BY32160-27TP26.96-27.28 MHz Wireless Remote Control Toy - TX

OPERATING INSTRUCTIONS: BATTERY LOADING: (FOR MAXIMUM PERFORMANCE, ONLY USE ALKALINE BATTERIES) Remember to take out all batteries from vehicle and transmitter after playing. 1. Do not mix old and new batteries. 2. Do not mix alkaline, standard (Carbon-Zinc), or rechargeable (Nickel-Cadmium) batteries. BATTERY INSTALLATION VEHICLE 1. Make sure the ON/OFF switch of the vehicle is at the OFF position (See Diagram 1). 2. Open the battery lid (See Diagram 1). 3. Take out the battery pack. Insert batteries by matching (+) and (–) sign as indicated in the battery pack (See Diagram 2). Only uses alkaline batteries. 4. Snap the battery pack into the battery compartment with the contacts as shown. (See Diagram 2). 5. Replace the battery lid (See Diagram 3). TRANSMITTER 1. Remove battery cover and install 9 'V' battery by matching (+) and (–) sign as indicated in the battery compartment (See diagram 4). 2. Replace the battery cover. HOW TO PLAY START TO PLAY 1. Push the ON/OFF switch to the "ON" position of the vehicle. (See Diagram 5). FORWARD RUNNING 2. Push the Driving Control Stick forward for forward running. (See Diagram 6). REVERSE RUNNING 3. Pull the Driving Control Stick backward for reverse running. (See Diagram 7). STOP OPERATION 4. Release the Driving Control Stick to stop the vehicle. (See Diagram 8). Ramp Climb / Flip Over (See Diagram 9/10). - For best performance, only use alkaline batteries. - Performance may vary on different surfaces. PERFORMANCE TIPS: 1. Don't drive in grass, sand or carpet. 2. Don't go through water. 3. Use fresh alkaline batteries. 4. Be sure to rest your vehicle for at least 30 minutes after every 15 minutes of operation. 5. Make sure ON/OFF switch on your vehicle is OFF when not in use. 6. Don't bend antenna. 7. Electrical, CB interference, mobile phones, air conditioning, elevators and steel girders in building will affect the operation of your vehicle. 8. Don't leave the vehicle or transmitter near sources of heat or under direct sunlight for long periods of time. 9. Remove the batteries from the vehicle and transmitter when not in use. BATTERY CAUTIONS 1. For maximum performance, use alkaline batteries 2. Do not mix old and new batteries 3. Do not mix alkaline, standard (carbon-zinc), or rechargeable batteries 4. Do not recharge non-rechargeable battery 5. Ensure batteries are inserted with the correct polarity 6. Remove batteries when toy is not in use 7. Remove exhausted batteries from toy and dispose of in accordance with the makers recommendation 8. Rechargeable batteries should only be charged under adult supervision 9. Remove rechargeable batteries from toy before charging 10. The supply terminals are not to be short-circuited 11. The antenna wires are not to be inserted into socket outlet. CAUTION: In locations subject to radio frequency interference, the product may not function normally. ATTENTION PARENTS: IT IS RECOMMENDED THAT THIS TOY AND ALL ACCESSORIES BE PERIODICALLY EXAMINED FOR POTENTIAL HAZARDS AND THAT POTENTIALLY HAZARDOUS PARTS BE REPAIRED OR REPLACED. FCC INFORMATION This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult your local RadioShack store or an experienced radio/TV technician for help. If you cannot eliminate the interference, the FCC requires that you stop using your equipment. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. SIZE: 210MM X 420MM PN#65-5674-000-0100 ADVERTENCIA: PELIGRO DE ASFIXIA- Pequeñas partes, No recomendado para niños menores de 3 anõs ESPAÑOL Diagram 1Diagram 2Diagram 3Diagram 4 Diagram 5Diagram 8Diagram 6Diagram 7 (4) (3) (6) (5) © 2014 SCIENTIFIC TOYS LTD. 1108, TOWER B, 14 SCIENCE MUSEUM ROAD, TSIMSHATSUI, HONG KONG. PRINTED IN CHINA O.I. NO.5674 ENGLISH WARNING: CHOKING HAZARD- Small parts, Not for chidren under 3 years (1) (2) (7) (8) Diagram 9 Diagram 10 (9)(10) (Diagram 1) <1> Open (Diagram 3) <2> Close (Diagram 6) <3> Forward <4> Forward (Diagram 7) <5> Reverse <6> Backwards and turn (Diagram 8) <7> Stop <8> Stop (Diagram 10) <9> Reverse <10> Forward MANUAL DE INSTRUCCIONES: MANTENIMIENTO DE BATERÍAS: (PARA UN MAXIMO RENDIMIENTO, UTILIZAR PILAS ALCALINAS) Para un mejor mantenimiento, recuerde retirar todas las pilas del vehículo y de la emisora después de jugar con él. 1. No mezclar baterías usadas con baterías nuevas. 2. No mezclar tipos de baterías diferentes, alcalinas, estándar (carbono-Zinc), o recargables . INSTALACIÓN DE BATERÍAS: VEHICULO 1. Asegúrese de que el interruptor de “ON/OFF” está en la posición “OFF” (Ver dibujo 1). 2. Abra la cubierta de las baterías (Ver dibujo 1). 3. Saque el soporte de las baterías. Coloque las baterías siguiendo los signos de polaridad “+” y “–”c…

Text truncated - open the document above for the full version.

Shenzhen SEM.Test Technology Co., Ltd. 1/F, Building A, Hongwei Industrial Park, Liuxian 2nd Road, Bao'an District, Shenzhen, 518101, Guangdong, China Letter for Confirmation of the Test Date of Test: 2014‐5‐15 Applicant Name: Scientific Toys Ltd. FCC ID Number: FCC ID: BY32160‐27TP Name of Engineer to perform the Test: Lahm Peng (Engineer) Statement for Confirmation of the Test: Gakkiku Technology Company hired us to perform the test. We declare that tested sample has been tested in accordance with the test method identified on the test report and our test engineer was performing the test. We also declare that sample complied with the relevant limits. All instrumentation and accessories were used to test that sample for compliance to the indicated test method and those were calibrated regularly in accordance with ISO 17025: 2005 requirements by laboratories accredited by A2LA, NVLAP or ACLAS for the measurement parameters. The measurements were made at: Shenzhen SEM.Test Technology Co., Ltd. 1/F, Building A, Hongwei Industrial Park, Liuxian 2nd Road, Bao'an District, Shenzhen, 518101, Guangdong, China Representative of the organization performing the test: Jandy So (Manager) Signature: Email Address: [email protected] Tel No.: +86755‐33663308‐808

10th June, 2014. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046. Request correction of test setup photos regarding application for certification of the Scientific Toys Ltd./FCC ID: BY32160-27TP. To Whom It May Concern: I am sorry for submitting wrong test setup photos (BY32160-27TP_TestSetupPhotos.pdf) to the FCC filing of the Scientific Toys Ltd./FCC ID: BY32160-27TP (Timco Job #: 896CC14) because of sending wrong photos. The file of correct test setup photos is BY32160-27TP_RevisedTestSetupPhotos.pdf. Please process our request that wrong test setup photos needed to be superseded by correct test setup photos. Thank you. Please do not hesitate to contact me if you have any queries. Yours faithfully, Gakkiku Technology Company ___________________ Dick Chan (Director) Gakkiku Technology Company Flat B, 5/F., Selwyn Factory Building, No. 404 Kwun Tong Road, Kwun Tong, Kowloon, Hong Kong Tel: (852) 8113 2281 Fax: (852) 2797 0192 Email: [email protected]

Scientific Toys Ltd. Model Number(s)/Catalog Number(s): 33361 REPORT NUMBER: GKK201405140C PAGE 1 OF 15 PART 15.227 & RSS-310 ISSUE 3 Test Report Applicant Scientific Toys Ltd. Address Rm. 1108, 11/F., Block B, New Mandarin Plaza, 14 Science Museum Road, TST East, Kowloon, Hong Kong FCC ID Number FCC ID: BY32160-27TP Brand Name(s) None Model Number(s)/ Catalog Number(s) 33361, 33360, 33362, BY32160-27TP Product Description 26.96-27.28 MHz Wireless Remote Control Toy - TX Operating Frequency 27.145 MHz Rules/Standards Part 15.227 of the FCC Rules, RSS-310 Issue 3 and RSS-Gen Issue 3 of the Industry Canada Received Date 14th May, 2014 Tested Date 15th May, 2014 Approved by Dick Chan (Director of Gakkiku) Tested by Lahm Peng (Engineer of Shenzhen SEM.Test) Signed by Jandy So (Manager of Shenzhen SEM.Test) Report Number GKK201405140C Test Results PASSED FAILED Gakkiku Technology Company Flat B, 5/F., Selwyn Factory Building, No. 404 Kwun Tong Road, Kwun Tong, Kowloon, Hong Kong Tel: (852) 8113 2281 Fax: (852) 2797 0192 Email: [email protected] Scientific Toys Ltd. Model Number(s)/Catalog Number(s): 33361 REPORT NUMBER: GKK201405140C PAGE 2 OF 15 PART 15.227 & RSS-310 ISSUE 3 GENERAL The report is written by Gakkiku Technology Company. The tested device complies with the general approval requirements of the FCC Rules and the Industry Canada as identified in this test report. TEST LOCATION The tested device was tested at the test site of the Shenzhen SEM.Test Technology Co., Ltd., 1/F, Building A, Hongwei Industrial Park, Liuxian 2nd Road, Bao'an District, Shenzhen, 518101, Guangdong, China. The FCC Recognized 2.948 Listed Test Firm Registration Number is 934118. The Industry Canada IC OATS Filing Number/Assigned Code is 11464A. Scientific Toys Ltd. Model Number(s)/Catalog Number(s): 33361 REPORT NUMBER: GKK201405140C PAGE 3 OF 15 PART 15.227 & RSS-310 ISSUE 3 TABLE OF CONTENTS 1. GENERAL INFORMATION ............................................................................................... 4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................... 4 1.2 TEST STANDARDS ....................................................................................................................................... 4 1.3 RELATED SUBMITTAL(S)/GRANT(S) ............................................................................................................ 4 1.4 TEST METHODOLOGY .................................................................................................................................. 5 1.5 EUT EXERCISE SOFTWARE .......................................................................................................................... 5 1.6 ACCESSORIES EQUIPMENT LIST AND DETAILS............................................................................................... 5 1.7 EUT CABLE LIST AND DETAILS .................................................................................................................... 5 2. SUMMARY OF TEST RESULTS ......................................................................................... 6 3. PART 15.203 & RSS-GEN ISSUE 3 §7.1.2 - ANTENNA REQUIREMENT .............................. 7 3.1 STANDARD APPLICABLE ............................................................................................................................... 7 3.2 TEST RESULT .............................................................................................................................................. 7 4. PART 15.227, 15.209, 15.205 & RSS-310 ISSUE 3 §3.8 - RADIATED EMISSION ................. 8 4.1 MEASUREMENT UNCERTAINTY ................................................................................................................... 8 4.2 STANDARD APPLICABLE .............................................................................................................................. 8 4.3 TEST EQUIPMENT LIST AND DETAILS .......................................................................................................... 8 4.4 TEST PROCEDURE ...................................................................................................................................... 9 4.5 CORRECTED AMPLITUDE & MARGIN CALCULATION ..................................................................................... 9 4.6 ENVIRONMENTAL CONDITIONS................................................................................................................... 9 4.7 SUMMARY OF TEST RESULTS/PLOTS .......................................................................................................... 10 5. PART 15.227(B) & RSS-310 ISSUE 3 §2.4 - OUT OF BAND EMISSIONS ........................... 13 5.1 STANDARD APPLICABLE ............................................................................................................................. 13 5.2 TEST EQUIPMENT LIST AND DETAILS ......................................................................................................... 13 5.3 TEST PROCEDURE ..................................................................................................................................... 13 5.4 ENVIRONMENTAL CONDITIONS .................................................................................................................. 13 5.5 SUMMARY OF TEST RESULTS/PLOTS .......................................................................................................... 14 Scientific Toys Ltd. Model Number(s)/Catalog Number(s): 33361 REPORT NUMBER: GKK201405140C PAGE 4 OF 15 PART 15.227 & RSS-310 ISSUE 3 1. GENERAL INFORMATION 1.1 Product Description for Equipment Under Test (EUT) Client Information Applicant: Scientific Toys Ltd. Address of applicant: Rm. 1108, 11/F., Block B, New Mandarin Plaza, 14 Science Museum Road, TST East, Kowloon, Hong Kong Manufacturer: Scientific Toys Ltd. Address of manufacturer: Rm. 1108, 11/F., Blo…

Text truncated - open the document above for the full version.
