BY34916-49PA49.82-49.90 MHz WIRELESS REMOTE CONTROL TOY-RX

©2013. RadioShack Corporation. All rights reserved. RadioShack is a registered trademark used by RadioShack Corporation. 06A13 6000926 Printed in China 6000926 1:8 Monster Wheel 4x4 Charge the Truck Battery Pack 1. Plug the battery charger into a standard AC outlet. 2. Connect the battery pack and the charger together by snapping the connectors tightly. 3. Allow 2 hours for each charge. The charging indicator flashes during charging. It stops flashing and stays on in green when charging is complete. 4. Unplug the charger and pull apart the battery connectors when fully charged. When fully charged, the truck can run 10 – 15 minutes. w Caution: • To avoid damage and personal injury, use only the supplied charger to charge the battery pack. • After playing, wait at least 20 minutes to let the battery pack cool before charging it. Install the Antenna Tube 1. Thread the truck’s antenna wire through the supplied antenna tube. 2. Insert the tube into the antenna hole on the truck’s body. 3. Tie a loose knot to hold the antenna wire in place. 1. Turn on the truck. 2. Operate the truck with the transmitter. • Push both the right and left control sticks forward or reverse to drive in a straight line. • Push either the right or left control stick to turn. • Push one control stick forward and the other in reverse to spin. 3. Turn off the truck when you finish driving. Thank you for purchasing your 1:8 Monster Wheel 4×4 from RadioShack. Please read this user’s guide before using your new truck. What’s Included • 1:8 Monster Wheel 4×4 • Transmitter • Battery Pack • Charger • Antenna Tube (2) • User’s Guide Features • Oversized tires for better traction • Up to 400 feet (122 m) per minute • Off road Specifications Input ...............................120 V AC, 60 Hz, 10 W Output ....................................12 V DC, 350 mA Control Distance ........................100 feet (31 m) Climbing Angle ................................30 degrees Band ...............................................27 or 49 MHz Specifications are subject to change and improvement without notice. Actual product may vary from the images found in this document. FCC Information This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult your local RadioShack store or an experienced radio/TV technician for help. If you cannot eliminate the interference, the FCC requires that you stop using your equipment. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Limited Warranty RadioShack warrants this product against defects in materials and workmanship under normal use by the original purchaser for ninety (90) days after the date of purchase from a RadioShack-owned store or an authorized RadioShack franchisee or dealer. RADIOSHACK MAKES NO OTHER EXPRESS WARRANTIES. This warranty does not cover: (a) damage or failure caused by or attributable to abuse, misuse, failure to follow instructions, improper installation or maintenance, alteration, accident, Acts of God (such as floods or lightning), or excess voltage or current; (b) improper or incorrectly performed repairs by persons who are not a RadioShack Authorized Service Facility; (c) consumables such as fuses or batteries; (d) ordinary wear and tear or cosmetic damage; (e) transportation, shipping or insurance costs; (f) costs of product removal, installation, set-up service, adjustment or reinstallation; and (g) claims by persons other than the original purchaser. Should a problem occur that is covered by this warranty, take the product and the RadioShack sales receipt as proof of purchase date to any RadioShack store in the U.S. RadioShack will, at its option, unless otherwise provided by law: (a) repair the product without charge for parts and labor; (b) replace the product with the same or a comparable product; or (c) refund the purchase price. All replaced parts and products, and products on which a refund is made, become the property of RadioShack. New or reconditioned parts and products may be used in the performance of warranty service. Repaired or replaced parts and products are warranted for the remainder of the original warranty period. You will be charged for repair or replacement of the product made after the expiration of the warranty period. RADIOSHACK EXPRESSLY DISCLAIMS ALL WARRANTIES AND CONDITIONS NOT STATED IN THIS LIMITED WARRANTY. ANY IMPLIED WARRANTIES THAT MAY BE IMPOSED BY LAW, INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY AND, IF APPLICABLE, THE IMPLIED WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE, SHALL EXPIRE ON THE EXPIRATION OF THE STATED WARRANTY PERIOD. EXCEPT AS DESCRIBED ABOVE, RADIOSHACK SHALL HAVE NO LIABILITY OR RESPONSIBILITY TO THE PURCHASER…

Text truncated - open the document above for the full version.

Shenzhen SEM.Test Technology Co., Ltd. 1/F, Building A, Hongwei Industrial Park, Liuxian 2nd Road, Bao'an District, Shenzhen, 518101, Guangdong, China Letter for Confirmation of the Test Date of Test: 2014‐3‐10 Applicant Name: Scientific Toys Ltd. FCC ID Number: FCC ID: BY34916‐49PA Name of Engineer to perform the Test: Lahm Peng (Engineer) Statement for Confirmation of the Test: Gakkiku Technology Company hired us to perform the test. We declare that tested sample has been tested in accordance with the test method identified on the test report and our test engineer was performing the test. We also declare that sample complied with the relevant limits. All instrumentation and accessories were used to test that sample for compliance to the indicated test method and those were calibrated regularly in accordance with ISO 17025: 2005 requirements by laboratories accredited by A2LA, NVLAP or ACLAS for the measurement parameters. The measurements were made at: Shenzhen SEM.Test Technology Co., Ltd. 1/F, Building A, Hongwei Industrial Park, Liuxian 2nd Road, Bao'an District, Shenzhen, 518101, Guangdong, China Representative of the organization performing the test: Jandy So (Manager) Signature: Email Address: [email protected] Tel No.: +86755‐33663308‐808

Scientific Toys Ltd. Model Number(s)/Catalog Number(s): 99924 REPORT NUMBER: GKK201403080B PAGE 1 OF 10 PART 15.109 & RSS-310 ISSUE 3 Test Report Applicant Scientific Toys Ltd. Address Rm. 1108, 11/F., Block B, New Mandarin Plaza, 14 Science Museum Road, TST East, Kowloon, Hong Kong FCC ID Number FCC ID: BY34916-49PA Brand Name(s) None Model Number(s)/ Catalog Number(s) 99924, 99926, 99927, 99928, 99929, 99932, 99086, 99088, 99099, 97038, BY34916-49PA, 6001050, 6000926 Product Description 49.82-49.90 MHz Wireless Remote Control Toy - RX Operating Frequency 49.860 MHz Rules/Standards Part 15.109 of the FCC Rules, RSS-310 Issue 3 and RSS-Gen Issue 3 of the Industry Canada Received Date 8th March, 2014 Tested Date 10th March, 2014 Approved by Dick Chan (Director of Gakkiku) Tested by Lahm Peng (Engineer of Shenzhen SEM.Test) Signed by Jandy So (Manager of Shenzhen SEM.Test) Report Number GKK201403080B Test Results PASSED FAILED Gakkiku Technology Company Flat B, 5/F., Selwyn Factory Building, No. 404 Kwun Tong Road, Kwun Tong, Kowloon, Hong Kong Tel: (852) 8113 2281 Fax: (852) 2797 0192 Email: [email protected] Scientific Toys Ltd. Model Number(s)/Catalog Number(s): 99924 REPORT NUMBER: GKK201403080B PAGE 2 OF 10 PART 15.109 & RSS-310 ISSUE 3 GENERAL The report is written by Gakkiku Technology Company. The tested device complies with the general approval requirements of the FCC Rules and the Industry Canada as identified in this test report. TEST LOCATION The tested device was tested at the test site of the Shenzhen SEM.Test Technology Co., Ltd., 1/F, Building A, Hongwei Industrial Park, Liuxian 2nd Road, Bao'an District, Shenzhen, 518101, Guangdong, China. The FCC Recognized 2.948 Listed Test Firm Registration Number is 934118. The Industry Canada IC OATS Filing Number/Assigned Code is 11464A. Scientific Toys Ltd. Model Number(s)/Catalog Number(s): 99924 REPORT NUMBER: GKK201403080B PAGE 3 OF 10 PART 15.109 & RSS-310 ISSUE 3 TABLE OF CONTENTS 1. GENERAL INFORMATION ............................................................................................... 4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................... 4 1.2 TEST STANDARDS ....................................................................................................................................... 4 1.3 TEST METHODOLOGY ................................................................................................................................. 4 1.4 EUT EXERCISE SOFTWARE .......................................................................................................................... 5 1.5 ACCESSORIES EQUIPMENT LIST AND DETAILS ............................................................................................... 5 1.6 EUT CABLE LIST AND DETAILS .................................................................................................................... 5 2. SUMMARY OF TEST RESULTS ......................................................................................... 6 3. PART 15.109(A) & RSS-310 ISSUE 3 §3.1 - RADIATED EMISSION ..................................... 7 3.1 MEASUREMENT UNCERTAINTY .................................................................................................................... 7 3.2 TEST EQUIPMENT LIST AND DETAILS ........................................................................................................... 7 3.3 TEST PROCEDURE ....................................................................................................................................... 7 3.4 TEST RECEIVER SETUP ............................................................................................................................... 8 3.5 CORRECTED AMPLITUDE & MARGIN CALCULATION ..................................................................................... 8 3.6 ENVIRONMENTAL CONDITIONS ................................................................................................................... 8 3.7 SUMMARY OF TEST RESULTS/PLOTS ........................................................................................................... 8 Scientific Toys Ltd. Model Number(s)/Catalog Number(s): 99924 REPORT NUMBER: GKK201403080B PAGE 4 OF 10 PART 15.109 & RSS-310 ISSUE 3 1. GENERAL INFORMATION 1.1 Product Description for Equipment Under Test (EUT) Client Information Applicant: Scientific Toys Ltd. Address of applicant: Rm. 1108, 11/F., Block B, New Mandarin Plaza, 14 Science Museum Road, TST East, Kowloon, Hong Kong Manufacturer: Scientific Toys Ltd. Address of manufacturer: Rm. 1108, 11/F., Block B, New Mandarin Plaza, 14 Science Museum Road, TST East, Kowloon, Hong Kong General Description of EUT Item Description Product Description: 49.82-49.90 MHz Wireless Remote Control Toy - RX Brand Name(s): None Model Number(s)/ Catalog Number(s): 99924, 99926, 99927, 99928, 99929, 99932, 99086, 99088, 99099, 97038, BY34916-49PA, 6001050, 6000926 Power Source: DC 9.6V Rechargeable Battery Pack Rated Current: / For more information refer to the circuit diagram form and the user’s manual. The test data is gathered from a production sample, provided by the manufacturer. 1.2 Test Standards The following report is prepared on behalf of the Scientific Toys Ltd. in accordance with Part 2 Subpart J and Part 15 Subparts B of the FCC Rules. The objective is to determine compliance with Part 15.109 of the FCC Rules and RSS-310 Issue 3 & RSS-Gen Issue 3 of the Industry Canada. Maintenance of compliance is the responsibility of the manufacturer. Any modification of the product, which results in lowering the emission/immunity, should be checked to ensure compliance has been maintained. 1.3 Test Methodology All measurements contained in this report were conducted with ANSI Standard C63.4-2009, American National Standard Institute for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrica…
