1 Contents 1. Preface 2. Safety Notices 3. Ready to Use 3.1 Packing List 3.2 Product Appearance 3.3 Instructions on Keys 3.4 Features Overview 3.5 Technical Specifications 4. Quick Guides 4.1 Switch On/Off 4.2 Battery Management and Charging 4.3 Operation of the Function Icons 4.4 WIFI Settings 4.5 USB-HOST and Extended Function 4.5.1 External USB Function 4.5.2 External 3G USB Dongle Function 4.5.3 External RJ45 USB Dongle Function 4.6 Camera Function 4.7 High Definition Function 4.8 tf (Micro sd) Card Storage 4.9 APK Install and Manage 5. Operation Details 5.1 Desktop System 1(Multimedia) 5.1.1 Audio Player 5.1.2 Video Player 5.1.3 Photo Browser 5.1.4 Sound Recorder 5.1.5 Explorer 5.2 Desktop System 2 (E-book) 5.2.1 Local E-book Reader 5.2.2 Online E-book Reader 5.3 Desktop System 3 (Network Function) 5.3.1 Web Brower 5.3.2 Email 5.4 Desktop System 4 (Games) 5.5 Desktop System 5 (Other Functions) 5.5.1 Calculator 5.5.2 Clock 5.5.3 APK Installer 2 5.5.4 Settings 5.5.4.1 Wireless and network 5.5.4.2 Sound 5.5.4.3 Display 5.5.4.4 High Definition 5.5.4.5 Location and security 5.5.4.6 Application 5.5.4.7 Accounts and sync 5.5.4.8 Privacy 5.5.4.9 Storage 5.5.4.10 Language and keyboard 5.5.4.11 Voice input and output 5.5.4.12 Date and time 5.5.4.13 About MID 5.6 Desktop Function Icon and Setting 5.6.1 Desktop Function Icon 5.6.2 Desktop Notification 5.6.3 Add, Move, or Delete Desktop Icon 6. Firmware Update 7. Troubleshooting 1. Preface Dear Customers, Thanks very much for purchasing our product! This device is a built-in high performance Wifi receiver module, supporting an external 3G USB-DONGLE wireless network card, using broadband wireless networks, breaking through the restraint of network cables; it will bring you into the portable media player world and fulfill your entertainment needs. It also supports picture browsing, e-book reading, games, online chat and other functions; various settings will fully show your individuality. To operate this player easily, first, please read this User Manual included with the player. Then you will have a better understanding of the operations. Before operating this player, please carefully read all data we provide about the player, so that you will have a better understanding of the product and its operations. The Company will not be responsible for any loss of personal data and damage caused by incorrect operation of the Software/Hardware, artificial damages, replacement of batteries or 3 any other accident. To avoid loss of your data, please backup your data to your computer at all times. Also, since we can not control any dispute from users’ misunderstanding or incorrect operation against the manual, the Company will not take any relevant responsibility for any accidental loss potentially occurring in the process of using this manual. Due to constant product development, the information in this manual is subject to change without any prior notice. This manual is protected by copyright and no part is permitted to be copied or reproduced in any way without prior written permission of the Company. The Company reserves the final explanation right of this manual, warranty as well as its related information. (Note: When compiling this manual, we are very careful to provide you completely reliable information. However, there is inevitably some error and oversight, please understand, and we welcome your suggestions. If any problem occurs during your use of this product, please immediately contact your local seller) Thanks for your support and please pay attention to our other products 2. Safety Notices 1) Please keep the device away from strong magnetic fields in order to avoid damage to the product. 2) Please do not let the device fall onto, rub against or knock against hard objects during use, because this may cause surface scratches on the device, battery damage, data loss or other damage to the hardware. 3) Never let this product be exposed to a humid environment or rain as the water leaking into the device could disable it to the extent of being beyond repair. 4) Never clean the device with any chemicals or detergent, these will damage the product surface and corrode the finish. 5) You are recommended not to use the headset with the volume at its highest settings, please adjust the volume to an appropriate safe level and limit the amount of time you spend using headphones to avoid possible damage to your hearing. Excessive volume will cause permanent hearing damage. 6) Please do not cut off the power abruptly during software updates 4 or downloading, because this may cause data loss or system errors. 7) Over-voltage, power cable strain and bending or squeezing of the power cable by heavy objects must be avoided to prevent the possibility of overheating or fire. 8) In order to eliminate the risk of electric shock, do not touch the cable power plug with wet hands. 9) Some movies, music and pictures are under the protection of copyright, unauthorized usage is deemed as an infringement to the laws of copyright. 10) Please don’t turn on the device on in locations where wireless equipment is forbidden or when the usage of the device will cause interference and possible danger. 11) All the wireless equipment is subject to external interference and this can affect its performance. 12) Please comply with any related restrictions and rules, wireless equipment can influence the flight of the plane; please consult the relevant airline company if you intend to use the device on a plane. 13) Please don’t use the device in a petrol station, or near to fuel or chemicals. 14) Please comply with any related restrictions and rules; do not use the device where blasting operations are in progress. 15) Only qualified maintenance personnel can install or repair the device. Opening the device in any way will invalidate the warranty. 16) Please use the original accessories and battery provided with the device, do not use the incompatible products. 17) The device is not water…

Text truncated - open the document above for the full version.

Attestation Statements

Kintech Co., Ltd. April 20, 2012 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD FCC ID: BRCPC7001A To Whom It May Concern: This letter is to ascertain that Kintech Co., Ltd. （Product：MID Model name: KW-PC70XXA） has been the units used for conducting FCC compliance testing, the DoC part will be tested by FCC recognized test lab. If you have any question or concerns, pls. contact us. Sincerely, Client’s signature : Client’s name / title : Zhi Quan/ Manager Contact information / address : 1F-5F, Bldg 22, Chen Tian Industrial Zone, Xi Xiang, Bao An District, Shenzhen, Guang Dong, China

Cover Letter(s)

Kintech Co., Ltd. April 20, 2012 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, ______ Kintech Co., Ltd. ___hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product Description: MID Model name: KW-PC70XXA We affirm that between SIEMIC and _ Kintech Co., Ltd. __, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature : Client’s name / title : Zhi Quan/ Manager Contact information / address : 1F-5F, Bldg 22, Chen Tian Industrial Zone, Xi Xiang, Bao An District, Shenzhen, Guang Dong, China

Cover Letter(s)

SCS-F19: Confidentiality Request Letter Page 1 of 1 Rev 2.0 Kintech Co., Ltd. April 20, 2012 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Confidentiality Request regarding application for certification of FCC ID: BRCPC7001A We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Operational Description - Schematic The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : Client’s name / title : Zhi Quan/ Manager Contact information / address : 1F-5F, Bldg 22, Chen Tian Industrial Zone, Xi Xiang, Bao An District, Shenzhen, Guang Dong, China

ID Label/Location Info

FCC Certification label Sample Applicant: Kintech Co., Ltd. Manufacturer: Kintech Co., Ltd./Kin Wei Technology(Shenzhen) Ltd. MODEL NO.: KW-PC70XXA FCC ID: BRCPC7001A This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, includin g interference that may cause undesired operation.

ID Label/Location Info

FCC ID LABER LOCATION:

Internal Photos

Antenna

RF Exposure Info

FCC ID : BRCPC7001A Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB 447498 (2)(a)(i) Frequency Range Low Frequency (MHz) High Frequency(MHz) Maximum measured transmitter power frequency (MHz) 60/f SAR Limitation (mw) 2412 2462 2412 24.9 Maximum measured transmitter power Conducted Power (mw) Max Antenna Gain (dBi) EIRP (mw) 12.45 0 12.45 Remark: The best case gain of the antenna is 0dBi. 0dBi logarithmic terms convert to numeric result is nearly 1 According to the formula. calculate the EIRP test result: EIRP= P x G = 12.45x 1 = 12.45 Threshold at which no SAR required is 24.9mw. Maximum Tx power is 12.45EIRP. Conclusion: No SAR is required. SIMULTANEOUS TRANSMISSION EVALUATION N/A
