BOU-AD7000WWireless speaker with AirPlay

Register your product and get support at www.philips.com/welcome EN User manual 3 Contents 1 Important 4 Safety 4 Notice 5 2 Your Entertainment System 8 Introduction 8 What’s in the box 8 What else you need 8 Overview of the main unit 9 Get started to use AirPlay 9 3 Prepare 10 Connect power 10 Turn AD7000W on 10 4 Connect to your home Wi-Fi network for AirPlay 11 Scenario 1: Connect to a WPS router 11 Scenario 2: Connect to a non-WPS router 12 5 Play 20 Stream audio from your iTunes music library to AD7000W 20 Control play 21 Use advanced sound settings 21 Play/charge your iPod/iPhone/iPad through USB socket 22 Play from an external device 22 Update firmware 23 6 Product information 26 Specifications 26 7 Troubleshooting 27 EN 4 k Only use attachments/accessories specified by the manufacturer. l Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. m Unplug this apparatus during lightning storms or when unused for long periods of time. n Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. o Battery usage CAUTION – To prevent battery leakage which may result in bodily injury, property damage, or damage to the unit: Install all batteries correctly, + and - as marked on the unit. Remove batteries when the unit is not used for a long time. Perchlorate Material-special handling may apply. See www.dtsc.ca.gov/ hazardouswaste/perchlorate. p Apparatus shall not be exposed to dripping or splashing, keep it away from direct sunlight,naked flames or heat. • • • 1 Important Safety Important Safety Instructions a Read these instructions. b Keep these instructions. c Heed all warnings. d Follow all instructions. e Do not use this apparatus near water. f Clean only with dry cloth. g Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. h Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. i Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. j Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. EN 5 separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter. Installers must ensure that 20cm separation distance will be maintained between the device (excluding its handset) and users. FCC rules This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. Canada: This Class B digital apparatus complies with Canadian ICES-003. • • • • Warning Never remove the casing of this apparatus. Never lubricate any part of this apparatus. Never place this apparatus on other electrical equipment. Keep this apparatus away from direct sunlight, naked flames or heat. Ensure that you always have easy access to the power cord, plug or adaptor to disconnect this apparatus from the power. • • • • • Risk of overheating! Never install this apparatus in a confined space. Always leave a space of at least four inches around this apparatus for ventilation. Ensure curtains or other objects never cover the ventilation slots on this apparatus. Notice Notice of compliance Modifications The user is cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC & RSS compliance statement This device complies with Part 15 of the FCC Rules and Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: a This device may not cause harmful interference, and b This device must accept any interference received, including interference that may cause undesired operation. FCC Radiation Exposure Statement This equipment complies with FCC’s and IC’s RF radiation exposure limits set forth for an uncontrolled environment. The antenna(s) used for this transmitter must be installed and operated to provide a EN 6 Never dispose of your product with other household waste. Please inform yourself about the local rules on the separate collection of electrical and electronic products and batteries. The correct disposal of these products helps preven…

Text truncated - open the document above for the full version.

RF_160, Issue 02 Declaration of Authorization We Name: Philips Electronics Hong Kong Ltd. Address: 5/F., Philips Electronics Building, 5 Science Park East Avenue,Hong Kong Science Park, Shatin N.T. City: Hong Kong Country: China Declare that: Name Representative of agent: Ms. Cathy Wang Agent Company name: Neutron Engineering, Inc. Address: No.3 Jinshagang 1 st Road, Shixia, Dalang Town City: Dongguan Country: China is authorized to apply for Certification of the following product(s): Product description: Wireless speaker with AirPlay Type designation: AD7000W/37 Trademark: PHILIPS on our behalf. Date: 2011-08-04 Agency Agreement Expiration Date: 3 months City: Hong Kong Name: Benson LAI Function: Lead Engineer, Safety & Compliance Signature: _____________________________ Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

FCC, Request for non-disclosure Date: 10-AUG-09 RF_501, Issue 5 Page 1 of 1 Company Name: Philips Consumer Lifestyle Address: 3029 East Governor John Sevier Hwy. City: Knoxville Country: United States To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: BOU-AD7000W Reference number: AD7000W/37 Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, a pplicant hereby requests Short-Term Confidential treatment of the following materials (note 1): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: Planned Release Date STC: (notes 2, 3, 4, 5) Date: 2011-08-04 Name and signature of applicant: Benson LAI Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

CERTIFICATE OF COMPLIANCE Ref No.: NEI-FCCE-1-1107C101 Date of Issue: Jul. 29, 2011 Authorized under Declaration of Conformity according to 47 CFR, Part 2 and Part 15 of the FCC Rules. The product listed in follows was (were) tested in the Neutron EMC Laboratory to comply with the criteria limits Class B of conducted and radiated emissions of the Technical Standards FCC Part 15, Subpart B, established by the FCC, USA. Equipment Wireless speaker with Airplay Model Name AD7000W/37 Brand Name PHILIPS Applicant Philips Consumer Lifestyle Address 3029 East Governor John Sevier Hwy. Knoxville Tennessee 37914 United States Measurement ANSI C63.4 (2003) Method The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCE-1-1107C101) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of NVLAP and TAF according to the ISO-17025 quality assessment standard and technical standard(s). The test data contained in the referenced test report relate only to the EUT sample and item(s) tested. Andy Chiu Authorized Signatory Neutron Engineering Inc. B1, No.37, Lane 365, Yang Guang St., NeiHu District 114., Taipei, Taiwan TEL：+886-2-2657-3299 FAX：+886-2-2657-3331

Neutron Engineering Inc. Project No.: 1107C101 Page 2 of 21 1107C101 1107C101 1107C101 Neutron Engineering Inc. Project No.: 1107C101 Page 2 of 21 1107C101 1107C101 1107C101 Neutron Engineering Inc. Project No.: 1107C101 Page 3 of 21 1107C101 Neutron Engineering Inc. Project No.: 1107C101 Page 4 of 21 1107C101 1107C101 Neutron Engineering Inc. Project No.: 1107C101 Page 4 of 21 1107C101 1107C101 Neutron Engineering Inc. Project No.: 1107C101 Page 5 of 21 1107C101 1107C101 Neutron Engineering Inc. Project No.: 1107C101 Page 5 of 21 1107C101 1107C101

Label on bottom Label on bottom AD7000W/37 LABEL FOR MAIN UNITAD7000W/10 LABEL FOR MAIN UNIT AD7000W/12 LABEL FOR MAIN UNIT NP3300/12 LABEL FOR MAIN UNIT Add a line in mold Label on bottom Add a line in mold Label on bottom Add a line in mold DS3800W/10 LABEL FOR MAIN UNITDS3880W/10 LABEL FOR MAIN UNIT DS3801W/37 LABEL FOR MAIN UNITDS3881W/37 LABEL FOR MAIN UNIT Label on bottom rubber Label on base bottom Label on bottom rubber Model No.: DS3800W/10 12V3A Serial Serial No.: No.: PPTT11AA Model No.: DS3800W/10Model No.: DS3800W/10 11003311000000000011 FCC NO.: XXX-XXXX CAN IC: XXX-XXXX Manufactured June,2011 COMPLIES WITH FCC PART 15 RULES COMPLIES WITH RSS-210 OF INDUSTRY CANADA Model:DS3801W/37 12V3A Serial Serial No.: No.: PPTT11AA Model: DS3801W/37Model: DS3801W/37 11003311000000000011 Operation is subject to the following two conditions (1) the device may not cause harmful interference and (2) This device must accept any interference received including interference that may cause undesired operation. This Class B digital apparatus complies with Canadian ICES-003.Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. Philips Consumer Lifestyle, P.O. Box 10313 Stamford, CT 06904 5mm 7.6mm =57mm =57mm Label on base bottom FCC NO.: XXX-XXXX CAN IC: XXX-XXXX Manufactured June,2011 COMPLIES WITH FCC PART 15 RULES COMPLIES WITH RSS-210 OF INDUSTRY CANADA Model: DS3881W/37 12V3A Serial Serial No.: No.: PPTT11AA Model: DS3881W/37Model: DS3881W/37 11003311000000000011 Operation is subject to the following two conditions (1) the device may not cause harmful interference and (2) This device must accept any interference received including interference that may cause undesired operation. This Class B digital apparatus complies with Canadian ICES-003.Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. Philips Consumer Lifestyle, P.O. Box 10313 Stamford, CT 06904 =57mm Model No.: DS3880W/10 12V3A Serial Serial No.: No.: PPTT11AA Model No.: DS3880W/10Model No.: DS3880W/10 11003311000000000011 5mm 7.6mm =57mm Wireless speaker with AirPlay Wireless speaker with AirPlay Wireless speaker with AirPlay Wireless speaker with AirPlay Model No.: AD7000W/12Model No.: AD7000W/12 Serial Serial No.: No.: PPTT11AA11003311000000000011 7.6mm 5mm Model No.: AD7000W/12 12V3A Wireless speaker with AirPlay This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. Model: AD7000W/37Model: AD7000W/37 Serial Serial No.: No.: PPTT11AA11003311000000000011 Model:AD7000W/37 12V3A Manufactured June,2011 COMPLIES WITH FCC PART 15 RULES COMPLIES WITH RSS-210 OF INDUSTRY CANADA Operation is subject to the following two conditions (1) the device may not cause harmful interference and (2)This device must accept any interference received including interference that may cause undesired operation. Philips Consumer Lifestyle, P.O. Box 10313 Stamford, CT 06904 Wireless speaker with AirPlay IC : 135M-AD7000W FCC ID : BOU-AD7000W

Neutron Engineering Inc. Project No.: 1107C101 Page 6 of 21 1107C101 1107C101 Neutron Engineering Inc. Project No.: 1107C101 Page 6 of 21 1107C101 1107C101 Neutron Engineering Inc. Project No.: 1107C101 Page 7 of 21 1107C101 1107C101 Neutron Engineering Inc. Project No.: 1107C101 Page 7 of 21 1107C101 1107C101 Neutron Engineering Inc. Project No.: 1107C101 Page 8 of 21 1107C101 1107C101 Neutron Engineering Inc. Project No.: 1107C101 Page 8 of 21 1107C101 1107C101 Neutron Engineering Inc. Project No.: 1107C101 Page 9 of 21 1107C101 1107C101 Neutron Engineering Inc. Project No.: 1107C101 Page 9 of 21 1107C101 1107C101 Neutron Engineering Inc. Project No.: 1107C101 Page 10 of 21 1107C101 1107C101 Neutron Engineering Inc. Project No.: 1107C101 Page 10 of 21 1107C101 1107C101 Neutron Engineering Inc. Project No.: 1107C101 Page 11 of 21 1107C101 1107C101 Neutron Engineering Inc. Project No.: 1107C101 Page 11 of 21 1107C101 1107C101 Neutron Engineering Inc. Project No.: 1107C101 Page 12 of 21 1107C101 1107C101 Neutron Engineering Inc. Project No.: 1107C101 Page 12 of 21 1107C101 1107C101 Neutron Engineering Inc. Project No.: 1107C101 Page 13 of 21 1107C101 1107C101 Neutron Engineering Inc. Project No.: 1107C101 Page 13 of 21 1107C101 1107C101 Neutron Engineering Inc. Project No.: 1107C101 Page 14 of 21 1107C101 1107C101 1107C101 1107C101 Neutron Engineering Inc. Project No.: 1107C101 Page 14 of 21 1107C101 1107C101 1107C101 1107C101 Neutron Engineering Inc. Project No.: 1107C101 Page 15 of 21 1107C101 1107C101 Neutron Engineering Inc. Project No.: 1107C101 Page 15 of 21 1107C101 1107C101 Neutron Engineering Inc. Project No.: 1107C101 Page 16 of 21 1107C101 1107C101 Neutron Engineering Inc. Project No.: 1107C101 Page 16 of 21 1107C101 1107C101 Neutron Engineering Inc. Project No.: 1107C101 Page 17 of 21 1107C101 1107C101 Neutron Engineering Inc. Project No.: 1107C101 Page 17 of 21 1107C101 1107C101 Neutron Engineering Inc. Project No.: 1107C101 Page 18 of 21 1107C101 1107C101 Neutron Engineering Inc. Project No.: 1107C101 Page 18 of 21 1107C101 1107C101 Neutron Engineering Inc. Project No.: 1107C101 Page 19 of 21 1107C101 Neutron Engineering Inc. Project No.: 1107C101 Page 20 of 21 1107C101 1107C101 Neutron Engineering Inc. Project No.: 1107C101 Page 20 of 21 1107C101 1107C101 Neutron Engineering Inc. Project No.: 1107C101 Page 21 of 21 1107C101 1107C101 Neutron Engineering Inc. Project No.: 1107C101 Page 21 of 21 1107C101 1107C101

Neutron Engineering Inc. FCC RF EXPOSURE REPORT FCC ID: BOU-AD7000W Project No. : 1107C101 Equipment : Wireless speaker with AirPlay Model : AD7000W/37 Applicant : Philips Consumer Lifestyle Address : 3029 East Governor John Sevier Hwy. According: : FCC Guidelines for Human Exposure IEEE C95.1 Neutron Engineering Inc. No.3, Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. MPE CALCULATION METHOD: Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Ant. Brand name Model Name Antenna TypeConnector Gain (dBi) cable length 1 Mogear C6048-510 030PA Integral Antenna U.FL 2.0 195mm 2 Mogear C6048-510 028PA Integral Antenna U.FL 2.0 145mm TEST RESULTS EUT： Wireless speaker with AirPlay Model Name ： AD7000W/37 Temperature： 25 °C Relative Humidity： 60 % Pressure： 1012 hPa Test Voltage ： AC 120V/60Hz Test Mode ： TX B MODE CH01/CH06/CH11 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 2.0 1.5849 16.80 47.8630 0.015099081 Complies 2.0 1.5849 16.06 40.3645 0.012733581 Complies 2.0 1.5849 16.02 39.9945 0.012616831 Complies Neutron Engineering Inc. EUT： Wireless speaker with AirPlay Model Name ： AD7000W/37 Temperature： 25 °C Relative Humidity： 60 % Pressure： 1012 hPa Test Voltage ： AC 120V/60Hz Test Mode ： TX G MODE CH01/CH06/CH11 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 2.0 1.5849 19.70 93.3254 0.029440851 Complies 2.0 1.5849 19.60 91.2011 0.028770701 Complies 2.0 1.5849 19.71 93.5406 0.029508721 Complies

Neutron Engineering Inc. Report No.: NEI-FICP-1-1107C101 Page 1 of 78 FCC/IC Radio Test Report FCC ID: BOU-AD7000W IC: 135M-AD7000W This report concerns (check one) : Original Grant Class II Change Issued Date : Jul. 29, 2011 Project No. : 1107C101 Equipment : Wireless speaker with Airplay Model Name : AD7000W/37 Applicant : Philips Consumer Lifestyle Address : 3029 East Governor John Sevier Hwy. Knoxville Tennessee 37914 United States Manufacturer : Philips Electronics Hong Kong Ltd. Address : 5/F,HONG KONG SCIENCE PARK,5 SCIENCE PARK EAST AVENUE,SHATIN,NEW TERRITORIES, Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Jul. 21, 2011 Date of Test: Jul. 21, 2011 ~ Jul. 28, 2011 Testing Engineer : (Ivan Cao) Technical Manager : (Leo Hung) Authorized Signatory : (Steven Lu) Neutron Engineering Inc. No.3,Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. Report No.: NEI-FICP-1-1107C101 Page 2 of 78 Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C, or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FICP-1-1107C101 Page 3 of 78 Table of Contents Page 1 . CERTIFICATION 5 2 . SUMMARY OF TEST RESULTS 6 2.1 TEST FACILITY 7 2.2 MEASUREMENT UNCERTAINTY 7 3 . GENERAL INFORMATION 8 3.1 GENERAL DESCRIPTION OF EUT 8 3.2 DESCRIPTION OF TEST MODES 10 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 11 3.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 12 3.5 DESCRIPTION OF SUPPORT UNITS 13 4 . EMC EMISSION TEST 14 4.1 CONDUCTED EMISSION MEASUREMENT 14 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 14 4.1.2 MEASUREMENT INSTRUMENTS LIST AND SETTING 14 4.1.3 TEST PROCEDURE 15 4.1.4 DEVIATION FROM TEST STANDARD 15 4.1.5 TEST SETUP 15 4.1.6 EUT OPERATING CONDITIONS 15 4.1.7 TEST RESULTS 16 4.2 RADIATED EMISSION MEASUREMENT 20 4.2.1 RADIATED EMISSION LIMITS 20 4.2.2 MEASUREMENT INSTRUMENTS LIST ANS SETTING 21 4.2.3 TEST PROCEDURE 22 4.2.4 DEVIATION FROM TEST STANDARD 22 4.2.5 TEST SETUP 23 4.2.6 EUT OPERATING CONDITIONS 23 4.2.7 TEST RESULTS (BETWEEN 30 – 1000 MHZ) 24 4.2.8 TEST RESULTS (ABOVE 1000 MHZ) 28 5 . BANDWIDTH TEST 54 5.1 APPLIED PROCEDURES / LIMIT 54 5.1.1 MEASUREMENT INSTRUMENTS LIST 54 5.1.2 TEST PROCEDURE 54 5.1.3 DEVIATION FROM STANDARD 54 5.1.4 TEST SETUP 54 5.1.5 EUT OPERATION CONDITIONS 54 5.1.6 TEST RESULTS 55 Neutron Engineering Inc. Report No.: NEI-FICP-1-1107C101 Page 4 of 78 Table of Contents Page 6 . PEAK OUTPUT POWER TEST 59 6.1 APPLIED PROCEDURES / LIMIT 59 6.1.1 MEASUREMENT INSTRUMENTS LIST 59 6.1.2 TEST PROCEDURE 59 6.1.3 DEVIATION FROM STANDARD 59 6.1.4 TEST SETUP 59 6.1.5 EUT OPERATION CONDITIONS 59 6.1.6 TEST RESULTS 60 7 . ANTENNA CONDUCTED SPURIOUS EMISSION 61 7.1 APPLIED PROCEDURES / LIMIT 61 7.1.1 MEASUREMENT INSTRUMENTS LIST 61 7.1.2 TEST PROCEDURE 61 7.1.3 DEVIATION FROM STANDARD 61 7.1.4 TEST SETUP 61 7.1.5 EUT OPERATION CONDITIONS 61 7.1.6 TEST RESULTS 62 8 . POWER SPECTRAL DENSITY TEST 72 8.1 APPLIED PROCEDURES / LIMIT 72 8.1.1 MEASUREMENT INSTRUMENTS LIST 72 8.1.2 TEST PROCEDURE 72 8.1.3 DEVIATION FROM STANDARD 72 8.1.4 TEST SETUP 72 8.1.5 EUT OPERATION CONDITIONS 72 8.1.6 TEST RESULTS 73 9 . EUT TEST PHOTO 77 Neutron Engineering Inc. Report No.: NEI-FICP-1-1107C101 Page 5 of 78 1. CERTIFICATION Equipment : Wireless speaker with Airplay Brand Name : PHILIPS Model Name : AD7000W/37 Applicant : Philips Consumer Lifestyle Date of Test : Jul. 21, 2011 ~ Jul. 28, 2011 Te s t I t e m : ENGINEERING SAMPLE Standards : FCC Part15, Subpart C(15.247) / ANCI C63.4 : 2003; Canada RSS-210:2010 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FICP-1-1107C101) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of NVLAP and TAF according to the ISO-17025 quality assessment standard and technical standard(s). Test result included in this report is only for the 802.11 b/g part of the product. Neutron Engineering Inc. Report No.: NEI-FICP-1-1107C101 Page 6 of 78 2. SUMMARY OF TEST RESULTS FCC Part15 (15.247) , Subpart C / RSS-210: 2010 Standard Section Test Item Judgment Remark RSS-GEN 7.2.2 15.207 Conducted Emission PASS RSS-210 A8.5 15.247 (d) Antenna conducted Spurious EmissionPASS RSS-210 A8.2(a) 15.247 (a)(2) 6dB Bandwidth PASS RSS-210 A8.4(4) 15.247 (b) Peak Output Power PASS RSS-210 A8.2(b) 15.247 (e) Power Spectral Density PASS - …

Text truncated - open the document above for the full version.

Neutron Engineering Inc. Report No.: NEI-FICP-1-1107C101 Page 77 of 78 9. EUT TEST PHOTO Conducted Measurement Photos Neutron Engineering Inc. Report No.: NEI-FICP-1-1107C101 Page 77 of 78 9. EUT TEST PHOTO Conducted Measurement Photos Neutron Engineering Inc. Report No.: NEI-FICP-1-1107C101 Page 78 of 78 Radiated Measurement Photos Neutron Engineering Inc. Report No.: NEI-FICP-1-1107C101 Page 78 of 78 Radiated Measurement Photos
