BY34795-27TP26.96-27.28 MHz WIRELESS R/C TOY-TX

FCC PART 15.227 TEST REPORT LOW POWER UNLICENSED TRANSMITTER Applicant SCIENTIFIC TOYS, LTD. Address RM.1108, 11/F., BLOCK B, NEW MANDARIN PLAZA 14 SCIENCE MUSEUM ROAD TST EAST KOWLOON HONG KONG FCC ID BY34795-27TP Product Description 26.96-27.28 MHz WIRELESS R/C TOY - TX Date Sample Received 5/14/2010 Date Tested 5/18/2010 Tested By Nam Nguyen Approved By Mario R. de Aranzeta Timco Report No. 1110HT10TestReport.doc Test Results Pass Fail THE ATTACHED REPORT SHALL NOT BE REPRODUCED EXCEPT IN FULL WITHOUT THE WRITTEN APPROVAL OF TIMCO ENGINEERING, INC. 849 NW STATE ROAD 45 NEWBERRY, FL 32669 USA PH: 888.472.2424 OR 352.472.5500 FAX: 352.472.2030 EMAIL: [email protected] HTTP://WWW.TIMCOENGR.COM Certificate # 0955-01 APPLICANT: SCIENTIFIC TOYS, LTD. FCC ID: BY34795-27TP REPORT: Z:\S\SCIENTIF\1110HT10\1110HT10TestReport.doc Page 2 of 10 mdea 09.20.2007 TABLE OF CONTENTS GENERAL REMARKS .................................................................................................. 3 REPORT SUMMARY .................................................................................................... 4 TEST ENVIRONMENT.................................................................................................. 4 TEST SETUP ............................................................................................................... 4 DUT SPECIFICATION .................................................................................................. 5 TEST EQUIPMENT LIST .............................................................................................. 6 TEST PROCEDURES ................................................................................................... 7 RADIATION INTERFERENCE ....................................................................................... 8 OCCUPIED BANDWIDTH............................................................................................. 9 TEST SET UP PHOTO ................................................................................................ 10 APPLICANT: SCIENTIFIC TOYS, LTD. FCC ID: BY34795-27TP REPORT: Z:\S\SCIENTIF\1110HT10\1110HT10TestReport.doc Page 3 of 10 mdea 09.20.2007 GENERAL REMARKS The attached report shall not be reproduced except in full without the written permission of Timco Engineering Inc. Summary The device under test does: fulfill the general approval requirements as identified in this test report not fulfill the general approval requirements as identified in this test report Attestations This equipment has been tested in accordance with the standards identified in this test report. To the best of my knowledge and belief, these tests were performed using the measurement procedures described in this report. All instrumentation and accessories used to test products for compliance to the indicated standards are calibrated regularly in accordance with ISO 17025 requirements. Testing Certificate # 0955-01 I attest that the necessary measurements were made, under my supervision, at: Timco Engineering Inc. 849 NW State Road 45 Newberry, Fl 32669 Authorized Signatory Name: Mario de Aranzeta C.E.T. Compliance Engineer/ Lab. Supervisor Date: 5/18/2010 APPLICANT: SCIENTIFIC TOYS, LTD. FCC ID: BY34795-27TP REPORT: Z:\S\SCIENTIF\1110HT10\1110HT10TestReport.doc Page 4 of 10 mdea 09.20.2007 REPORT SUMMARY Disclaimer The test results only relate to the item tested. Applicable Rule(s) FCC Pt 15.227, ANSI C63.4: 2003 TEST ENVIRONMENT Test Facility The test sites are located at 849 NW State Road 45 Newberry, FL 32669 USA. Test Condition: Temperature: 26ºC Relative humidity: 50% TEST SETUP Test Exercise (e.g software description, test signal, etc.): The DUT was placed in continuous transmit mode of operation. Deviation from the standard(s) No deviation from the standard(s) Modification to the DUT: No modification was made to the DUT. Supporting Peripheral Equipment Not applicable. The device is a stand-alone remote control radio. APPLICANT: SCIENTIFIC TOYS, LTD. FCC ID: BY34795-27TP REPORT: Z:\S\SCIENTIF\1110HT10\1110HT10TestReport.doc Page 5 of 10 mdea 09.20.2007 DUT SPECIFICATION Applicant SCIENTIFIC TOYS, LTD. Description 26.96-27.28 MHz WIRELESS R/C TOY - TX FCC ID BY34795-27TP Frequency Range 26.96-27.28 MHz DUT Power Source 110–120Vac/50– 60Hz DC Power Battery Operated Exclusively Test Item Prototype Pre-Production Production Type of Equipment Fixed Mobile Portable APPLICANT: SCIENTIFIC TOYS, LTD. FCC ID: BY34795-27TP REPORT: Z:\S\SCIENTIF\1110HT10\1110HT10TestReport.doc Page 6 of 10 mdea 09.20.2007 TEST EQUIPMENT LIST Device Manufacturer Model Serial Number Cal/Char Date Due Date 3-Meter Semi- Anechoic Chamber Panashield N/A N/A Listed 03/10/10 03/10/12 Analyzer Tan Tower Quasi-Peak Adapter HP 85650A 3303A01690 CAL 11/22/09 11/22/11 Analyzer Tan Tower RF Preselector HP 85685A 3221A01400 CAL 11/21/09 11/21/11 Analyzer Tan Tower Spectrum Analyzer HP 8566B Opt 462 3138A07786 3144A20661 CAL 11/24/09 11/24/11 Analyzer Tan Tower Preamplifier HP 8449B-H02 3008A00372 CAL 11/21/09 11/21/11 Coaxial Cable #64 Semflex Inc. 60637 Timco #64 CHAR 3/30/09 3/30/11 Antenna: Dipole Kit Electro-Metrics TDA-30/1- 4 152 CAL 3/3/09 3/3/12 Antenna: Dipole Kit Electro-Metrics TDA-30/1- 4 153 CHAR 4/5/09 4/5/12 Hygro- Thermometer Extech 445703 0602 CAL 1/30/09 1/30/11 Modulation Analyzer HP 8901A 3435A06868 CAL 5/9/09 5/9/11 Digital Multimeter Fluke FLUKE-77- 3 79510405 CAL 5/14/09 5/14/11 Antenna: Passive Loop EMC Test Systems EMCO 6512 9706-1211 CAL. 6/1/09 6/2/11 APPLICANT: SCIENTIFIC TOYS, LTD. FCC ID: BY34795-27TP REPORT: Z:\S\SCIENTIF\1110HT10\1110HT10TestReport.doc Page 7 of 10 mdea 09.20.2007 TEST PROCEDURES Radiated Spurious Emissions: The test procedure used was ANSI C63.4-2003 using a spectrum analyzer with a preselector. The bandwidth of the spectrum analyzer was 100 kHz with an appropriate sweep speed. The analyzer was calibrated in dB above a microvolt at the output of the antenna. The resolution bandwidth was 100 …
