BRWSPMBT2000BT2000 Bluetooth Module

The Spektrum BT2000 bluetooth module allows wireless connection from supported Spektrum transmitters, such as the DX3 ™ , to Spektrum developed mobile apps on supported smart phones and tablets. The application displays a dashboard for various telemetry functions and allows for programming of adjustable parameters. These vehicle parameters can then be saved within the application. • Compatibility: iOS 5 or later, Android 5.1 or later • Max Range: 25-30 feet INSTALLATION 1. Power the transmitter off. 2. Remove the top cover from the DX3 ™ transmitter. 3. Firmly press the BT2000 into the connection, ensuring the pins line up with the connector. The BT2000 will only fi t in the transmitter in one direction. 4. Re-install the transmitter top cover after the pairing process is complete. PAIRING 1. Download and install the Spektrum Dashboard app to your mobile device. 2. Ensure Bluetooth is enabled on your device. 3. Open the Dashboard app. 4. Power on DX3. The LED on BT2000 will blink slowly (1 time per second). 5. Start the pairing process by pressing and holding the BIND button on BT2000 module for a second. The LED on the module will blink rapidly (4 times per second). 6. On your mobile device, open the Bluetooth settings and select BT2000. If prompted for a passkey, enter the code 123456. After successful pairing, the LED on BT2000 will remain solid, and the Dashboard app will show Bluetooth is connected. The BT2000 and the mobile device store the pairing information. The module BIND button does not need to be pressed to connect to the same mobile device the next time the DX3 is powered on. However, the mobile device may require the BT2000 be selected again in the Bluetooth settings menu to re-connect to the Dashboard app. If required, this should be done within 45 seconds of powering on the DX3. PAIRING TO A DIFFERENT MOBILE DEVICE If you wish to pair the BT2000 module to a different device, with the transmitter powered on, hold the module BIND button for 5 seconds. The module LED fl ashes very rapidly (8 times per second), indicating the existing pairing information has been erased. The BT2000 module may now be paired to a different mobile device using the PAIRING steps above. LED Bind button ENGLISH BT2000 Bluetooth Module (SPMBT2000) Instruction Manual | Bedienungsanleitung | Manuel d’utilisation | Manuale di istruzioni WARNING AGAINST COUNTERFEIT PRODUCTS: Always purchase from a Horizon Hobby, LLC authorized dealer to ensure authentic high-quality Spektrum product. Horizon Hobby, LLC disclaims all support and warranty with regards, but not limited to, compatibility and performance of counterfeit products or products claiming compatibility with DSM ® or Spektrum technology. NOTICE: This product is only intended for use with unmanned, hobby-grade, remote-controlled vehicles and aircraft. Horizon Hobby disclaims all liability outside of the intended purpose and will not provide warranty service related thereto. Age Recommendation: Not for children under 14 years. This is not a toy. WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product before operating. Failure to operate the product correctly can result in damage to the product, personal property and cause serious injury. This is a sophisticated hobby product. It must be operated with caution and common sense and requires some basic mechanical ability. Failure to operate this Product in a safe and responsible manner could result in injury or damage to the product or other property. This product is not intended for use by children without direct adult supervision. Do not attempt disassembly, use with incompatible components or augment product in any way without the approval of Horizon Hobby, LLC. This manual contains instructions for safety, operation and maintenance. It is essential to read and follow all the instructions and warnings in the manual, prior to assembly, setup or use, in order to operate correctly and avoid damage or serious injury. MEANING OF SPECIAL LANGUAGE The following terms are used throughout the product literature to indicate various levels of potential harm when operating this product: WARNING: Procedures, which if not properly followed, create the probability of property damage, collateral damage, and serious injury OR create a high probability of superfi cial injury. CAUTION:Procedures, which if not properly followed, create the probability of physical property damage AND a possibility of serious injury. NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND a little or no possibility of injury. NOTICE All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, LLC. For up-to-date product literature, visit horizonhobby.com or towerhobbies.com and click on the support tab for this product. WARRANTY REGISTRATION Visit www.spektrumrc.com/registration today to register your product. © 2020 Horizon Hobby, LLC. DSM, DX3 and the Horizon Hobby logo are trademarks or registered trademarks of Horizon Hobby, LLC. The Spektrum trademark is used with permission of Bachmann Industries, Inc. Created 5/20 SPMBT2000 65067 1-Year Limited Warranty What this Warranty Covers Horizon Hobby, LLC, (Horizon) warrants to the original purchaser that the product purchased (the “Product”) will be free from defects in materials and workmanship for a period of 1 year from the date of purchase. What is Not Covered This warranty is not transferable and does not cover (i) cosmetic damage, (ii) damage due to acts of God, accident, misuse, abuse, negligence, commercial use, or due to improper use, installation, operation or maintenance, (iii) modifi cation of or to any part of the Product, (iv) attempted service by anyone other than a Horizon Hobby authorized service center, (v) Product not purchased from an authorized Horizon dealer, (vi) Product not compliant with applicable technical regulati…

Text truncated - open the document above for the full version.

Date: May 18, 2020 Federal Communications Commission Authorization and Evaluation Division FCC ID: BRWSPMBT2000 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: 1. Block Diagram 2. Schematics 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, ---------------------------------------------------------- Name: Christopher Dickerson Horizon Hobby, LLC

Declaration of Authorization We Name: Horizon Hobby, LLC Address: 2904 Research Rd., Champaign, IL 61822 Declare that: Name Representative of agent: Robin Wu Agent Company name: MRT Technology (Suzhou) Co., Ltd Address: D8 Building, Youxin Industrial Park, No.2 Tian'edang Rd., Wuzhong Economic Development Zone, City: Suzhou Country China is authorized to apply for Certification of the following product(s): Product description: BT2000 Bluetooth Module Type designation: BT2000 FCC ID: BRWSPMBT2000 Trademark: Spektrum on our behalf. Date: May 28, 2020 Name: Christopher Dickerson Signature:

Report No.: 2004RSU030-UE 1 of 2 EUT Internal Photograph (1) EUT Photo (2) EUT Photo Report No.: 2004RSU030-UE 2 of 2 (3) EUT Photo (4) EUT Photo

MRT Technology (Suzhou) Co., Ltd Report No.: 2003RSU030-U2 Phone: +86-512-66308358 Report Version: V01 Web: www.mrt-cert.com Issue Date: 05-25-2020 1 of 9 RF Exposure Evaluation Declaration FCC ID: BRWSPMBT2000 IC: 6157A-SPMBT2000 Applicant: Horizon Hobby, LLC Application Type: Certification Product: BT2000 Bluetooth Module Model No.: BT2000 Brand Name: Spektrum FCC Classification: Digital Transmission System (DTS) Test Procedure(s): KDB 447498 D01v06, RSS-102 Issue 5 Reviewed By: ( Sunny Sun ) Approved By: ( Robin Wu ) The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standards through the calibration of the equipment and evaluated measurement uncertainty herein. The test report shall not be reproduced except in full without the written approval of MRT Technology (Suzhou) Co., Ltd. Report No.: 2003RSU030-U2 2 of 9 Revision History Report No. Version Description Issue Date Note 2003RSU030-U2 Rev. 01 Initial Report 05-25-2020 Valid Report No.: 2003RSU030-U2 3 of 9 1. Equipment Description 1.1. Feature of Equipment under Test 1.2. Product Specification Subjective to this Report Product Name: BT2000 Bluetooth Module Model No.: BT2000 Brand Name: Spektrum Hardware Version: rev.D Software Version: 0.0.4 Working Temperature: 0 ~ 35C Working Voltage: 6VDC Bluetooth Version: V5.1 (BLE only) Sample Code: 03 Bluetooth Frequency: 2402 ~ 2480MHz Type of modulation: GFSK Data Rate: 1Mbps Antenna Type: Ceramic Antenna Max Antenna Gain: 0.5 dBi Report No.: 2003RSU030-U2 4 of 9 1.3. Working Frequencies for this report Channel Frequency Channel Frequency Channel Frequency 00 2402 MHz 01 2404 MHz 02 2406 MHz 03 2408 MHz 04 2410 MHz 05 2412 MHz 06 2414 MHz 07 2416 MHz 08 2418 MHz 09 2420 MHz 10 2422 MHz 11 2424 MHz 12 2426 MHz 13 2428 MHz 14 2430 MHz 15 2432 MHz 16 2434 MHz 17 2436 MHz 18 2438 MHz 19 2440 MHz 20 2442 MHz 21 2444 MHz 22 2446 MHz 23 2448 MHz 24 2450 MHz 25 2452 MHz 26 2454 MHz 27 2456 MHz 28 2458 MHz 29 2460 MHz 30 2462 MHz 31 2464 MHz 32 2466 MHz 33 2468 MHz 34 2470 MHz 35 2472 MHz 36 2474 MHz 37 2476 MHz 38 2478 MHz 39 2480 MHz -- -- -- -- Report No.: 2003RSU030-U2 5 of 9 2. RF Exposure Evaluation 2.1. Limits For FCC: SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The equation and threshold in Note 1 must be applied to determine SAR test exclusion. MHz 5 10 15 20 25 mm 150 39 77 116 155 194 SAR Test Exclusion Threshold (mW) 300 27 55 82 110 137 450 22 45 67 89 112 835 16 33 49 66 82 900 16 32 47 63 79 1500 12 24 37 49 61 1900 11 22 33 44 54 2450 10 19 29 38 48 3600 8 16 24 32 40 5200 7 13 20 26 33 5400 6 13 19 26 32 5800 6 12 19 25 31 MHz 30 35 40 45 50 mm 150 232 271 310 349 387 SAR Test Exclusion Threshold (mW) 300 164 192 219 246 274 450 134 157 179 201 224 835 98 115 131 148 164 900 95 111 126 142 158 1500 73 86 98 110 122 1900 65 76 87 98 109 2450 57 67 77 86 96 3600 47 55 63 71 79 5200 39 46 53 59 66 5400 39 45 52 58 65 5800 37 44 50 56 62 Report No.: 2003RSU030-U2 6 of 9 Note: The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] * [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where ⚫ f(GHz) is the RF channel transmit frequency in GHz ⚫ Power and distance are rounded to the nearest mW and mm before calculation ⚫ The result is rounded to one decimal place for comparison ⚫ 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. Report No.: 2003RSU030-U2 7 of 9 For ISED: SAR Test Exclusion Thresholds for RSS-102 issue 5 Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. For low frequencies (300 MHz to 835 MHz), the exemption limits are derived from a linear fit. For high frequencies (1900 MHz and above), the exemption limits are derived from a third order polynomial fit. MHz 5 10 15 20 25 mm ≤ 300 71 101 132 162 193 SAR Test Exclusion Threshold (mW) 450 52 70 88 106 123 835 17 30 42 55 67 1900 7 10 18 34 60 2450 4 7 15 30 52 3500 2 6 16 32 55 5800 1 6 15 27 41 MHz 30 35 40 45 50 mm ≤ 300 223 254 284 315 345 SAR Test Exclusion Threshold (mW) 450 141 159 177 195 213 835 80 92 105 117 130 1900 99 153 225 316 431 2450 83 123 173 235 309 3500 86 124 170 225 290 5800 56 71 85 97 106 2.2. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. The temperature and related humidity: 18°C and 78% RH. Report No.: 2003RSU030-U2 8 of 9 2.3. Test Result of RF Exposure Evaluation Product BT2000 Bluetooth Module Test Item RF Exposure Evaluation Output Power into Antenna: Test Mode Frequency Band (MHz) Maximum output power to antenna (dBm) Maximum output power to antenna (mW) SAR Test Exclusion Threshold (mW) BLE 2402 ~ 2480 2.92 1.96 10 Note: Per FCC KDB 447498 D01v06, the SAR exclusion threshold for distances < 50mm is defined by the following equation: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] * [√f(GHz)] ≤ 3.0 Based on the maximum conducted power of this device and the antenna to use separation distance, The SAR test was not required: [(1.96mW/5)* √2.402] = 0.61 < 3.0 Note: When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. For ISED SAR exclusion assessment via e.i.r.p Power: Te…

Text truncated - open the document above for the full version.

Report No.: 2004RSU030-UT 1 of 1 Test Setup Photograph Description: Radiated Emission Test Setup for below 1000MHz Description: Radiated Emission Test Setup for above 1000MHz
