BY39946-49P49.82-49.90 MHz WIRELESS REMOTE CONTROL TOY-RX

SEM.Test Compliance Service Co., Ltd. 3/F, Jinbao Commerce Building, Xin’an Fanshen Road, Bao’an District, Shenzhen, P.R. China Letter for Confirmation of the Test Date of Tests: 2013‐05‐29 Applicant Name: Scientific Toys Ltd. FCC ID Number: FCC ID: BY39946‐49P Name of Engineer to perform the Tests: Lahm Peng (Engineer) Statement for Confirmation of the Tests: Gakkiku Technology Company hired us to perform the tests. We declare that tested sample has been tested in accordance with the test method identified on the test report and our test engineer was performing the tests. We also declare that sample complied with the relevant limits. All instrumentation and accessories were used to test that sample for compliance to the indicated test method and those were calibrated regularly in accordance with ISO 17025: 2005 requirements by laboratories accredited by A2LA, NVLAP or ACLAS for the measurement parameters. The measurements were made at: SEM.Test Compliance Service Co., Ltd. 3/F, Jinbao Commerce Building, Xin'an Fanshen Road, Bao'an District, Shenzhen, P.R. China Representative of the organization performing the tests: Jandy So (Manager) Signature: Email Address: [email protected] Tel No.: +86755‐33663308‐808

Product: 49MHz RECEIVER NO.DescriptionLocationQtyUnit 1 RECEIVER 2 ELECT-CAP. 100uF +/-20% 50VC8,102 PCS 3 SMD 0603 4.7uF +80--20% 50VC111 PCS 4 SMD 0603 0.02uF +/--10% 50VC12,C132 PCS 5 SMD 0603 10K +/-5% 0.1W R3,R4,R5,R12,R21,R226 PCS 6 SMD 0603 3.3K +/-5% 0.1W R6,R7,R113 PCS 7 SMD 1206 3.3K +/-5% 0.25W R91 PCS 8 SMD 0603 1K +/-5% 0.1W R8,R102 PCS 9 SMD 0603 12K +/-5% 0.1W R131 PCS 10 SMD 0603 680 +/-5% 0.1W R14,R202 PCS 11 SMD 1206 270 +/-5% 0.25W R15,R16,R18,R234 PCS 12 SMD 0603 10 +/-5% 2W R171 PCS 13 SMD 0603 560K +/-5% 0.1W R191 PCS 14 RESISTOR 0.25 OHM +/-5% 5W R241 PCS 15 SMD 1206 0 +/-5% 0.25W JP2,JP3,JP4,JP54 PCS 16 JUMPER 2" D=0.5mmJP71 PCS 17 SMD D0-213 LL4148 DIODED1,D22 PCS 18 SMD SOD-123 2.7V ZENER DIODE ZD11 PCS 19 SMD SOD-123 4.7V ZENER DIODE ZD21 PCS 20 SMD SOP-8 4435 30VQ1,Q22 PCS 21 SMD SOT-23 8050M TRANSISTORQ3,Q4,Q7,Q8,Q12,Q13,Q157 PCS 22 SMD SOP-8 4468 30VQ5,Q62 PCS 23 SMD SOT-23 8550M TRANSISTORQ9,Q102 PCS 24 SMD SOT-23 9013 TRANSISTORQ11,Q142 PCS 25 WAFER JM24182-02CON11 PCS 26 WAFER 2139-04CON21 PCS 27 SMD SOP-8 555U21 PCS 28 D0-9946-32 SNTPCB1 PCS 29 TUNE COIL 0.7uH L11 PCS 20 SMD 0603 22PF +/-5% 50VC1,C22 PCS 31 SMD 0603 0.1uF +80-20% 50VC3,C72 PCS 32 SMD 0603 100PF +/-5% 50VC41 PCS 33 SMD 0603 0.047uF +/-20% 50VC51 PCS 34 ELECT-CAP. 10uF +/-20% 50VC91 PCS 35 SMD 0603 19.1K +/-1% 0.1W R11 PCS 36 SMD 0603 47K +/-5% 0.1W R21 PCS 37 "Winbond" IC DICE W55RFS27R1BU11 PCS 38 D0-9544-612 SNTCPCB1 PCS Bill of Materials 列印日期: 18/6/20130:33第1/1頁

Scientific Toys Ltd. Model Number(s)/Item Number(s): 99467 REPORT NUMBER: GKK201305290A PAGE 1 OF 10 PART 15.109 & RSS-310 ISSUE 3 Test Report Applicant Scientific Toys Ltd. Address Rm. 1108, 11/F., Block B, New Mandarin Plaza, 14 Science Museum Road, TST East, Kowloon, Hong Kong FCC ID Number FCC ID: BY39946-49P Brand Name(s) None Model Number(s)/Item Number(s) 99467, 98866, 98867, 98877, 99357 Product Description 49.82-49.90 MHz Wireless Remote Control Toy - RX Operating Frequency 49.860 MHz Rules/Standards Part 15.109 of the FCC Rules, RSS-310 Issue 3 and RSS-Gen Issue 3 of the Industry Canada Received Date 29th May, 2013 Tested Date 30th May, 2013 Approved by Dick Chan (Director of Gakkiku) Tested by Lahm Peng (Engineer of SEM.Test) Signed by Jandy So (Manager of SEM.Test) Report Number GKK201305290A Test Results PASSED FAILED Gakkiku Technology Company Flat B, 5/F., Selwyn Factory Building, No. 404 Kwun Tong Road, Kwun Tong, Kowloon, Hong Kong Tel: (852) 8113 2281 Fax: (852) 2797 0192 Email: [email protected] Scientific Toys Ltd. Model Number(s)/Item Number(s): 99467 REPORT NUMBER: GKK201305290A PAGE 2 OF 10 PART 15.109 & RSS-310 ISSUE 3 GENERAL The report is written by Gakkiku Technology Company. The tested device complies with the general approval requirements of the FCC Rules and the Industry Canada as identified in this test report. TEST LOCATION The tested device was tested at the test site of the SEM.Test Compliance Service Co., Ltd., 3/F, Jinbao Commerce Building, Xin'an Fanshen Road, Bao'an District, Shenzhen, 518101, Guangdong, China. The FCC Recognized 2.948 Listed Test Firm Registration Number is 994117. The Industry Canada IC OATS Filing Number/Assigned Code is 7673A. Scientific Toys Ltd. Model Number(s)/Item Number(s): 99467 REPORT NUMBER: GKK201305290A PAGE 3 OF 10 PART 15.109 & RSS-310 ISSUE 3 TABLE OF CONTENTS 1. GENERAL INFORMATION ............................................................................................... 4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................... 4 1.2 TEST STANDARDS ....................................................................................................................................... 4 1.3 TEST METHODOLOGY ................................................................................................................................. 4 1.4 EUT EXERCISE SOFTWARE .......................................................................................................................... 5 1.5 ACCESSORIES EQUIPMENT LIST AND DETAILS ............................................................................................... 5 1.6 EUT CABLE LIST AND DETAILS .................................................................................................................... 5 2. SUMMARY OF TEST RESULTS ......................................................................................... 6 3. PART 15.109(A) & RSS-310 ISSUE 3 §3.1 - RADIATED EMISSION ..................................... 7 3.1 MEASUREMENT UNCERTAINTY .................................................................................................................... 7 3.2 TEST EQUIPMENT LIST AND DETAILS ........................................................................................................... 7 3.3 TEST PROCEDURE ....................................................................................................................................... 7 3.4 TEST RECEIVER SETUP ............................................................................................................................... 8 3.5 CORRECTED AMPLITUDE & MARGIN CALCULATION ..................................................................................... 8 3.6 ENVIRONMENTAL CONDITIONS ................................................................................................................... 8 3.7 SUMMARY OF TEST RESULTS/PLOTS ........................................................................................................... 8 Scientific Toys Ltd. Model Number(s)/Item Number(s): 99467 REPORT NUMBER: GKK201305290A PAGE 4 OF 10 PART 15.109 & RSS-310 ISSUE 3 1. GENERAL INFORMATION 1.1 Product Description for Equipment Under Test (EUT) Client Information Applicant: Scientific Toys Ltd. Address of applicant: Rm. 1108, 11/F., Block B, New Mandarin Plaza, 14 Science Museum Road, TST East, Kowloon, Hong Kong Manufacturer: Scientific Toys Ltd. Address of manufacturer: Rm. 1108, 11/F., Block B, New Mandarin Plaza, 14 Science Museum Road, TST East, Kowloon, Hong Kong General Description of EUT Item Description Product Description: 49.82-49.90 MHz Wireless Remote Control Toy - RX Brand Name(s): None Model Number(s)/Item Number(s): 99467, 98866, 98867, 98877, 99357 Power Source: DC 9.6V Ni-MH Rechargeable Battery Pack Rated Current: / For more information refer to the circuit diagram form and the user’s manual. The test data is gathered from a production sample, provided by the manufacturer. 1.2 Test Standards The following report is prepared on behalf of the Scientific Toys Ltd. in accordance with Part 2 Subpart J and Part 15 Subparts B of the FCC Rules. The objective is to determine compliance with Part 15.109 of the FCC Rules and RSS-310 Issue 3 & RSS-Gen Issue 3 of the Industry Canada. Maintenance of compliance is the responsibility of the manufacturer. Any modification of the product, which results in lowering the emission/immunity, should be checked to ensure compliance has been maintained. 1.3 Test Methodology All measurements contained in this report were conducted with ANSI Standard C63.4-2009, American National Standard Institute for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the range of 9 kHz to 40 GHz. The equipment under test (EUT) was configured to measure its highest possible susceptibility against the tested phenomen…
