REPORT NO : HEI-RF-9812003 FCC ID : CKLP990 DATE : DEC. 23, 1998 ATTACHMENT A. ID LABEL INFORMATION AND LOCATION PHOTOS REPORT NO : HEI-RF-9812003 FCC ID : CKLP990 DATE : DEC. 23, 1998 1.1 ID Label Information According to the requirement section 2.925 and 2.926,the sample label shown below shall be Permanently affixed at a conspicuous location on the device supplied to the user and be readily visible to the purchaser at the time purchase Figure 3.1 PRODUCT LABEL Both the FCC ID and compliance statement are included in the product label Model NO : P990 POWER : AC 100-240VAC 3 A FCC ID : CKLP990 Serial No : This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. " Product complies with DHHS Rules-21 CFR subchapter J-applicable at date of manufacture" HYUNDAI ELECTRONICS AMERICA 166 Baypoint Parkway, San Jose , CA 95134 MANUFACTURED BY HYUNDAI ELECTRONICS IND. CO., LTD. MADE IN KOREA REPORT NO : HEI-RF-9812003 FCC ID : CKLP990 DATE : DEC. 23, 1998 1.2 Label Photo REPORT NO : HEI-RF-9812003 FCC ID : CKLP990 DATE : DEC. 23, 1998 1.3 Label Location Photo

REPORT NO : HEI-RF-9812003 FCC ID : CKLP990 DATE : DEC. 23, 1998 ATTACHMENT A. ID LABEL INFORMATION AND LOCATION PHOTOS REPORT NO : HEI-RF-9812003 FCC ID : CKLP990 DATE : DEC. 23, 1998 1.1 ID Label Information According to the requirement section 2.925 and 2.926,the sample label shown below shall be Permanently affixed at a conspicuous location on the device supplied to the user and be readily visible to the purchaser at the time purchase Figure 3.1 PRODUCT LABEL Both the FCC ID and compliance statement are included in the product label Model NO : P990 POWER : AC 100-240VAC 3 A FCC ID : CKLP990 Serial No : This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. " Product complies with DHHS Rules-21 CFR subchapter J-applicable at date of manufacture" HYUNDAI ELECTRONICS AMERICA 166 Baypoint Parkway, San Jose , CA 95134 MANUFACTURED BY HYUNDAI ELECTRONICS IND. CO., LTD. MADE IN KOREA REPORT NO : HEI-RF-9812003 FCC ID : CKLP990 DATE : DEC. 23, 1998 1.2 Label Photo REPORT NO : HEI-RF-9812003 FCC ID : CKLP990 DATE : DEC. 23, 1998 1.3 Label Location Photo

REPORT NO : HEI-RF-9812003 FCC ID : CKLP990 DATE : DEC. 23, 1998 ATTACHMENT F. INTERNAL PHOTOS REPORT NO : HEI-RF-9812003 FCC ID : CKLP990 DATE : DEC. 23, 1998 REPORT NO : HEI-RF-9812003 FCC ID : CKLP990 DATE : DEC. 23, 1998 REPORT NO : HEI-RF-9812003 FCC ID : CKLP990 DATE : DEC. 23, 1998 REPORT NO : HEI-RF-9812003 FCC ID : CKLP990 DATE : DEC. 23, 1998 REPORT NO : HEI-RF-9812003 FCC ID : CKLP990 DATE : DEC. 23, 1998 REPORT NO : HEI-RF-9812003 FCC ID : CKLP990 DATE : DEC. 23, 1998 REPORT NO : HEI-RF-9812003 FCC ID : CKLP990 DATE : DEC. 23, 1998 REPORT NO : HEI-RF-9812003 FCC ID : CKLP990 DATE : DEC. 23, 1998 REPORT NO : HEI-RF-9812003 FCC ID : CKLP990 DATE : DEC. 23, 1998 REPORT NO : HEI-RF-9812003 FCC ID : CKLP990 DATE : DEC. 23, 1998 REPORT NO : HEI-RF-9812003 FCC ID : CKLP990 DATE : DEC. 23, 1998 REPORT NO : HEI-RF-9812003 FCC ID : CKLP990 DATE : DEC. 23, 1998 REPORT NO : HEI-RF-9812003 FCC ID : CKLP990 DATE : DEC. 23, 1998 REPORT NO : HEI-RF-9812003 FCC ID : CKLP990 DATE : DEC. 23, 1998 REPORT NO : HEI-RF-9812003 FCC ID : CKLP990 DATE : DEC. 23, 1998 REPORT NO : HEI-RF-9812003 FCC ID : CKLP990 DATE : DEC. 23, 1998 REPORT NO : HEI-RF-9812003 FCC ID : CKLP990 DATE : DEC. 23, 1998 REPORT NO : HEI-RF-9812003 FCC ID : CKLP990 DATE : DEC. 23, 1998

REPORT NO : HEI-RF-9812003 FCC ID : CKLP990 DATE : DEC. 23, 1998 MEASUREMENT/TECHNICAL REPORT HYUNDAI ELECTRONICS INDUSTRIES CO.,LTD. MODEL : P990 This report concerns(check one) : Original grant X Class  change Equipment type : MONITOR Deferred grant requested per 47 CFR 0.457(d)(1)() ? yes no X If yes, defer until: agrees to notify the Commission by of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37? yes no X If no, assumed Part 15, Subpart B for unintentional radiators - the new 47 CFR [10-1-91 Edition] provision. Report prepared by : BONG JAE, HUR - Manager of QA Office Company : HYUNDAI ELECTRONICS INDUSTRIES CO., LTD. Address : SAN 136-1, AMI-RI, BUBAL-EUB, ICHON-SI, KYOUNGKI-DO, KOREA Phone No : 82-336-630-3280 Fax No : 82-336-630-3265 1 REPORT NO : HEI-RF-9812003 FCC ID : CKLP990 DATE : DEC. 23, 1998 TABLE OF CONTENTS PAGE 1. GENERAL INFORMATION........................................................................................3 1.1 Product Description...........................................................................................3 1.2 Related submittal(s)/Grant(s)............................................................................3 1.3 Tested System Details........................................................................................4 1.4 Test Methodology...............................................................................................4 1.5 Test Facility......................................................................................................4 2. SYSTEM TEST CONFIGURATION..............................................................................5 2.1 Justification.......................................................................................................5 2.2 EUT Exercise Software......................................................................................5 2.3 Cable Description..............................................................................................6 2.4 Noise Suppression Parts on Cable......................................................................6 2.5 Equipment Modifications..................................................................................7 2.6 Configuration of Tested System..........................................................................8 3. PRELIMINARY TESTS................................................................................................9 3.1 Power line Conducted Emissions Tests...............................................................9 3.2 Radiated Emissions Tests...................................................................................9 4. FINAL CONDUCTED AND RADIATED EMISSION TESTS SUMMARY.......................10 4.1 Conducted Emission Tests.................................................................................10 4.2 Radiated Emission Tests....................................................................................11 5. FIELD STRENGTH CALCULATION............................................................................12 ATTACHMENT A ....................................................ID Label / Location Info. ATTACHMENT B.....................................................External Photos. ATTACHMENT C .....................................................Block Diagram.. ATTACHMENT D .....................................................Test Setup Photos. ATTACHMENT E .....................................................User’s Manual. ATTACHMENT F .....................................................Internal Photos. 2 REPORT NO : HEI-RF-9812003 FCC ID : CKLP990 DATE : DEC. 23, 1998 1. GENERAL INFORMATION 1.1 Product Description The Hyundai Electronics Industries Co., Ltd. Model P990(refered to as the EUT in this report) is a 19"COLOR Monitor HOR. Freq.93.5kHz w/max. Resolution of 1600×1200 Non-Interlaced. Product specification information described herein was obtained from product data sheet or user's manual. CHASSIS TYPE PLASTIC LIST OF EACH OSC. OR XTAL. FREQ.(FREQ.≥ 1MHz) 6 MHz CHIPSET BRAND AND PART NO. SAMSUNG : KA3843B SAMSUNG : KA358 PHILIPS : TDA4856 MITSUBISH : M52743ASP NATIONAL : LM4202T MOTOROLA : MC68HC705BD9B MOTOROLA : LSC4388P2 MATSUSHITA : AN5870K POWER REQUIREMENT 100 - 240 VAC 50/60Hz 3A NUMBER OF LAYERS MAIN BOARD 1 LAYER CRT SOCKET BOARD 1 LAYER BNC BOARD 1 LAYER FRONT CONTROL BOARD 1 LAYER MAX. RESOLUTION 1600 X 1200 NON-INTERLACED (@ 93.5 kHz/75 Hz) H-SYNC FREQUENCY RANGE 30 kHz  95 kHz V-SYNC FREQUENCY RANGE 50 Hz  150 Hz CRT SIZE 19" (PANASONIC / Type : M46LNS180X18) VIDEO CONNECTOR TYPE D-SUB 15-PIN, BNC 1.2 Related Submittal(s) / Grant(s) ORIGINAL SUBMITTAL ONLY 3 REPORT NO : HEI-RF-9812003 FCC ID : CKLP990 DATE : DEC. 23, 1998 The Model names for all equipment, plus descriptions used in the tested system (including inserted cards) are: 1.4 Test Methodology Both conducted and radiated testing were performed according to the procedures in ANSI C63.4/1992. Radiated testing was performed at an antenna to EUT distance of 3 meters. 1.5 Test Facility The open area test site and conducted measurement facility used to collect the radiated data are located at the 254-1,MAEKOK-RI,HOBUP-MYUN,ICHON-SI,KYOUNGKI-DO, 467-701,KOREA. The site is constructed in conformance with the requirements of ANSI C63.4 and CISPR Publication 22. Detailed description of test facility was submitted to the Commission on May 22, 1997 and accepted dated July 25,1997(1300F2) 4 DEVICE TYPEMANUFACTURER MODEL NUMBER FCC ID / DoCCONNECTED TO COLOR MONITOR(EUT) HYUNDAIP990CKLP990HOST PC(HOST)H/PHP BRIO 80XXDoCN/A KEYBOARDH/PSK-2501-2D-KDZL211029HOST PRINTERH/PC2168AB94C2121XHOST MODEMHYUNDAIHMD-2404MCKL8J7HMD-2404MHOST VIDEO CARDDIAMONDSTEATH 3D 3000FTUPCI130208HOST MOUSEH/PM-S34GYUR38SKHOST REPORT NO : HEI-RF-9812003 FCC ID : CKLP990 DATE : DEC. 23, 1998 2.SYSTEM TEST CONFIGURATION 2.1 Justification The device was confi…
