BY39713-49RR/C Car

Printed in China 12A14 6001324 ©2014 RadioShack Corporation. All rights reserved. RadioShack is a registered trademark used by RadioShack Corporation. Install Battery in the Remote Control 1. Turn off the Tri-Runner. 2. Use a screwdriver to open the remote control’s battery compartment cover. 3. Insert one 9V battery (not included) matching the polarity symbols (+ and –) marked inside. 4. Replace the battery cover and secure it with the screw. Install Batteries in the Tri-Runner 1. Turn off the Tri-Runner. 2. Use a screwdriver to open the battery cover, then insert 8 AA batteries, matching the polarity symbols (+ and –) marked inside the compartment. 3. Replace the battery cover and secure it with the screw. RC Tri-Runner We hope you enjoy your RC Tri-Runner from RadioShack. Please read this user’s guide before setting up and using your Tri-Runner. What’s Included • RC Tri-Runner • Remote Control • User’s Guide Age 6+ Specif ications Speed .......................................up to 600 ft/min (183m/min) Control Distance ...................................................90 ft (27 m) Climbing Angle .......................................................................15° Specifications are subject to change and improvement without notice. Actual product may vary from the images found in this document. Safety and Care • Not recommended for children under 6 years of age. Adult supervision is recommended at all times. • Do not use your Tri-Runner near transmitters with the same frequency (27 or 49 MHz). • A nearby CB radio can interfere with your Tri- Runner. If this happens, move the Tri-Runner away from the CB radio. • Never play with your Tri-Runner in the street. • Avoid high-impact collisions with people and objects. WaRnIng: CHOKIng HaZaRD – Small parts. not for children under 3 years. Batter y Notes • Use only fresh batteries of the required size and type. Dispose of batteries promptly and properly. Do not burn or bury them. • Do not mix old and new batteries, different types of batteries (standard, alkaline or rechargeable), or rechargeable batteries of different capacities. • If you do not plan to use the Tri-Runner for a long period, remove the batteries from both the Tri- Runner and remote control . Batteries can leak chemicals that can destroy electronic parts. Limited Warranty RadioShack warrants this product against defects in materials and workmanship under normal use by the original purchaser for ninety (90) days after the date of purchase from a RadioShack- owned store or an authorized RadioShack franchisee or dealer. RADIOSHACK MAKES NO OTHER EXPRESS WARRANTIES. This warranty does not cover: (a) damage or failure caused by or attributable to abuse, misuse, failure to follow instructions, improper installation or maintenance, alteration, accident, Acts of God (such as floods or lightning), or excess voltage or current; (b) improper or incorrectly performed repairs by persons who are not a RadioShack Authorized Service Facility; (c) consumables such as fuses or batteries; (d) ordinary wear and tear or cosmetic damage; (e) transportation, shipping or insurance costs; (f) costs of product removal, installation, set-up service, adjustment or reinstallation; and (g) claims by persons other than the original purchaser. Should a problem occur that is covered by this warranty, take the product and the RadioShack sales receipt as proof of purchase date to any RadioShack store in the U.S. RadioShack will, at its option, unless otherwise provided by law (a) replace the product with the same or a comparable product, or (b) refund the purchase price. All replaced products, and products on which a refund is made, become the property of RadioShack. RADIOSHACK EXPRESSLY DISCLAIMS ALL WARRANTIES AND CONDITIONS NOT STATED IN THIS LIMITED WARRANTY. ANY IMPLIED WARRANTIES THAT MAY BE IMPOSED BY LAW, INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY AND, IF APPLICABLE, THE IMPLIED WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE, SHALL EXPIRE ON THE EXPIRATION OF THE STATED WARRANTY PERIOD. EXCEPT AS DESCRIBED ABOVE, RADIOSHACK SHALL HAVE NO LIABILITY OR RESPONSIBILITY TO THE PURCHASER OF THE PRODUCT OR ANY OTHER PERSON OR ENTITY WITH RESPECT TO ANY LIABILITY, LOSS OR DAMAGE CAUSED DIRECTLY OR INDIRECTLY BY USE OR PERFORMANCE OF THE PRODUCT OR ARISING OUT OF ANY BREACH OF THIS WARRANTY, INCLUDING, BUT NOT LIMITED TO, ANY DAMAGES RESULTING FROM INCONVENIENCE AND ANY LOSS OF TIME, DATA, PROPERTY, REVENUE, OR PROFIT AND ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, EVEN IF RADIOSHACK HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. You may contact RadioShack at: RadioShack Customer Relations 300 RadioShack Circle Fort Worth, TX 76102 02/14 www.RadioShack.com FCC Information This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the…

Text truncated - open the document above for the full version.

1 2 3 4 ABCD 4 3 2 1 D CBA Title Number Revision Size A Date: 14-Nov-2014 Sheet of File: I:\I\SM\97136\97136\97136.Ddb Drawn By: ANTENNA FORWARD / BACKWARD MOTOR 1DRIVING CIRCUIT Q2,3 BLOCK DIAGRAM OF RECEIVER 49MHz BY39713-49R A 1 1 K ONG DECODER IC U1 SUPERREGENERATION 49.860MHz Q1 LEFT / RIGHT MOTOR 2 DRIVING CIRCUIT Q6,7,8,9,10,11,12,13,14 M1MOTOR 1 M2MOTOR 2

External Photos

Label Artwork and Location Label Size: 62mm(W) x 15mm(H) 200% 100% 15 x 62mm (Label) 49MHz for Vehicle SKU: 6001324 RC TRI-RUNNER Power: 8 × AA 1 × 9V 01A 15 RC Tri-Runner Catalog No. 6001324 Custom Manufactured in Shenzhen, China for RadioShack Corporation Fort Worth, TX 76102 FCC ID: BY39713-49R batteries for RX battery for TX This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. PAGE 2 OF 2

Internal Photos

RX Technical description Description Function Component Antenna Receive the RF signal ANTENNA Super- regenerative receiver Select the RF signal (49.860MHz) Q1 and associated circuit RF IC Decode the RF signal to Motor Driver U1 Motor Driver 1 Drive the Motor Q2, Q3 Motor Driver 2 Drive the Motor Q6,Q7,Q8,Q9,Q10,Q11,Q12,Q13,Q14 Type of antenna: Integral antenna

1 2 3 4 5 6 ABCD 6 5 4 3 2 1 D CBA Title Number Revision Size B Date: 22-Dec-2014 Sheet of File: I:\I\SM\97136\97136\97136.Ddb Drawn By: R24470 M2 R31270 R30 270 R28 2.2K R372.2K SW1 ON/OFF BATT C21 0.1uF R16 15ohm /2W D10 1N4148 D13 1N4148 D14 1N4148 D15 1N4148 D17 1N4148 D16 1N4148 D18 1N4148 R383.3K R325.6K R352.7K R34 1K R33 1M R36390K D11 1N4148 D12 1N4148 E B C A F G D K J DICK R/C RX 49MHz 1234567 CON2 E BCA F GD A R271K Q28050 Q3 8050 Q12 8050D Q6 9013 Q13 8050D Q14 9013 Q9 9013 Q7 8550D Q8 8550D Q10 8550D Q11 8550D VDD VCC R294.7K BY39713-49R L4 L5 H IJ K ZD1 3V VCC C5 10PF L2 C6 10p C1 47pF Q1 C380O L1C10 272M C11 4.7uF C2 103M C3 103M C7104 C8 104 C12100P C9 100pF TL106B E1ANTENNA 49.860M R33K3 R1150K R101K2 R4100 R23K3 R51M R6100KR73M9 R93K3 R8200K + C4220uF C130.1uF VCC + C17 2200uF + C18 470uF JP30 M1 H I C15104 C14104CA104 CB104 CC104 CD104 LA LB D1 1N4001 D21N4001 R13100 R12100 R211K 21 RE1ABS-115C 3 54 RE1BBS-115C 21 RE2ABS-115C 3 54 RE2BBS-115C VDD R11100 R14100 L30 OHM JP80 OHM 1 1 1 2 3 4 5 6 78 9 10 11 12 13 14 U1 ICDE 206 JP1Jumper 12.0V 6.8uH

• The test results reported in this test report shall refer only to the sample actually tested and shall not refer or be deemed to refer to bulk from which such a sample may be said to have been obtained. • This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to copy or distribute this report. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results referenced from this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. • For Terms And Conditions of the services, it can be provided upon request. • The evaluation data of the report will be kept for 3 years from the date of issuance. TRF No.: FCC 15C_RX_b Intertek Testing Services Shenzhen Ltd. Kejiyuan Branch 6F , D Block, Huahan Building, Langshan Road, Nanshan District, Shenzhen, P. R. China Tel: (86 755) 8601 6288 Fax: (86 755) 8601 6751 SCIENTIFIC TOYS LIMITED Ap plication For Certification FCC ID: BY39713-49R R/C Car Model: 6001324 Additional Models: 97136,21820 (21821,21822,21823,21824, 21825,21826,21827,21828,21829,21830,21831-21850,21424,94440), 28035,21882,21884,98880,24920,21883,97121,21821,21425,21475, 21478,99056,22102,22115,22103,22113,21116,26117,21110,21218, 98790,98781,99660,95555,95551,95558,95559,95167,95261,21936, 24931,21937,24938,99037,99049,25929,25939,20017,20057,22004, 22009,21448,21959,22958,23810,97217,21867,21880,21870,21860, 21878, 21865, 99918, 99927, 99099, 99085,97138,97038,97039, 97138, 25929, 25939, 25919, 25949, 25959 Superregenerative Receiver Report No.: SZHH00926172-001 Pr epared and Checked by: Approved by: S ign on file Powell Bao Engineer Andy Yan S enior Project Engineer Date: January 13, 2015 INTERTEK TESTING SERVICES Report No.: SZHH00926172-001 FCC ID: BY39713-49R TRF No.: FCC 15C_RX_b i G ENERAL INFORMATION SCIENTIFIC TOYS LIMITED Model: 6001324 FCC ID: BY39713-49R G rantee: SCIENTIFIC TOYS LIMITED Grantee Address: Rm. 1108, 11/F.,Block B, New Mandarin Plaza 14 Science Museum Road,TST East Kowloon,HongKong Contact Person: Muk Shui Leung Tel: 852-25573202 Manufacturer: SCIENTIFIC TOYS LIMITED Manufacturer Address: Rm. 1108, 11/F.,Block B, New Mandarin Plaza 14 Science Museum Road,TST East Kowloon,HongKong Model: 6001324 Type of EUT: Superregenerative Receiver Description of EUT: R/C Car Serial Number: N/A FCC ID : BY39713-49R Date of Sample Submitted: January 4, 2015 Date of Test: January 4, 2015 Report No.: SZHH00926172-001 Report Date: January 13, 2015 Environmental Conidtions: Temperature: +10 to 40°C Humidity: 10 to 90% INTERTEK TESTING SERVICES Report No.: SZHH00926172-001 FCC ID: BY39713-49R TRF No.: FCC 15C_RX_b ii SUMMARY OF TEST RESULT S CIENTIFIC TOYS LIMITED Model: 6001324 FCC ID: BY39713-49R TEST SPECIFICATION REFERENCE RESULTS Maximum Peak Output Power 15.247(b), (c) / RSS-210 A8.4 N/A Hopping Channel Carrier Frequencies Separation (for 2.4GHz Digital) 15.247(e) / RSS-210 A8.1 N/A 20dB Bandwidth of the Hopping Channel 15.247(a) / RSS-210 A8.1 N/A Number of Hopping Frequencies 15.247(e) / RSS-210 A8.1 N/A Average Time of Occupancy of Hopping Frequency 15.247(e) / RSS-210 A8.1 N/A Anteann Conducted Spurious Emissions 15.247(d) / RSS-210 A8.5 N/A Radiated Spurious Emissions 15.247(d) / RSS-210 A8.5 N/A RF Exposure Compliance 15.247(i) / RSS-Gen 5.5 N/A Transmitter Power Line Conducted Emissions 15.207 / RSS-Gen 7.2.2 N/A Transmitter Field Strength (for 27MHz) 15.227 / RSS-310 3.8 N/A Transmitter Field Strength (for 40MHz) 15.229 / RSS-210 A2.7 N/A Transmitter Field Strength, Bandwidth and Timing Requirement 15.231(a) / RSS-210 A1.1.1 N/A Transmitter Field Strength, Bandwidth and Timing Requirement (for 433MHz) 15.231(e) / RSS-210 A1.1.5 N/A Transmitter Field Strength and Bandwidth Requirement(for 88-108MHz) 15.239 / RSS-210 A2.8 N/A Transmitter Field Strength and Bandwidth Requirement 15.249 / RSS-210 A2.9 N/A Transmitter Field Strength and Bandwidth Requirement (for 49MHz) 15.235 / RSS-310 3.9 N/A Receiver / Digital Device Radiated Eissions 15.109 / RSS-310 3.1 Pass Digital Device Conducted Emissions 15.107 / ICES-003 N/A INTERTEK TESTING SERVICES Report No.: SZHH00926172-001 FCC ID: BY39713-49R TRF No.: FCC 15C_RX_b iii T able of Contents 1.0 General Description ....................................................................................... 1 1.1 Product Description .......................................................................................... 1 1.2 Related Submittal(s) Grants.............................................................................. 1 1.3 Test Methodology ............................................................................................. 1 1.4 Test Facility ...................................................................................................... 1 2.0 System Test Configuration ............................................................................ 2 2.1 Justification ...................................................................................................... 2 2.2 EUT Exercising Software .................................................................................. 2 2.3 Special Accessories ......................................................................................... 2 2.4 Equipment Modification .................................................................................... 2 2.5 Measurement Uncertainty....................................…

Text truncated - open the document above for the full version.

Radiated Photos
