BRCPC1015Tablet PC

Kintech Co. Ltd

Click to zoom

Application Details

Equipment Class: JBP - Part 15 Class B Computing Device Peripheral
Date of Grant: Mar 25, 2015
Application Purpose: Original Equipment
Date of Application: Mar 25, 2015
Equipment Note: Tablet PC
Company: Kintech Co. Ltd
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

TABLET PC1015 USER MANUAL (English) Content 1. Preface 2. Safety Notices 3. Ready to Use 3.1 Packing List 3.2 Product Appearance 3.3 Instructions on Keys 3.4 Features Overview 4. Quick guides 4.1 Switch on/off 4.2 Battery management and charging 4.3 Operation of the Function Icons 5. Operation details 5.1.1 Music 5.1.2 Video 5.1.3 Picture 5.1.4 Sound Recorder 5.1.5 File Manager 5.1.6 IE browser 5.1.7 Calculator 5.1.8 Clock 5.1.9 Camera 5.2.0 TF (Micro SD) Card Storage 5.2.2 External Mouse and Keyboard 6. System setting 6.1.1 Wi-Fi Setting 6.1.2 External 3G USB Dongle function 6.1.3 External RJ45 USB Dongle function 6.1.4 Sound 6.1.5 Display wallpaper Settings 6.1.6 Storage 6.1.7Battery 6.1.8Apps 6.1.9Location & security services 6.2.0Language & input 6.2.1Backup & reset 6.2.2 Date & time 6.2.3 Accessibility 6.2.4 Developer options 6.2.5 about Tablet 6.3 Add, Move or Delete Desktop Icon 7. Movil Teacher (Optional) 8. Firmware upgrade 9. Troubleshooting and FAQ 1. Preface Dear Customers, Thanks very much for purchasing our product! This Tablet PC is a built-in high performance Wi-Fi receiver module, supporting an external 3G USB-DONGLE wireless network card, using broadband wireless networks, breaking through the restraint of network cables; it will bring you into the portable media player world and fulfill your entertainment needs. It also supports picture browsing, e-book reading, games, online chat and other functions; various settings will fully show your individuality. To operate this player easily, first, please read this User Manual included with the player. Then you will have a better understanding of the operations. Before operating this player, please carefully read all data we provide about the player, so that you will have a better understanding of the product and its operations. The Company will not be responsible for any loss of personal data and damage caused by incorrect operation of the Software/Hardware, artificial damages, replacement of batteries or any other accident. To avoid loss of your data, please backup your data to your computer at all times. Also, since we cannot control any dispute from users’ misunderstanding or incorrect operation against the manual, the Company will not take any relevant responsibility for any accidental loss potentially occurring in the process of using this manual. Due to constant product development, the information in this manual is subject to change without any prior notice. This manual is protected by copyright and no part is permitted to be copied or reproduced in any way without prior written permission of the Company. The Company reserves the final explanation right of this manual, warranty as well as its related information. (Note: When compiling this manual, we are very careful to provide you completely reliable information. However, there is inevitably some error and oversight, please understand, and we welcome your suggestions. If any problem occurs during your use of this product, please immediately contact your local seller) Thanks for your support and please pay attention to our other products. 2. Safety Notices 1) Please keep the Tablet PC away from strong magnetic fields in order to avoid damage to the product. 2) Please do not let the Tablet PC fall onto, rub against or knock against hard objects during use, because this may cause surface scratches on the Tablet PC, battery damage, data loss or other damage to the hardware with the result that it can’t start up. 3) Never let this product be exposed to a humid environment or rain as the water leaking into the Tablet PC could disable it to the extent of being beyond repair. 4) Never clean the Tablet PC with any chemicals or detergent, these will damage the product surface and corrode the finish. 5) You are recommended not to use the headset with the volume at its highest settings, please adjust the volume to an appropriate safe level and limit the amount of time you spend using headphones to avoid possible damage to your hearing. Excessive volume will cause permanent hearing damage. 6) Please do not cut off the power abruptly during software updates or downloading, because this may cause data loss or system errors. 7) Over-voltage, power cable strain and bending or squeezing of the power cable by heavy objects must be avoided to prevent the possibility of overheating or fire. 8) In order to eliminate the risk of electric shock, do not touch the cable power plug with wet hands. 9) Some movies, music and pictures are under the protection of copyright, unauthorized usage is deemed as an infringement to the laws of copyright. 10) Please don’t turn on the Tablet PC on in locations where wireless equipment is forbidden or when the usage of the Tablet PC will cause interference and possible danger. 11) All the wireless equipment is subject to external interference and this can affect its performance. 12) Please comply with any related restrictions and rules, wireless equipment can influence the flight of the plane; please consult the relevant airline company if you intend to use the Tablet PC on a plane. You must be very careful when using electronic equipment in flight. 13) Please don’t use the Tablet PC in a petrol station, or near to fuel or chemicals. 14) Please comply with any related restrictions and rules; do not use the Tablet PC where blasting operations are in progress. 15) Only qualified maintenance personnel can install or repair the Tablet PC. 16) Please use the original accessories and battery provided with the Tablet PC, do not use the incompatible products. 17) The Tablet PC is not waterproof, please keep it dry. 18) For the sake of data safety, please back up any important information stored in MID or keep a handwritten record. 19) When the Tablet PC is connecting with other devices, please read the user manual for detailed safety instructions. Don’t connect the Tablet PC to incompatible products. 20) Please upgrade device with enclosed optical disk when the pract…

Text truncated - open the document above for the full version.
