BY3E891-27TP26.96-27.28 MHz WIRELESS REMOTE CONTROL TOY-TX

O.I. NO. 5383 #94440 BATTERY LOADING: (FOR MAXIMUM PERFORMANCE, USE ALKALINE BATTERIES) Remember to take out all batteries from the vehicle and transmitter after playing. 1. Do not mix old and new batteries. 2. Do not mix alkaline, standard (Carbon-Zinc), or rechargeable (nickel metal hydride) batteries. HOW TO INSTALL BATTERIES IN BOAT 1. Remove boat top. (See Diagram 1) 2. Push the ON/OFF to "OFF" position. (See Diagram 2) 3. Insert 5 “AA”(LR6) batteries by matching the (+) and (–) signs as indicated in the battery compartment. (See Diagram 2) 4. Replace the battery cover. HOW TO INSTALL BATTERY IN TRANSMITTER 1. Slide to open the battery cover at the back of the transmitter and put a 9-volt battery inside following the engraved signs. (See Diagram 3) 2. Replace the battery cover. NOTE: REMOVE BATTERY AFTER YOU HAVE FINISHED USING YOUR VEHICLE. OPERATING INSTRUCTIONS: HOW TO PLAY 1. Build up antenna by passing the cable through the antenna tube provided and plug into the boat tightly. Otherwise, the boat will not work. (See Diagram 4) 2. Push the ON/OFF switch to the "ON" position of the boat. (See Diagram 1) FORWARD RUNNING 3. Push the Driving Control Stick forward for forward running. (See Diagram 5). REVERSE RUNNING 4. Pull the Driving Control Stick backward for reverse running. (See Diagram 6) STEERING OPERATION 5. Turn the Steering Control Stick to the left or right while pushing the Driving Stick forward at the same time, the boat will turn left or right and run forward. (See Diagram 7) 6. Turn the Steering Control Stick to the left or right while pulling the Driving Stick backward at the same time, the boat will turn left or right and run backward. (See Diagram 8) STOP OPERATION 7. Release both Control Sticks, the boat will stop. (See Diagram 9) DIAGRAM 2 / SCHÉMA 2 / DIAGRAMA 2 DIAGRAM 3 / SCHÉMA 3 / DIAGRAMA 3DIAGRAM 1 / SCHÉMA 1 / DIAGRAMA 1 DIAGRAM 4 / SCHÉMA 4 / DIAGRAMA 4 DIAGRAM 5 / SCHÉMA 5 / DIAGRAMA 5 DIAGRAM 6 / SCHÉMA 6 / DIAGRAMA 6 DIAGRAM 7 / SCHÉMA 7 / DIAGRAMA 7 DIAGRAM 8 / SCHÉMA 8 / DIAGRAMA 8 DIAGRAM 9 / SCHÉMA 9 / DIAGRAMA 9 Cable Câble Cable Antenna tube Tube de l’antenne Tubo de antena Backward Arrière Hacia atrás Reverse Marche arrière Marcha atrás PERFORMANCE TIPS: - Don't drive in grass, sand or carpet. - Use fresh alkaline batteries. - Be sure to rest your vehicle for at least 30 minutes after every 15 minutes of operation. - Make sure ON/OFF switch on your vehicle is OFF when not in use. - Don't bend antenna. - Electrical, CB interference, mobile phones, air conditioning, elevators and steel girders in building will affect the operation of your vehicle. - Don't leave the vehicle or transmitter near sources of heat or under direct sunlight for long periods of time. - Remove the batteries from the vehicle and transmitter when not in use. FCC NOTE: THE ANTENNA PROVIDED IS A UNIQUE ANTENNA. BY INSTALLATION OF UNAUTHORIZED ANTENNA TO THIS EQUIPMENT. SUCH UNAUTHORIZED INSTALLATION COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. ATTENTION PARENTS: IT IS RECOMMENDED THAT THIS TOY AND ALL ACCESSORIES BE PERIODICALLY EXAMINED FOR POTENTIAL HAZARDS AND THAT ANY POTENTIALLY HAZARDOUS PARTS BE REPAIRED OR REPLACED. IMPORTANT If you experience any problems or issues with this item do not take it back to the store where you purchased. Please email [email protected] and we will be happy to assist you in resolving any issues you may have. We thank you for your purchase. On/Off switch Interrupteur On/Off (Marche/arrêt) Interruptor ON/OFF 5 x AA battery 5 piles AA 5 baterías “AA” O.I. NO. 5383 #94440 CONSEJOS PARA UN MEJOR RENDIMIENTO - No conduzca sobre hierba, arena o moqueta. - Utilice baterías alcalinas nuevas. - Asegúrese de dejar descansar el vehículo al menos 30 minutos después de cada 15 minutos de funcionamiento. - Asegúrese de que el interruptor ON/OFF del vehículo está en posición OFF cuando no está en uso. - No doble la antena. - Las interferencias eléctricas, los teléfonos móviles, el aire acondicionado, los ascensores y las vigas de acero de los edificios pueden afectar al funcionamiento del vehículo. - No deje el vehículo o el transmisor cerca de una fuente de calor o bajo la luz directa del sol durante largos periodos de tiempo. - Retire las baterías del vehículo y el transmis-or cuando no se estén utilizando. NOTA DE FCC: LA ANTENA QUE SE SUMINISTRA ES EXCLUSIVA. EN CASO DE INSTALAR UNA ANTENA NO AUTORIZADA EN ESTE EQUIPO, PODRÍA QUEDAR ANULADA LA AUTORIDAD DEL USUARIO PARA OPERAR EL MISMO. EL FABRICANTE NO SE HACE RESPONSABLE DE LAS INTERFERENCIAS DE RADIO O TELEVISIÓN PROVOCADAS POR LAS MODIFICACIONES NO AUTORIZADAS A LAS QUE SE HAYA SOMETIDO ESTE EQUIPO. DICHAS MODIFICACIONES PUEDEN ANULAR LA AUTORIDAD DEL USUARIO PARA OPERAR EL EQUIPO. ATENCIÓN A LOS PADRES: SE RECOMIENDA EXAMINAR ESTE JUGUETE Y TODOS LOS ACCESORIOS REGULARMENTE CON EL FIN DE EVITAR POSIBLES PELIGROS. ASIMISMO, SE RECOMIENDA SUSTIUIR O REPARAR LAS PIEZAS QUE PUEDAN ENTRAÑAR ALGÚN TIPO DE PELIGRO. INSTRUCCIONES DE FUNCIONAMIENTO INSTALACIÓN DE LAS BATERÍAS (PARA UN RENDIMIENTO ÓPTIMO, UTILICE BATERÍAS ALCALINAS) No olvide retirar todas las baterías del vehículo y del transmisor después de jugar. 1. No mezcle baterías nuevas y usadas. 2. No mezcle baterías alcalinas y estándar (carbono-zinc) o recargables (níquel-metal híbrido). COMO INSTALAR LAS BATERÍAS EN EL BARCO 1. Quitar la parte superior del barco. (consulte el Diagrama 1) 2. Colocar el interruptor ON/OFF en posición “OFF”. (consulte el Diagrama 2) 3. Insertar 5 baterías AA(LR6) haciendo coincidir los signos de (+) y (–), tal como se indica en el compartimento para las pilas. (consulte el Diagrama 2) 4. Cierre el compartimento. CÓMO INSTALAR LA BATERÍA EN EL TRANSMISOR 1. Abra la tapa del compartimento para bater…

Text truncated - open the document above for the full version.

SEM.Test Compliance Service Co., Ltd. 3/F, Jinbao Commerce Building, Xin’an Fanshen Road, Bao’an District, Shenzhen, P.R. China Letter for Confirmation of the Test Date of Tests: 2013‐04‐10 Applicant Name: Scientific Toys Ltd. FCC ID Number: FCC ID: BY3E891‐27TP Name of Engineer to perform the Tests: Lahm Peng (Engineer) Statement for Confirmation of the Tests: Gakkiku Technology Company hired us to perform the tests. We declare that tested sample has been tested in accordance with the test method identified on the test report and our test engineer was performing the tests. We also declare that sample complied with the relevant limits. All instrumentation and accessories were used to test that sample for compliance to the indicated test method and those were calibrated regularly in accordance with ISO 17025: 2005 requirements by laboratories accredited by A2LA, NVLAP or ACLAS for the measurement parameters. The measurements were made at: SEM.Test Compliance Service Co., Ltd. 3/F, Jinbao Commerce Building, Xin'an Fanshen Road, Bao'an District, Shenzhen, P.R. China Representative of the organization performing the tests: Jandy So (Manager) Signature: Email Address: [email protected] Tel No.: +86755‐33663308‐808

Scientific Toys Ltd. Model Number(s)/Item Number(s): 21476 REPORT NUMBER: GKK201304080A PAGE 1 OF 15 PART 15.227 & RSS-310 ISSUE 3 Test Report Applicant Scientific Toys Ltd. Address Rm. 1108, 11/F., Block B, New Mandarin Plaza, 14 Science Museum Road, TST East, Kowloon, Hong Kong FCC ID Number FCC ID: BY3E891-27TP Brand Name(s) None Model Number(s)/Item Number(s) 21476, 94440, 94445, 95030, 98777, BY3E891-27TP, BY3E891 Product Description 26.96-27.28 MHz Wireless Remote Control Toy - TX Operating Frequency 27.145 MHz Rules/Standards Part 15.227 of the FCC Rules, RSS-310 Issue 3 and RSS-Gen Issue 3 of the Industry Canada Received Date 8th April, 2013 Tested Date 10th April, 2013 Approved by Dick Chan (Director of Gakkiku) Tested by Lahm Peng (Engineer of SEM.Test) Signed by Jandy So (Manager of SEM.Test) Report Number GKK201304080A Test Results PASSED FAILED Gakkiku Technology Company Flat B, 5/F., Selwyn Factory Building, No. 404 Kwun Tong Road, Kwun Tong, Kowloon, Hong Kong Tel: (852) 8113 2281 Fax: (852) 2797 0192 Email: [email protected] Scientific Toys Ltd. Model Number(s)/Item Number(s): 21476 REPORT NUMBER: GKK201304080A PAGE 2 OF 15 PART 15.227 & RSS-310 ISSUE 3 GENERAL The report is written by Gakkiku Technology Company. The tested device complies with the general approval requirements of the FCC Rules and the Industry Canada as identified in this test report. TEST LOCATION The tested device was tested at the test site of the SEM.Test Compliance Service Co., Ltd., 3/F, Jinbao Commerce Building, Xin'an Fanshen Road, Bao'an District, Shenzhen, 518101, Guangdong, China. The FCC Recognized 2.948 Listed Test Firm Registration Number is 994117. The Industry Canada IC OATS Filing Number/Assigned Code is 7673A. Scientific Toys Ltd. Model Number(s)/Item Number(s): 21476 REPORT NUMBER: GKK201304080A PAGE 3 OF 15 PART 15.227 & RSS-310 ISSUE 3 TABLE OF CONTENTS 1. GENERAL INFORMATION ............................................................................................... 4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................... 4 1.2 TEST STANDARDS ....................................................................................................................................... 4 1.3 RELATED SUBMITTAL(S)/GRANT(S) ............................................................................................................ 4 1.4 TEST METHODOLOGY .................................................................................................................................. 5 1.5 EUT EXERCISE SOFTWARE .......................................................................................................................... 5 1.6 ACCESSORIES EQUIPMENT LIST AND DETAILS .............................................................................................. 5 1.7 EUT CABLE LIST AND DETAILS .................................................................................................................... 5 2. SUMMARY OF TEST RESULTS ......................................................................................... 6 3. PART 15.203 & RSS-GEN ISSUE 3 §7.1.2 - ANTENNA REQUIREMENT .............................. 7 3.1 STANDARD APPLICABLE ............................................................................................................................... 7 3.2 TEST RESULT .............................................................................................................................................. 7 4. PART 15.227, 15.209, 15.205 & RSS-310 ISSUE 3 §3.8 - RADIATED EMISSION ................. 8 4.1 MEASUREMENT UNCERTAINTY ................................................................................................................... 8 4.2 STANDARD APPLICABLE .............................................................................................................................. 8 4.3 TEST EQUIPMENT LIST AND DETAILS .......................................................................................................... 8 4.4 TEST PROCEDURE ...................................................................................................................................... 9 4.5 CORRECTED AMPLITUDE & MARGIN CALCULATION ..................................................................................... 9 4.6 ENVIRONMENTAL CONDITIONS................................................................................................................... 9 4.7 SUMMARY OF TEST RESULTS/PLOTS .......................................................................................................... 10 5. PART 15.227(B) & RSS-310 ISSUE 3 §2.4 - OUT OF BAND EMISSIONS ........................... 13 5.1 STANDARD APPLICABLE ............................................................................................................................. 13 5.2 TEST EQUIPMENT LIST AND DETAILS ......................................................................................................... 13 5.3 TEST PROCEDURE ..................................................................................................................................... 13 5.4 ENVIRONMENTAL CONDITIONS .................................................................................................................. 13 5.5 SUMMARY OF TEST RESULTS/PLOTS .......................................................................................................... 14 Scientific Toys Ltd. Model Number(s)/Item Number(s): 21476 REPORT NUMBER: GKK201304080A PAGE 4 OF 15 PART 15.227 & RSS-310 ISSUE 3 1. GENERAL INFORMATION 1.1 Product Description for Equipment Under Test (EUT) Client Information Applicant: Scientific Toys Ltd. Address of applicant: Rm. 1108, 11/F., Block B, New Mandarin Plaza, 14 Science Museum Road, TST East, Kowloon, Hong Kong Manufacturer: Scientific Toys Ltd. Address of manufacturer: Rm. 1108, 11/F., Block B, New Mandarin…

Text truncated - open the document above for the full version.
