August 23, 2001 Federal Communications Commission Equipment Authorization Division 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: We made a mistake and forgot to mark one of the files uploaded as confidential. Please add confidentiality to the block diagram uploaded If you have any questions, please feel free to contact me at (770)741-0717. Sincerely, Timothy R. Johnson

FCC ID: BQI01DR-10000 PHOTOS OF THE TESTED EUT The following photos are attached: Photo 1. EUT, Front View Photo 2. EUT, Rear View Photo 3. EUT, Top View, Cover Opened Photo 4. EUT, Top View, Cover Opened, Transceivers Removed Photo 5. EUT, Bottom View, Cover Opened Photo 6. EUT, Transceiver Module, Top View Photo 7. EUT, Transceiver Module, Bottom View Photo 8. EUT, Internal View of Shield Cover Photo 9. EUT, Top View of Transceiver Board Photo 10. EUT, Bottom View of Transceiver Board Photo 11. Patch Antenna, Top View Photo 12. Patch Antenna, Bottom View Photo 13. Whip Antenna FCC ID: BQI01DR-10000 Photo 1. EUT, Front View FCC ID: BQI01DR-10000 Photo 2. EUT, Rear View FCC ID: BQI01DR-10000 Photo 11. Patch Antenna, Top View FCC ID: BQI01DR-10000 Photo 12. Patch Antenna, Bottom View FCC ID: BQI01DR-10000 Photo 13. Whip Antenna

FCC ID: BQI01DR-10000

FCC ID: BQI01DR-10000 Photo 3. EUT, Top View, Cover Opened FCC ID: BQI01DR-10000 Photo 4. EUT, Top View, Cover Opened, Transceivers Removed FCC ID: BQI01DR-10000 Photo 5. EUT, Bottom View, Cover Opened FCC ID: BQI01DR-10000 Photo 6. EUT, Transceiver Module, Top View FCC ID: BQI01DR-10000 Photo 7. EUT, Transceiver Module, Bottom View FCC ID: BQI01DR-10000 Photo 8. EUT, Internal View of Shield Cover FCC ID: BQI01DR-10000 Photo 9. EUT, Top View of Transceiver Board FCC ID: BQI01DR-10000 Photo 10. EUT, Bottom View of Transceiver Board

FCC ID: BQI01DR-10000 SECTION 7 RF EXPOSURE INFO FCC ID: BQI01DR-10000 7.0 RF Safety Requirements to 2.1091/95.1125 for Mobile Transmitters Part 95 transmitters are considered categorically excluded from routine environmental evaluation as given in 47 CFR 2.1091. However, the following information is presented to prove compliance with the limits. Power Output The EUT’s maximum output power as measured directly from the transmitter module is +12.0 dBm (15.8 mW). The EUT may utilize 2 different types of antenna’s (patch @ + 2 dBi, monopole @ 0 dBi). Frequency of Fundamental (MHz) Measurement (Watt)* Antenna Gain (dBi) P ERP (Watt) 608.6656- 612.898133 0.01582.00.0251 Source Based Time Averaging Source Time Averaging has not been evaluated regarding this product. MPE Calculations The limits for this unit (uncontrolled exposure) are 0.4 mW/cm 2 . Taking the RF Density Field Equation: S = (EIRP in mW)/(4πR 2 ) and solving for Distance R R = SQRT (EIRP in mW)/(S4π) Solving the above equation yields R (cm) = SQRT (25.1(mw))/(0.4(mW/cm 2 )*4*π) = 5.0 cm Since the EUT is designed only for mobile applications (where the expected separation distance between antenna and humans is greater than 20 cm), all manual instructions have specified 20 cm as the minimum exposure distance.

VitalCom, Inc. FCC Part 95 Application Model DR-10000 August 13, 2001 FCC ID: BQI01DR-10000 MEASUREMENT/TECHNICAL REPORT COMPANY NAME:VitalCom, Inc. MODEL:DR-10000 FCC ID:BQI01DR-10000 DATE:August 13, 2001 This report concerns (check one): Original grant X Class II change ____ Equipment type: Low Power Transmitter (for Biomedical Applications) Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? yes_____ No X If yes, defer until:_________________ date N.A. agrees to notify the Commission by N.A. date of the intended date of announcement of the product so that the grant can be issued on that date. Report prepared by: United States Technologies, Inc. 3505 Francis Circle Alpharetta, GA 30004 Phone Number: (770) 740-0717 Fax Number: (770) 740-1508 FCC ID: BQI01DR-10000 TABLE OF CONTENTS AGENCY AGREEMENT LETTER OF CONFIDENTIALITY SECTION 1 GENERAL INFORMATION Product Description SECTION 2 TESTS AND MEASUREMENTS Configuration of Tested Test Facility Modifications Test Equipment Modifications Antenna Description Field Strength of Fundamental Field Strength of Spurious Emissions Radiated Digital Device Emissions Power Line Conducted Emissions for Digital Device, Transmitter, and Receiver Emissions Type Frequency Stability SECTION 3 LABELING INFORMATION SECTION 4 BLOCK DIAGRAM(S)/SCHEMATICS SECTION 5 THEORY OF OPERATION SECTION 6 PHOTOGRAPHS SECTION 7 RF EXPOSURE INFORMATION SECTION 8 USER'S MANUAL FCC ID: BQI01DR-10000 LIST OF FIGURES AND TABLES FIGURES Test Configuration Photograph(s) for Fundamental, Spurious, and Digital Device Emissions Photograph(s) for Conducted Emissions Field Strength of Fundamental Emission Field Strength of Spurious Emissions TABLES EUT and Peripherals Test Instruments Field Strength of Fundamental Emission Field Strength of Spurious Emissions Radiated Digital Device Emissions Power Line Conducted Emissions for Digital Device, Transmitter, and Receiver FCC ID: BQI01DR-10000 SECTION 1 GENERAL INFORMATION FCC ID: BQI01DR-10000 GENERAL INFORMATION Product Description The Equipment Under Test (EUT) is a VitalCom, Inc., DR-10000. The DR-10000 is a wireless Access Point (AP) designed for use in medical monitoring applications. The DR- 10000 receives patient monitoring data from similar radios (FCC ID: BQI00DT-4500) attached to the patients in that hospital. The DR-10000 is linked to other DR-10000's through a 10Base-T Ethernet backbone. This backbone allows the AP's to pass patient data back to the end user of the system - a nurses monitoring station. The DR-10000 is composed of two 608-614 MHz wireless transceivers and Ethernet conversion circuitry that passes data from these transceivers to the Ethernet backbone. The DR-10000 may operate with two different types of antennas: a 0 dBi monopole to provide omni-directional coverage and a +2 dBi patch antenna to provide unidirectional coverage. The unit requires external DC power but has its own internal voltage regulation. The DR-10000 is self contained in a plastic package and is designed to be installed on the ceiling of a hospital hallway. The EUT has been previously approved under FCC ID: BQI00DR-10000 by the FCC on 9/8/00 (original certification) and 12/28/00 (permissive change). For the permissive change application, the transmitter modules were modified as follows: 1) The SAW RF bandpass filter (reference designator F5 in the transmit chain has been replaced by a third order, top capacitively coupled LC filter. This change will result in increased yield. 2) The power amplifier transistor, HBFP450 (reference designator Q3) in the transmit chain has been replaced by transistor BFP450. The replacement transistor is the functional and performance equivalent of the original transistor. The change is in place to allow alternate supply to facilitate planning. Since only a portion of the tests needed to be performed for the permissive change application, this application includes data from the both the original submittal and the permissive change application. FCC ID: BQI01DR-10000 Related Submittal(s)/Grant(s) The EUT has been previously approved under FCC ID: BQI00DR-10000 on September 8, 2000 under Part 15.242 and with a permissive change on December 28, 2000. The EUT is being resubmitted under FCC ID: BQI01DR-10000 to new requirements specified in Part 95 of the rules. Additionally, the EUT will be used with other transceivers (already submitted and approved under FCC ID: BQIOODT-4500). FCC ID: BQI01DR-10000 SECTION 2 TESTS AND MEASUREMENTS FCC ID: BQI01DR-10000 TESTS AND MEASUREMENTS Configuration of Tested System The sample was tested per ANSI C63.4, Methods of Measurement from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz (1992). Conducted and radiated emissions data were taken with the test receiver or spectrum analyzer's resolution bandwidth adjusted to 9 kHz and 120 kHz, respectively. All measurements are peak unless stated otherwise. The video filter associated with the spectrum analyzer was off throughout the evaluation process. Interconnecting cables were manipulated as necessary to maximize emissions. A block diagram of the tested system is shown in Figure 1. Test configuration photographs for spurious and fundamental emissions are shown in Figure 2. Test Facility Testing was performed at US Tech's measurement facility at 3505 Francis Circle, Alpharetta, GA. This site has been fully described and submitted to the FCC, and accepted in their letter marked 31040/SIT. Additionally this site has also been fully described and submitted to Industry Canada (IC), and has been approved under file number IC2982. Modifications No modifications were made by US Tech, to bring the EUT into compliance with FCC Part 95 limits for the transmitter portion of the EUT or the Class A Digital Device Requirements. Test Equipment Table 2 describes test equipment used to evaluate this product. FCC ID: BQI01DR-10000 FIGURE 1 TEST CONFIGURATION Transceiver (EUT) Monitor Computer Keyboard Mouse AC Adapter Patc…

Text truncated - open the document above for the full version.

FCC ID: BQI01DR-10000 Field Strength Of Spurious Emissions (47 CFR 95.1115(b)) Measurements were made using a peak detector. Field strength of Spurious Emissions are shown in Tables 4a through 4b and Figures 3a through 3b. For comparison to the average limits, duty cycle corrections were made as shown below. Both Radios were checked (one radio with patch antennas and the other with monopoles). The results from each radio were similar, but preliminary data showed that the Radio with the monopole antennas to be worse case. Therefore all results shown are for the radio configured with the monopole antennas (for a low and high channel). Duty Cycle Correction During 100 msec: The system is designed that the system hops at 35 msec per channel. The system will only be on one channel in any 100 msec period of time. During this 35 msec per channel, each transmitter is allotted only a small duration of this period (5 msec max). Therefore the worse case duty cycle is: Duty Cycle Correction = 20 log (0.05) = -26.0 dB FCC ID: BQI01DR-10000 TABLE 4a FIELD STRENGTH OF SPURIOUS EMISSIONS Test Date:October 3, 2000 UST Project:01-0406 Customer:VitalCom, Inc. Model:DR-10000 Peak Measurements (Low Channel) FREQ. (MHz.) TEST DATA (dBm) @ 1m ANTENNA FACTOR + CABLE ATTENUATION RESULTS (uV/m) @ 3m PEAK FCC LIMITS (uV/m) @ 3m 1.215-69.6 28.7 672.95000 Peak Measurements (High Channel) FREQ. (MHz.) TEST DATA (dBm) @ 1m ANTENNA FACTOR + CABLE ATTENUATION RESULTS (uV/m) @ 3m PEAK FCC LIMITS (uV/m) @ 3m 1.226-70.2 28.7 628.15000 * - To achieve better dynamic range, all measurements were made a 1 meter SAMPLE CALCULATIONS: RESULTS uV/m @ 3m = Antilog ((-69.6 – 9.54 + 28.7 + 107)/20) = 672.9 CONVERSION FROM dBm TO dBuV = 107 dB CONVERSION FROM 1m TO 3m = 20 log (1/3) = -9.54 dB Test Results Reviewed By: Name: Tim R. Johnson FCC ID: BQI01DR-10000 TABLE 4b FIELD STRENGTH OF SPURIOUS EMISSIONS Test Date:October 3, 2000 UST Project:01-0406 Customer:VitalCom, Inc. Model:DR-10000 Average Measurements (Low Channel) FREQ. (MHz.) TEST DATA (dBm) @ 1m ANTENNA FACTOR + CABLE ATTENUATION RESULTS (uV/m) @ 3m AVERAGE FCC LIMITS (uV/m) @ 3m 1.215-95.6 28.7 33.7500 Average Measurements (High Channel) FREQ. (MHz.) TEST DATA (dBm) @ 1m ANTENNA FACTOR + CABLE ATTENUATION RESULTS (uV/m) @ 3m AVERAGE FCC LIMITS (uV/m) @ 3m 1.226-96.2 28.7 31.5500 * - To achieve better dynamic range, all measurements were made a 1 meter ** - Readings adjusted by duty cycle = 20 log (0.05) = -26.0 dB SAMPLE CALCULATIONS: RESULTS uV/m @ 3m = Antilog ((-95.6 – 9.54 + 28.7 + 107)/20) = 33.7 CONVERSION FROM dBm TO dBuV = 107 dB Test Results Reviewed By: Name: Tim R. Johnson FCC ID: BQI01DR-10000 FIGURE 3a SPURIOUS EMISSIONS 15.242(c) FCC ID: BQI01DR-10000 FIGURE 3b SPURIOUS EMISSIONS 15.242(c) FCC ID: BQI01DR-10000 Radiated Digital Device Emissions (47 CFR 15.109a) Radiated emissions were evaluated from 30 MHz to 6.5 GHz with the EUT set to a receive mode of operation. Measurements were made with the analyzer's bandwidth set to 120 kHz for measurements below 1 GHz and 1 MHz for measurements above greater than or equal to 1 GHz. Results of these emissions are shown in Tables 5a and 5b. FCC ID: BQI01DR-10000 TABLE 5a CLASS A RADIATED EMISSIONS Test Date:June 17, 2000 UST Project:01-0406 Customer:VitalCom, Inc. Model:DR-10000 Measurements 30 MHz – 1 GHz FREQ. (MHz) TEST DATA (dBm) @ 10m ANTENNA FACTOR + CABLE ATTEN. RESULTS (uV/m) @ 10m LIMITS (uV/m) @ 10m MARGIN BELOW LIMIT (dB) 240.0-84.114.776.0210.08.8 400.0-85.9*19.6108.4210.05.7 420.0-85.9*20.3117.8210.05.0 440.0-84.8*20.9142.2210.03.4 450.0-89.3*21.1 87.1210.07.6 520.0-89.3*23.0108.4210.05.7 540.0-88.423.2122.7210.04.7 * = Quasi-Peak Measurement SAMPLE CALCULATIONS: RESULTS uV/m @ 10m = Antilog ((-84.1 + 14.7 + 107)/20) = 76.0 CONVERSION FROM dBm TO dBuV = 107 dB Test Results Reviewed By: Name: Tim R. Johnson FCC ID: BQI01DR-10000 TABLE 5b CLASS A RADIATED EMISSIONS Test Date:October 3, 2000 UST Project:01-0406 Customer:VitalCom, Inc. Model:DR-10000 Peak Measurements >1 GHz FREQ. (GHz) TEST DATA (dBm) @ 3m AMP GAIN (dB) ANT. FACTOR (dB) CABLE LOSS (dB) RESULTS (uV/m) @ 10m FCC LIMITS (uV/m) @ 10m MARGIN BELOW LIMIT (dB) 1.000-47.835.925.22.3111.4300.08.6 1.064-55.835.825.72.444.8300.016.7 1.620-53.735.227.53.181.7300.011.3 3.248-55.934.832.14.7135.5300.06.9 SAMPLE CALCULATIONS: RESULTS uV/m @ 10m = Antilog ((-47.8 - 35.9 + 25.2 + 2.3 -10.46 + 107)/20) = 111.4 CONVERSION FROM dBm TO dBuV = 107 dB CONVERSION FROM 3m to 10m = -10.46 Test Results Reviewed By Signature: Name: Tim R. Johnson FCC ID: BQI01DR-10000 Power Line Conducted Emissions for Digital Device, Transmitter, and Receiver (FCC Section 15.107) The conducted voltage measurements have been carried out in accordance with FCC Section 15.107, with a spectrum analyzer connected to a LISN and the EUT placed into an idle condition or a continuous mode of receive. The results are given in Table 6. FCC ID: BQI01DR-10000 TABLE 6 CONDUCTED EMISSIONS DATA CLASS B Test Date:October 8, 2000 UST Project:01-0406 Customer:VitalCom, Inc. Model:DR-10000 FREQ. (MHz) TEST DATA (dBm) PHASE NEUTRAL RESULTS (uV) PHASE NEUTRAL FCC LIMITS (uV) MARGIN BELOW LIMIT (dB) PHASE MARGIN BELOW LIMIT (dB) NEUTRAL 0.72-71.8-69.657.574.1250.012.810.6 4.1-67.1-70.898.964.6250.08.111.8 6.3-69.7-69.073.379.4250.010.710.0 15.6-67.6-71.493.360.3250.08.612.4 26.6-63.9-68.9142.980.4250.04.99.9 26.8-65.0-68.4125.985.1250.06.09.4 SAMPLE CALCULATIONS: RESULTS uV = Antilog ((-71.8 + 107)/20) = 57.5 CONVERSION FROM dBm TO dBuV = 107 dB Tested Results Reviewed By Signature: Name: Tim R. Johnson FCC ID: BQI01DR-10000 Emissions Type (47 CFR Section 95.631(i), 95.1115(c), and 95.1117) A wireless medical telemetry device may transmit any emission type appropriate for communications in this service, except for video and voice. Waveforms such as electrocardiograms (ECG’s) are not considered video. Basic Description of Transmitter Emissions The EUT utilizes spread spectrum (frequency hopping) type technol…

Text truncated - open the document above for the full version.

FCC ID: BQI01DR-10000 FIGURE 2a Photograph(s) for Fundamental, Spurious and Digital Devices Emissions FCC ID: BQI01DR-10000 FIGURE 2b Photograph(s) for Fundamental, Spurious and Digital Devices Emissions FCC ID: BQI01DR-10000 FIGURE 2c Photograph(s) for Conducted Emissions
