BY33548-275P26.96-27.28 MHz WIRELESS R/C TOY-TX
Scientific Toys Ltd
Click to zoom
Application Details
- Equipment Class
- DXX - Part 15 Low Power Communication Device Transmitter
- Date of Grant
- Jul 19, 2010
- Application Purpose
- Original Equipment
- Date of Application
- Jul 18, 2010
- Equipment Note
- 26.96-27.28 MHz WIRELESS R/C TOY-TX
- Frequency Range
- 27.14500000 - 27.14500000
- Company
- Scientific Toys Ltd
- Country
- Hong Kong
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Users Manual
INSTRUCTION MANUAL ATTENTION PARENTS It is recommended that this toy and all accessories be periodically examined for potential hazards and that any potentially hazardous parts be repaired or replaced. PRINTED IN CHINA O.I. NO.4774 ATENCION PARA LOS PADRES Se recomienda que este juguete y accesorios sean examinados periodicamente para evitar problemas o daños en piezas para que puedan ser reparados o reemplazados. IMPRESO EN CHINA O.I. NO.4774 COMO JUGAR COMIENZO DEL JUEGO 1. Coloque la antena pasando el cable a travĂ©s del tubo incluido y conectelo en el coche firmemente. Sino el vehĂculo no fundionará. (Ver Diagrama #5) COMO COLOCAR LAS PILAS EN EL MANDO DE CONTROL 1. AsegĂşrese que está apagado en posiciĂłn "OFF". Desatornille la tapa del compartimiento de las pilas de la parte inferior del mando. (Ver Diagrama #4) 2. Instale la baterĂa de 9V haciendo coincidir los polos (+) y (–) como se indica en el compartimiento de la baterĂa. (Ver Diagrama #4) 3. Vuelva a colocar la tapa de la baterĂa. Nota: Retire las pilas despuĂ©s de usar el vehĂculo. IMPORTANT: Please note the vehicle uses a 9.6V Rechargeable Battery Pack and the Battery Pack is charged by a Charger . BATTERY LOADING (The rechargeable battery pack is not charged, please charge it for 8 hours prior to use) 1. Plug the Battery Charger. 2. Connect the cables leading from the Battery Pack and the Charger together by snapping the jack and the socket tightly. (See Diagram #1a) 3. To disconnect cables, press down on the clip and pull apart. (See Diagram #1a) 4. You should charge the battery pack for 8 hours the first two times. Then subsequent charges will only require 4 hours. 5. After charging for 4 hours, the battery will be warm. This condition is normal for fully charged batteries. 6. If the speed of the car slows down suddenly, it is time to recharge. 7. After use, the battery pack will be hot! Wait at least 20 minutes until it cools before recharging. Recharging a warm or hot battery pack will greatly shorten the use life of the battery. 8. The toy must be used with the recommended transformer. 9. The transformer is not a toy. IMPORTANTE: Por favor tenga en cuenta que el vehĂculo necesita un pack de pilas recargable de 9.6V y Ă©ste debe ser recargado solamente con un Cargador. COMO RECARGAR LAS PILAS (El pack de pilas recargables no está recargado, por favor recarguelo 8 horas antes de su uso) 1. Enchufe el cargador de las pilas. 2. Conecte los cables del pack de pilas con el cargador mediante las clavijas firmemente. (ver Diagrama #1a) 3. Para desconectar los cables, presione el clip y estire hacia fuera. (ver Diagrama #1a) 4. Debes recargar el pack de pilas durante 8 horas las primeras dos veces. Las siguientes veces solo hará falta recargar durante 4 horas. 5. DespuĂ©s de recargar durante 4 horas, el pack estará caliente. Esto es normal en los packs recargados. 6. Si la velocidad del coche disminuye derrepente, será el momento de volver a recargar las pilas. 7. DespuĂ©s de usar, el pack de pilas estará caliente! Espere al menos 20 minutos hasta que se enfrie antes de volver a recargarlo. Recargar un pack de pilas caliente o templado puede disminuir considerablemente la vida del pack. 8. El juguete debe ser usado solamente con el transformador recomendado. 9. El transformador no es un juguete. COLOCACION DE LAS PILAS COMO COLOCAR LAS PILAS EN EL VEHĂŤCULO 1. AsegĂşrese que el interruptor “ON/OFF” está en la posiciĂłn “OFF”. (Ver Diagrama #2) 2. Desatornille y quite la tapa del compartimiento de las pilas. (Ver Diagrama #2) 3. Conectar la toma de la baterĂa recargable de 9.6V a la toma del compartimiento de baterĂa, luego insertar la baterĂa. (Ver Diagrama #3) 4. Reemplace la tapa del compartimiento de pilas y apretar el tornillo firmemente para cerrar. SIZE: 210 X 481MM PN#65-4774-000-0100 DIAGRAM #5 DIAGRAM #2DIAGRAM #3 DIAGRAM #4 9V Battery Unscrew to open HOW TO PLAY START TO PLAY 1. Thread the antenna by passing the cable through the antenna tube provided and plug into the vehicle tightly. Otherwise, the vehicle will not work. (See Diagram #5) HOW TO INSTALL BATTERY IN TRANSMITTER 1. Make sure the unit is "OFF". Unscrew the battery compartment lid at the bottom of the transmitter. (See Diagram #4) 2. Install 9V battery by matching the polarity marks (+ & –) as indicated in the battery compartment. (See Diagram #4) 3. Replace the battery cover. Note: Remove all batteries after you have finished using your vehicle. BATTERY INSTALLATION HOW TO INSTALL BATTERY IN VEHICLE 1. Make sure the “ON/OFF” switch at the underside of the vehicle is at the “OFF” position. (See Diagram #2) 2. Unscrew to open battery cover.(See Diagram #2) 3. Plug the jack of the 9.6V rechargeable battery pack into the socket of the battery compartment, and put the battery pack inside properly. (See Diagram #3) 4. Replace the battery cover and tighten the screw to secure the battery cover. ON/OFF switch Unscrew to open 9.6V rechargeable Battery pack Press here when opening CAUTION- ELECTRIC TOY NOT RECOMMENDED FOR CHILDREN UNDER 6 YEARS OF AGE. AS WITH ALL ELECTRIC PRODUCTS, PRECAUTIONS SHOULD BE OBSERVED DURING HANDLING AND USE TO PREVENT ELECTRIC SHOCK. INPUT: 120VAC, 60HZ 9.5W ONLY. OUTPUT: 12VDC, 0.2A NO RECOMENDADO PARA NIĂ‘OS MENORES DE 6 AĂ‘OS. AL FUNCIONAR CON ELECTRICIDAD, DEBEN CUMPLIRSE LOS CONSEJOS DE SEGURIDAD DURANTE LA MANIPULACIĂ“N Y LA UTILIZACIĂ“N PARA EVITAR POSIBLES DESCARGAS ELÉCTRICAS. ENTRADA: 120 V CA, 60 HZ 9,5 W SOLAMENTE. SALIDA: 12 V CC, 0,2 A PRECAUCIĂ“N: FUNCIONA CON ELECTRICIDAD (DIAGRAM #1) (DIAGRAM #1a) Press here when opening Battery Charger 9.6V battery pack Battery Cover Antenna tube Cable (DIAGRAMA #1) (DIAGRAMA #1a) Pulse aqui para abrir Cargador de pilas Paquete de pilas de 9.6V. DIAGRAMA #2DIAGRAMA #3 Interruptor “ON/ OFF” Desatornillar Para abrir Desatornillar Para abrir BaterĂa recargable de 9.6V Pulse aqui para abrir Compartimento de las pilas DIAGRAMA #4 Pila de 9V DIAGRAMA #5 Cable Tubo BATTERY CAUTIONS 1. Do not charge non-…
Text truncated - open the document above for the full version.
Test Report
FCC PART 15.227 TEST REPORT LOW POWER UNLICENSED TRANSMITTER Applicant SCIENTIFIC TOYS, LTD. Address RM.1108, 11/F., BLOCK B, NEW MANDARIN PLAZA 14 SCIENCE MUSEUM ROAD TST EAST KOWLOON HONG KONG FCC ID BY33548-275P Product Description 26.96-27.28 MHZ WIRELESS R/C TOY - TX Date Sample Received 7/6/2010 Date Tested 7/7/2010 Tested By Joe Scoglio Approved By Mario R. de Aranzeta Timco Report No. 1627HT10TestReport.doc Test Results Pass Fail THE ATTACHED REPORT SHALL NOT BE REPRODUCED EXCEPT IN FULL WITHOUT THE WRITTEN APPROVAL OF TIMCO ENGINEERING, INC. 849 NW STATE ROAD 45 NEWBERRY, FL 32669 USA PH: 888.472.2424 OR 352.472.5500 FAX: 352.472.2030 EMAIL: [email protected] HTTP://WWW.TIMCOENGR.COM Certificate # 0955-01 APPLICANT: SCIENTIFIC TOYS, LTD. FCC ID: BY33548-275P REPORT: S\SCIENTIF\1627HT10\1627HT10TestReport.doc Page 2 of 9 mdea 09.20.2007 TABLE OF CONTENTS GENERAL REMARKS ...................................................................................................... 3 REPORT SUMMARY ....................................................................................................... 4 TEST ENVIRONMENT ..................................................................................................... 4 TEST SETUP................................................................................................................... 4 DUT SPECIFICATION ..................................................................................................... 5 TEST EQUIPMENT LIST ................................................................................................. 6 TEST PROCEDURES ...................................................................................................... 7 RADIATION INTERFERENCE .......................................................................................... 8 OCCUPIED BANDWIDTH ................................................................................................ 9 APPLICANT: SCIENTIFIC TOYS, LTD. FCC ID: BY33548-275P REPORT: S\SCIENTIF\1627HT10\1627HT10TestReport.doc Page 3 of 9 mdea 09.20.2007 GENERAL REMARKS The attached report shall not be reproduced except in full without the written permission of Timco Engineering Inc. Summary The device under test does: fulfill the general approval requirements as identified in this test report not fulfill the general approval requirements as identified in this test report Attestations This equipment has been tested in accordance with the standards identified in this test report. To the best of my knowledge and belief, these tests were performed using the measurement procedures described in this report. All instrumentation and accessories used to test products for compliance to the indicated standards are calibrated regularly in accordance with ISO 17025 requirements. Testing Certificate # 0955-01 I attest that the necessary measurements were made, under my supervision, at: Timco Engineering Inc. 849 NW State Road 45 Newberry, Fl 32669 Authorized Signatory Name: Mario de Aranzeta C.E.T. Compliance Engineer/ Lab. Supervisor Date: 7/13/2010 APPLICANT: SCIENTIFIC TOYS, LTD. FCC ID: BY33548-275P REPORT: S\SCIENTIF\1627HT10\1627HT10TestReport.doc Page 4 of 9 mdea 09.20.2007 REPORT SUMMARY Disclaimer The test results only relate to the item tested. Applicable Rule(s) FCC Pt 15.227, ANSI C63.4: 2003 TEST ENVIRONMENT Test Facility The test sites are located at 849 NW State Road 45 Newberry, FL 32669 USA. Test Condition: Temperature: 26ºC Relative humidity: 50% TEST SETUP Test Exercise (e.g software description, test signal, etc.): The DUT was placed in continuous transmit mode of operation. Deviation from the standard(s) No deviation from the standard(s) Modification to the DUT: No modification was made to the DUT. Supporting Peripheral Equipment Not applicable. The device is a stand-alone remote control radio. APPLICANT: SCIENTIFIC TOYS, LTD. FCC ID: BY33548-275P REPORT: S\SCIENTIF\1627HT10\1627HT10TestReport.doc Page 5 of 9 mdea 09.20.2007 DUT SPECIFICATION Applicant SCIENTIFIC TOYS, LTD. Description 26.96-27.28 MHZ WIRELESS R/C TOY - TX FCC ID BY33548-275P Frequency Range 27.145 MHz DUT Power Source 110–120Vac/50– 60Hz DC Power Battery Operated Exclusively Test Item Prototype Pre-Production Production Type of Equipment Fixed Mobile Portable APPLICANT: SCIENTIFIC TOYS, LTD. FCC ID: BY33548-275P REPORT: S\SCIENTIF\1627HT10\1627HT10TestReport.doc Page 6 of 9 mdea 09.20.2007 TEST EQUIPMENT LIST Device Manufacturer Model Serial Number Cal/Char Date Due Date 3-Meter Semi- Anechoic Chamber Panashield N/A N/A Listed 03/10/10 03/10/12 Analyzer Tan Tower Quasi-Peak Adapter HP 85650A 3303A01690 CAL 11/22/09 11/22/11 Analyzer Tan Tower RF Preselector HP 85685A 3221A01400 CAL 11/21/09 11/21/11 Analyzer Tan Tower Spectrum Analyzer HP 8566B Opt 462 3138A07786 3144A20661 CAL 11/24/09 11/24/11 Analyzer Tan Tower Preamplifier HP 8449B-H02 3008A00372 CAL 11/21/09 11/21/11 Coaxial Cable #64 Semflex Inc. 60637 Timco #64 CHAR 3/30/09 3/30/11 Antenna: Dipole Kit Electro-Metrics TDA-30/1- 4 152 CAL 3/3/09 3/3/12 Antenna: Dipole Kit Electro-Metrics TDA-30/1- 4 153 CHAR 4/5/09 4/5/12 Hygro- Thermometer Extech 445703 0602 CAL 1/30/09 1/30/11 Modulation Analyzer HP 8901A 3435A06868 CAL 5/9/09 5/9/11 Digital Multimeter Fluke FLUKE-77- 3 79510405 CAL 5/14/09 5/14/11 Antenna: Passive Loop EMC Test Systems EMCO 6512 9706-1211 CAL. 6/1/09 6/2/11 APPLICANT: SCIENTIFIC TOYS, LTD. FCC ID: BY33548-275P REPORT: S\SCIENTIF\1627HT10\1627HT10TestReport.doc Page 7 of 9 mdea 09.20.2007 TEST PROCEDURES Radiated Spurious Emissions: The test procedure used was ANSI C63.4-2003 using a spectrum analyzer with a preselector. The bandwidth of the spectrum analyzer was 100 kHz with an appropriate sweep speed. The analyzer was calibrated in dB above a microvolt at the output of the antenna. The resolution bandwidth was 100 kHz and the video bandwidth was always greater than the RBW. Occupied Bandwidth: A small sample of the transmitter out…
Text truncated - open the document above for the full version.
Contact Information
Applicant
Muk Shui Leung(Electronic Engineering Assistant Manager)
Test Firm
Timco Engineering, Inc.Bruno Clavier
Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 27.145 MHz - 27.145 MHz | - |
