BRFLT151AA15.1" LCD TV& Monitor

Part No.11906542 TFT LCD TV User’s Manual KLT151 KLT201 Copyright and Trademark Notice NO part of this document may be copied, photocopied, reproduced and translated without the prior written consent of manufacturer. This company reserves the right to revise this publication and to make change from time in the contents without obligation of this company to notify a person of such revision or changes. All brand or product names are trademarks or registered trademarks of their respective companies. TFT LCD TV 2 Safety Instructions Before connecting the AC power cord to the DC adapter outlet, make sure the voltage designation of the DC adapter corresponds to the local electrical supply. Never insert anything metallic into the cabinet openings of the Liquid Crystal Display LCD TV: doing so may create the danger of electric shock. To avoid electric shock, never touch the inside of the LCD TV. Only a qualified technician should open the case of the LCD TV. Never use your LCD TV if the power cord has been damaged. Do not allow anything to rest on the power cord, and keep the cord away from areas wherepeople can trip over it. Be sure to hold the plug, not the cord, when disconnecting the LCD TV from an electric socket. Openings in the LCD TV cabinet are provided for ventilation. To prevent overheating, these openings should not be blocked or covered. Also, avoid using the LCD TV on a bed, sofa, rug, or other soft surface. Doing so may block the ventilation openings in the bottom of the cabinet. If you put the LCD TV in a bookcase or some other enclosed space, be sure to provide adequate ventilation. Put your LCD TV in a location with low humidity and a minimum of dust. Do not expose the LCD TV to rain or use it near water (in kitchen, near swimming pool, etc.). If the LCD TV accidentally gets wet, unplug it and contact an authorized dealer immediately. You can clean the LCD TV with a damp cloth when necessary, but be sure to unplug the LCD TV first. Place the LCD TV on a solid surface and treat it carefully. The screen is made of thin glass with a plastic front surface and be damaged if dropped, hit or scratched. Do not clean the front panel with keton-type materials (e.g., acetone), ethyl alcohol, toluene, ethylacid, methyl, or chloride - these may damage the panel. Locate your LCD TV near an easily accessible AC outlet. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. 3 European Notice products with the CE Marking comply with both the EMC Directive (89/336/EEC),(93/68/ECC) and the Low Voltage Directive(72/23/ECC) issued by the Commission of the European Community. Compliance with these directives implies conformity to the following European Norms: EN 60950 / All: 1997 EN 55 022 Class B: 1998 EN 55 013:1990 + A12: 1994 + A13: 1996 EN 61 000-3-2: 1995 + A1: 1998 + A2: 1998 EN 61 000-3-3: 1995 EN 50 082-1: 1992 (EN 61000-4-2: 1995 + A1: 1998, IEC 801-3: 1984, EN 61000-4-4: 1995 EN 55 020: 1994 + All: 1996 FCC Information User Instructions The Federal Communications Radio Frequency Interference Statement includes the following warning: NOTE :This equipment has been tested and found to comply with limits for a Class B digital devices, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communication. However, there is no guarantee that interference will not occur in a particular installation If this equipment does cause harmful interference to radio or television receptions, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet of a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. User Information Changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. If necessary, consult your dealer or an experienced radio/TV technician for additional suggestions. You may find the booklet called How to Identify and Resolve Radio/TV Interference Problems helpful. This booklet was prepared by the Federal Communications Commission. It is available from the U.S. Goverment Printing Office, Washington,DC 20402, Stock Number 004-000-00345-4. Warning User must use shielded signal interface cables to maintain FCC compliance for the product. Declaration of conformity for products Marked with FCC Logo This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any 4 5 6 7 Front Panel TFT LCD TV 20.1"(51cm) Front Panel 1 2 35 4 6 1 2 3 4 5 6 TV/MTR(MODE) TV, Monitor MENU VOL CH POWER LED 8 Front Panel Accessory TFT LCD TV 15.1"(38cm) 1 2 3 4 5 6 TV/MTR(MODE) TV, Monitor MENU VOL CH POWER LED 9 6 1 2 3 4 5 TFT LCD TV 20.1"(51cm) Rear Panel Rear Panel Jacks 1 5 6 7 8 9 4 3 2 10 TFT LCD TV 15.1"(38cm) Rear Panel 1 5 6 7 4 3 2 11 Remote Control Unit 1 2 3 4 5 7 6 8 9 11 10 12 POWER Turns the TV On and Off. Numeric buttons Direct channel select. Direct page select during teletext display(option) MENU Displays ‘On Screen Menu. VOL , Press the increase or decrease the volume. Also used to make selections on the on-screen menus. MTS Press to choose stereo, dual or mono. MUTE Press to temporarily cut of the sound. TV Select TV signal. PC Select PC signal. CH, Press CH or …
