CKLHD-MIC800Base Station Transceiver Subsystem (Micro-BTS Syst

USER’S MANUAL for HD-BSC 960 and HD-MIC 800 1999. 9 Copyright  1999 Hyundai Electronics Industries Co., Ltd. All rights are reserved. No part of this document may be used or reproduced in any means without the prior written permission of the copyright holders. User’s Manual PROPRIETARY & CONFIDENTIAL Table of Contents Chapter 1. System Overview 1.1 Purpose of this document 1.2 Features of Hyundai CDMA System 1.3 Overview Chapter 2. BSC Basics 2.1 System Overview and Specification 2.1.1 Overview 2.1.2 Specifications and Characteristics 2.2 H/W Structure and Function 2.2.1 Overview 2.2.2 Structure of Subsystem 2.3 S/W Structure and Function 2.3.1 Overview 2.3.2 Structure Chapter 3. BSM Operation & Administration 3.1 BSM Operation 3.1.1 Overview 3.1.2 Main Display Structure 3.1.3 Main Button 3.1.4 Command Buttons 3.1.5 Service Button 3.1.6 Operations of “Alarm” window 3.2 System Status Management 3.2.1 System Status Test 3.2.2 System Diagnosis 3.2.3 Statistics 3.3 Data Management 3.3.1 Access Channel Parameter 3.3.2 Access Parameter User’s Manual PROPRIETARY & CONFIDENTIAL 3.3.3 Information of Micro-BTS Configuration 3.3.4 Base Station CDMA Environment 3.3.5 Base Station CDMA Information 3.3.6 Base Station Channel List Message 3.3.7 Extended System Parameter Information 3.3.8 Forward Link Power Information 3.3.9 Paging Channel Parameter 3.3.10 Psync Channel Parameter 3.3.11 RFC Parameter 3.3.12 Forward Link Power Control Data 3.3.13 Reverse Link Power Control Data 3.3.14 Base Station Cell Information 3.3.15 Corresponding Sector Information of Micro-BTS 3.3.16 Sync Channel Message 3.3.17 System Parameter 3.3.18 System Parameter Message 3.3.19 Traffic Channel Parameter 3.4 Call Processing System 3.4.1 Overview 3.4.2 Call Processing Flow 3.4.3 Call Trace 3.4.4 Call Release Reason and State Chapter 4. BSC References 4.1 Rack Configuration 4.2 DIP Switch & Strap 4.2.1 Summary 4.2.2 Purpose 4.2.3 Address Setting in Common 4.2.4 MCDA (Main Control & Duplication board Assembly-A1) 4.2.5 CIFA-A1 (Cin Interface Function board Assembly-A1) 4.2.6 HICA-A2 (High capacity Ipc Control board Assembly-A2) 4.2.7 HRNA-A2 (High capacity Routing Node Assembly-A2) User’s Manual PROPRIETARY & CONFIDENTIAL 4.2.8 HNTA-A2 (High capacity ipc Node & T1 interface Assembly-A2) 4.2.9 TFSA-A1 (Time & Frequency Split Assembly-A1) 4.2.10 TSGA-A1 (Time & frequency Splitting Generation Assembly-A1) 4.2.11 TFDA-A1 (Time & Frequency Distribution Assembly-A1) 4.2.12 VSIA-C1 (Vocoder Selector Interface Assembly-C1) 4.2.13 VSOA-A1 (Vocoder Selector Operation Assembly-A1) 4.2.14 CHBB-A1 (Cin Hipc Back Board-A1) 4.2.15 CCBB-A1 (CCp Back wiring Board-A1) 4.2.16 ACPA-A1 (Alarm Control Processor Assembly-A1) 4.2.17 SDBB-A1 (CKd Split & Distributed Back Board-A1) 4.2.18 TSBB-A1 (TSb Back Board-A1) 4.2.19 BABB-A1 (Bsc Alarm Back Board-A1) 4.2.20 HSBB-A1 (HIPC Small BackBoard-A1) 4.3 LED Descriptions 4.4 Command List 4.5 Acronym Chapter 5. Micro-BTS Basics 5.1 System Overview and Specification 5.1.1 Overview 5.1.2 Functions 5.1.3 System Specification 5.2 Micro-BTS Structure and Configuration 5.2.1 Micro-BTS Structure 5.2.2 Micro-BTS Block Configuration 5.3 H/W Structure and Function 5.3.1 BMP 5.3.2 DU 5.3.3 TFU 5.3.4RFU 5.3.5Antenna Subsystem (AIU-RRU, AIDU-AAU) 5.3.6BTU 5.3.7 RPU User’s Manual PROPRIETARY & CONFIDENTIAL 5.4 S/W Structure and Function 5.4.1 Overview 5.4.2 Basic Functions 5.5 Abbreviations Chapter 6. Micro-BTS References 6.1 Rack Configuration 6.1.1 MBTR I (1.9GHz) 6.1.2 MBTR I (800MHz) 6.2 DIP Switch and Strap 6.2.1 Summary 6.2.2 Purpose 6.2.3 Address Setting in Common 6.2.4 BMPA-B2 6.2.5 CDCA-B1 6.2.6 BICA-B1 6.2.7 HLTA-B1 6.3 LED Descriptions 6.3.1 BMP 6.3.2 DU 6.3.3 TFU 6.3.4 RPU 6.4 Alarm Source List 6.5 Abbreviations User’s Manual PROPRIETARY & CONFIDENTIAL 1-1 Chapter 1 System Overview 1.1 Purpose of this document This chapter contains description of Hyundai Micro-BTS PCS System that is operating on 800MHz and 1.9GHz frequency band, repectively. 1.2 Features of Hyundai CDMA System There are two sub-systems in Hyundai CDMA system ; Micro-BTS and BSC. BSC interfaces with switching equipment and has roles of vocoding and call processing. Micro- BTS is functionally located between MS (Mobile Station) and BSC. Hyundai Micro-BTS has channel resource unit and radio frequency RF unit similar to the conventional 3-Sector BTS. Contrary to conventional 3-Sector BTS, Hyundai Micro-BTS is small in size, easily can be installed and maintained, and is very cheap in cost. 1.3 Overview Hyundai Micro-BTS system can support 2FA/3Sector using 2 racks, but Micro-BTS system is composed of 1FA/3sector system for the FCC authorization. Thus this manual will describe all of the specifications based on 1FA/3sector system. The system configuration is shown in Figure 1.1. In this configuration, there are 1 BSC and 3 Micro-BTS systems. Each Micro-BTS system is separately located in 3 sites. Micro-BTS can use 2 types of antenna subsystem, RRU (Remote RF Unit) and AAU (Active Antenna Unit). RRU is connected to Micro-BTS main system through AIU (Antenna Interface Unit) and AAU through AIDU (Active Internal Distribution Unit). In case of trunk line, we have several solutions, T1 and E1. We use T1 trunk line in USA. It means that we do not use HLEA but HLTA as trunk card. BSM manages and maintains Micro-BTS and BSC. It communicates with each system by transmitting and receiving packets through LCIN. Its features include performance management, configuration management, fault management, etc.. User’s Manual PROPRIETARY & CONFIDENTIAL 1-2 RRU-B1 DEC, 8, 1998 System Configuration for Test_Bed 1x T1 leased line 1x T1 leased line 1x T1 leased line GPS Antenna MBTR1 RFU AIU-B1 RPU GPS Antenna MBTR1 RFU AIU-B1 RPU GPS Antenna MBTR1 RFU RPU AIU-B1 MBTR: Micro-BTS Rack DU: Digital Unit BMP: BTS Main Processor TFU: Time & Frequency Unit RFU: Radio Frequency Unit RPU : Rectifier Power Unit AIU: Antenna Interface Unit RRU: Remote RF Unit GPS: Global Positioning…

Text truncated - open the document above for the full version.

© 1999 PCTEST Engineering Lab., Inc. PCTEST Engineering Laboratory, Inc. 6660-B 6660-B DobbinDobbin Road Road •• Columbia, MD 21045 Columbia, MD 21045 •• U.S.A. U.S.A. TEL (410) 290-6652 TEL (410) 290-6652 •• FAX (410) 290-6654 FAX (410) 290-6654 http://www.pctestlab.comhttp://www.pctestlab.com CERTIFICATE OF COMPLIANCE (MPE EVALUATION) HYUNDAI Electronics Industries Co., Ltd.Dates of Tests: September 13-17, 1999 San 136-1, Ami-Ri, Bubal-EubTest Report S/N: MPE.990913521.CKL Ichon-Si, Kyoungki-Do, KOREA 467-701Test Site: PCTEST Lab, Columbia MD Attn: Mr. Ki-Soo Kim, Section Chief, QA Office FCC ID CKLHD-MIC800 APPLICANT HYUNDAI Electronics Industries Co., Ltd. EUT Type:Base Station Transceiver Subsystem (Micro-BTS System) Tx Frequency:870.03 – 889.32 MHz Rx Frequency:825.03 – 844.32 MHz Frequency Block(s):Block A, Block B Max. Output Power:10.0 Watts Trade Name/Model(s):HYUNDAI HD-MIC 800 FCC Classification:Non-Broadcast Station Transmitter (TNB) Frequency Tolerance:0.000005% (0.05 ppm) Application Type:Certification FCC Rule Part(s):§22(H); ET Docket 96.326 This wireless device has been shown to be capable of compliance for localized maximum permissible exposure (MPE) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and was tested in accordance with the measurement procedures specified in ANSI/IEEE Std. C95.3-1992. (See Test Report). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. NVLAP accreditation does not constitute any product endorsement by NVLAP or any agency of the United States Government. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a) 990913521.CKL MPE Measurement ReportFCC Part 22 Certification © 1999 PCTEST Labi Table of Contents SCOPE .............................................................................1 INTRODUCTION / RF HAZARDS ...........................................2 MPE DEFINITION ...............................................................3 MPE LIMITS ......................................................................4 FCC LIMITS FOR MPE ........................................................5 RF HUMAN EXPOSURE DATA & MEASUREMENT PROCEDURE ...... 6 TEST DATA SUMMARY ......................................................7 SPECIFICATIONS ...............................................................8 CONCLUSION / REFERENCES .............................................9 Test Report S/N: MPE.990913521.CKLFCC Part 22 Certification Test Dates: September 13-17, 1999MPE Measurement Report HYUNDAI Base Station Transceiver Subsystem © 1999 PCTEST LabFCC ID: CKLHD-MIC800 (Tx 870.03-889.32 MHz)1 MPE MEASUREMENT REPORT Scope - Environmental evaluation measurements of Maximum Permissible Exposure (MPE) exposed to radiofrequency (RF) radiation from transmitter for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 1 Company Name:HYUNDAI Electronics Industries Co., Ltd. ADDRESS :San 136-1, Ami-Ri, Bubal-Eub Ichon-Si, Kyoungki-Do, KOREA 467-701 Attention :Mr. Ki-Soo Kim, Section Chief, QA Office • EUT Type:Base Station Transceiver Subsystem (Micro-BTS System) • Trade Name:HYUNDAI • FCC IDENTIFIER:CKLHD-MIC800 • Model:HD-MIC 800 • Tx Frequency Range: 870.03 – 889.32 MHz • Rx Frequency Range:825.03 – 844.32 MHz • Application Type: Certification • FCC Classification:Non-Broadcast Station Transmitter (TNB) • FCC Rule Part(s):§ 22(H); Docket 96-326 • Max. Power Rating:10.0 W • Channel(s):1 - 344 • Frequency Block(s):Block A, Block B • Modulation:CDMA • Frequency Tolerance:± 0.000005% (0.05 ppm) • Dates of Test(s):September 13-17, 1999 • Place of Test(s):PCTEST Engineering Lab. Columbia, MD, U.S.A. • Test Report S/N:MPE.990913521.CKL 1 IEEE/ANSI Std. C95.1-1992 limits are used to determine compliance with FCC ET-Docket 93-62. Test Report S/N: MPE.990913521.CKLFCC Part 22 Certification Test Dates: September 13-17, 1999MPE Measurement Report HYUNDAI Base Station Transceiver Subsystem © 1999 PCTEST LabFCC ID: CKLHD-MIC800 (Tx 870.03-889.32 MHz)2 1.1 INTRODUCTION The Federal Communications Commissions (FCC) has adopted the guidelines for evaluating the environmental effects of radiofrequency radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public from the potential hazards of RF emissions.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) and maximum permissible exposure (MPE) in IEEE/ANSI C95.1-1992 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. (c) 1992 by the Institute of Electrical and Electronics Engineers, Inc., New York, New York 10017.[2] The measurement procedure described in IEEE/ANSI C95.3-1992 Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields - RF and Microwave[3] is used for guidance in measuring SAR/MPE due to the RF radiation exposure from the Equipment Under Test (EUT). The new guidelines incorporate limits for Maximum Permissible Exposure (MPE) in terms of electric and magnetic field strength and power density for transmitters operating at frequencies between 300 kHz and 100 GHz. These criteria for SAR/MPE evaluation are similar to those recommended by the National Council on Radiation Protection and Measurements (NCRP) in Biological Effects and Exposure Criteria for Radiofrequency Electromagnetic Fields,” NCRP Report No. 86 (c) NCRP, 1986, Bethesda, MD 20814.[4] SAR is a measure of the rate of energy absorption due to …

Text truncated - open the document above for the full version.

September 16, 1999 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT:HYUNDAI Electronics Industries Co., Ltd. FCC ID: CKLHD-MIC800 Part 22 Certification Gentlemen: Submitted herewith, on behalf of HYUNDAI Electronics Industries Co., Ltd., is an application for Part 22 Certification of the following: FCC ID:CKLHD-MIC800 TRADE / MODEL(s):HYUNDAI HD-MIC 800 EUT TYPE:Non-Broadcast Station Transmitter (TNB) Tx Freq. Range:870.03 – 889.32 MHz Max. Output Power:10 Watts Frequency Block(s):Block A, Block B Attached is the applicant’s Letter of Authorization, Confidentiality Request, measurement report data and plots, RF Exposure measurement report, FCC ID label and location, test setup photographs, internal and external photographs, block diagrams (confidential), schematic diagrams (confidential), operational description (confidential), parts list & tune-up procedure (confidential), and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc:Mr. Ki-Soo Kim Section Chief, QA Office HYUNDAI Electronics Industries Co., Ltd.
