BY32782-49TP49.82-49.90 MHz WIRELESS REMOTE CONTROL TOY-TX

IMPRESO EN CHINA © 2012 SCIENTIFIC TOYS LTD. 1108, TOWER B, 14 SCIENCE MUSEUM ROAD, TSIMSHATSUI, HONG KONG. PRINTED IN CHINA O.I. NO.5234 INSTRUCTION MANUAL ATTENTION PARENTS It is recommended that this toy and all accessories be periodically examined for potential hazards and that any potentially hazardous parts be repaired or replaced. COMO JUGAR COMIENZO DEL JUEGO 1. Coloque la antena pasando el cable a través del tubo incluido y conectelo en el coche firmemente. Sino el vehículo no fundionará. (Ver Diagrama #5) COMO COLOCAR LAS PILAS EN EL MANDO DE CONTROL 1. Desenrosca y abre la tapa del compartimiento de la pila. Coloca una pila nueva de 9V (Ver Diagrama #4). 2. Coloque la tapa del compartimento de las pilas. Nota: Retire las pilas después de usar el vehículo. IMPORTANT: Please note the vehicle uses a 9.6V Rechargeable Battery Pack and the Battery Pack is charged by a Charger . BATTERY LOADING (The rechargeable battery pack is not charged, please charge it for 8 hours prior to use) 1. Plug the wall pack battery charger into wall outlet. (See Diagram 1) 2. Click the battery pack into the charger. Make certain the battery pack is secure in charger. 3. To disconnect, push the button of the charger (See Diagram 1) and simultaneously slide battery pack out. 4. You should charge the battery pack for 8 hours the first two times. Then subsequent charges will only require 4 hours. 5. After charging for 4 hours, the battery will be warm. This condition is normal for fully charged batteries. 6. If the speed of the car slows down suddenly, it is time to recharge. 7. After use, the battery pack will be hot! Wait at least 20 minutes until it cools before recharging. Recharging a warm or hot battery pack will greatly shorten the battery life. 8. The toy must be used with the recommended transformer. 9. The transformer is not a toy. COLOCACION DE LAS PILAS COMO COLOCAR LAS PILAS EN EL VEHÍCULO 1. Asegúrese que el interruptor “ON/OFF” está en la posición “OFF”. (Ver Diagrama #2) 2. Desatornille y quite la tapa del compartimiento de las pilas. (Ver Diagrama #2) 3. Coloque o conjunto de pilhas de 9.6V dentro e volte a colocar a tampa do compartimento das pilhas. (Ver Diagrama #3) 4. Reemplace la tapa del compartimiento de pilas y apretar el tornillo firmemente para cerrar. SIZE: 210 X 420MM PN#65-5234-000-0100 DIAGRAM #5 DIAGRAM #2DIAGRAM #3 HOW TO PLAY START TO PLAY 1. Thread the antenna by passing the cable through the antenna tube provided and plug into the vehicle tightly. Otherwise, the vehicle will not work. (See Diagram #5) HOW TO INSTALL BATTERY IN TRANSMITTER 1. Unscrew to open the battery lid. Insert a new 9V battery. (See diagram #4). 2. Replace battery cover. Note: Remove battery after you have finished using your vehicle. BATTERY INSTALLATION HOW TO INSTALL BATTERY IN VEHICLE 1. Make sure the “ON/OFF” switch at the underside of the vehicle is at the “OFF” position. (See Diagram #2) 2. Unscrew to open battery cover.(See Diagram #2) 3. Place the 9.6V battery pack inside securely and replace the battery cover. (See Diagram #3) 4. Replace the battery cover and tighten the screw to secure the battery cover. ON/OFF switch Unscrew to open (DIAGRAM #1) Battery Charger 9.6V battery pack Antenna tube Cable DIAGRAMA #2DIAGRAMA #3 Interruptor “ON/ OFF” Desatornillar Para abrir DIAGRAMA #5 Cable Tubo BATTERY CAUTIONS 1. Do not charge non-rechargeable batteries. 2. Remove rechargeable batteries from the toy before recharging. 3. Rechargeable battery pack is only to be charged by adult or by children at least 8 year old. 4. Different types of batteries, new and used batteries are not to be mixed. 5. Only batteries of the same or equivalent type as recommended are to be used. 6. Batteries are to be inserted with the correct polarity. 7. Exhausted batteries are to be removed from the toy. 8. The supply terminals are not to be short-circuited. 9. The transformer is not a toy. 10. The toy must be used with the recommended transformer. 11. This toy is not intended for children under 3 years old. 12. Do not charge battery pack that is hot, wet or shows leakage or corrosion. 13. The battery pack may explode if disposed of in fire. 14. Do not disassemble the battery pack. 15. If the battery pack and connectors are wet, thoroughly dry before charging. 16. Overcharging can damage the battery pack. Charge according to recommended time. 17. This toy and all accessories must be periodically examined for potential hazards, and that potentially hazardous parts must be repaired and replaced before use. WARNING: CHOKING HAZARD - SMALL PARTS, NOT FOR CHILDREN UNDER 3 YEARS. FCC Information This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: · Reorient or relocate the receiving antenna. · Increase the separation between the equipment and receiver. · Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult your local retailer store or an experienced radio/TV technician for help. If you cannot eliminate the interference, the FCC requires that you stop using your product. Changes or modifications not expressly approved by the retailer may cause interference and void the user’s authority to operate the equipment. FCC Note: The antenna installed on …

Text truncated - open the document above for the full version.

Scientific Toys Ltd. Model: 21876 REPORT NO.: GKK201204120A PAGE 1 OF 14 PART 15.235 & RSS-310 ISSUE 3 Test Report Applicant Scientific Toys Ltd. Address Rm. 1108, 11/F., Block B, New Mandarin Plaza, 14 Science Museum Road, TST East, Kowloon, Hong Kong FCC ID Number FCC ID: BY32782-49TP Brand Name None Model Number(s) 21876 Product Description 49.82-49.90 MHz Wireless Remote Control Toy - TX Operating Frequency 49.860 MHz Rules/Standards Part 15.235 of the FCC Rules, RSS-310 Issue 3 and RSS-Gen Issue 3 of the Industry Canada Received Date 12th April, 2012 Tested Date 14th April, 2012 Approved by Dick Chan (Director of Gakkiku) Tested by Lahm Peng (Engineer of SEM.Test) Signed by Jandy So (Manager of SEM.Test) Report Number GKK201204120A Test Results PASSED FAILED Gakkiku Technology Company Flat B, 5/F., Selwyn Factory Building, No. 404 Kwun Tong Road, Kwun Tong, Kowloon, Hong Kong Tel: (852) 8113 2281 Fax: (852) 2797 0192 E-mail: [email protected] Scientific Toys Ltd. Model: 21876 REPORT NO.: GKK201204120A PAGE 2 OF 14 PART 15.235 & RSS-310 ISSUE 3 GENERAL The report is written by Gakkiku Technology Company. The tested device complies with the general approval requirements of the FCC Rules and the Industry Canada as identified in this test report. TEST LOCATION The tested device was tested at the test site of the SEM.Test Compliance Service Co., Ltd., 3/F, Jinbao Commerce Building, Xin'an Fanshen Road, Bao'an District, Shenzhen, 518101, Guangdong, China. The FCC Recognized 2.948 Listed Test Firm Registration Number is 994117. The Industry Canada IC OATS Filing Number/Assigned Code is 7673A. Scientific Toys Ltd. Model: 21876 REPORT NO.: GKK201204120A PAGE 3 OF 14 PART 15.235 & RSS-310 ISSUE 3 TABLE OF CONTENTS 1. GENERAL INFORMATION ................................................................................................................................... 4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ............................................................................... 4 1.2 TEST STANDARDS ................................................................................................................................................... 4 1.3 RELATED SUBMITTAL(S)/GRANT(S) ....................................................................................................................... 4 1.4 TEST METHODOLOGY ............................................................................................................................................. 5 1.5 EUT EXERCISE SOFTWARE .................................................................................................................................... 5 1.6 ACCESSORIES EQUIPMENT LIST AND DETAILS ....................................................................................................... 5 1.7 EUT CABLE LIST AND DETAILS ............................................................................................................................. 5 2. SUMMARY OF TEST RESULTS ........................................................................................................................... 6 3. PART 15.203 - ANTENNA REQUIREMENT ........................................................................................................ 7 3.1 STANDARD APPLICABLE ......................................................................................................................................... 7 3.2 TEST RESULT.......................................................................................................................................................... 7 4. PART 15.205, 15.209, 15.235 & RSS-310 ISSUE 3 §3.8 - RADIATED EMISSION ............................................ 8 4.1 MEASUREMENT UNCERTAINTY .............................................................................................................................. 8 4.2 STANDARD APPLICABLE ......................................................................................................................................... 8 4.3 TEST EQUIPMENT LIST AND DETAILS ..................................................................................................................... 8 4.4 TEST PROCEDURE ................................................................................................................................................... 9 4.5 CORRECTED AMPLITUDE & MARGIN CALCULATION .............................................................................................. 9 4.6 ENVIRONMENTAL CONDITIONS .............................................................................................................................. 9 4.7 SUMMARY OF TEST RESULTS/PLOTS .................................................................................................................... 10 5. PART 15.235(B) - OUT OF BAND EMISSIONS ................................................................................................. 12 5.1 STANDARD APPLICABLE ....................................................................................................................................... 12 5.2 TEST EQUIPMENT LIST AND DETAILS ................................................................................................................... 12 5.3 TEST PROCEDURE ................................................................................................................................................. 12 5.4 ENVIRONMENTAL CONDITIONS ............................................................................................................................ 12 5.5 SUMMARY OF TEST RESULTS/PLOTS .................................................................................................................... 13 Scientific Toys Ltd. Model: 21876 REPORT NO.: GKK201204120A PAGE 4 OF 14 PART 15.235 & RSS-310 ISSUE 3 1. GENERAL INFORMATION 1.1 Product Description for Equipment Under Test (EUT) Client Information Applicant: Scie…
