BOU-SB3700SoundRing Bluetooth speaker

After successful connection, start music play on the Bluetooth device. The music streaming may be interrupted by obstacles between the device and SB3700, such as walls, or other devices nearby that operate in the same frequency. If SB3700 is connected through Bluetooth and an MP3 link cable at the same time, music should play through Bluetooth. To play through the MP3 link cable , switch off Bluetooth on SB3700 by pressing the Bluetooth button for more than two seconds. The Bluetooth indicator is off. Charging ongoing: The white light flashes. Battery low: The red light flashes. Charge LadenMise en charge Pla y WiedergabeLecture Specifications Technische DatenCaractéristiques techniques Amplifier Rated output power : 4 X 4W RMS Signal to noise ratio: > 75 dB AUDIO-IN: 0.6 V RMS 22 kOhm Bluetooth Standard: Bluetooth Standard Ver sion 2.1 + EDR Fr equency band: 2.402 ~ 2.480 GHz ISM Band Range: 10 m (free space) General information AC power Input: 100-240 V~ 50/60 Hz, 1 A Output: 12 V DC, 3 A Built-in battery Rating: 2000 mAh, 7.4V Charging maximum 2100 mA for USB (power charging of mobile phones), 880 mA for power adapter (power charging of the speaker in the power-off mode) Dimensions Main Unit (W x H x D): 198 x 196 x 100 mm Weight Main Unit: 1.1 kg Starten Sie nach erfolgreicher Verbindungsherstellung die Musikwiedergabe auf dem Bluetooth-Gerät. Die Musikübertragung kann von Hindernissen zwischen dem Gerät und P9, z. B.einer Wand oder anderen nahegelegenen Geräten, die die gleiche Frequenz verwenden, beeinträchtigt werden. Une fois la connexion établie, lancez la lecture de la musique sur le périphérique Bluetooth. La diffusion de musique peut être interrompue par la présence d'obstacles entre le périphérique et l'enceinte P9, commedes murs, ou par d'autres appareils à proximité fonctionnant sur la même fréquence. EN DE FR EN DE FR EN When there is an incoming call, music play pauses. Press to answer the call. Press again to end the call. Music play resumes. During call waiting, press to switch between calls. To make a call, press twice to call the last dialed number on your phone. AUDIO-IN When music plays from the speaker through an MP3 link cable, increase the volume on the audio player if necessary. Wenn die Musik vom Lautsprecher über ein MP3 Link-Kabel wiedergegeben wird, erhöhen Sie ggf. die Lautstärke desAudio-Players. Lorsque la musique est diffusée depuis l'enceinte via un câble MP3 Link, augmentez le volume sur le périphérique audio, sinécessaire. 5V / 2.1A EN EN DE FR Bluetooth 2 sec 3

2EN 1 Important Safety This 'bolt of lightning' indicates uninsulated material within the device may cause an electrical shock. For the safety of everyone in your household, please do not remove the covering. The 'exclamation mark' calls attention to features for which you should read the enclosed literature closely to prevent operating and maintenance problems. WARNING: To reduce the risk of fire or electric shock, the device should not be exposed to rain or moisture and objects filled with liquids, such as vases, should not be placed on the device. CAUTION: To prevent electric shock, fully insert the plug. (For regions with polarized plugs: To prevent electric shock, match wide blade to wide slot.) Important Safety Instructions a Read these instructions. b Keep these instructions. c Heed all warnings. d Follow all instructions. 3EN e Do not use this apparatus near water. f Clean only with dry cloth. g Do not block any ventilation openings. Install in accordance with the manufacturer's instructions. h Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. i Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. j Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. k Only use attachments/accessories specified by the manufacturer. l Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. m Unplug this apparatus during lightning storms or when unused for long periods of time. n Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. o The batteries shall not be exposed to excessive heat such as sunshine, fire or the like. 4EN • Perchlorate Material - special handling may apply. See www.dtsc.ca.gov/ hazardouswaste/perchlorate. p Apparatus shall not be exposed to dripping or splashing. q Do not place any sources of danger on the apparatus (e.g. liquid filled objects, lighted candles). r Where the plug of the Direct Plug-in Adapter is used as the disconnect device, the disconnect device shall remain readily operable. s This product may contain lead and mercury. Disposal of these materials may be regulated due to environmental considerations. For disposal or recycling information, please contact your local authorities or the Electronic Industries Alliance: www.eiae.org. Compliance FCC Radiation Exposure Statement This equipment complies with FCC’s and IC’s RF radiation exposure limits set forth for an uncontrolled environment. The antenna(s) used for this transmitter must be installed and operated to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any 5EN other antenna or transmitter. Installers must ensure that 20cm separation distance will be maintained between the device (excluding its handset) and users. Notice for the USA This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Relocate the receiving antenna. • Increase the separation between equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. The set complies with the FCC-Rules, Part-15. Operation is subject to the following two conditions: • This device may not cause harmful interference, and • This device must accept any interference received, including interference that may cause undesired operation. Notice for Canada This Class B digital apparatus complies with Canadian ICES-003. This device complies with Industry Canada licence-exempt RSS standard(s): Operation is subject to the following Two conditions:(1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Note • The type plate is located on the bottom of the product. Any changes or modifications made to this product that are not expressly approved by Philips Consumer Lifestyle may void the user’s authority to operate the equipment. 6EN Care of the environment Environmental information All unnecessary packaging has been omitted. We have tried to make the packaging easy to separate into three materials: cardboard (box), polystyrene foam (buffer) and polyethylene (bags, protective foam sheet.) Your system consists of materials which can be recycled and reused if disassembled by a specia…

Text truncated - open the document above for the full version.

RF_160, Issue 02 Declaration of Authorization We Name: Philips Consumer Lifestyle Address: 5/F, Philips Electronics Building, 5 Science Park East Avenue, Hong Kong Science Park, City: Shatin, New Territories, Country: Hong Kong Declare that: Name Representative of agent: Ms. Cathy Wang Agent Company name: Neutron Engineering, Inc. Address: No.3 Jinshagang 1 st Road, Shixia, Dalang Town City: Dong Guan Country: China is authorized to apply for Certification of the following product(s): Product description: SoundRing Bluetooth speaker Model: SB3700/37 Trademark: PHILIPS on our behalf. Date: 2012-11-06 City: Shatin, New Territories, Name: Benson Lai Function: Lead Engineer, Safety & Compliance Signature: .

FCC, Request for non-disclosure Date: 10-AUG-09 RF_501, Issue 5 Page 1 of 1 Company Name: Philips Consumer Lifestyle Address: 5/F, Philips Electronics Building 5 Science Park East Avenue, Hong Kong Science Park City: Shatin, New Territories Country: Hong Kong To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: BOU-SB3700 Reference number: SB3700/37 Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, a pplicant hereby requests Short-Term Confidential treatment of the following materials (note 1): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: Planned Release Date STC: (notes 2, 3, 4, 5) Date: 2011-11-06 Name and signature of applicant: Benson Lai Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

Neutron Engineering Inc. Project No.: 1210C081 Page 2 of 22 Neutron Engineering Inc. Project No.: 1210C081 Page 3 of 22 Neutron Engineering Inc. Project No.: 1210C081 Page 4 of 22

Neutron Engineering Inc. Project No.: 1210C081 Page 5 of 22 Neutron Engineering Inc. Project No.: 1210C081 Page 6 of 22 Neutron Engineering Inc. Project No.: 1210C081 Page 7 of 22 Neutron Engineering Inc. Project No.: 1210C081 Page 8 of 22 Neutron Engineering Inc. Project No.: 1210C081 Page 9 of 22 Neutron Engineering Inc. Project No.: 1210C081 Page 10 of 22 Neutron Engineering Inc. Project No.: 1210C081 Page 11 of 22 Neutron Engineering Inc. Project No.: 1210C081 Page 12 of 22 Neutron Engineering Inc. Project No.: 1210C081 Page 13 of 22 Neutron Engineering Inc. Project No.: 1210C081 Page 14 of 22 Neutron Engineering Inc. Project No.: 1210C081 Page 15 of 22 Neutron Engineering Inc. Project No.: 1210C081 Page 16 of 22 Neutron Engineering Inc. Project No.: 1210C081 Page 17 of 22 Neutron Engineering Inc. Project No.: 1210C081 Page 18 of 22 Neutron Engineering Inc. Project No.: 1210C081 Page 19 of 22 Neutron Engineering Inc. Project No.: 1210C081 Page 20 of 22 Neutron Engineering Inc. Project No.: 1210C081 Page 21 of 22 Neutron Engineering Inc. Project No.: 1210C081 Page 22 of 22

Neutron Engineering Inc. FCC RF EXPOSURE REPORT FCC ID: BOU-SB3700 Project No. : 1210C081 Equipment : SoundRing Bluetooth speaker Model : SB3700/37 Applicant : Philips Consumer Lifestyle Address : 5/F, Philips Electronics Building,Shatin, New Territories, Hong Kong, China According: : FCC Guidelines for Human Exposure IEEE C95.1 Neutron Engineering Inc. No.3, Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. MPE CALCULATION METHOD: Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Ant. Brand name Model Name Antenna TypeConnector Gain (dBi) 1 N/A N/A PIFA Antenna N/A 2.12 TEST RESULTS EUT： SoundRing Bluetooth speaker Model Name ： SB3700/37 Temperature： 25 °C Relative Humidity： 60 % Pressure： 1012 hPa Test Voltage ： AC 120V/60Hz Test Mode ： CH00/CH39/CH78-1Mbps Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 2.12 1.6293 2.58 1.8113 0.000587421 Complies 2.12 1.6293 0.53 1.1298 0.000366401 Complies 2.12 1.6293 -1.58 0.6950 0.000225401 Complies EUT： SoundRing Bluetooth speaker Model Name ： SB3700/37 Temperature： 25 °C Relative Humidity： 60 % Pressure： 1012 hPa Test Voltage ： AC 120V/60Hz Test Mode ： CH00/CH39/CH78-3Mbps Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 2.12 1.6293 1.86 1.5346 0.000497681 Complies 2.12 1.6293 -0.14 0.9683 0.000314011 Complies 2.12 1.6293 -2.33 0.5848 0.000189651 Complies

Neutron Engineering Inc. Report No.: NEI-FICP-1-1210C081 Page 1 of 108 FCC/IC Radio Test Report FCC ID: BOU-SB3700 IC: 135M-SB3700 This report concerns (check one) : Original Grant Class II Change Issued Date : Nov. 02, 2012 Project No. : 1210C081 Equipment : SoundRing Bluetooth speaker Model Name : SB3700/37 Applicant : Philips Consumer Lifestyle Address : 5/F, Philips Electronics Building, 5 Science Park East Avenue, Hong Kong Science Park, Shatin, New Territories, Hong Kong Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Oct. 15, 2012 Date of Test: Oct. 15, 2012 ~ Nov. 01, 2012 Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory : (Steven Lu) Neutron Engineering Inc. No.3,Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. Report No.: NEI-FICP-1-1210C081 Page 2 of 108 Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of CHINA, or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutronshall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FICP-1-1210C081 Page 3 of 108 Table of Contents Page 1 . CERTIFICATION 5 2 . SUMMARY OF TEST RESULTS 6 2.1 TEST FACILITY 7 2.2 MEASUREMENT UNCERTAINTY 7 3 . GENERAL INFORMATION 8 3.1 GENERAL DESCRIPTION OF EUT 8 3.2 DESCRIPTION OF TEST MODES 10 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 10 3.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 3.5 DESCRIPTION OF SUPPORT UNITS 12 4 . EMC EMISSION TEST 13 4.1 CONDUCTED EMISSION MEASUREMENT 13 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 4.1.2 MEASUREMENT INSTRUMENTS LIST AND SETTING 13 4.1.3 TEST PROCEDURE 14 4.1.4 DEVIATION FROM TEST STANDARD 14 4.1.5 TEST SETUP 14 4.1.6 EUT OPERATING CONDITIONS 14 4.1.7 TEST RESULTS 15 4.2 RADIATED EMISSION MEASUREMENT 17 4.2.1 RADIATED EMISSION LIMITS 17 4.2.2 MEASUREMENT INSTRUMENTS LIST ANS SETTING 18 4.2.3 TEST PROCEDURE 19 4.2.4 DEVIATION FROM TEST STANDARD 19 4.2.5 TEST SETUP 20 4.2.6 EUT OPERATING CONDITIONS 21 4.2.7 TEST RESULTS (BETWEEN30 – 1000 MHZ) 22 4.2.8 TEST RESULTS (ABOVE 1000 MHZ) 26 5 . NUMBER OF HOPPING CHANNEL 62 5.1 APPLIED PROCEDURES / LIMIT 62 5.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 62 5.1.2 TEST PROCEDURE 62 5.1.3 DEVIATION FROM STANDARD 62 5.1.4 TEST SETUP 62 5.1.5 EUT OPERATION CONDITIONS 62 5.1.6 TEST RESULTS 63 6 . AVERAGE TIME OF OCCUPANCY 65 Neutron Engineering Inc. Report No.: NEI-FICP-1-1210C081 Page 4 of 108 Table of Contents Page 6.1 APPLIED PROCEDURES / LIMIT 65 6.1.1 MEASUREMENT INSTRUMENTS LIST 65 6.1.2 TEST PROCEDURE 65 6.1.3 DEVIATION FROM STANDARD 65 6.1.4 TEST SETUP 66 6.1.5 EUT OPERATION CONDITIONS 66 6.1.6 TEST RESULTS 67 7 . HOPPING CHANNEL SEPARATION MEASUREMENT 79 7.1 APPLIED PROCEDURES / LIMIT 79 7.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 79 7.1.2 TEST PROCEDURE 79 7.1.3 DEVIATION FROM STANDARD 79 7.1.4 TEST SETUP 79 7.1.5 EUT OPERATION CONDITIONS 79 7.1.6 TEST RESULTS 80 8 . BANDWIDTH TEST 84 8.1 APPLIED PROCEDURES / LIMIT 84 8.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 84 8.1.2 TEST PROCEDURE 84 8.1.3 DEVIATION FROM STANDARD 84 8.1.4 TEST SETUP 84 8.1.5 EUT OPERATION CONDITIONS 84 8.1.6 TEST RESULTS 85 9 . PEAK OUTPUT POWER TEST 89 9.1 APPLIED PROCEDURES / LIMIT 89 9.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 89 9.1.2 TEST PROCEDURE 89 9.1.3 DEVIATION FROM STANDARD 89 9.1.4 TEST SETUP 89 9.1.5 EUT OPERATION CONDITIONS 89 9.1.6 TEST RESULTS 90 10 . ANTENNA CONDUCTED SPURIOUS EMISSION 94 10.1 APPLIED PROCEDURES / LIMIT 94 10.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 94 10.1.2 TEST PROCEDURE 94 10.1.3 DEVIATION FROM STANDARD 94 10.1.4 TEST SETUP 94 10.1.5 EUT OPERATION CONDITIONS 94 10.1.6 TEST RESULTS 95 11 . EUT TEST PHOTO 107 Neutron Engineering Inc. Report No.: NEI-FICP-1-1210C081 Page 5 of 108 1. CERTIFICATION Equipment : SoundRing Bluetooth speaker Brand Name : PHILIPS Model Name : SB3700/37 Applicant : Philips Consumer Lifestyle Factory : 1. Eastech Electronics ( Hui Yang ) Co. Limited. 2. Philips Ltd. Assembly Centre Hungary Address : 1. Dong Feng District Xinxu, Hui Yang, Guangdong, P.R.China 2. Szekesfehervar Holland fasor 6. H-8000 Hungary Date of Test : Oct. 15, 2012 ~ Nov. 01, 2012 Test Item : ENGINEERING SAMPLE Standards : FCC Part15, Subpart C(15.247) / ANSI C63.4 : 2009 FCC Public Notice DA 00-705, March 30, 2000. Canada RSS-210:2010 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FICP-1-1210C081) were obtained utilizing the test …

Text truncated - open the document above for the full version.

Neutron Engineering Inc. Report No.: NEI-FICP-1-1210C081 Page 107 of 108 11. EUT TEST PHOTO Conducted Measurement Photos Neutron Engineering Inc. Report No.: NEI-FICP-1-1210C081 Page 108 of 108 Radiated Measurement Photos
