CCRCBXD2TRANSMITTER

OWNER'S MANUAL DIGITAL WIRELESS TWO - CHANNEL Copyright 2023, Samson Technologies Corp V1.3 Samson Technologies Corp. 278-B Duffy Ave Hicksville, NY 11801 www.samsontech.com Concert XD2 Wireless System3 Important Safety Information 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9. Do not defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. 10. Protect the power cord from being walked on or pinched particularly at the plugs, convenience receptacles, and at the point where they exit from the apparatus. 11. Only use attachments/accessories specified by the manufacturer. 12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. 13. Unplug the apparatus during lightening storms, or when unused for long periods of time. 14. Refer all servicing to qualified personnel. Service is required when the apparatus has been damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. 15. This appliance shall not be exposed to dripping or splashing water and that no object filled with liquid such as vases shall be placed on the apparatus. 16. Caution-to prevent electrical shock, match wide blade plug wide slot fully insert. 17. Please keep a good ventilation environment around the entire unit. 18. The direct plug-in adapter is used as disconnect device, the disconnect device shall remain readily operable. 19. Batteries (battery pack or batteries installed) shall not be exposed to excessive heat such as sunshine, fire or the like. If you want to dispose this product, do not mix it with general household waste. There is a separate collection system for used electronic products in accordance with legislation that requires proper treatment, recovery and recycling. Private household in the 27 member states of the EU, in Switzerland and Norway may return their used electronic products free of charge to designated collection facilities or to a retailer (if you purchase a similar new one). For Countries not mentioned above, please contact your local authorities for a correct method of disposal. By doing so you will ensure that your disposed product undergoes the necessary treatment, re- covery and recycling and thus prevent potential negative effects on the environment and human health. 4 FCC Rules and Regulations Samson wireless receivers are certified under FCC Rules part 15 and transmitters are certified under FCC Rules part 15D. Licensing of Samson equipment is the user’s responsibility and licensability depends on the user’s classification, application and frequency selected. This device complies with Part 15 of the FCC rules Class B and RSS-213 of Industry & Science Canada. Operation is subject to the following two conditions: (1) This device must not cause harmful interference, and (2) This device must accept any interference received including interference that may cause undesired operation. Suitable for home or office use. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced Radio/TV technician for help. WARNING: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment is intended for use in wireless microphone applications. Equipment is intended for sale in: AT, BE, CH, CY, CZ*, DK, EE, FI*, FR*, DE*, GR*, HU, IE, IS, IT, LV, LT*, LU, MT*, NL, NO*, PL* PT, RO, SK, SI, ES, SE, UK *Subject to license. Please contact your national frequency authority for information on available legal use in your area. Any changes or modifications not expressly approved by Samson Technologies Corp. could void your authority to operate the equipment. Hereby, Samson Technologies Corp., declares that this CRXD2 and CHXD2/CBXD2 is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/ EU. Important Safety Information Concert XD2 Wireless System5 Introduction The Concert XD2 system provides a bullet-proof, reliable wireless performance at any venue around the globe. In these pages, you’ll find a detaile…

Text truncated - open the document above for the full version.

Sam Ash Music Corporation 2.911 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – Equipment Type Company name: Sam Ash Music Corporation Address: 262 Duffy Avenue Hicksville New York United States 11801 Product Name: TRANSMITTER FCC ID: CCRCBXD2 Model(s): CBXD2 2.911(d)(5)(i) Equipment Type We, [Sam Ash Music Corporation] (“the applicant”) certify that the equipment for which authorization is sought through certification is not:  Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules.  Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Don Albanese Date: 2023.12.19 Title and Company name: Manager Sam Ash Music Corporation NOTE 1 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Sam Ash Music Corporation 2.911 (d)(5)(ii) Applicant Attestation v1.3 Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: Sam Ash Music Corporation Address: 262 Duffy Avenue Hicksville New York United States 11801 Product Name: TRANSMITTER FCC ID: CCRCBXD2 Model(s): CBXD2 2.911(d)(5)(ii) Applicant filing We, [Sam Ash Music Corporation] (“the applicant”) certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 , established pursuant to § 1.50002 of this chapter, as an entity producing covered communications equipment. Yours sincerely, Name: Don Albanese Date: 2023.10.23 Title and Company name:Manager Sam Ash Music Corporation NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Sam Ash Music Corporation 2.911 (d)(7)USA Agent v1.5 Section 2.911(d)(7) USA Agent for Service of Process Company name: Sam Ash Music Corporation Address: 262 Duffy Avenue Hicksville New York United States 11801 Product Name: TRANSMITTER FCC ID: CCRCBXD2 Model(s): CBXD2 2.911(d)(7) USA Designated Agent for Service of Process We, [Sam Ash Music Corporation] (“the applicant”) designate [Sam Ash Music Corporation] NOTE1 for the purpose of accepting service of process on behalf of the applicant. Applicant consent: We acknowledge our consent to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address of the designated agent and acknowledge our acceptance of our obligation to maintain an agent for service of process in the United States for no less than one year after either we the grantee have permanently terminated all marketing and importation of the applicable equipment within the U.S., or at the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Agent obligation: We acknowledge our obligation to accept service of process in the United States for matters related to the applicable equipment at our physical U.S. address and email address for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or at the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. USA Agent Company name: Sam Ash Music Corporation USA Address: 262 Duffy Avenue Hicksville New York United States 11801 FRN Number 0009055401 Contact Name: Don Albanese Telephone No: 516 364-2244 Email: [email protected] Applicant Company name: Sam Ash Music Corporation Address: 262 Duffy Avenue Hicksville New York United States 11801 Grantee FRN Number 0009055401 FCC Grantee Code: CCR Contact Name: Don Albanese Telephone No: 516 364-2244 Email: [email protected] Signature: Signature: Sam Ash Music Corporation 2.911 (d)(7)USA Agent v1.5 Title: Manager Title: Manager Date:2023.10.23 Date: 2023.10.23 NOTE 1: An applicant located in the United States may designate itself as the agent for service of process. Reference; Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-nation al-security-threats-to-the-communications-supply-chain-through-the

Sam Ash Music Corporation Agent Authorization Company: Sam Ash Music Corporation Address: 262 Duffy Avenue Hicksville New York United States 11801 Product Name: TRANSMITTER Model Number(s): CBXD2 Product Description: TRANSMITTER We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2023.10.23 Name: Don Albanese Title: Manager Company: Sam Ash Music Corporation

Sam Ash Music Corporation Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2023.10.23 Subject; Request for Confidentiality FCC ID: CCRCBXD2 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Date: 2023.10.23 Name: Don Albanese Title: Manager Company: Sam Ash Music Corporation

Page 1 of 4 Report No.: STS2308155 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model:CBXD2 Photo 1 Photo 2 Page 2 of 4 Report No.: STS2308155 Photo 3 Photo 4 Page 3 of 4 Report No.: STS2308155 Photo 5 Photo 6 Page 4 of 4 Report No.: STS2308155 Photo 7 Photo 8

FCC Label Size: 20*10mm The label is attached to the shell TRANSMITTER CBXD2 FCC ID: CCRCBXD2

Page 1 of 3 Report No.: STS2308155 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model:CBXD2 Photo 1 Photo 2 DECT Antenna 1 DECT Antenna 2 Page 2 of 3 Report No.: STS2308155 Photo 3 Photo 4 Page 3 of 3 Report No.: STS2308155 Photo 5

Page 1 of 57 FCC ID: CCRCBXD2 Report No.:LCSA12123080E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity SAR TEST REPORT For Sam Ash Music Corporation TRANSMITTER Test Model:CBXD2 Prepared for : Sam Ash Music Corporation Address : 262 Duffy Avenue Hicksville New York United States 11801 Prepared by : Shenzhen LCS Compliance Testing Laboratory Ltd. Address : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Date of receipt of test sample : Sep 22, 2023 Number of tested samples Sample number : : 1 A231212081 Serial number : Prototype Date of Test : Sep 22, 2023 Date of Report : Sep 27, 2023 Page 2 of 57 FCC ID: CCRCBXD2 Report No.:LCSA12123080E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity SAR TEST REPORT Report Reference No. ............... : LCSA12123080E Date Of Issue .............................. : Sep 27, 2023 Testing Laboratory Name ........ : Shenzhen LCS Compliance Testing Laboratory Ltd. Address ....................................... : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Testing Location/ Procedure ....... : Full application of Harmonised standards ■ Partial application of Harmonised standards □ Other standard testing method □ Applicant’s Name ...................... : Sam Ash Music Corporation Address ....................................... : 262 Duffy Avenue Hicksville New York United States 11801 Test Specification: Standard ...................................... : IEEE Std C95.1, 2019/IEEE Std 1528™-2013/FCC Part 2.1093 Test Report Form No. ................. : LCSEMC-1.0 TRF Originator ........................... : Shenzhen LCS Compliance Testing Laboratory Ltd. Master TRF ................................. : Dated 2011-03 Shenzhen LCS Compliance Testing Laboratory Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen LCS Compliance Testing Laboratory Ltd. is acknowledged as copyright owner and source of the material. Shenzhen LCS Compliance Testing Laboratory Ltd. takes noresponsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test Item Description. .............. : TRANSMITTER Trade Mark ................................. : SAMSON Test Model .................................. : CBXD2 Operation Frequency .................. : DECT: 1921.536 MHz ~ 1928.448 MHz Result ........................................ : Positive Compiled by: Supervised by: Approved by: Jay Zhan / File administrators Cary Luo / Technique principal Gavin Liang / Manager Page 3 of 57 FCC ID: CCRCBXD2 Report No.:LCSA12123080E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity SAR -- TEST REPORT Test Result Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Test Report No. : LCSA12123080E Sep 27, 2023 Date of issue Type / Model......................... : CBXD2 EUT....................................... : TRANSMITTER Applicant.............................. : Sam Ash Music Corporation Address.................................. : 262 Duffy Avenue Hicksville New York United States 11801 Telephone.............................. : / Fax......................................... : / Manufacturer....................... : ShenZhen TianheiYan Science and technology Address.................................. : Room113. Zixinda. Building, NO.1053, Baoyuan Road, XiXiang Sub-district, Baoan Distric, Shenzhen City, China. Telephone.............................. : / Fax......................................... : / Factory.................................. : / Address.................................. : / Telephone.............................. : / Fax......................................... : / Page 4 of 57 FCC ID: CCRCBXD2 Report No.:LCSA12123080E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Revison History Revision Issue Date Revision Content Revised By 000 Sep 27, 2023 Initial Issue --- Page 5 of 57 FCC ID: CCRCBXD2 Report No.:LCSA12123080E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity TABLE OF CONTENTS 1. TEST STANDARDS AND TEST DESCRIPTION .....................................................................................................................6 1.1. TEST STANDARDS ...................................................................................................................................................................6 1.2. TEST DESCRIPTION ..................................................................................................................…

Text truncated - open the document above for the full version.

1/14 承认书 SPECIFICATIONFORAPPROVAL （ Version ： V00 ） 客户名称 CUSTOMERNAME: 东莞精恒电子有限公司 产品名称 PRODUCTNAME: 天線 -RS 产品型号 PRODUCTMODEL:1.9GHz( Φ 2 × 60mm) 客户料号 CUSTOMERP/N: 康捷料号 KTECHP/N: 版本日期 VERSIONDATE:2023/08/22 Sign(客户确认签字盖章)：_________ 深圳市康捷通讯科技有限公司 SHENZHENKTECHTELECOMTECH.CO.,LTD 地址：深圳市宝安区燕罗塘下涌雄宇路平泰昌科技园B栋2楼 电话： 0755-2983510513352999996 传真： 0755-29835007 Http//www.ktech.net.cn CUSTOMER QA CHECKED ME CHECKED RF CHECKED MANAGER CHECKED SHENZHENKTECHTELECOMTECH.CO.,LTD LISTER ME CHECKED RF CHECKED MANAGER CHECKED 武勇林建文 深圳市康捷通讯科技有限公司 SHENZHENKTECHTELECOMTECH.CO.,LTD Add:PingTaiChangsciencePark,TangXiaYongcommunity,Songgangstreet,Shenzhen Tel:+86-7552983510513352999996Http://www.ktech.net.cn Fax:+86-75529835007 2/14 文件制/修订履历表 RevisionHistory 项次 变更文 件名 版本 变更 制/修订原因制/修订内容描述制/修订人制修订日期 1 V00首次承认书制定 2023/08/22 深圳市康捷通讯科技有限公司 SHENZHENKTECHTELECOMTECH.CO.,LTD Add:PingTaiChangsciencePark,TangXiaYongcommunity,Songgangstreet,Shenzhen Tel:+86-7552983510513352999996Http://www.ktech.net.cn Fax:+86-75529835007 3/14 目录 Index 1.封面 Cover .........................................................................................1 2.文件制/修订履历 RevisionHistory ........................................................2 3.目录Index.........................................................................................3 4.产品图面ProductDrawing.....................................................................4 5.产品实物图ProjectChart.....................................................................5 6.产品主要技术参数ElectricalPerformanceIndex........................................6 7.测试数据 Reliadilitytestreport ...........................................................7-11 7.1驻波图 StandingWaveDiagram ..........................................................7 7.2回损图Returnlossfigure.................................................................8 7.3暗室测试项目-增益、效率、方向图 MicrowaveAnechoicChamberTestProject-Gain、Efficiency、Directions ..............9-10 7.4测试环境及设备Antennatestenvironmentandequipment.......................11 8.材料保证书 MaterialWarranty ..............................................................12 9.包装规范 PackingCriterion ...................................................................13 10.材料和零部件成分表Materialandcomponentcompositiontable....................14 深圳市康捷通讯科技有限公司 SHENZHENKTECHTELECOMTECH.CO.,LTD Add:PingTaiChangsciencePark,TangXiaYongcommunity,Songgangstreet,Shenzhen Tel:+86-7552983510513352999996Http://www.ktech.net.cn Fax:+86-75529835007 4/14 4.产品图面 ProductDrawing 深圳市康捷通讯科技有限公司 SHENZHENKTECHTELECOMTECH.CO.,LTD Add:PingTaiChangsciencePark,TangXiaYongcommunity,Songgangstreet,Shenzhen Tel:+86-7552983510513352999996Http://www.ktech.net.cn Fax:+86-75529835007 5/14 5.产品实物图 ProjectChart 深圳市康捷通讯科技有限公司 SHENZHENKTECHTELECOMTECH.CO.,LTD Add:PingTaiChangsciencePark,TangXiaYongcommunity,Songgangstreet,Shenzhen Tel:+86-7552983510513352999996Http://www.ktech.net.cn Fax:+86-75529835007 6/14 6.产品主要技术参数 ElectricalPerformanceIndex 型号 1.9GHz(Φ2×60mm) Model 1.9GHz(Φ2×60mm) 主要技术指标MainTechnicalSpecifications 射频参数 频率范围（MHz）1850-1950FrequencyRange（MHz）1850-1950 频带宽度（MHz）100Bandwidth（MHz）100 电压驻波比对比波形VSWRContrastwaveform 增益（dB）0.9Gain（dB）0.9 输入阻抗（Ω）50InputImpedance（Ω）50 极化形式/Polarization/ 机械参数 长度（mm）62±2Length（mm）62±2 接口形式 / ConnectorType / 环境参数 工作温度 -30~60C°Operationtemperature-30~60C° 储藏温度-30~75C°Storetemperature-30~75C° 深圳市康捷通讯科技有限公司 SHENZHENKTECHTELECOMTECH.CO.,LTD Add:PingTaiChangsciencePark,TangXiaYongcommunity,Songgangstreet,Shenzhen Tel:+86-7552983510513352999996Http://www.ktech.net.cn Fax:+86-75529835007 7/14 7.测试数据 Reliadilitytestreport 7.1驻波图 StandingWaveDiagram 深圳市康捷通讯科技有限公司 SHENZHENKTECHTELECOMTECH.CO.,LTD Add:PingTaiChangsciencePark,TangXiaYongcommunity,Songgangstreet,Shenzhen Tel:+86-7552983510513352999996Http://www.ktech.net.cn Fax:+86-75529835007 8/14 7.2回损图 Returnlossfigure 深圳市康捷通讯科技有限公司 SHENZHENKTECHTELECOMTECH.CO.,LTD Add:PingTaiChangsciencePark,TangXiaYongcommunity,Songgangstreet,Shenzhen Tel:+86-7552983510513352999996Http://www.ktech.net.cn Fax:+86-75529835007 9/14 7.3暗室测试项目-增益、效率、方向图 MicrowaveAnechoicChamberTestProject-Gain 、 Efficiency 、 Directions Frequency（MHz）Directivity（dBi）Efficiency（dB）Efficiency（%）Gain（dBi） 18506.51-4.7532.53-0.91 19006.65-4.3735.62-0.39 19506.71-5.1429.85-1.17 深圳市康捷通讯科技有限公司 SHENZHENKTECHTELECOMTECH.CO.,LTD Add:PingTaiChangsciencePark,TangXiaYongcommunity,Songgangstreet,Shenzhen Tel:+86-7552983510513352999996Http://www.ktech.net.cn Fax:+86-75529835007 10/14 深圳市康捷通讯科技有限公司 SHENZHENKTECHTELECOMTECH.CO.,LTD Add:PingTaiChangsciencePark,TangXiaYongcommunity,Songgangstreet,Shenzhen Tel:+86-7552983510513352999996Http://www.ktech.net.cn Fax:+86-75529835007 11/14 7.4天线测试环境及设备 Antennatestenvironmentandequipment 深圳市康捷通讯科技有限公司 SHENZHENKTECHTELECOMTECH.CO.,LTD Add:PingTaiChangsciencePark,TangXiaYongcommunity,Songgangstreet,Shenzhen Tel:+86-7552983510513352999996Http://www.ktech.net.cn Fax:+86-75529835007 12/14 8.材料保证书 MaterialWarranty 深圳市康捷通讯科技有限公司 SHENZHENKTECHTELECOMTECH.CO.,LTD Add:PingTaiChangsciencePark,TangXiaYongcommunity,Songgangstreet,Shenzhen Tel:+86-7552983510513352999996Http://www.ktech.net.cn Fax:+86-75529835007 13/14 9.产品包装规范 PackingCriterion 产品料号： 产品名称/规格： －标签要求： 二装箱要求： 作业说明：1．内包装： 产品XXXPCS一袋； 2．外包装： XXXPCS一箱 注意事项： 1．是否要增设隔板、珍珠棉； 2．标签的贴附，如ROHS等； 需方 供方深圳市康捷通讯科技有限公司 采购单号 物料编码 品名规格 数量/单XXXPCS出厂日期X年X月X日 备注 深圳市康捷通讯科技有限公司 SHENZHENKTECHTELECOMTECH.CO.,LTD Add:PingTaiChangsciencePark,TangXiaYongcommunity,Songgangstreet,Shenzhen Tel:+86-7552983510513352999996Http://www.ktech.net.cn Fax:+86-75529835007 14/14 10.材料和零部件成分表 Materialandcomponentcompositiontable 精恒电子有限公司 材料和零件部件成分表 2023年8月22日 供方名称深圳市康捷通讯科技有限公司客户料号 产品名称 天線-RS 产品型号 1.9GHz(Φ2×60mm) 项目RoHS 序号 組件 名称 材料 名称 铅 (Pb) 镉 (Cd) 汞 (Hg) 六价 铬 (Cr 6+ ) 溴化联 苯 (PBB) 溴化联 苯醚 (PBDE) DEHP 鄰苯二 甲酸二 (2-乙 基己 基)酯 BBP (鄰苯 二甲酸 丁苄 酯) DBP (鄰苯 二甲酸 二丁 酯) DIBP (鄰苯 二甲酸 二異丁 酯) 测试构与报告号 报告有效日 期 1电缆同轴线NDNDNDNDNDNDNDNDNDNDA2220467603102001C2023.10.27 2塑胶PVCNDNDNDNDNDNDNDNDNDNDCANEC23011923042024.1.19 3焊锡 环保 锡线 10NDNDNDNDNDNDNDNDNDCANEC22232743042023.11.9 結論WEEE RoHS 核准:林建文审核:武勇制表人:陈代…

Text truncated - open the document above for the full version.

1/14 承认书 SPECIFICATIONFORAPPROVAL （ Version ： V00 ） 客户名称 CUSTOMERNAME: 东莞精恒电子有限公司 产品名称 PRODUCTNAME:FPC 天线 产品型号 PRODUCTMODEL:FPC-1900-IPEXRG113-40 客户料号 CUSTOMERP/N: 康捷料号 KTECHP/N: 版本日期 VERSIONDATE:2023/08/23 Sign(客户确认签字盖章)：_________ 深圳市康捷通讯科技有限公司 SHENZHENKTECHTELECOMTECH.CO.,LTD 地址：深圳市宝安区燕罗塘下涌雄宇路平泰昌科技园B栋2楼 电话： 0755-2983510513352999996 传真： 0755-29835007 Http//www.ktech.net.cn CUSTOMER QA CHECKED ME CHECKED RF CHECKED MANAGER CHECKED SHENZHENKTECHTELECOMTECH.CO.,LTD LISTER ME CHECKED RF CHECKED MANAGER CHECKED 武勇林建文 深圳市康捷通讯科技有限公司 SHENZHENKTECHTELECOMTECH.CO.,LTD Add:PingTaiChangsciencePark,TangXiaYongcommunity,Songgangstreet,Shenzhen Tel:+86-7552983510513352999996Http://www.ktech.net.cn Fax:+86-75529835007 2/14 文件制/修订履历表 RevisionHistory 项次 变更文 件名 版本 变更 制/修订原因制/修订内容描述制/修订人制修订日期 1 V00首次承认书制定 2023/08/23 深圳市康捷通讯科技有限公司 SHENZHENKTECHTELECOMTECH.CO.,LTD Add:PingTaiChangsciencePark,TangXiaYongcommunity,Songgangstreet,Shenzhen Tel:+86-7552983510513352999996Http://www.ktech.net.cn Fax:+86-75529835007 3/14 目录 Index 1.封面 Cover .........................................................................................1 2.文件制/修订履历 RevisionHistory ........................................................2 3.目录Index.........................................................................................3 4.产品图面ProductDrawing.....................................................................4 5.产品实物图ProjectChart.....................................................................5 6.产品主要技术参数ElectricalPerformanceIndex........................................6 7.测试数据 Reliadilitytestreport ...........................................................7-11 7.1驻波图 StandingWaveDiagram ..........................................................7 7.2回损图Returnlossfigure.................................................................8 7.3暗室测试项目-增益、效率、方向图 MicrowaveAnechoicChamberTestProject-Gain、Efficiency、Directions ..............9-10 7.4测试环境及设备Antennatestenvironmentandequipment.......................11 8.材料保证书 MaterialWarranty ..............................................................12 9.包装规范 PackingCriterion ...................................................................13 10.材料和零部件成分表Materialandcomponentcompositiontable....................14 深圳市康捷通讯科技有限公司 SHENZHENKTECHTELECOMTECH.CO.,LTD Add:PingTaiChangsciencePark,TangXiaYongcommunity,Songgangstreet,Shenzhen Tel:+86-7552983510513352999996Http://www.ktech.net.cn Fax:+86-75529835007 4/14 4.产品图面 ProductDrawing 武 勇 2023.8.20 技术要求： 1、电气特性：性能良率100％。适用频率范围： 1900±50MHZ。 2、尺寸检验：*为重点检测项目；非关键尺寸可适当 放宽，对其性能与装配使用无影响。 3、外观检验：目视全检。 产品外观洁净、规整；表面不得有刮伤、破损、 脏污；镀层色泽光亮均匀，不得有氧化。 4、包装规范：// 5、环保要求：产品及其使用之物料皆需要符合ROSH 要求。 * 焊点 Name/Descrlptlon NO. Part number Q'ty 第 张 康捷通讯科技有限公司 RG1.13电缆 内置天线 单位：mm 未注尺寸公差:±0.5mm 2023.8.20 FPC-1900-IPEXRG113-40 FIT 名称 项 目 单位 mm 表面处理 材 料 比 例 型号 结构 电气 标准化 审核 批准 签名 日期 林建文 00 深圳市康捷通讯科技有限公司 SHENZHENKTECHTELECOMTECH.CO.,LTD Add:PingTaiChangsciencePark,TangXiaYongcommunity,Songgangstreet,Shenzhen Tel:+86-7552983510513352999996Http://www.ktech.net.cn Fax:+86-75529835007 5/14 5.产品实物图 ProjectChart KTECH KT2308SYJHV1.0-0 深圳市康捷通讯科技有限公司 SHENZHENKTECHTELECOMTECH.CO.,LTD Add:PingTaiChangsciencePark,TangXiaYongcommunity,Songgangstreet,Shenzhen Tel:+86-7552983510513352999996Http://www.ktech.net.cn Fax:+86-75529835007 6/14 6.产品主要技术参数 ElectricalPerformanceIndex 型号 FPC-1900-IPEXRG113-40 Model FPC-1900-IPEXRG113-40 主要技术指标MainTechnicalSpecifications 射频参数 频率范围（MHz）1850-1950FrequencyRange（MHz）1850-1950 频带宽度（MHz）100Bandwidth（MHz）100 电压驻波比≤2.0VSWR≤2.0 增益（dB）1.8Gain（dB）1.8 输入阻抗（Ω）50InputImpedance（Ω）50 极化形式垂直极化PolarizationVertical 机械参数 天线长度（mm）75±5Length（mm）75±5 接口形式 IPEX-1 ConnectorType IPEX-1 环境参数 工作温度 -30~60C°Operationtemperature-30~60C° 储藏温度-30~75C°…

Text truncated - open the document above for the full version.
