapter * These items could be changed or excluded as it may chance. * USB CableUser ManualWarranty card Description of Parts Charging Area Limited Warranty (United Kingdom) Subject to the conditions of this Limited Warranty, LG Electronics warrants this product to be free from defects in design, material and workmanship at the time of its original purchase by a consumer, and for a subsequent period of one (1) year. It shall neither exclude nor limit any mandatory statutory rights of the customer or any of the customer rights against the seller/dealer of the product.Should your product need warranty service, please return it to the dealer from whom it was purchased or contact your local LG Electronics contact centre to get further information. (http://www.lg.com/uk/support) Garantía limitada (España) Sujeta a las condiciones de la presente garantía limitada, LG Electronics garantiza que este producto no presenta fallos de diseño, materiales ni mano de obra en el momento en que un consumidor realiza la compra original, y que no las presentará por un periodo mínimo de/ un (1) año. La presente garantía comercial no afecta a los derechos que dispone el cliente final conforme a las previsiones contenidas en el RDL 1/2007 de 16 de Noviembre de 2007 (BOE 287 de 30 de Noviembre de 2007), frente a la garantía por falta de conformidad del vendedor, que son independientes y compatibles con la presente garantía. En caso de que el producto requiera servicio de garantía, devuélvalo al proveedor o comuníquese con el centro de contacto de LG Electronics en su región para obtener más información.(http://www.lg.com/es/ posventa) Ограниченная гарантия (Россия) В соответствии с условиями ограниченной гарантии, LG Electronics гарантирует, что изделие не имеет каких-либо дефектов конструкции, материалов и качества сборки на момент первичной покупки клиентом и в последующий период в течение одного (1) года. В случае необходимости гарантийного обслуживания, обратитесь к продавцу устройства или свяжитесь с местным информационным центром LG Electronics. Garantia limitada (Brasil) Sujeita às condições desta garantia limitada, a LG Electronics garante que, à época da aquisição original pelo comprador e por um período subseqüente de 1 (um) ano, este produto não apresenta defeitos de design, material ou de fabricação. Caso seja necessário executar serviços de garantia, devolva o produto ao revendedor que efetuou a venda ou entre em contato com o centro de contato da LG Electronics mais próximo para obter informações adicionais. Garantie limitée (France) La présente garantie est due gratuitement en France métropolitaine pour tout vice ou défaut de conception, matériel ou d’assemblage, non exclus ci-après, survenant dans un délai d’un (1) an à compter de la date d’achat du produit par le premier utilisateur final. Elle donne lieu, au choix de LG, à réparation ou à remplacement du bien endommagé et ne donne droit à aucune indemnité en nature ou en espèce. La responsabilité de LG se limite aux coûts de réparation et/ou de remplacement, à l’exclusion de frais d’expédition et d’enlèvement. Ne sont pas couverts par la garantie : l’adéquation à une fin particulière, l’usure ou le vieillissement normal du produit, les pièces jetables ou consommables, les dommages liés à une utilisation du produit non conforme aux prescriptions du fabricant, à une utilisation anormale ou à toute intervention effectuée par toute personne non agrée par LG et les produits dont le numéro de série a été enlevé ou rendu illisible. Si votre produit devait nécessiter un dépannage sous garantie, renvoyez-le au plus vite au revendeur chez qui il a été acheté ou contactez immédiatement par courrier ou par téléphone votre centre de contact LG Electronics local pour davantage d’informations. La facture d’achat sera exigée comme justificatif de garantie. LG Electronics France Service Clients Paris Nord II, 117 avenue des Nations, BP 59372 Villepinte, 95942 Roissy CDG N° magique Vert : 3220, dites « LG » (appel gratuit depuis un poste fixe). Indépendamment de la garantie ainsi consentie, LG reste tenu des défauts de conformité du bien au contrat et des vices rédhibitoires dans les conditions prévues aux articles 1641 à 1649 du Code civil et L211-4 à L211-14 du Code de la consommation. Beschränkte Garantie (Deutschland) Garantievoraussetzungen LG Electronics gewährt Ihrem Fachhändler für alle LG Consumer- Produkte aus den Bereichen (a) „Unterhaltungselektronik“ (u.a. TV/ Heimkino/BluRay etc.), (b) „Information System Products – ISP“ (u.a. Monitore, Notebooks, optische Laufwerke, Speichermedien etc.), (c) „Handys & Smartphones“ (auch: Akkus, Ladekabel, sonstiges Zubehör) sowie (d) „Hausgeräte“ (u.a. Waschmaschinen, Kühl-/ Gefriergeräte, Mikrowellen etc.) - genaue Produktübersicht unter: www.lg.de - eine freiwillige Garantie dafür, dass sie und ihre Teile frei von Material- oder Verarbeitungsfehlern sind. Maßgabe für die Fehlerfreiheit ist der Stand der Technik vergleichbarer Produkte zum Zeitpunkt des Inverkehrbringens. Die Garantie findet Anwendung auf alle in den oben genannten Bereichen von der LG Electronics Deutschland GmbH in den Handel gebrachten LG Consumer-Produkte…

Text truncated - open the document above for the full version.

LG Electronics USA. 1000 Sylvan Avenue Englewood Ciliffs, New Jersey, United States Date: May 26, 2014 Letter of declaration a) Power transfer frequency is less than 1MHz  The power transfer frequency of DUT(Device Under Test) is between 110KHz and 205KHz. b) Output power from each primary coil is less than 5 watts  Output power from each coils are Max. 5 watts. c) The transfer system includes only single primary and second coils. This includes charging systems that may have multiple primary coils and clients that are able to detect and allow coupling only between individual pairs of coils  The DUT are consist of one charging coil using A16 coil as below, so the DUT can detect and allow coupling only between TX and RX Coil.(A16 coil is only single coil.) d) Client device is inserted in or placed directly in contact with transmitter  When the client device is placed directly in contact with transmitter, then charging is able to start. e) The maximum coupling surface area of the transmit (charging) device is between 60Cm 2 and 400 Cm 2  The Maximum coupling surface area of the charging transmit is 63 ㎠. Maximum coupling surface area (7 Cm X 9 Cm) f) Aggregate leakage fields at 10㎠ surrounding the device from all simultaneous transmitting coils are demonstrated to be less than 30% of the MPE limit.  The highest leakage filed is less than 30 % of the MPE limit. Sincerely, Jacob Cho Director, Standards & Compliance

LG Electronics USA. 1000 Sylvan Avenue Englewood Ciliffs, New Jersey, United States Date: May 23, 2014 Letter of Authorization We, the undersigned, hereby authorize Digital EMC Co., Ltd. to act on our behalf in all manners relating to application for equipment authorization for FCCID: BEJWCD100 including signing of all documents relating to these matters. Any and all acts carried out by Digital EMC Co., Ltd. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from LG Electronics USA . “I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a).” Sincerely, Jacob Cho Director, Standards & Compliance

Digital EMC Co., Ltd. 42, Yurim-ro, 154beon-gil, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea 449-935 Date: May 23,2014 UL Verification Services Inc. 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Ms. Claire Hoque/Application Examiner of Compliance Engineering Services, Inc., d.b.a. Compliance Certification Services and hereafter referred to as CCS, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Ms. Claire Hoque of CCS on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing CCS as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards;

LG Electronics USA. 1000 Sylvan Avenue Englewood Cliffs, New Jersey, United States Date: May 23, 2014 UL Verification Services Inc. 47173 Benicia Street Fremont, CA 94538, USA RE: Request of Confidentiality for FCCID: BEJWCD100 To Whom It may Concern: Pursuant to Sections 0.457 and 0.459 of the Commission`s Rules(CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, LG Electronics USA. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give LG Electronics USA. temporary confidentiality of commercially sensitive information prior to product release. The requested permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT & SHORT-TERM CONFIDENTIAL LIST Exhibit Description PERMANENT 1 Block Diagram 2 Schematics 3 Part Lists 4 Operation Description SHORT-TERM 5 Internal Photos 6 External Photos 7 Test-Setup Photos 8 User Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be public before the date of the Grant for this application. Sincerely, Jacob Cho Director, Standards & Compliance

FCCID: BEJWCD100 Copyright Ⓒ 2014, Digital EMC Co., Ltd. Page 1 / 3 View 1 FCCID: BEJWCD100 Copyright Ⓒ 2014, Digital EMC Co., Ltd. Page 2 / 3 View 2 FCCID: BEJWCD100 Copyright Ⓒ 2014, Digital EMC Co., Ltd. Page 3 / 3 View 3

FCC ID: BEJWCD100 Copyright Ⓒ 2014, Digital EMC Co., Ltd. FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase - The FCC label shown is representative of the label that will appear on the radio when in production. Other information may also be included on this label. - The device is so small that it is not practicable to place the statement specified under 15.19 statement request, the information required by this paragraph shall be placed in a prominent location in the user's manual.

FCCID: BEJWCD100 Copyright Ⓒ 2014, Digital EMC Co., Ltd. Page 1 / 3 View 1 FCCID: BEJWCD100 Copyright Ⓒ 2014, Digital EMC Co., Ltd. Page 2 / 3 View 2 FCCID: BEJWCD100 Copyright Ⓒ 2014, Digital EMC Co., Ltd. Page 3 / 3 View 4

FCC ID : BEJWCD100 DEMC1405-01651 Report No.: DRTFCC1405-0653 TRF-RF-204(01)110221 Page 2 / 23 Copyright ○ C 2014, Digital EMC Co., Ltd. Test Report Version Test Report No. Date Description DRTFCC1405-0653 May. 23, 2014 Initial issue FCC ID : BEJWCD100 DEMC1405-01651 Report No.: DRTFCC1405-0653 TRF-RF-204(01)110221 Page 3 / 23 Copyright ○ C 2014, Digital EMC Co., Ltd. CONTENTS 1. Equipment information ............................................................. 4 1.1 Equipment description ............................................................ 4 1.2 Support equipments ............................................................... 4 2. Information about test items .................................................... 5 2.1 Test mode ............................................................................... 5 2.2 Tested environment ................................................................ 5 2.3 EMI Suppression Device(s)/Modifications .............................. 5 3. FACILITIES AND ACCREDITATIONS ........................................ 6 3.1 FACILITIES ............................................................................ 6 3.2 EQUIPMENT .......................................................................... 6 4. Test Report ................................................................................ 7 4.1 Summary of tests ................................................................... 7 4.2 Transmitter requirements........................................................ 8 4.2.1 20dB Bandwidth ................................................................. 8 4.2.2 Radiated Emissions ........................................................... 9 4.2.3 AC Line Conducted Emissions .......................................... 11 APPENDIX I ................................................................................. 22 FCC ID : BEJWCD100 DEMC1405-01651 Report No.: DRTFCC1405-0653 TRF-RF-204(01)110221 Page 4 / 23 Copyright ○ C 2014, Digital EMC Co., Ltd. 1. Equipment information 1.1 Equipment description FCC Equipment Class Part 15 Low Power Transmitter Below 1705 kHz (DCD) Equipment type Wireless Charger Equipment model name WCD-100 Equipment add model name N/A Equipment serial no. Identical prototype Frequency band 110 ~ 205 kHz Output power Max : 5 W Power AC 120 V 60 Hz Antenna type Coil Antenna(single coil) 1.2 Support equipments Equipment Model No. Serial No. Manufacturer Note Wireless Charging Cover N/A N/A LG Mobile Phone LG-VS980 N/A LG FCC ID : ZNFVS980 Travel Adapter MCS-04KT TA370706113 Tan Pao Electronics Co., Ltd. Note: The above equipments were supported by manufacturer. FCC ID : BEJWCD100 DEMC1405-01651 Report No.: DRTFCC1405-0653 TRF-RF-204(01)110221 Page 5 / 23 Copyright ○ C 2014, Digital EMC Co., Ltd. 2. Information about test items 2.1 Test mode This device has been tested with the below test modes and charging current conditions: Charging Current Support Equipment 300mA Wireless Charging Cover 600mA 1000mA(Max) @ < 1% battery status Mobile Phone(M/N: LG-VS980) @ 50% battery status 2.2 Tested environment Temperature : 20 ~ 23 °C Relative humidity content : 35 ~ 45 % R.H. Details of power supply : AC 120 V 60 Hz 2.3 EMI Suppression Device(s)/Modifications EMI suppression device(s) added and/or modifications made during testing → None FCC ID : BEJWCD100 DEMC1405-01651 Report No.: DRTFCC1405-0653 TRF-RF-204(01)110221 Page 6 / 23 Copyright ○ C 2014, Digital EMC Co., Ltd. 3. FACILITIES AND ACCREDITATIONS 3.1 FACILITIES The semi anechoic chamber and conducted measurement facility used to collect the radiated and conducted test data are located at the 38, Yurim-ro, 154beon-gil, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea 449-935. The site is constructed in conformance with the requirements. - Semi anechoic chamber registration Number : 678747 3.2 EQUIPMENT Radiated emissions are measured with one or more of the following types of antennas: loop, tuned dipole, bi-conical, log periodic, bi-log, and/or ridged waveguide horn. Spectrum analyzers with pre-selectors and peak, quasi-peak detectors are used to perform radiated measurements. Conducted emissions are measured with Line Impedance Stabilization Networks and EMI Test Receivers. Calibrated wideband preamplifiers, coaxial cables, and coaxial attenuators are also used for making measurements. All receiving equipment conforms to CISPR Publication 16-1, “Radio Interference Measuring Apparatus and Measurement Methods.” FCC ID : BEJWCD100 DEMC1405-01651 Report No.: DRTFCC1405-0653 TRF-RF-204(01)110221 Page 7 / 23 Copyright ○ C 2014, Digital EMC Co., Ltd. 4. Test Report 4.1 Summary of tests FCC Part Section(s) RSS Section(s) Parameter Limit Test Condition Status Note 1 Test Items 2.1049 N/A 20 dB Bandwidth N/A Radiated C 15.209 RSS-Gen [7.2.5] Radiated Emission FCC 15.209 limits C 15.207 RSS-Gen [7.2.4] AC Conducted Emissions FCC 15.207 limits AC Line Conducted C Note 1: C=Comply NC=Not Comply NT=Not Tested NA=Not Applicable The sample was tested according to the following specification: ANSI C-63.4 2009 FCC ID : BEJWCD100 DEMC1405-01651 Report No.: DRTFCC1405-0653 TRF-RF-204(01)110221 Page 8 / 23 Copyright ○ C 2014, Digital EMC Co., Ltd. 4.2 Transmitter requirements 4.2.1 20dB Bandwidth - Procedure: The 20 dB bandwidth is measured with a spectrum analyzer connected via a receiving antenna placed near the EUT while the EUT is operating. - Measurement Data: Charging Current 1000 mA FCC ID : BEJWCD100 DEMC1405-01651 Report No.: DRTFCC1405-0653 TRF-RF-204(01)110221 Page 9 / 23 Copyright ○ C 2014, Digital EMC Co., Ltd. 4.2.2 Radiated Emissions - Limit: FCC Part 15.209(a) & RSS-GEN, section 7.2.5 Frequency [MHz] Field Strength [uV/m] Measurement Distance [Meters] 0.009 ~ 0.490 2400/F(kHz) 300 0.490 ~ 1.705 24000/F(kHz) 30 1.705 ~ 30 30 30 30 ~ 88 100 3 88 ~ 216 150 3 216 ~ 960 200 3 Above 960 500 3 ** Except as provided in 15.209(g), fundamental emissions from intentional radiators operating under this Se…

Text truncated - open the document above for the full version.

FCC ID: BEJWCD100 Copyright Ⓒ 2014, Digital EMC Co., Ltd. Support equipment: Wireless Charging Cover(M/N: N/A) FCC ID: BEJWCD100 Copyright Ⓒ 2014, Digital EMC Co., Ltd. Support equipment: Mobile Phone (M/N: LG-VS980) FCC ID: BEJWCD100 Copyright Ⓒ 2014, Digital EMC Co., Ltd. Test Setup Photo for Radiated Emissions FCC ID: BEJWCD100 Copyright Ⓒ 2014, Digital EMC Co., Ltd. Test Setup Photo for AC Conducted Emissions FCC ID: BEJWCD100 Copyright Ⓒ 2014, Digital EMC Co., Ltd. Test Setup Photo for RF Exposure FCC ID: BEJWCD100 Copyright Ⓒ 2014, Digital EMC Co., Ltd. Test Setup Photo for RF Exposure
