BY32342-24GTR/C BOAT

CAUTIONS 1. Do not charge battery pack that is hot, wet or shows leakage or corrosion. 2. May explode if disposed of in fire! 3 Do not disassemble the battery pack. 4. Non-rechargeable batteries are not to be recharged. 5. Rechargeable batteries are to be removed from the toy before being charged. 6. Rechargeable batteries are only to be charged under adult supervision. 7. Different types of batteries or new and used batteries are not to be mixed. 8. Only batteries of the same or equivalent type as recommended are to be used. 9. Batteries are to be inserted with the correct polarity. 10. Exhausted batteries are to be removed from the toy. 11. The supply terminals are not to be short-circuited. PERFORMANCE TIPS / CAUTIONS: 1. Operate your boat in calm and clear water only. 2. Do not operate your boat in salt water as this can damage your boat permanently. 3. Do not expose the transmitter to moisture or water. 4. Do not expose the boat to water unless the battery compartment cover is securely closed and latched. 5. Bring the boat back to the water edge when it is running out of battery or starts to slow down. 6. Note that the approximate operation range averages 20 meters. 7. Do not pick up your boat while it is in motion. 8. The propeller rotates at high speed.Keep fingers, hair and clothing clear of the propeller while the propeller is spinning. 9. After playing, drain the water out of the hull by pulling out the two plugs located at either side of the back of the boat. Replace the plugs before using again. 10. Do not operate near swimmers. 11. Stay away from water edge when operating. 12. Dry the boat with a dry, clean cloth before storing. 13. Before storing, please drain the hull and leave the battery compartment open for fully dry. 14. To be operated under adult supervision. Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult your local RadioShack store or an experienced radio/TV technician for help. Please Note: The CE and logos are not applicable to Australia and New Zealand. © 2015 SCIENTIFIC TOYS LTD. 1108, TOWER B, 14 SCIENCE MUSEUM ROAD, TSIMSHATSUI, HONG KONG. PRINTED IN CHINA O.I. NO.5776 Battery Charger Press button on side of charger to release battery pack ON/OFF Pairing button Unscrew to open Boat power IndicatorPairing Indicator Safety contacts ON/OFF 9.6V Rechargeable battery pack Wall outlet OPERATING INSTRUCTION ATTENTION PARENTS: 1. It is recommended that this toy and all accessories be periodically examined for potential hazards and that any potential hazardous parts be repaired or replaced. 2. Children should be made aware of potential danger associated with playing near water. BATTERY INSTALLATION: BATTERY LOADING 1. Plug the wall pack battery charger into wall outlet (See Diagram 1). 2. Click the battery pack into the charger. Make certain the battery pack is secure in charger. 3. To disconnect, push the button of the charger (See Diagram 1) and simultaneously slide battery pack out. 4. Allow about 2 hours for full-charge. The green LED indicator will be flashing continuously when charging is in process. 5. The charging is completed when the green LED indicator stops flashing and stays on. Then unplug the charger and disconnect the battery pack from charger. 6. After charging for 2 hours, the battery will be warm. This condition is normal for fully charged batteries. 7. If the speed of the car slows down suddenly, it is time to recharge. 8. After use, the battery pack will be hot! Wait at least 20 minutes until it cools before recharging. Recharging a warm or hot battery pack will greatly shorten the battery life. CAUTION • To avoid damage and personal injury, use only the supplied battery charger to charge the battery pack. • After playing, wait at least 20 minutes to let the battery pack cool before recharging it. BATTERY NOTES • Use only fresh batteries of the required size and recommended type. Do not mix old and new batteries or batteries of different capacities, types, or chemistries. • Dispose of the old batteries promptly and properly. Do not burn or bury them. • Do not disassemble the charger and battery pack. Incorrect assembly can result in risk of electric shock or fire. • If you do not plan to use the boat for a week or longer, remove the batteries from the controller and the boat. • Batteries should NEVER be left unattended while charging. Only adults should charge the batteries. Use caution when using the charger to avoid electric shock. INSTALL BATTERIES IN THE BOAT 1. Turn the rear latch to release and remove the cabin cover (See Diagram 2). 2. Turn off the boat. 3. To install the battery pack, open the battery hatch latches and remove the hatch (See Diagram 3). Insert the 9.6 V battery pack into the battery socket (See Diagram 4). Make sure you fit the battery and battery cables neatly inside, before you replace the hatch securely.…

Text truncated - open the document above for the full version.

External Photos

Power : 1 x 9.6V batter y for RX Catalog No. 6001323 RC Aqua King 4 x AAA batteries for TX FCC ID: BY32342-24GT Custom Manufactured in Shenzhen, China for RadioShack Corporation For t Wor th, T X 76102 01A15 100% 57 x 27mm (White Pad Printing) 2.4GHz for transmitter 200% This device complies with Par t 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause har mful inter ference, a n d ( 2 ) t h i s d e v i c e m u s t a c c e p t a n y i n t e r f e r e n c e r e c e i v e d , i n c l u d i n g inter ference that may cause undesired operation.

Internal Photos

1 INTERTEK TESTING SERVICES RF Exposure The Equipment under Test (EUT) is a Control unit for R/C BOAT model: BY32342-24GT operating at 2.4GHz band. It is powered by DC 6.0V (4 x 1.5V AAA batteries). For more detail information pls. refer to the user manual. Antenna Type: Integral antenna. Antenna Gain: 2dBi. The normal radiated output power (e.i.r.p) is: - 4.0dBm (tolerance: +/- 3dB). The normal conducted output power is -6.0dBm (tolerance: +/- 3dB). Modulation Type: GFSK. According to the KDB 447498: The Maximum peak radiated emission for the EUT is 94.1dB μV/m at 3m in t he frequency 2406MHz The EIRP = [(FS*D) ^2 / 30] mW = -1.13dBm which is within the production variation. The Minimum peak radiated emission for the EUT is 90.9 dB μV/m at 3m in t he frequency 2414MHz The EIRP = [(FS*D) ^2 / 30] mW = -4.33dBm which is within the production variation. The maximum conducted output power specified is -3.0dBm = 0.5mW T he source- based time-averaging conducted output power = 0.5 * Duty Cycle mW < 0.5 mW (Duty Cycle< 100%) The SAR Exclusion Threshold Level: = 3.0 * (min. test separation distance, mm) / sqrt(freq. in GHz) = 3.0 * 5 / sqrt (2.414) mW = 9. 7 mW S ince the source-based time-averaging conducted output power is well below the SAR low threshold level, so the EUT is considered to comply with SAR requirement without testing. FCC ID: BY32342-24GT
