BY33564-27PP26.96-27.28 MHz WIRELESS REMOTE CONTROL TOY-TX

OPERATING INSTRUCTIONS: BATTERY PACK CARE / CAUTIONS: 1. If battery pack and/or connectors are wet, thoroughly dry before charging. 2. Unplug the battery pack if it is not going to be used for several days. 3. Do not charge battery pack that is hot, wet or shows signs of leakage or corrosion. 4. Do not expose to fire, as explosion may result. 5. Do not disassemble the battery pack. 6. The toy must only be used with the recommended charger. 7. The charger is not a toy. 8. Rechargeable battery pack is only to be charged by adult. BATTERY INSTALLATION: THE RECHARGEABLE BATTERY PACK IS NOT CHARGED. 1. Plug the battery charger into a wall outlet. 2. Click the battery pack into the charger. Make certain the battery pack is securely inserted into the charger. 3. To disconnect, push the button of the charger (See Diagram 1) and simultaneously slide battery pack out. 4. The battery pack should be charged for 8 hours the first two times. Then subsequent charges will only require 4 hours. 5. After charging, the battery will be warm. This condition is normal for fully charged batteries. 6. If the speed of the vehicle slows down suddenly, it is time to recharge. 7. After each use, the battery pack will be hot! Allow the battery pack to cool for at least 20 minutes before recharging. Recharging a warm or hot battery pack will greatly shorten the useful life of the battery. 8. The toy must be used with the recommended transformer. 9. The transformer is not a toy. (DIAGRAM 2)(DIAGRAM 3) PERFORMANCE TIPS FOR VEHICLE • Do not drive car through water. • Be sure to rest your vehicle for at least 30 minutes after every 15 minutes of operation. • Make sure OFF/ON switch on your vehicle is in the “OFF” position when it is not in use. • Do not bend the antenna. • Electrical, CB interference, mobile phones, air conditioning, elevators and steel girders in buildings will affect the operation of your vehicle. • Do not leave the vehicle or transmitter near sources of heat or in direct sunlight for long periods of time. • Remove the batteries from the vehicle and transmitter when they are not in use. • Do not drive car into people or animals. • Do not attempt to sit or ride on product. Serious injury can result. BATTERY CAUTIONS 1. For maximum performance, use alkaline batteries 2. Do not mix old and new batteries 3. Do not mix alkaline, standard (carbon-zinc), or rechargeable batteries 4. Do not recharge non-rechargeable battery 5. Ensure batteries are inserted with the correct polarity 6. Remove batteries when toy is not in use 7. Remove exhausted batteries from toy and dispose of in accordance wit the makers recommendation 8. Rechargeable batteries should only be charged under adult supervision 9. Remove rechargeable batteries from toy before charging 10. The supply terminals are not to be short-circuited 11. The antenna wires are not to be inserted into socket outlet. 12. Rechargeable battery pack is only to be charged by adult. NOT SUITABLE FOR CHILDREN UNDER 3 YEARS OF AGE, DUE TO SMALL PARTS. UNSCREW TO OPEN OFFON ON/OFF switch 9.6V RECHARGEABLE BATTERY PACK HOW TO PLAY 1. Build up antenna by passing the cable through the antenna tube provided and plug into the vehicle tightly. Otherwise, the vehicle will not work. (See Diagram #5) 2. Push the ON/OFF switch to the “ON” position of the vehicle. (See Diagram #6) FORWARD RUNNING 3. Push both the Driving Control Sticks forward for forward running. (See Diagram #7) REVERSE RUNNING 4. Pull both the Driving Control Sticks backward for reverse running. (See Diagram #8) OFFON ON/OFF switch (DIAGRAM 5)(DIAGRAM 6) ANTENNA TUBE CABLE FORWARD FORWARDFORWARDBACKWARDBACKWARD DRIVING CONTROL STICK DRIVING CONTROL STICK (DIAGRAM 7)(DIAGRAM 8) REVERSE STOP OPERATION 9. Release both Driving Control Sticks, the vehicle will Stop. (See Diagram #13) FORWARDBACKWARD RIGHTLEFT FORWARDBACKWARD STOP (DIAGRAM 11)(DIAGRAM 12) (DIAGRAM 13) DRIVING CONTROL STICK DRIVING CONTROL STICK FORWARD RIGHTLEFT FORWARD (DIAGRAM 9)(DIAGRAM 10) DRIVING CONTROL STICK DRIVING CONTROL STICK STEERING OPERATION 5. Push only the Left Driving Control Stick forward to turn Right. (See Diagram #9) 6. Push only the Right Driving Control Stick forward to turn Left. (See Diagram #10) 360 DEGREE SPINS 7. Push the Left Driving Control Stick forward while pulling the Right Driving Control Stick backward at the same time. (See Diagram #11) 8. Push the Right Driving Control Stick forward while pulling the Left Driving Control Stick backward at the same time. (See Diagram #12) © 2013 SCIENTIFIC TOYS LTD. 1108, TOWER B, 14 SCIENCE MUSEUM ROAD, TSIMSHATSUI, HONG KONG. PRINTED IN CHINA O.I. NO.5459 SIZE: 297MM X 242MM PN#65-5459-000-0100 (DIAGRAM 4) (DIAGRAM 1) PRESS BUTTON ON SIDE OF CHARGER TO RELEASE BATTERY PACK WALL OUTLET BATTERY CHARGER 9.6V RECHARGEABLE BATTERY PACK 9.6 V CAUTION- ELECTRIC TOY NOT RECOMMENDED FOR CHILDREN UNDER 6 YEARS OF AGE. AS WITH ALL ELECTRIC PRODUCTS, PRECAUTIONS SHOULD BE OBSERVED DURING HANDLING AND USE TO PREVENT ELECTRIC SHOCK. INPUT: 120VAC, 60HZ 10W ONLY. OUTPUT: 12VDC, 0.2A FCC NOTE: THE ANTENNA PROVIDED IS A UNIQUE ANTENNA. BY INSTALLATION OF UNAUTHORIZED ANTENNA TO THIS EQUIPMENT. SUCH UNAUTHORIZED INSTALLATION COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a pa…

Text truncated - open the document above for the full version.

SEM.Test Compliance Service Co., Ltd. 3/F, Jinbao Commerce Building, Xin’an Fanshen Road, Bao’an District, Shenzhen, P.R. China Letter for Confirmation of the Test Date of Tests: 2013‐04‐10 Applicant Name: Scientific Toys Ltd. FCC ID Number: FCC ID: BY33564‐27PP Name of Engineer to perform the Tests: Lahm Peng (Engineer) Statement for Confirmation of the Tests: Gakkiku Technology Company hired us to perform the tests. We declare that tested sample has been tested in accordance with the test method identified on the test report and our test engineer was performing the tests. We also declare that sample complied with the relevant limits. All instrumentation and accessories were used to test that sample for compliance to the indicated test method and those were calibrated regularly in accordance with ISO 17025: 2005 requirements by laboratories accredited by A2LA, NVLAP or ACLAS for the measurement parameters. The measurements were made at: SEM.Test Compliance Service Co., Ltd. 3/F, Jinbao Commerce Building, Xin'an Fanshen Road, Bao'an District, Shenzhen, P.R. China Representative of the organization performing the tests: Jandy So (Manager) Signature: Email Address: [email protected] Tel No.: +86755‐33663308‐808

Scientific Toys Ltd. Model Number(s)/Item Number(s): 99086 REPORT NUMBER: GKK201304080B PAGE 1 OF 15 PART 15.227 & RSS-310 ISSUE 3 Test Report Applicant Scientific Toys Ltd. Address Rm. 1108, 11/F., Block B, New Mandarin Plaza, 14 Science Museum Road, TST East, Kowloon, Hong Kong FCC ID Number FCC ID: BY33564-27PP Brand Name(s) None Model Number(s)/Item Number(s) 99086, 3564 Product Description 26.96-27.28 MHz Wireless Remote Control Toy - TX Operating Frequency 27.145 MHz Rules/Standards Part 15.227 of the FCC Rules, RSS-310 Issue 3 and RSS-Gen Issue 3 of the Industry Canada Received Date 8th April, 2013 Tested Date 10th April, 2013 Approved by Dick Chan (Director of Gakkiku) Tested by Lahm Peng (Engineer of SEM.Test) Signed by Jandy So (Manager of SEM.Test) Report Number GKK201304080B Test Results PASSED FAILED Gakkiku Technology Company Flat B, 5/F., Selwyn Factory Building, No. 404 Kwun Tong Road, Kwun Tong, Kowloon, Hong Kong Tel: (852) 8113 2281 Fax: (852) 2797 0192 Email: [email protected] Scientific Toys Ltd. Model Number(s)/Item Number(s): 99086 REPORT NUMBER: GKK201304080B PAGE 2 OF 15 PART 15.227 & RSS-310 ISSUE 3 GENERAL The report is written by Gakkiku Technology Company. The tested device complies with the general approval requirements of the FCC Rules and the Industry Canada as identified in this test report. TEST LOCATION The tested device was tested at the test site of the SEM.Test Compliance Service Co., Ltd., 3/F, Jinbao Commerce Building, Xin'an Fanshen Road, Bao'an District, Shenzhen, 518101, Guangdong, China. The FCC Recognized 2.948 Listed Test Firm Registration Number is 994117. The Industry Canada IC OATS Filing Number/Assigned Code is 7673A. Scientific Toys Ltd. Model Number(s)/Item Number(s): 99086 REPORT NUMBER: GKK201304080B PAGE 3 OF 15 PART 15.227 & RSS-310 ISSUE 3 TABLE OF CONTENTS 1. GENERAL INFORMATION ............................................................................................... 4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................... 4 1.2 TEST STANDARDS ....................................................................................................................................... 4 1.3 RELATED SUBMITTAL(S)/GRANT(S) ............................................................................................................ 4 1.4 TEST METHODOLOGY .................................................................................................................................. 5 1.5 EUT EXERCISE SOFTWARE .......................................................................................................................... 5 1.6 ACCESSORIES EQUIPMENT LIST AND DETAILS .............................................................................................. 5 1.7 EUT CABLE LIST AND DETAILS .................................................................................................................... 5 2. SUMMARY OF TEST RESULTS ......................................................................................... 6 3. PART 15.203 & RSS-GEN ISSUE 3 §7.1.2 - ANTENNA REQUIREMENT .............................. 7 3.1 STANDARD APPLICABLE ............................................................................................................................... 7 3.2 TEST RESULT .............................................................................................................................................. 7 4. PART 15.227, 15.209, 15.205 & RSS-310 ISSUE 3 §3.8 - RADIATED EMISSION ................. 8 4.1 MEASUREMENT UNCERTAINTY ................................................................................................................... 8 4.2 STANDARD APPLICABLE .............................................................................................................................. 8 4.3 TEST EQUIPMENT LIST AND DETAILS .......................................................................................................... 8 4.4 TEST PROCEDURE ...................................................................................................................................... 9 4.5 CORRECTED AMPLITUDE & MARGIN CALCULATION ..................................................................................... 9 4.6 ENVIRONMENTAL CONDITIONS................................................................................................................... 9 4.7 SUMMARY OF TEST RESULTS/PLOTS .......................................................................................................... 10 5. PART 15.227(B) & RSS-310 ISSUE 3 §2.4 - OUT OF BAND EMISSIONS ........................... 13 5.1 STANDARD APPLICABLE ............................................................................................................................. 13 5.2 TEST EQUIPMENT LIST AND DETAILS ......................................................................................................... 13 5.3 TEST PROCEDURE ..................................................................................................................................... 13 5.4 ENVIRONMENTAL CONDITIONS .................................................................................................................. 13 5.5 SUMMARY OF TEST RESULTS/PLOTS .......................................................................................................... 14 Scientific Toys Ltd. Model Number(s)/Item Number(s): 99086 REPORT NUMBER: GKK201304080B PAGE 4 OF 15 PART 15.227 & RSS-310 ISSUE 3 1. GENERAL INFORMATION 1.1 Product Description for Equipment Under Test (EUT) Client Information Applicant: Scientific Toys Ltd. Address of applicant: Rm. 1108, 11/F., Block B, New Mandarin Plaza, 14 Science Museum Road, TST East, Kowloon, Hong Kong Manufacturer: Scientific Toys Ltd. Address of manufacturer: Rm. 1108, 11/F., Block B, New Mandarin Plaza, 14 Science Museum Road, TST East, Kow…
