BOU-DWHP83Digital Wireless Audio Transceiver

. DWHP83 Module: The information is provided “as is” without any express or implied warranty of any kind, including warranties of merchantability, non-infringement of intellectual property, or fitness for any particular purpose. In no event shall SMSC and/or its affiliate companies, or its suppliers be liable for any damages whatsoever arising out of the use of or inability to use the information or the materials. SMSC, its affiliate companies, and its suppliers further do not warrant the accuracy or completeness of information, text, graphics, or other items contained within materials. SMSC, may make changes to materials, or the products described within, at any time, without notice. ©2011 SMSC. All rights reserved. mm) DWHP83 The DWHP83 chip itself provides the basic functions of Audio Processing and buffering, 5.8 GHz RF Transceiver 5.8GHz Rev 0.0 1. Product Description The DWHP83 Module is an OEM module (20x40 an uncompressed wireless digital audio transceiver operating in the bands. The wireless audio link supports up to 4 stereo audio streams and comes together with additional features such as: data encryption, pairing functionality, bi-directional control data messages, low power audio snooze mode, WLAN detection, Automatic Frequency Allocation. Data Link Layer and Physical Layer. The module integrates all functionality for a wireless digital audio connection, comprising:  Wireless Audio Processor   Embedded Antennas  Digital audio interfaces (I 2 S and/or S/PDIF)  I 2 C control interface  26 pins header connector for power, digital audio and control interface and GPIOs  Built-in 1MB SPI interface Flash 2.4. 2.3. 2.2. 2.1. 2. Rev 0.0 Description of operation Operating Conditions Symbol Parameter Min. Typ Max Unit VCC Supply Voltage - 3.3 - V Tamb Operating Temperature -10 25 60 °C Note: Regulated 3.3V power from FFC Interface RF Information Parameter Value Unit RF Frequency range 5725 - 5875 MHz Note: Country/ Region dependent Receive mode In receive mode, antenna diversity is supported. The single ended output of the TR switch is connected to the RF LNA input through a matching network. Filtering and amplification is all performed by the radio transceiver. The gain setting is controlled by the BB. The analog IQ outputs are sampled by the BB by its integrated 22Msps dual channel 8bit ADC. This received data is demodulated and fed to the audio processing engine controlling the audio function. Transmit mode In transmit mode, the audio engine transforms the audio data into packetized digital IQ signals. These are in turn pulse-shaped before conversion by a 10bits 44Msps DAC to match to the analog IQ inputs of the radio IC. The radio IC has programmable baseband filters to lower the RF spectrum side lobes and to suppress the DAC image and the DAC spurious. The output power is programmable. A power detector (PD_out) on the radio IC enables close-loop TX power control. The differential RF PA outputs are connected via a balun and low pass filter to a transmit/receive switch with TX diversity option to the antenna outputs. 3. Regulatory Statements for DWHP83 Contains FCC ID: BOU-DWHP83
USA-Federal Communications Commission (FCC) This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy. If not installed and used in accordance with the instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by tuning the equipment off and on, the user is encouraged to try and correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna - Increase the distance between the equipment and the receiver. - Connect the equipment to outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. To assure continued compliance, any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Caution: Exposure to Radio Frequency Radiation. To comply with FCC RF exposure compliance requirements, for mobile configurations, a separation distance of at least 20 cm must be maintained between the antenna of this device and all persons. This device must not be co-located or operating in conjunction with any other antenna or transmitter. Host product must be labeled with "". Canada – Industry Canada (IC) This Device complies with RSS-210 of the IC Rules; Operation is subject to the following two conditions: (1). This device may not cause interference and (2). This device must accept any interference received,, including interference that may cause undesired operation. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. Caution - Exposure
㉡
㉡
㉡
㉡   The device meets the exemption from the routine evaluation limits in section 2.5 of RSS102 and users can obtain Canadian information on RF exposure and compliance. Le dispositif…

Text truncated - open the document above for the full version.

RF_734_00, Issue 1 Modular Approval Request FCC (per DA 00-1407) FCC ID: BOU-DWHP83 Items to be covered Answer from applicant 1. The modular transmitter must have its own RF shielding. Yes, it has its own RF shielding, refer to EUT photos 2. The modular transmitter must have buffered modulation/data inputs (if such inputs are provi ded) t o ensure t hat the module will co mply w ith Part 15 requi rements under conditions of excessive data rates or over-modulation. YES, the component which control this function is DARR- 83. 3. The modular transmitter must have its own power supply regulation. YES，the IC AP2125k is to stable the voltage for this kind of module. 4. The modular transmitter must co mply with the an tenna r equirements of Section 15.203 and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable).. YES, it is printed antenna 5. The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing. This is intended to demonstrate that the module is capable of complying with Part 15 emission limits regardless of the device into which it is eventually installed. YES, The EUT is tested in a stand-alone configuration as the test photos show 6. The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of t he device into which the module is installed must also di splay a label referring to the enclosed module. This exterior label can use wordi ng such as the following: “Cont ains Transm itter M odule FC C ID: ZQO-DWPCIE83” or “Contains FCC ID: ZQO-DW PCIE83.” Any sim ilar wor ding t hat expresses t he same meaning m ay be used. The Grantee may e ither provide such a l abel, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. YES, please refer to the exhibition label sample for this module 7. The modular transmitter must co mply w ith any speci fic rul e or operati ng requirements a pplicable to the transmitter and t he manufacturer must provi de adequate instructions along with the module to explain any such requirements. A copy of t hese i nstructions must be i ncluded i n t he ap plication for equi pment authorization. For exam ple, t here are very st rict operat ional and timing requirements that must be met before a transmitter is authorized for operation under Section 15.231. For instance, data transmission is prohibited, except for operation under Section 15.231(e), in which case t here are separate fi eld strength level and timing requirements. Compliance with these requirements must be assured. YES, please refer to the user manual 8. The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 2.1091, 2.1093 and specific Sections of Part 15, including 15.319(i), 15.407(f), 15.253(f) and 15.255(g), require that Unlicensed PCS, UNII and millimeter wave devices perform routine environmental evaluation for RF Exposure to demonstrate compliance. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF Exposure compliance in accordance with Section 15.247(b)(4). Modular transmitters approved under other Sections of Part 15, when necessary, may also need to address certain RF Exposure concerns, typically by providing specific installation and operating instructions for users, installers and other interested parties to ensure compliance. YES, due to the output power and EIRP value is much lower than FCC SAR exemption threshold, this module comply with any applicable RF exposure requirement. Note: If compliance with one or more of the numbered requirements, listed above, cannot be demonstrated, it may be possible to obtain a “Limited Modular Approval” (LMA). Name and surname of applicant (or authorized representative): Maria Lei Date: 2013-5-14 Signature:

RF_160, Issue 02 Declaration of Authorization We Name: Philips Consumer Lifestyle Address: 5/F, Philips Electronics Building, 5 Science Park East Avenue, Hong Kong Science Park, City: Shatin, New Territories, Country: Hong Kong Declare that: Name Representative of agent: Ms. Cathy Wang Agent Company name: Neutron Engineering, Inc. Address: No.3 Jinshagang 1 st Road, Shixia, Dalang Town City: Dong Guan Country: China is authorized to apply for Certification of the following product(s): Product description: Digital Wireless Audio Transceiver Model: DWHP83 Trademark: PHILIPS on our behalf. Date: 2013- 5-15 City: Shatin, New Territories, Name: Maria Lei Function: Quality Account Lead Signature:

FCC, Request for non-disclosure Date: 10-AUG-09 RF_501, Issue 5 Page 1 of 1 Company Name: Philips Consumer Lifestyle Address: 5/F, Philips Electronics Building 5 Science Park East Avenue, Hong Kong Science Park City: Shatin, New Territories Country: Hong Kong To: Telefica tion B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: BOU-DWHP83 Re ference n umber: DWHP83 Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, a pplicant hereby requests Short-Term Confidential treatment of the following materials (note 1): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: Planned Release Date STC: (notes 2, 3, 4, 5) Date: 2013- 5-15 Name and signature of applicant: Maria Lei Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

Neutron Engineering Inc. Project No.: 1304C230 Page 2 of 4 Neutron Engineering Inc. Project No.: 1304C230 Page 3 of 4 Neutron Engineering Inc. Project No.: 1304C230 Page 4 of 4

Neutron Engineering Inc. Project No.: 1304C230 Page 2 of 4 Neutron Engineering Inc. Project No.: 1304C230 Page 3 of 4 Neutron Engineering Inc. Project No.: 1304C230 Page 4 of 4

Neutron Engineering Inc. FCC RF EXPOSURE REPORT FCC ID: BOU-DWHP83 Project No. : 1304C230 Equipment : Digital Wireless Audio Transceiver Model : DWHP83 Applicant : Philips Consumer Lifestyle Address : 5/F, Philips Electronics Building, 5 Science Park East Avenue, Hong Kong Science Park, Shatin, New Territories, Hong Kong According: : FCC Guidelines for Human Exposure IEEE C95.1 Neutron Engineering Inc. No.3, Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. GENERAL CONCULUSION: Table for Filed Antenna: Ant. Brand Model NameAntenna TypeConnector Gain (dBi) A SMSC DWHP83 Printed N/A 3.2 B SMSC DWHP83 Printed N/A 3.2 Only “one” antenna is selected for use at any one time, through the on-board Transmit-Receive / Diversity RF switch. Maximum measured transmitter power: (MHz) Output Power (dBm) Out Power (mW) Limit (mW) Distance (mm) 5736~5814 14.83 30.4 62 50 According to FCC KDB447498, Appendix B, SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and > 50 mm The transmitter power is 30mW, less than 62mW at minimum 50mm distance due to this module intended used into audio and video devices. Conclusion: No SAR evaluation required since transmitter power is below FCC threshold

Neutron Engineering Inc. Report No.: NEI-FICP-3-1304C230 Page 1 of 53 FCC/IC Radio Test Report FCC ID: BOU-DWHP83 IC: 135M-DWHP83 This report concerns (check one): Original Grant Class I Change Issued Date : May. 13, 2013 Project No. : 1304C230 Equipment : Digital Wireless Audio Transceiver Model Name : DWHP83 Applicant : Philips Consumer Lifestyle Address : 5/F, Philips Electronics Building, 5 Science Park East Avenue, Hong Kong Science Park, Shatin, New Territories, Hong Kong Manufacturer : Philips Electronics Hong Kong Ltd. Address : 5/F., Philips Electronics Building 5 Science Park East Avenue, Hong Kong Science Park, Shatin, New Territories, Hong Kong Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Apr. 23, 2013 Date of Test: Apr. 23, 2013 ~ May. 10, 2013 Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory: (Steven Lu) Neutron Engineering Inc. No.3,Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. Report No.: NEI-FICP-3-1304C230 Page 2 of 53 Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of CHINA, or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FICP-3-1304C230 Page 3 of 53 Table of Contents Page 1 . CERTIFICATION 5 2 . SUMMARY OF TEST RESULTS 6 2.1 TEST FACILITY 7 2.2 MEASUREMENT UNCERTAINTY 7 3 . GENERAL INFORMATION 8 3.1 GENERAL DESCRIPTION OF EUT 8 3.2 DESCRIPTION OF TEST MODES 10 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 11 3.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 12 3.5 DESCRIPTION OF SUPPORT UNITS 13 4 . EMC EMISSION TEST 14 4.1 CONDUCTED EMISSION MEASUREMENT 14 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 14 4.1.2 MEASUREMENT INSTRUMENTS LIST AND SETTING 14 4.1.3 TEST PROCEDURE 15 4.1.4 DEVIATION FROM TEST STANDARD 15 4.1.5 TEST SETUP 15 4.1.6 EUT OPERATING CONDITIONS 15 4.1.7 TEST RESULTS 16 4.2 RADIATED EMISSION MEASUREMENT 19 4.2.1 RADIATED EMISSION LIMITS 19 4.2.2 MEASUREMENT INSTRUMENTS LIST ANS SETTING 20 4.2.3 TEST PROCEDURE 21 4.2.4 DEVIATION FROM TEST STANDARD 21 4.2.5 TEST SETUP 22 4.2.6 EUT OPERATING CONDITIONS 22 4.2.7 TEST RESULTS (BETWEEN 30 – 1000 MHZ) 23 4.2.8 TEST RESULTS (ABOVE 1000 MHZ) 26 5 . BANDWIDTH TEST 38 5.1 APPLIED PROCEDURES / LIMIT 38 5.1.1 MEASUREMENT INSTRUMENTS LIST 38 5.1.2 TEST PROCEDURE 38 5.1.3 DEVIATION FROM STANDARD 38 5.1.4 TEST SETUP 38 5.1.5 EUT OPERATION CONDITIONS 38 5.1.6 TEST RESULTS 39 6 . MAXIMUM OUTPUT POWER TEST 41 Neutron Engineering Inc. Report No.: NEI-FICP-3-1304C230 Page 4 of 53 Table of Contents Page 6.1 APPLIED PROCEDURES / LIMIT 41 6.1.1 MEASUREMENT INSTRUMENTS LIST 41 6.1.2 TEST PROCEDURE 41 6.1.3 DEVIATION FROM STANDARD 41 6.1.4 TEST SETUP 41 6.1.5 EUT OPERATION CONDITIONS 41 6.1.6 TEST RESULTS 42 7 . ANTENNA CONDUCTED SPURIOUS EMISSION 43 7.1 APPLIED PROCEDURES / LIMIT 43 7.1.1 MEASUREMENT INSTRUMENTS LIST 43 7.1.2 TEST PROCEDURE 43 7.1.3 DEVIATION FROM STANDARD 43 7.1.4 TEST SETUP 43 7.1.5 EUT OPERATION CONDITIONS 43 7.1.6 TEST RESULTS 44 8 . POWER SPECTRAL DENSITY TEST 49 8.1 APPLIED PROCEDURES / LIMIT 49 8.1.1 MEASUREMENT INSTRUMENTS LIST 49 8.1.2 TEST PROCEDURE 49 8.1.3 DEVIATION FROM STANDARD 49 8.1.4 TEST SETUP 49 8.1.5 EUT OPERATION CONDITIONS 49 8.1.6 TEST RESULTS 50 9 . EUT TEST PHOTO 52 Neutron Engineering Inc. Report No.: NEI-FICP-3-1304C230 Page 5 of 53 1. CERTIFICATION Equipment : Digital Wireless Audio Transceiver Brand Name : PHILIPS Model Name : DWHP83 Applicant : Philips Consumer Lifestyle Date of Test : Apr. 23, 2013 ~ May. 10, 2013 Test Item : ENGINEERING SAMPLE Standards : FCC Part15, Subpart C(15.247) / ANSI C63.4 : 2009; Canada RSS-210:2010 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FICP-3-1304C230) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of NVLAP and TAF according to the ISO-17025 quality assessment standard and technical standard(s). Neutron Engineering Inc. Report No.: NEI-FICP-3-1304C230 Page 6 of 53 2. SUMMARY OF TEST RESULTS FCC Part15 (15.247) , Subpart C / RSS-210: 2010 Standard Section Test Item Judgment Remark RSS-GEN 7.2.2 15.207 Conducted Emission PASS RSS-210 A8.5 15.247 (d) Antenna conducted Spurious EmissionPASS RSS-210 A8.2(a) 15.247 (a)(2) 6dB Bandwidth PASS RSS-210 A8.4(4) 15.247 (b) Peak Output Power PASS RSS-210 A8.2(b) 15.247 (e) Power Spectral Density PASS …
