BEJWCFDM00N2AWireless Charger

10, Magokjungang 10-ro, Gangseo-gu, Seoul, Korea. The device under test is manufactured by the grantee (LG Electronics USA), and sold as an OEM product. Per 47 CFR 2.909, 2.927, 2.931, 2.1033, etc..., the grantee must ensure the end-user has all applicable / appropriate operating instructions. When end-user instructions are required, as in the case of this product, the grantee must notify the OEM to notify the end- user. LG Electronics USA will supply this document to the reseller/distributor dictating what must be included in the end user’s manual for the commercial product. INFORMATION TO BE INCLUDED IN THE END USER’S MANUAL The following information ( in blue) must be included in the end-product user’s manual to ensure continued FCC and Innovation, Science and Economic Development Canada regulatory compliance. The ID numbers must be included in the manual if the device label is not readily accessible to the end user. The compliance paragraphs below must be included in the user's manual. 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : 1. L’appareil ne doit pas produire de brouillage; 2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. ****************************************************************************** FCC ID: BEJWCFDM00N2A IC: 2703H-WCFDM00N2A This equipment generates, uses, and can radiate radio frequency energy and may cause harmful interference to radio communications. There is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, please consult the dealer. This product is not end-user serviceable. RF Radiation Exposure Statement: This equipment complies with FCC RF Radiation exposure limits set forth for an uncontrolled environment. This device and its antenna must not be co- located or operating in conjunction with any other antenna or transmitter. This equipment should be installed and operated with a minimum distance of 20cm between the radiator and your body. This device complies with Part 15 of the FCC Rules and with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions:

Willow Run (WR) Test Labs, Inc. 7117 Fieldcrest Dr., Brighton, Michigan 48116 USA Tel: (734) 252-9785, Fax: (734) 926-9785, e-mail: [email protected] Attn.:Certification and Engineering Bureau, Innovation, Science and Economic Development Canada 3701 Carling Avenue, Bldg. 94 Ottawa, Ontario K2H 8S2 Re: Certification for LG Electronics WCFDM00N2A Series IC: 2703H-WCFDM00N2A If necessary, we have enclosed application materials for certification of LG Electronics WCFDM00N2A Series. It has been verified to comply with ISED RSS-216v2. Current Variants: There are three hardware variants of the EUT: WCFDM00N2A1 with cooling fan, WCFDM00N2A5 without cooling fan, and WCFDM00N2A3 without cooling fan or top rubber pad. All employ identical WPT circuitry and antennas, but the unit with the cooling fan includes a fan control IC populated on the PCB. The unit with the cooling fan populated is fully tested herein and was confirmed to be the worst case variant. If there are any questions regarding the application or testing performed, please contact us at the above address or call (734) 252-9785, or e-mail [email protected]. Sincerely, Joseph D. Brunett Willow Run (WR) Test Labs, Inc. Willow Run (WR) Test Labs, Inc. 7117 Fieldcrest Dr., Brighton, Michigan 48116 USA Tel: (734) 252-9785, Fax: (734) 926-9785, e-mail: [email protected] Attn.:Federal Communications Commission Equipment Approval Services P.O. Box 358315 Pittsburgh, PA 15251-5315 Re: Certification for LG Electronics WCFDM00N2A Series FCC ID: BEJWCFDM00N2A If necessary, we have enclosed application materials for certification of LG Electronics WCFDM00N2A Series. It has been verified to comply with CFR Title 47, Part 15.209. Current Variants: There are three hardware variants of the EUT: WCFDM00N2A1 with cooling fan, WCFDM00N2A5 without cooling fan, and WCFDM00N2A3 without cooling fan or top rubber pad. All employ identical WPT circuitry and antennas, but the unit with the cooling fan includes a fan control IC populated on the PCB. The unit with the cooling fan populated is fully tested herein and was confirmed to be the worst case variant. If there are any questions regarding the application or testing performed, please contact us at the above address or call (734) 252-9785, or e-mail [email protected]. Sincerely, Joseph D. Brunett Willow Run (WR) Test Labs, Inc.

Willow Run (WR) Test Labs, Inc. 7117 Fieldcrest Dr., Brighton, Michigan 48116 USA Tel: (734) 252-9785, Fax: (734) 926-9785, e-mail: [email protected] Re: Certification for LG Electronics FCC ID: BEJWCFDM00N2A IC: 2703H-WCFDM00N2A REQUEST FOR CONFIDENTIALITY Pursuant to USA FCC 47 CFR 0.457(d) and 0.459 and Canada IC RSP-100, Section 10, LG Electronics requests that a part of the subject application be held confidential. LG Electronics has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to ”competition” would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Exhibit Conf. TypeRational Exh 04 - Block DiagramPermanentIncludes proprietary internal oscillator frequency information. Exh 05 - SchematicsPermanentIncludes proprietary design information Exh 10 - BOM + PlacementPermanentIncludes proprietary design information Exh 12 - Operational DescriptionPermanentIncludes proprietary design information Long Term Confidentiality (Permanent):LG Electronics requests that any exhibits listed above as permanently confidential be permanently withheld from public review. Wherein Long Term Confidentiality is not an option for specific exhibits with ISED, this request applies only to the FCC application for those exhibits. Short-Term Confidentiality (FCC Only):LG Electronics requests that any exhibits selected above as short term confidential be withheld from public view for a period of days (noted above) from the date of the Grant of Equipment Authorization and prior to marketing. If there are any questions regarding the application or testing performed, please contact us at the above address or call (734) 252-9785, or e-mail [email protected]. Sincerely, Joseph D. Brunett Willow Run (WR) Test Labs, Inc. 9

To Whom It May Concern: Authority to Act as Agent and REL Listing We appoint Bradley J. Koski on behalf of Wireless Approval Consultants and Joseph D. Brunett on behalf of Willow Run Test Labs and Amber Helm Development, LC to act as our agent in the preparation of this application for equipment certification. We certify that submitted documents properly describe the device or system for which equipment certification is sought. We also certify that each unit manufactured, imported or marketed, as defined in Industry Canada’s regulations will have affixed to it a label identical to that submitted for approval with this application. Further, in accordance with section 6.5 of IC CB-02, we hereby acknowledge that our company’s product cannot be distributed, leased or offered for sale in Canada until it’s listed on the Industry Canada Radio Equipment List (REL). For instances where our authorized agent signs the application for certification on our behalf, we acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by American Certification Body, Inc. and/or TUV Rheinland Group and/or Vista Laboratories, Inc. still resides with LG Electronics Inc., 222, LG-ro, Jinwi-myeon, Pyeongtaek-si, Gyeonggi-do, 451-713, Korea (Republic of). Dated: 19 January 2021 Signature: Name: [Jordan Vaeth] Title: [General Counsel] email: [[email protected]] On behalf of: [LG Electronics Inc.] Telephone: [1-647-253-6300]

To Whom It May Concern: Authority to Act as Agent We appoint Bradley J. Koski on behalf of Wireless Approval Consultants and Joseph D. Brunett on behalf of Willow Run Test Labs and Amber Helm Development, LC to act as our agent in the preparation of this application for equipment certification. We certify that submitted documents properly describe the device or system for which equipment certification is sought. For instances where our authorized agent signs the application for certification on our behalf, we acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by American Certification Body, Inc. and/or TUV Rheinland Group and/or Vista Laboratories, Inc. still resides with LG Electronics USA, 111 Sylvan Avenue, North Building, Englewood Cliffs, New Jersey, 07632, United States of America. For TCB applications, we certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. We also declare that the information provided to the FCC is true and correct to the best of our knowledge (47 CFR 2.911(d)) and we have been informed of the grantee responsibilities (47 CFR 2.909) regarding certified equipment. Dated: 19 January 2021 Signature: Name: [Dae Woong Kim] Title: [Director, Regulatory and Environmental Affairs] email: [[email protected]] On behalf of: [LG Electronics USA] Telephone: [1-201-266-2215]

FCC RF Exposure Evaluation Per Section 5 of FCC KDB Publication 680106D03 Inductive wireless power transfer applications that meet all of the following requirements are not required to submit a PAG for equipment approved using certification to address RF exposure compliance: 1) Power transfer frequency is less that 1 MHz Device operates nominally at 127.9 kHz (123.7 – 131.7 kHz range). 2) Output power from each primary coil is less than 15 watts The EUT is a WPC Power Class 0 device following the Wireless Power Consortium design specifications for a device operating at 15 watts. 3) The transfer system includes only single primary and secondary coils. This includes charging systems that may have multiple primary coils and clients that are able to detect and allow coupling only between individual pairs of coils This device is designed to comply with this requirement. 4) Client device is inserted in or placed directly in contact with the transmitter This device is designed for direct contact charging only. 5) Mobile exposure conditions only (portable exposure conditions are not covered by this exclusion). The EUT is Mobile (not portable). f) Aggregate leakage fields at 15 cm surrounding the device and 20 cm from all simultaneous transmitting coils are demonstrated to be less than 50% of the MPE limit. Aggregate leakage fields at 15 cm distance surrounding the EUT and at 20cm above the EUT pad antenna were measured with each integral coil loaded by a Samsung Galaxy 6 Edge cellular phone and, over three charging levels (1%, 50%, 99%). Results noted in the following pages demonstrate that these fields remains well below 50% of the MPE limit. USA REF: 1.1310, 2.1091/1093, 447498 D01 General RF Exposure Guidance v06 Test Date: 8-Jan-21 Application: Mobile Test Engineer: EUT: LG WCFDM00Y2A EUT Mode: Worst Case / 6min Meas. Distance: 20 cm Meas.Max Measured Field*USA FCC 1.1310 MPE ModeFreq.DistanceE(Pk)H(Pk)E Field Limit***Worst Case MPE Ratio #MHzcm 1Sens/Pol0.105120.0 118.4105.9 175.8124.2.12083 215W, Charging0.127920.0 126.7114.7 175.8124.2.33328 Max MPE Ratio.33328 Complies? Yes *As Measured Peak value used to demonstrate compliance. Joseph D. Brunett Hfield Limit*** dBuV/mdBuA/mdBuV/mdBuA/m *** For FCC MPE,use of 300 kHz limit at 125 kHz as previously allowed by FCC. **** EIRP (mW) = S (mW/cm^2) x 4 x PI x 20cm^2 Frequency BandE-Field SensorApplication:Test Date: 01/08/21 0.009-30 MHzEFPGALX101Mobile (desktop) Test Engineer: DetectorH-Field SensorLoad:EUT Mode: Charging, Coil 1,2,3,4 Integrated RMSHFPGALX101Samsung Edge S6 EUT Tested: LG Meas. Electric FieldMagnetic Field EUTSensor DistanceMeasuredLimitMeasuredLimit # SideVector cm*V/mV/m*A/mA/m 1 1% Left x 15.0 110.9 1.00614.00 54.7 0.111.63 6.7 2y 15.0 108.042.8 3z 15.0 112.1100.7 4 Front x 15.0 105.2 1.29614.00 59.4 0.111.63 6.9 5y 15.0 120.569.5 6z 15.0 93.7100.7 7 Back x 15.0 109.9 1.40614.00 53.9 0.111.63 6.8 8y 15.0 120.262.4 9z 15.0 96.4100.7 10 Top x 20.0 110.2 2.79614.00 99.1 0.311.63 19.2 11y 20.0 121.396.5 12z 20.0 122.3103.9 13 Right x 15.0 116.6 0.88614.00 84.6 0.141.63 8.5 14y 15.0 101.082.2 15z 15.0 99.0100.7 16 50% Left x 15.0 110.6 0.93614.00 53.5 0.091.63 5.6 17y 15.0 106.041.9 18z 15.0 111.899.1 19 Front x 15.0 103.3 1.06614.00 57.7 0.091.63 5.7 20y 15.0 118.867.8 21z 15.0 92.899.1 22 Back x 15.0 109.0 1.28614.00 53.5 0.101.63 6.4 23y 15.0 119.562.0 24z 15.0 93.6100.2 25 Top x 20.0 108.1 2.49614.00 98.7 0.261.63 16.0 26y 20.0 121.094.2 27z 20.0 120.9101.9 28 Right x 15.0 115.0 0.73614.00 84.0 0.101.63 6.4 29y 15.0 99.880.5 30z 15.0 96.497.8 31 99% Left x 15.0 89.3 0.08614.00 28.5 0.011.63 0.3 32y 15.0 85.815.8 33z 15.0 90.474.6 34 Front x 15.0 82.8 0.10614.00 32.7 0.011.63 0.3 35y 15.0 98.043.2 36z 15.0 71.973.7 37 Back x 15.0 88.1 0.12614.00 27.8 0.011.63 0.3 38y 15.0 98.535.2 39z 15.0 74.774.5 40 Top x 20.0 87.9 0.23614.00 73.0 0.021.63 0.9 41y 20.0 99.469.7 42z 20.0 100.777.6 43 Right x 15.0 94.9 0.07614.00 57.9 0.011.63 0.4 44y 15.0 79.255.5 45z 15.0 77.474.3 *Total Field Strength = 10^(x-field_dB/20)+10^(y-field_dB/20)+10^(z-field_dB/20)) Joseph D Brunett Load Charge % Worst Case MPE Level (%) dBuV/mdBuA/m

Amber Helm Development L.C. 92723 Michigan Hwy-152 Sister Lakes, Michigan 49047 USA Tel: 888-847-8027 LGN2A-WR2101TX Issued:January 16, 2021 EMC Test Report regarding USA: CFR Title 47, Part 15.209(Emissions) Canada:ISED RSS-216v2(Emissions) for WCFDM00N2A Series Category: FCC 15.209 / RSS-216 Type 3, Cat 1 Judgments: 15.209/RSS-216v2 Compliant Transmitter Testing Completed: January 8, 2021 TESTING NVLAP LAB CODE 200129-0 Prepared for: LG Electronics 111 Sylvan Avenue North Building, Englewood Cliffs New Jersey 07632 USA Phone: +1 (201) 266-2215, Fax: Contact: Dae Woong Kim, [email protected] Data Recorded by: Reviewed by: Dr. Joseph Brunett, EMC-002790-NEGordon Helm, EMC-002401-NE Prepared by:Date of Issue: January 16, 2021 Dr. Joseph Brunett, EMC-002790-NE A copy of this report will remain on file until February 2031.Page 1 of 17 Date: January 16, 2021Prepared For: LG ElectronicsReport No.: LGN2A-WR2101TX Revision History Rev. No.DateDetailsRevised By r0January 16, 2021Initial Release.J. Brunett r1January 27, 2021ICES-001 Limits added + typo corr.J. Brunett r2January 28, 2021ICES-001 Limits corr.J. Brunett Contents Revision History2 Table of Contents2 1 Test Report Scope and Limitations4 1.1 Laboratory Authorization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 1.2 Report Retention . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 1.3 Subcontracted Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 1.4 Test Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 1.5 Limitation of Results . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 1.6 Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 1.7 Endorsements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 1.8 Test Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 1.9 Traceability and Equipment Used . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 2 Test Specifications and Procedures6 2.1 Test Specification and General Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 3 Configuration and Identification of the Equipment Under Test7 3.1 Description and Declarations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 3.1.1EUT Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 3.1.2Modes of Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 3.1.3Variants . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 3.1.4Test Samples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 3.1.5Functional Exerciser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 3.1.6Modifications Made . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 3.1.7Production Intent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 3.1.8Declared Exemptions and Additional Product Notes . . . . . . . . . . . . . . . . . . . . . . . .9 4 Emissions10 4.1 General Test Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 4.1.1Radiated Test Setup and Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 4.1.2Conducted Emissions Test Setup and Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . 12 4.1.3Power Supply Variation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 4.2 Intentional Emissions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 4.2.1Fundamental Emission Pulsed Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 4.2.2Fundamental Emission Bandwidth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 4.2.3Fundamental Emission . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 4.3 Unintentional Emissions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 4.3.1Transmit Chain Spurious Emissions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 5 Measurement Uncertainty and Accreditation Documents17 Amber Helm Development L.C., 92723 Michigan Hwy-152, Sister Lakes, Michigan 49047 USAPage 2 of 17 Date: January 16, 2021Prepared For: LG ElectronicsReport No.: LGN2A-WR2101TX List of Tables 1Test Site List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 2Equipment List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 3EUT Declarations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 4Pulsed Emission Characteristics (Duty Cycle). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 5Intentional Emission Bandwidth.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 6Fundamental Radiated Emissions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 7Transmit Chain Spurious Emissions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 8Measurement Uncertainty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 List of Figures 1Photos of EUT.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 2EUT Test Configuration Diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . …
