BOU-HTL2160VF7SoundBar Speaker

www.philips.com/welcome User manual Always there to help you Register your product and get support at HTL2160/F7 Question? Contact Philips 1EN 1 Important Read and understand all instructions before you use your product. If damage is caused by failure to follow instructions, the warranty does not apply. Help and support Philips provides extensive online support. Visit our website at www.philips.com/support to: • download the user manual and the quick start guide • watch video tutorials (available only for selected models) • find answers to frequently answered questions (F AQs) • email us a question • chat with our support representative. Follow the instructions on the website to select your language, and then enter your product model number. Alternatively, you can contact Philips Consumer Care in your country. Before you contact Philips, note down the model number and serial number of your product. Y ou can find this information on the back or bottom of your product. Important safety instructions •Read these instructions. •K eep these instructions. •Heed all warnings. •Follow all instructions. •Do not use this a pparatus near water. •Clean only with dry cloth. •Do not block an y ventilation openings. Install in accordance with the manufacturer's instructions. •Do not install near an y heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. •Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. •Pr otect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. •Onl y use attachments/accessories specified by the manufacturer. •Use only with the cart, stand, tripod, bracket or table specified by the manufacturer or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. •Unplug this a pparatus during lightning storm or when unused for long periods of time. •Ref er all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. •Batter y usage CAUTION - To prevent battery leakage which may result in bodily injury, property damage, or damage to the unit: 2EN • Install all batteries correctly, + and - as marked on the unit. • Do not mix batteries (old and new or carbon and alkaline, etc.). • Remove batteries when the unit is not used for a long time. • The batteries shall not be exposed to excessive heat such as sunshine, fire or the like. • Perchlorate Material - special handling may apply. See www.dtsc.ca.gov/ hazardouswaste/perchlorate. • The product/remote control may contain a coin/button type battery, which can be swallowed. Keep the battery out of reach of children at all times! If swallowed, the battery can cause serious injury or death. Severe internal burns can occur within two hours of ingestion. • If you suspect that a battery has been swallowed or placed inside any part of the body, seek immediate medical attention. • When you change the batteries, always keep all new and used batteries out of reach of children. Ensure that the battery compartment is completely secure after you replace the battery. • If the battery compartment cannot be completely secured, discontinue use of the product. Keep out of reach of children and contact the manufacturer. •Apparatus shall not be exposed to dripping or splashing. •Do not place an y sources of danger on the apparatus (for example. liquid filled objects, lighted candles). •This appar atus may contain lead and mercury. Dispose according to local, State or Federal laws. For disposal or recycling information, please contact your local authorities. For additional assistance on recycling options, please contact www. mygreenelectronics.com or www.eiae.org or www.recycle.philips.com. •Where the MAINS plug or an appliance coupler is used as the disconnect device , the disconnect device shall remain readily operable. •Do not place this apparatus on the furniture that is capable of being tilted by a child and an adult leaning, pulling, standing or climbing on it. A falling apparatus can cause serious injury or even death. • This apparatus should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided. Make sure to leave a space of 7.8 inches (20cm) or more around this apparatus. Class II equipment symbol This symbol indicates that the unit has a double insulation system. This 'bolt of lightning' indicates uninsulated material within your unit may cause an electrical shock. For the safety of everyone in your household, please do not remove product covering. The 'exclamation point' calls attention to features for which you should read the enclosed literature closely to prevent operating and maintenance problems. WARNING: To reduce the risk of fire or electr ic shock, this apparatus should not be exposed to rain or moisture and objects filled with liquids, such as vases, should not be placed on this apparatus. CAUTION: To prevent electric shock, match wide blade of plug to wide slot, fully insert. 3EN Care for your product Use only microfiber cloth to clean the product. Care of the environment Your product is designed and manufactured with high quality materials and components, which can be recycled and reused. Please visit www.recycle.philips.com for additional information on a recycling center in your…

Text truncated - open the document above for the full version.

English HTL2160/F7 Important Read and understand all instructions before you use your product. If damage is caused by failure to follow instructions, the warranty does not apply. Help and support Philips provides extensive online support. Visit our website at www.philips.com/support to: • download the user manual and the quick start guide • watch video tutorials (available only for selected models) • find answers to frequently answered questions (FAQs) • email us a question • chat with our support representative. Follow the instructions on the website to select your language, and then enter your product model number. Alternatively, you can contact Philips Consumer Care in your country. Before you contact Philips, note down the model number and serial number of your product. You can find this information on the back or bottom of your product. Important safety instructions •Read these instructions. •Keep these instructions. •Heed all warnings. •Follow all instructions. •Do not use this apparatus near water. •Clean only with dry cloth. •Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. •Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. •Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. •Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. •Only use attachments/accessories specified by the manufacturer. •Use only with the cart, stand, tripod, bracket or table specified by the manufacturer or sold with the apparatus. When a cart is used, use caution when moving the cart/ apparatus combination to avoid injury from tip-over. •Unplug this apparatus during lightning storm or when unused for long periods of time. •Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. •Battery usage CAUTION - To prevent battery leakage which may result in bodily injury, property damage, or damage to the unit: • Install all batteries correctly, + and - as marked on the unit. • Do not mix batteries (old and new or carbon and alkaline, etc.). • Remove batteries when the unit is not used for a long time. • The batteries shall not be exposed to excessive heat such as sunshine, fire or the like. • Perchlorate Material - special handling may apply. See www.dtsc.ca.gov/ hazardouswaste/perchlorate. • The product/remote control may contain a coin/button type battery, which can be swallowed. Keep the battery out of reach of children at all times! If swallowed, the battery can cause serious injury or death. Severe internal burns can occur within two hours of ingestion. • If you suspect that a battery has been swallowed or placed inside any part of the body, seek immediate medical attention. • When you change the batteries, always keep all new and used batteries out of reach of children. Ensure that the battery compartment is completely secure after you replace the battery. • If the battery compartment cannot be completely secured, discontinue use of the product. Keep out of reach of children and contact the manufacturer. •Apparatus shall not be exposed to dripping or splashing. •Do not place any sources of danger on the apparatus (for example. liquid filled objects, lighted candles). •This apparatus may contain lead and mercury. Dispose according to local, State or Federal laws. For disposal or recycling information, please contact your local authorities. For additional assistance on recycling options, please contact www.mygreenelectronics. com or www.eiae.org or www.recycle.philips.com. •Where the MAINS plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable. •Do not place this apparatus on the furniture that is capable of being tilted by a child and an adult leaning, pulling, standing or climbing on it. A falling apparatus can cause serious injury or even death. • This apparatus should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided. Make sure to leave a space of 7.8 inches (20cm) or more around this apparatus. Class II equipment symbol This symbol indicates that the unit has a double insulation system. This ‘bolt of lightning’ indicates uninsulated material within your unit may cause an electrical shock. For the safety of everyone in your household, please do not remove product covering. The ‘exclamation point’ calls attention to features for which you should read the enclosed literature closely to prevent operating and maintenance problems. WARNING: To reduce the risk of fire or electric shock, this apparatus should not be exposed to rain or moisture and objects filled with liquids, such as vases, should not be placed on this apparatus. CAUTION: To prevent electric shock, match wide blade of plug to wide slot, fully insert. Care for your product Use only microfiber cloth to clean the product. Care of the environment Your product is designed and manufactured with high quality materials and components, which can be recycled and reused. Please visit www.recycle.philips.com for additional information on a recycling center in your area. Never dispose of your product with other household waste. Please inform yourself about the local rules on the separate collection of electric…

Text truncated - open the document above for the full version.

RF_160, Issue 02 Declaration of Authorization We Name: Philips Consumer Lifestyle Address: 5/F, Philips Electronics Building, 5 Science Park East Avenue, Hong Kong Science Park, City: Shatin, New Territories, Hong Kong Country: China Declare that: Name Representative of agent: Ms. Cathy Wang Agent Company name: Neutron Engineering, Inc. Address: No.3 Jinshagang 1 st Road, Shixia, Dalang Town City: Dong Guan Country: China is authorized to apply for Certification of the following product(s): Product description: SoundBar Speaker Model: HTL2160/F7 Trademark: PHILIPS on our behalf. Date: 2012-10-08 City: Hong Kong Name: Benson Lai Function: Lead Engineer, Safety and Compliance Signature: .

FCC, Request for non-disclosure Date: 10-AUG-09 RF_501, Issue 5 Page 1 of 1 Company Name: Philips Consumer Lifestyle Address: 5/F, Philips Electronics Building 5 Science Park East Avenue, Hong Kong Science Park City: Shatin, New Territories Country: Hong Kong To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: BOU-HTL2160VF7 Reference number: HTL2160/F7 Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, a pplicant hereby requests Short-Term Confidential treatment of the following materials (note 1): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: Planned Release Date STC: (notes 2, 3, 4, 5) Date: 2012-10-08 Name and signature of applicant: Maria Lei Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

Neutron Engineering Inc. Project No.: 1209C052 Page 2 of 17 Neutron Engineering Inc. Project No.: 1209C052 Page 2 of 17 Neutron Engineering Inc. Project No.: 1209C052 Page 3 of 17 Neutron Engineering Inc. Project No.: 1209C052 Page 3 of 17 Neutron Engineering Inc. Project No.: 1209C052 Page 4 of 17 Neutron Engineering Inc. Project No.: 1209C052 Page 4 of 17 Neutron Engineering Inc. Project No.: 1209C052 Page 5 of 17 Neutron Engineering Inc. Project No.: 1209C052 Page 5 of 17 Neutron Engineering Inc. Project No.: 1209C052 Page 6 of 17

April 2012April 2012 M O D E L N O . : H T L 2 1 6 0 / 1 2 S E R I A L N O . : K X 1 A 1 2 0 0 0 0 0 0 0 1 2 2 0 - 2 4 0 V ~ 5 0 H z 3 0 W M A D E I N C H I N A 0560 HTL2160/F7 HTL2160/12

Neutron Engineering Inc. Project No.: 1209C052 Page 6 of 17 Neutron Engineering Inc. Project No.: 1209C052 Page 7 of 17 Neutron Engineering Inc. Project No.: 1209C052 Page 7 of 17 Neutron Engineering Inc. Project No.: 1209C052 Page 8 of 17 Neutron Engineering Inc. Project No.: 1209C052 Page 8 of 17 Neutron Engineering Inc. Project No.: 1209C052 Page 9 of 17 Neutron Engineering Inc. Project No.: 1209C052 Page 9 of 17 Neutron Engineering Inc. Project No.: 1209C052 Page 10 of 17 Neutron Engineering Inc. Project No.: 1209C052 Page 10 of 17 Neutron Engineering Inc. Project No.: 1209C052 Page 11 of 17 Neutron Engineering Inc. Project No.: 1209C052 Page 11 of 17 Neutron Engineering Inc. Project No.: 1209C052 Page 12 of 17 Neutron Engineering Inc. Project No.: 1209C052 Page 12 of 17 Neutron Engineering Inc. Project No.: 1209C052 Page 13 of 17 Neutron Engineering Inc. Project No.: 1209C052 Page 13 of 17 Neutron Engineering Inc. Project No.: 1209C052 Page 14 of 17 Neutron Engineering Inc. Project No.: 1209C052 Page 14 of 17 Neutron Engineering Inc. Project No.: 1209C052 Page 15 of 17 Neutron Engineering Inc. Project No.: 1209C052 Page 15 of 17 Neutron Engineering Inc. Project No.: 1209C052 Page 16 of 17 Neutron Engineering Inc. Project No.: 1209C052 Page 16 of 17 Neutron Engineering Inc. Project No.: 1209C052 Page 17 of 17

Neutron Engineering Inc. Report No.: NEI-FICP-1-1209C052 Page 1 of 109 FCC/IC Radio Test Report FCC ID: BOU-HTL2610VF7 IC: 135M-HTL2610VF7 This report concerns (check one) : Original Grant Class II Change Issued Date : Sep. 29, 2012 Project No. : 1209C052 Equipment : SoundBar Speaker Model Name : HTL2160/F7 Applicant : Philips Electronics Hong Kong Ltd. Address : 5/F., Philips Electronics Building 5 Science Park East Avenue, Hong Kong Science Park, Shatin, New Territories, Hong Kong Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Sep. 07, 2012 Date of Test: Sep. 07, 2012 ~ Sep. 28, 2012 Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory : (Steven Lu) Neutron Engineering Inc. No.3,Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. Report No.: NEI-FICP-1-1209C052 Page 2 of 109 Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of CHINA, or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FICP-1-1209C052 Page 3 of 109 Table of Contents Page 1 . CERTIFICATION 6 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 8 3 . GENERAL INFORMATION 9 3.1 GENERAL DESCRIPTION OF EUT 9 3.2 DESCRIPTION OF TEST MODES 11 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 11 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 12 3.5 DESCRIPTION OF SUPPORT UNITS 13 4 . EMC EMISSION TEST 14 4.1 CONDUCTED EMISSION MEASUREMENT 14 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 14 4.1.2 MEASUREMENT INSTRUMENTS LIST AND SETTING 14 4.1.3 TEST PROCEDURE 15 4.1.4 DEVIATION FROM TEST STANDARD 15 4.1.5 TEST SETUP 15 4.1.6 EUT OPERATING CONDITIONS 15 4.1.7 TEST RESULTS 16 4.2 RADIATED EMISSION MEASUREMENT 18 4.2.1 RADIATED EMISSION LIMITS 18 4.2.2 MEASUREMENT INSTRUMENTS LIST ANS SETTING 19 4.2.3 TEST PROCEDURE 20 4.2.4 DEVIATION FROM TEST STANDARD 20 4.2.5 TEST SETUP 21 4.2.6 EUT OPERATING CONDITIONS 22 4.2.7 TEST RESULTS (BETWEEN30 – 1000 MHZ) 23 4.2.8 TEST RESULTS (ABOVE 1000 MHZ) 27 5 . NUMBER OF HOPPING CHANNEL 63 5.1 APPLIED PROCEDURES / LIMIT 63 5.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 63 5.1.2 TEST PROCEDURE 63 5.1.3 DEVIATION FROM STANDARD 63 5.1.4 TEST SETUP 63 5.1.5 EUT OPERATION CONDITIONS 63 5.1.6 TEST RESULTS 64 6 . AVERAGE TIME OF OCCUPANCY 66 Neutron Engineering Inc. Report No.: NEI-FICP-1-1209C052 Page 4 of 109 Table of Contents Page 6.1 APPLIED PROCEDURES / LIMIT 66 6.1.1 MEASUREMENT INSTRUMENTS LIST 66 6.1.2 TEST PROCEDURE 66 6.1.3 DEVIATION FROM STANDARD 66 6.1.4 TEST SETUP 67 6.1.5 EUT OPERATION CONDITIONS 67 6.1.6 TEST RESULTS 68 7 . HOPPING CHANNEL SEPARATION MEASUREMENT 80 7.1 APPLIED PROCEDURES / LIMIT 80 7.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 80 7.1.2 TEST PROCEDURE 80 7.1.3 DEVIATION FROM STANDARD 80 7.1.4 TEST SETUP 80 7.1.5 EUT OPERATION CONDITIONS 80 7.1.6 TEST RESULTS 81 8 . BANDWIDTH TEST 85 8.1 APPLIED PROCEDURES / LIMIT 85 8.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 85 8.1.2 TEST PROCEDURE 85 8.1.3 DEVIATION FROM STANDARD 85 8.1.4 TEST SETUP 85 8.1.5 EUT OPERATION CONDITIONS 85 8.1.6 TEST RESULTS 86 9 . PEAK OUTPUT POWER TEST 90 9.1 APPLIED PROCEDURES / LIMIT 90 9.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 90 9.1.2 TEST PROCEDURE 90 9.1.3 DEVIATION FROM STANDARD 90 9.1.4 TEST SETUP 90 9.1.5 EUT OPERATION CONDITIONS 90 9.1.6 TEST RESULTS 91 10 . ANTENNA CONDUCTED SPURIOUS EMISSION 95 10.1 APPLIED PROCEDURES / LIMIT 95 10.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 95 10.1.2 TEST PROCEDURE 95 10.1.3 DEVIATION FROM STANDARD 95 10.1.4 TEST SETUP 95 10.1.5 EUT OPERATION CONDITIONS 95 10.1.6 TEST RESULTS 96 Neutron Engineering Inc. Report No.: NEI-FICP-1-1209C052 Page 5 of 109 Table of Contents Page 11 . EUT TEST PHOTO 108 Neutron Engineering Inc. Report No.: NEI-FICP-1-1209C052 Page 6 of 109 1. CERTIFICATION Equipment : SoundBar Speaker Brand Name : PHILIPS Model Name : HTL2160/F7 Applicant : Philips Electronics Hong Kong Ltd. Date of Test : Sep. 07, 2012 ~ Sep. 28, 2012 Test Item : ENGINEERING SAMPLE Standards : FCC Part15, Subpart C(15.247) / ANSI C63.4 : 2009 FCC Public Notice DA 00-705, March 30, 2000. Canada RSS-210:2010 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FICP-1-1209C052) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 qu…

Text truncated - open the document above for the full version.

Neutron Engineering Inc. Report No.: NEI-FICP-1-1209C052 Page 108 of 109 11. EUT TEST PHOTO Conducted Measurement Photos Neutron Engineering Inc. Report No.: NEI-FICP-1-1209C052 Page 108 of 109 11. EUT TEST PHOTO Conducted Measurement Photos Neutron Engineering Inc. Report No.: NEI-FICP-1-1209C052 Page 109 of 109 Radiated Measurement Photos Neutron Engineering Inc. Report No.: NEI-FICP-1-1209C052 Page 109 of 109 Radiated Measurement Photos
