CKLHGC-610EDual Mode Cellular Phone (AMPS/CDMA)

© 2000 PCTEST Lab ATTACHMENT M – USER’S MANUAL

© 2000 PCTEST Lab ATTACHMENT B – ATTESTATION STATEMENT(S)

© 2000 PCTEST Lab ATTACHMENT A – COVER LETTER July 21, 2000 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT:HYUNDAI Electronics Industries Co., Ltd. FCC ID: CKLHGC-610E Part 22 Certification Gentlemen: Attached herewith, on behalf of HYUNDAI Electronics Industries Co., Ltd. is an application for Part 22 Certification of the following Dual Mode Cellular Phone (AMPS/CDMA): FCC ID:CKLHGC-610E TRADE / MODEL(s):HYUNDAI DX-10 EUT TYPE:Non-Broadcast Transmitter Held to Ear (TNE) Tx Freq. Range:824.04 – 848.97 MHz (AMPS) 824.70 – 848.31 MHz (CDMA) Rx Freq. Range:869.04 – 893.97 MHz (AMPS) 869.70 – 893.31 MHz (CDMA) Max. Output Power:0.55 W ERP AMPS (27.38 dBm) 0.34 W ERP CDMA (25.27 dBm) Attached is the applicant’s Letter of Authorization, Confidentiality Request, ESN Affidavit, E911 compliance statement, measurement report data and plots, RF Exposure measurement report, FCC ID label and location, test setup photographs, internal and external photographs, block diagrams (confidential), schematic diagrams (confidential), operational description (confidential), parts list & tune-up procedure (confidential), and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc:Mr. Ki-Soo Kim, QA Dept. HYUNDAI Electronics Industries Co., Ltd.

August 17, 2000 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Joe Dichoso SUBJECT: HYUNDAI Electronics Industries Co., Ltd. FCC ID: CKLHGC-610E 731 Confirmation No.: EA98291 Correspondence Reference No.: 15603 Request for Tech. Info.: 8/15/00 Dear Joe: Transmitted herewith, on behalf of HYUNDAI Electronics Industries Co., Ltd. is an amendment provided in response to the request for technical information dated August 15, 2000. 1. Attached is the revised RF exposure warning statement, which will be place towards the front location in the user’s manual. 2. Please find the attached illustration identifying the peak SAR location with respect to the device for both head and body SAR. 3. Please find the attached photographs of the specific belt-clip tested for SAR compliance. We trust this information is sufficient to issue the grant ASAP. If you have any further questions, please do not hesitate to contact us. cc: HYUNDAI Electronics Industries Co., Ltd.

© 2000 PCTEST Lab ATTACHMENT G – EXTERNAL PHOTOGRAPHS © 2000 PCTEST Lab FCC ID: CKLHGC-610E NVLAP Lab Code: 100431-0 HYUNDAI Dual-Mode Cellular Phone (AMPS/CDMA) © 2000 PCTEST Lab FCC ID: CKLHGC-610E NVLAP Lab Code: 100431-0 HYUNDAI Dual-Mode Cellular Phone (AMPS/CDMA) © 2000 PCTEST Lab FCC ID: CKLHGC-610E NVLAP Lab Code: 100431-0 HYUNDAI Dual-Mode Cellular Phone (AMPS/CDMA) © 2000 PCTEST Lab FCC ID: CKLHGC-610E NVLAP Lab Code: 100431-0 HYUNDAI Dual-Mode Cellular Phone (AMPS/CDMA)

© 2000 PCTEST Lab ATTACHMENT E – FCC ID LABEL / LOCATION FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER § 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE)

© 2000 PCTEST Lab ATTACHMENT H – INTERNAL PHOTOGRAPHS © 2000 PCTEST Lab FCC ID: CKLHGC-610E NVLAP Lab Code: 100431-0 HYUNDAI Dual-Mode Cellular Phone (AMPS/CDMA) © 2000 PCTEST Lab FCC ID: CKLHGC-610E NVLAP Lab Code: 100431-0 HYUNDAI Dual-Mode Cellular Phone (AMPS/CDMA) © 2000 PCTEST Lab FCC ID: CKLHGC-610E NVLAP Lab Code: 100431-0 HYUNDAI Dual-Mode Cellular Phone (AMPS/CDMA) © 2000 PCTEST Lab FCC ID: CKLHGC-610E NVLAP Lab Code: 100431-0 HYUNDAI Dual-Mode Cellular Phone (AMPS/CDMA) © 2000 PCTEST Lab FCC ID: CKLHGC-610E NVLAP Lab Code: 100431-0 HYUNDAI Dual-Mode Cellular Phone (AMPS/CDMA) © 2000 PCTEST Lab FCC ID: CKLHGC-610E NVLAP Lab Code: 100431-0 HYUNDAI Dual-Mode Cellular Phone (AMPS/CDMA) © 2000 PCTEST Lab FCC ID: CKLHGC-610E NVLAP Lab Code: 100431-0 HYUNDAI Dual-Mode Cellular Phone (AMPS/CDMA) © 2000 PCTEST Lab FCC ID: CKLHGC-610E NVLAP Lab Code: 100431-0 HYUNDAI Dual-Mode Cellular Phone (AMPS/CDMA)

September 6, 2000 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Joe Dichoso SUBJECT: HYUNDAI Electronics Industries Co., Ltd. FCC ID: CKLHGC-610E 731 Confirmation No.: EA98291 Correspondence Reference No.: 15934 Request for Tech. Info.: 9/06/00 Dear Joe: Transmitted herewith, on behalf of HYUNDAI Electronics Industries Co., Ltd. is an amendment provided in response to the request for technical information dated August 6, 2000. 1. Please find attached, the PCB internal photo’s without shielding and covers. We trust this information is sufficient to issue the grant ASAP. If you have any further questions, please do not hesitate to contact us. cc: HYUNDAI Electronics Industries Co., Ltd.

© 2000 PCTEST Lab FCC ID: CKLHGC-610E NVLAP Lab Code: 1004310 HYUNDAI Dual-Mode Cellular Phone (AMPS/CDMA) © 2000 PCTEST Lab FCC ID: CKLHGC-610E NVLAP Lab Code: 1004310 HYUNDAI Dual-Mode Cellular Phone (AMPS/CDMA)

© 2000 PCTEST Lab ATTACHMENT N – SAR MEASUREMENT REPORT © 2000 PCTEST Engineering Lab., Inc. PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road 6660-B Dobbin Road •• Columbia, MD 21045 Columbia, MD 21045 •• U.S.A. U.S.A. TEL (410) 290-6652 TEL (410) 290-6652 •• FAX (410) 290-6654 FAX (410) 290-6654 http://www.pctestlab.comhttp://www.pctestlab.com CERTIFICATE OF COMPLIANCE (SAR EVALUATION) HYUNDAI Electronics Industries Co., Ltd.Dates of Tests: July 18-20, 2000 San 136-1, Ami-Ri, Bubal-EubTest Report S/N: SAR.200718355.CKL Ichon-Si, Kyungki-Do, KOREA 467-701Test Site: PCTEST Lab, Columbia MD U.S.A. Attn: Mr. Ki-Soo Kim, QM Dept System Quality Assurance Office FCC ID CKLHGC-610E APPLICANT HYUNDAI Electronics Industries Co., Ltd. EUT Type:Dual-Mode Cellular Phone (AMPS/CDMA) Tx Frequency:824.04 – 848.97 MHz (AMPS) / 824.70 – 848.31 MHz (CDMA) Rx Frequency:869.04 – 893.97 MHz (AMPS) / 869.70 – 893.31 MHz (CDMA) Max. RF Output Power:0.55W ERP AMPS (27.38 dBm) / 0.34W ERP CDMA (25.27 dBm) Trade Name/Model(s):HYUNDAI DX-10 FCC Classification:Non-Broadcast Transmitter Held to Ear (TNE) Application Type:Certification FCC Rule Part(s):2.1093; ET Docket 96.326 This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in ANSI/IEEE Std. C95.3-1992 (See Test Report). Part 22 AMPS Mode - Head Max. SAR:1.4374 W/kgFCC Limit: 1.6 W/kg Body Max. SAR:0.6379 W/kg FCC Limit: 1.6 W/kg Hand Max. SAR:1.3.775 W/kg FCC Limit: 4.0 W/kg Part 22 CDMA Mode - Head Max. SAR:1.1204 W/kg FCC Limit: 1.6 W/kg I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. NVLAP accreditation does not constitute any product endorsement by NVLAP or any agency of the United States Government. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. 200718355.CKL SAR Measurement ReportFCC Part 22 Certification © 2000 PCTEST Labi Table of Contents 1.1: SCOPE ..............................................................1 2.1-2: INTRODUCTION / SAR DEFINITION ..........................2 3.1: SAR MEASUREMENT SET-UP .................................3 4.1-2: E-FIELD PROBE SYSTEM .......................................4 5.1-4: E-FIELD PROBE CALIBRATION .............................. 5-6 6.1-3: PHANTOM & EQUIVALENT TISSUE ...........................7 7.1-2: SYSTEM SPECIFICATIONS ..................................... 8 8.1-2: MEASUREMENT PROCESS ....................................9 9.1-2: TEST POSITION OF THE PHONE ............................. 10 10.1-2: BODY-WORN TEST SETUP .................................. 11 11.1: ANSI/IEEE C95.1 RF EXPOSURE LIMITS .................. 12 12.1: MEASUREMENT UNCERTAINTIES ....................... 13 13.1-3: TEST DATA SUMMARY ......................................... 14-16 14.1: SAR TEST EQUIPMENT LIST ............................... 17 15.1: CONCLUSION / REFERENCES .............................. 18 Test Report S/N: SAR.200718355.CKLSAR Measurement Report Test Dates: July 18-20, 2000FCC Part 22 Certification HYUNDAI Dual-Mode Cellular Phone (AMPS/CDMA) © 2000 PCTEST LabFCC ID: CKLHGC-610E (Tx 824-849 MHz)1 SAR MEASUREMENT REPORT 1.1 SCOPE Environmental evaluation measurements of specific absorption rate 1 (SAR) distributions in simulated human head and body tissues exposed to radiofrequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 2 Company Name:HYUNDAI ELECTRONICS CO., LTD. Address:San 136-1, Ami-Ri, Bubal-Eab Ichon-Si, Kyunkgi-Do, KOREA 467-701 Attention:Mr. Ki-Soo Kim, QA Dept. System Quality Assurance Office • EUT Type:Dual-Mode Cellular Phone (AMPS/CDMA) • Trade Name:HYUNDAI • FCC IDENTIFIER:CKLHGC-610E • Model:DX-10 • Tx Frequency:824.04 – 848.97 MHz (AMPS) 824.70 – 848.31 MHz (CDMA) • Rx Frequency:869.04 – 893.97 MHz (AMPS) 869.70 – 893.31 MHz (CDMA) • Application Type: Certification • FCC Classification:Non-Broadcast Transmitter Held to Ear (TNE) • FCC Rule Part(s):§2.1093, Docket 96-326 • Max. RF Output Power:0.55W ERP AMPS (27.38 dBm) 0.34W ERP CDMA (25.27 dBm) • Modulation:AMPS / CDMA • Antenna Type:Helical (λ/2) • Antenna Dimensions:8.55 cm. (Length) • Dates of Test(s):July 18-20, 2000 • Place of Test(s):PCTEST Engineering Lab. Columbia, MD, U.S.A. • Report Serial No.:SAR.200718355.CKL 1 Specific Absorption Rate (SAR) is a measure of the rate of energy absorption due to exposure to an RF transmitting source (wireless portable device). 2 IEEE/ANSI Std. C95.1-1992 limits are used to determine compliance with FCC ET-Docket 93-62. Fig. 1 SAR Test Setup Test Report S/N: SAR.200718355.CKLSAR Measurement Report Test Dates: July 18-20, 2000FCC Part 22 Certification HYUNDAI Dual-Mode Cellular Phone (AMPS/CDMA) © 2000 PCTEST LabFCC ID: CKLHGC-610E (Tx 824-849 MHz)2 2.1 INTRODUCTION The FCC has adopted the guidelines for evaluating the environmental effects of radiofrequency radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-1992 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. (c) 1992 by the Institute of Electrical and E…

Text truncated - open the document above for the full version.

© 2000 PCTEST Lab ATTACHMENT P – SAR TEST SETUP PHOTOGRAPHS © 2000 PCTEST Lab FCC ID: CKLHGC-610E NVLAP Lab Code: 1004310 HYUNDAI Dual-Mode Cellular Phone (AMPS/CDMA) © 2000 PCTEST Lab FCC ID: CKLHGC-610E NVLAP Lab Code: 1004310 HYUNDAI Dual-Mode Cellular Phone (AMPS/CDMA) © 2000 PCTEST Lab FCC ID: CKLHGC-610E NVLAP Lab Code: 1004310 HYUNDAI Dual-Mode Cellular Phone (AMPS/CDMA) © 2000 PCTEST Lab FCC ID: CKLHGC-610E NVLAP Lab Code: 1004310 HYUNDAI Dual-Mode Cellular Phone (AMPS/CDMA) © 2000 PCTEST Lab FCC ID: CKLHGC-610E NVLAP Lab Code: 1004310 HYUNDAI Dual-Mode Cellular Phone (AMPS/CDMA) © 2000 PCTEST Lab FCC ID: CKLHGC-610E NVLAP Lab Code: 1004310 HYUNDAI Dual-Mode Cellular Phone (AMPS/CDMA) © 2000 PCTEST Lab FCC ID: CKLHGC-610E NVLAP Lab Code: 1004310 HYUNDAI Dual-Mode Cellular Phone (AMPS/CDMA) © 2000 PCTEST Lab FCC ID: CKLHGC-610E NVLAP Lab Code: 1004310 HYUNDAI Dual-Mode Cellular Phone (AMPS/CDMA) © 2000 PCTEST Lab FCC ID: CKLHGC-610E NVLAP Lab Code: 1004310 HYUNDAI Dual-Mode Cellular Phone (AMPS/CDMA)

FCC RF EXPOSURE INFORMATION In August 1996 the Federal Communications Commission (FCC) of the United States with its action in Report and Order FCC 96-326 adopted an updated safety standard for human exposure to radio frequency electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. The design of this phone complies with the FCC guidelines and these international standards. Use only the supplied or an approved antenna. Unauthorized antennas, modifications, or attachments could impair call quality, damage the phone, or result in violation of FCC regulations. Do not use the phone with a damaged antenna. If a damaged antenna comes into contact with the skin, a minor burn may result. Please contact your local dealer for replacement antenna. Body-worn Operation This device was tested for typical body-worn operations using the optional belt-clip/holster to provide a separation distance of 1 inch (2.54 cm) from the body. To comply with FCC RF exposure requirements, a minimum separation distance of 1 inch (2.54 cm) must be maintained between the user’s body and the belt-clip/holster, including the antenna, whether extended or retracted. Third-party belt-clips, holsters and similar accessories used by this device must meet the separation distance requirement of 1 inch (2.54 cm) from the body, and should not contain any metallic components. Body-worn accessories that do not meet these requirements, may not comply with FCC RF exposure limits and should be avoided. For more information about RF exposure, please visit the FCC website at www.fcc.gov WARNING! Read this information before using your phone

For more information about RF exposure, please visit the FCC website at www.fcc.gov FCC RF EXPOSURE INFORMATION In August 1996 the Federal Communications Commission (FCC) of the United States with its action in Report and Order FCC 96-326 adopted an updated safety standard for human exposure to radio frequency electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. The design of this phone complies with the FCC guidelines and these international standards. Use only the supplied or an approved antenna. Unauthorized antennas, modifications, or attachments could impair call quality, damage the phone, or result in violation of FCC regulations. Do not use the phone with a damaged antenna. If a damaged antenna comes into contact with the skin, a minor burn may result. Please contact your local dealer for replacement antenna. Body-worn Operation For body-worn operation, to maintain compliance with FCC RF exposure guidelines, use only Hyundai approved accessories. When carrying the phone while it is on, use the specific Hyundai belt-clip that has been tested for compliance. The use of non-Hyundai approved accessories may violate FCC RF exposure guidelines and should be avoided. WARNING! Read this information before using your phone © 2000 PCTEST Lab FCC ID: CKLHGC-610E NVLAP Lab Code: 1004310 HYUNDAI Dual-Mode Cellular phone (AMPS/CDMA) © 2000 PCTEST Lab FCC ID: CKLHGC-610E NVLAP Lab Code: 1004310 HYUNDAI Dual-Mode Cellular phone (AMPS/CDMA) © 2000 PCTEST Lab FCC ID: CKLHGC-610E NVLAP Lab Code: 1004310 HYUNDAI Dual -Mode Cellular Phone (AMPS/CDMA) © 2000 PCTEST Lab FCC ID: CKLHGC-610E NVLAP Lab Code: 1004310 HYUNDAI Dual -Mode Cellular Phone (AMPS/CDMA) © 2000 PCTEST Lab FCC ID: CKLHGC-610E NVLAP Lab Code: 1004310 HYUNDAI Dual -Mode Cellular Phone (AMPS/CDMA)

© 2000 PCTEST Engineering Lab., Inc. PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road 6660-B Dobbin Road •• Columbia, MD 21045 Columbia, MD 21045 •• U.S.A. U.S.A. TEL (410) 290-6652 TEL (410) 290-6652 •• FAX (410) 290-6654 FAX (410) 290-6654 www.pctestlab.comwww.pctestlab.com CERTIFICATE OF COMPLIANCE FCC Part 22 Certification HYUNDAI Electronics Industries Co., Ltd.Dates of Tests: July 18-20, 2000 San 136-1, Ami-Ri, Bubal-Eub Test Report S/N: 22.200718360.CKL Ichon-Si, Kyungki-Do, KOREA 467-701Test Site: PCTEST Lab, Columbia MD USA Attn: Mr. Ki-Soo Kim, QM Dept. System Quality Assurance Office FCC ID CKLHGC-610E APPLICANT HYUNDAI Electronics Industries Co., Ltd. Classification:Non-Broadcast Transmitter held to ear (TNE) FCC Rule Part(s):§22(H), §22.901(d), §2 EUT Type:Dual-Mode Cellular Phone (AMPS/CDMA) Trade Name/Model(s):HYUNDAI DX-10 Tx Frequency Range:824.04 ~ 848.97MHz (AMPS) / 824.70 ~ 848.31 MHz (CDMA) Rx Frequency Range:869.04 ~ 893.97MHz (AMPS) / 869.70 ~ 893.31 MHz (CDMA) Max. RF Output Power:0.55W ERP AMPS (27.38 dBm) / 0.34W ERP CDMA (25.27 dBm) Frequency Tolerance:0.00025% (2.5 ppm) Emission Designators:40K0F8W, 40K0F1D, 1M25F9W This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in §2.947 with the following remarks (Note Codes): * (BC) The output power is continuously variable from the value listed in this entry to 5%-10% of the value listed. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. 200718360.CKL FCC Part 22Certification © 2000 PCTEST Engineering Laboratory, Inc.FCC Part 22 TABLE OF CONTENTS ATTACHMENT A: COVER LETTER ATTACHMENT B: ATTESTATION STATEMENT(S) ATTACHMENT C: TEST REPORT 1.1 SCOPE 1 2.1 INTRODUCTION 2 3.1 INSERTS PER §2.1033(d) 3 4.1 DESCRIPTION OF TESTS 4-6 5.1 EFFECTIVE RADIATED POWER OUTPUT 7-8 6.1 RADIATED MEASUREMENTS 9-14 7.1 FREQUENCY STABILITY 15-16 8.1 PLOTS OF EMISSIONS 17 9.1 LIST OF TEST EQUIPMENT 18 10.1 SAMPLE CALCULATIONS 19 11.1 CONCLUSION 20 ATTACHMENT D: TEST PLOTS ATTACHMENT E: FCC ID LABEL & LOCATION ATTACHMENT F: TEST SETUP PHOTOGRAPHS ATTACHMENT G: EXTERNAL PHOTOGRAPHS ATTACHMENT H: INTERNAL PHOTOGRAPHS ATTACHMENT I: BLOCK DIAGRAM(S) ATTACHMENT J: CIRCUIT DIAGRAMS ATTACHMENT K: PARTS LIST/TUNE UP PROCEDURE ATTACHMENT L:OPERATIONAL DESCRIPTION ATTACHMENT M:USER’S MANUAL ATTACHMENT N:SAR MEASUREMENT REPORT ATTACHMENT O: SAR TEST DATA ATTACHMENT P:SAR TEST SETUP PHOTOGRAPHS © 2000 PCTEST Lab ATTACHMENT C – TEST REPORT Test Report S/N: 22.200718360.CKLFCC Part 22 Dates of Tests: July 18-20, 2000Certification © 2000 PCTEST LabFCC ID: CKLHGC-610E (Tx 824-849MHz) HYUNDAI Dual-Mode Cellular Phone (AMPS/CDMA)1 MEASUREMENT REPORT 1.1 Scope Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. §2.1033 General Information Applicant:HYUNDAI Electronics Industries Co., Ltd. Address:San 136-1, Ami-ri, Bubal-Eub Ichon-Si, Kyungki-Do, KOREA 467-701 Attention:Mr. Ki-Soo Kim, QM Dept System Quality Assurance Office • FCC ID:CKLHGC-610E • Trade Name(s):HYUNDAI • Model(s):DX-10 • Quantity:Quantity production is planned • Emission Designator:40K0F8W, 40K0F1D, 1M25F9W • Tx Freq. Range:824.04 – 848.97 MHz (AMPS) / 824.70 ~ 848.31 (CDMA) Rx Freq. Range:869.04 – 893.97 MHz (AMPS) / 869.70 ~ 893.31 (CDMA) • Equipment Class:Non-Broadcast Transmitter Held to Ear (TNE) • Equipment Type:Dual-Mode Cellular Phone • Modulation(s):AMPS / CDMA • Frequency Tolerance:± 0.00025% (2.5 ppm) • Max. RF Output Power:0.55W ERP AMPS (27.38 dBm) / 0.34W ERP CDMA (25.27 dBm) • FCC Rule Part(s):§22(H), §22.901(d), §2 • AC/DC Power Adapter:3.6VDC 1600mA • Battery Pack:4.2 VDC 400mAh Li-Ion • Dates of Tests:July 18-20, 2000 • Place of Tests:PCTEST Lab, Columbia, MD U.S.A. Test Report S/N: 22.200718360.CKLFCC Part 22 Dates of Tests: July 18-20, 2000Certification © 2000 PCTEST LabFCC ID: CKLHGC-610E (Tx 824-849MHz) HYUNDAI Dual-Mode Cellular Phone (AMPS/CDMA)2 2.1 INTRODUCTION These measurement tests were conducted at PCTEST Engineering Laboratory, Inc. facility in New Concept Business Park, Guilford Industrial Park, Columbia, Maryland. The site address is 6660-B Dobbin Road, Columbia, MD 21045. The test site is one of the highest points in the Columbia area with an elevation of 390 feet above mean sea level. The site coordinates are 39° 11'15" N latitude and 76° 49'38" W longitude. The facility is 1.5 miles North of the FCC laboratory, and the ambient signal and ambient signal strength are approximately equal to those of the FCC laboratory. There are no FM or TV transmitters within 15 miles of the site. The detailed description of the measurement facility was found to be in compliance with the requirements of § 2.948 according to ANSI C63.4 on October 19, 1992. Measurement Procedure The radiated and spurious measurements were made outdoors at 3-meter test range (see Figure2). The equipment under test is placed on the turntable connected to a RF wattmeter and a dummy RF load, and then its power is adjusted to its rated output. A receiving antenna located 2 meters from the turntable picks up any signal radiated from the transmitter. The turntable containing the system was rotated; the receiving antenna height was varied 1 to 4 meters and stopped at the azimuth or height producing the maximum emission. The testing procedure is …
