OPERATIONAL DESCRIPTION The device is a tablet pc; it supports wifi and lots of additional entertainment functions like Camera, Image Viewer, Video Player, and Audio Player. The device is able to connect to PC for data transfer through its USB port The device designated with the following general information and technical specification as following: The General Information of the Device FCC ID BRCPC1011 Model Name PC1011, PC1011B, PC1011ME,PC10XX(XX represents00~99), PC10XXB(XX represents00~99),PC10XXME(XX represents00~99) KW-PC1011T,KW-PC1011,KW-PC10XXT(XX represents00~99), KW-PC10XX(XX represents00~99) Brand Name Kinwei/Titan Hard ware Version N/A Soft ware Version N/A Main Chipset A33 OSC 24MHz, 40MHz, 32.768KHz Power Supply DC3.7V by Built-in Li-ion Battery The Basic Technical Specification for WIFI Frequency Band 2412 MHz to 2462 MHz Main Chipset RTL8188 Channels 11(max) Max. Output Power IEEE 802.11b:11.83dBm; IEEE 802.11g:9.87dBm; IEEE 802.11n(20):8.93dBm; IEEE 802.11n(40):6.12dBm Modulation DSSS(BPSK/QPSK/CCK);OFDM(16-QAM/64-QAM) Antenna Gain 0dBi Hot Spot mode Y N/A

RF Exposure (FCC ID: BRCPC1011) Applicable Standard According to §1.1307(b)(5), systems operating under the provisions of this section shall be operated in a manner that ensure that the public is not exposed to radio frequency energy level in excess of the Commission’s guideline. This is a Portable device. KDB447498 D01 V05 was used as the guidance. Maximum measured transmitter Conducted Power: 802.11b Maximum Peak Conducted Power (dBm) Maximum Conducted Power （AV）(dBm) Maximum Conducted Power (mW) 11.83 9.56 9.04 Maximum measured transmitter Conducted Power: 802.11g Maximum Peak Conducted Power (dBm) Maximum Conducted Power （AV）(dBm) Maximum Conducted Power (mW) 9.87 7.34 5.42 Maximum measured transmitter Conducted Power: 802.11n HT20 Maximum Peak Conducted Power (dBm) Maximum Conducted Power （AV）(dBm) Maximum Conducted Power (mW) 8.93 6.53 4.50 Maximum measured transmitter Conducted Power: 802.11n HT40 Maximum Peak Conducted Power (dBm) Maximum Conducted Power （AV）(dBm) Maximum Conducted Power (mW)) 6.12 3.82 2.41 Refer to 447498 25 D01 General RF Exposure Guidance v05 Appendix A, you see that for Maximum Conducted Output Power 9.04mW (<10mW), so no SAR is required. •
