CQOED00250Smart Key ECU

. Manual Requirement of FCC / IC Our product (ED00250) is one of vehicle parts incorporated into the vehicle as original equipment. Therefore, we will not supply the user’s manual. However, we will ask the vehicle manufacturer to include following statements in the vehicle user’s manual in accordance with FCC and IC requirements. 1. Requirement for User Manual 1.1. FCC Requirement 1.1.1. In accordance with 15.21 of FCC rule, following statement will be included in the user’s manual. 1.1.2. In accordance with requirement of FCC§15.19(a)(5), following statement will be included in the user’s manual. 1.2. IC Requirement 1.2.1. In accordance with requirement of RSS-GEN, following statement will be included in the user’s manual. FCC WARNING Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas provoquer de brouillage, et (2) l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. Smart Key ECU Product Outline Product Description Product Type Number ED00250 RF characteristic Nominal frequency 433.92MHz Local oscillator frequency 21.948717MHz (Crystal) RF Antenna Internal antenna LF characteristic Nominal frequency 134.2kHz Local oscillator frequency 4.026MHz (Crystal) LF Antenna External antenna (Ferrite antenna coil) Transponder characteristic Nominal frequency 134.2kHz Local oscillator frequency 4.00MHz (Ceramic Resonator) Transponder Antenna External antenna (antenna coil) Power Supply Nominal supply voltage 12V DC The Smart Key system is a comfort feature that allows the user to lock, unlock the doors of the vehicle without using a mechanical key. The user has to carry with him the Smart Key Fob as a wireless authentication is performed when toggle button or Start Stop Button inputs are triggered. For communication with the SMART Key FOB, Smart Key ECU generates a request (challenge) as an encoded and modulated signal (134.2 kHz..) at the inductive antenna outputs and receives the SMART Key FOB's response via the external RF ANT and internal receiver This product is installed inside the vehicle. Appearance Unit : mm

February 06, 2014 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 LETTER OF AUTHORIZATION To whom it may concern: I, the undersigned, hereby authorize Lab Manager Feel. Jeong (or Logan. Lee) and of SGS Korea Co., Ltd. and hereafter referred to as SGS Korea, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Lab Manager Feel. Jeong (or Logan. Lee) of SGS Korea Co., Ltd. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti‐Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing SGS Korea as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certifie d as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; DENSO KOREA ELECTRONICS CORPORATION 853-11, Oe-Dong, Sungsan-Gu, Changwon City, Kyungnam, Korea Tel : +82-31-3 40-1938 i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours DENSO KOREA ELECTRONICS CORPORATION 853-11, Oe-Dong, Sungsan-Gu, Changwon City, Kyungnam, Korea Tel : +82-31-34 0-1938 Dong-ki, Cho / General Manager DENSO KOREA ELECTRONICS CORPORATION Smart Team, R&D Center February 06, 2014

February 07, 2014 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 REQUEST OF CONFIDENTIALITY for FCC ID: CQOED00250 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, DENSO KOREA ELECTRONICS hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short‐Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04‐1705. This provision will give Samsung Electronics Co., Ltd temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: CONFIDENTIAL LIST Permanent 1 Block Diagram 2 Operational Descriptions 3 Schematics Short‐Term 4 External Photos 5 Internal Photos 6 Test‐Setup Photos 7 User Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely Yours, Dong-ki, Cho / General Manager Smart Team, R&D Center February 07, 2014 DENSO KOREA ELECTRONICS CORPORATION 853-11, Oe-Dong, Sungsan-Gu, Changwon City, Kyungnam, Korea Tel : +82-31-340-1938

Label Info. MODEL: ED00250 FCC ID: CQOED00250 IC: 1551E-ED00250 00250 00250

Internal photos of EUT Internal view of EUT Top view of Main Board Bottom view of Main Board

Report Number:F690501/RF-RTL007351-1Page:2of23 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGSKoreaCo.,Ltd.(GunpoLaboratory)4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 435-040 http://www.sgsgroup.kr RTT5041-20(2014.01.20)(2)Tel. +82 31 428 5700 / Fax. +82 31 427 2370 A4(210 mmx297 mm) INDEX TABLE OF CONTENTS Page 1. General Information -----------------------------------------------------------------------3 2. Field Strength of Fundamental ----------------------------------------------------------5 3. Spurious Emission--------------------------------------------------------------------------10 4. Occupied Bandwidth-----------------------------------------------------------------------16 Report Number:F690501/RF-RTL007351-1Page:3of23 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGSKoreaCo.,Ltd.(GunpoLaboratory)4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 435-040 http://www.sgsgroup.kr RTT5041-20(2014.01.20)(2)Tel. +82 31 428 5700 / Fax. +82 31 427 2370 A4(210 mmx297 mm) 1. General Information 1.1. Testing Laboratory SGS Korea Co., Ltd. (Gunpo Laboratory) -Wireless Div. 3FL, 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 435-040 All SGS services are rendered in accordance with the applicable SGS conditions of service available on request and accessible athttp://www.sgs.com/en/Terms-and-Conditions.aspx. Telephone:+82 31 428 5700 FAX:+82 31 427 2370 1.2. Details of Applicant Applicant:KOREA ELECTRONICS CORPORATION Address:(Oe-dong) 631, Nammyeon-ro, Sungsan-Gu, Chang-won-si, Gyeongsangnam-do, Korea Contact Person:Cho, Dong-Ki Phone No.:+82 31 340 1938 1.3. Description of EUT Kind of Product Smart Key ECU Model Name ED00250 Power Supply DC 12 V (Vehicle battery) Frequency Range Tx: 134.20㎑(LF Antenna) Rx: 433.92㎒(RF Antenna) Modulation Technique ASK Number of Channels 1 Operating Conditions -30°C~ 80°C Antenna Type Internal type (Loop Coil Antenna) 1.4. Declarations by the manufacturer -RF antenna is only Receiver antenna - The EUT of antennas cannot operate at the same time. Report Number:F690501/RF-RTL007351-1Page:4of23 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGSKoreaCo.,Ltd.(GunpoLaboratory)4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 435-040 http://www.sgsgroup.kr RTT5041-20(2014.01.20)(2)Tel. +82 31 428 5700 / Fax. +82 31 427 2370 A4(210 mmx297 mm) 1.5. Test Equipment List EquipmentManufacturerModelS/NCal. Date Cal. Interval Cal. Due. Spectrum AnalyzerR&SFSV30101004Jul. 20, 2013AnnualJul. 20, 2014 Signal GeneratorR&S SMR40100540 Jan. 08, 2014AnnualJan. 08, 2015 Loop AntennaR&SFMZB 15191519-039Jul. 09, 2013BiennialJul. 09, 2015 Bilog AntennaSCHWARZBECKVULB91639163-437Oct. 04, 2012BiennialOct. 04, 2014 DC Power SupplyAgilent U8002AMY48490027 Jan. 03, 2014 Annual Jan. 03, 2015 Test ReceiverR & SESU40100075Feb. 15, 2013AnnualFeb. 15, 2014 PreamplifierH.P.8447D2727A05143Aug. 08, 2013AnnualAug. 08, 2014 Antenna MasterMA4000-EPINN-CON/AN.C.R.N.C.R.N.C.R. Turn TableDT-3000S-3TINN-CON/AN.C.R.N.C.R.N.C.R. Anechoic ChamberSY Corporation L × W × H (21.5 m × 13.0 m × 9.0 m) N/A N.C.R.N.C.R.N.C.R. 1.6. Test Report Revision RevisionReport numberDescription 0F690501/RF-RTL007351Initial 1F690501/RF-RTL007351-1 1. Changed model name. 2. Correct the typo. 1.7. Summary of Test Results The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15 Subpart B&C 15.209/ IC RSS-210 Issue8, RSS-Gen Issue3 Section in FCC 15 Subpart B&C§15.209 Section in IC RSS-210 Issue8, RSS-Gen Issue 3 Test ItemResult 15.209(a) RSS-210 Issue8, 2.5.1 RSS-Gen Issue3, 7.2.5 Table 6 Radiated emission, Spurious Emission and Field Strength of Fundamental Complied -RSS-Gen Issue3, 4.6.1Occupied BandwidthComplied Report Number:F690501/RF-RTL007351-1Page:5of23 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGSKoreaCo.,Ltd.(GunpoLaboratory)4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 435-040 http://www.sgsgroup.kr RTT5041-20(2014.01.20)(2)Tel. +82 31 428 5700 / Fax. +82 31 427 2370 A4(210 mmx297 mm) 2. Field Strength of Fundamental 2.1. Test Setup The diagram below shows the test setup that is utilized to make the measurements for emission from 9㎑to 30㎒Emissions. The diagram below shows the test setup that is utilized to make the measurements for emission from 30㎒to 1㎓Emissions. Report Number:F690501/RF-RTL007351-1Page:6of23 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGSKoreaCo.,Ltd.(GunpoLaboratory)4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 435-040 http://www.sgsgroup.kr RTT5041-20(2014.01.20)(2)Tel. +82 31 428 5700 / Fax. +82 31 427 2370 A4(210 mmx297 mm) 2.2. Limit 2.2.1. Radiated emission limits, general requirements Except as provided elsewhere in this Subpart, the emissions from an intentional radiator shall not exceed the field strength levels specified in the following table: Frequency (㎒) Field Strength (microvolts/meter) Measurement Distance (meter) 0.009 – 0.4902400/F(㎑)300 0.490 – 1.70524000/F(㎑)30 1.705 – 30.03030 30 -88100**3 88 -216150**3 216 - 960200**3 Above 9605003 ** Except as provided in paragraph (g), fundamental emissions from intentional radiators operating under this Section shall not be located in the frequency bands 54-72㎒, 76-88㎒, 174-216㎒or 470-806㎒. However, …

Text truncated - open the document above for the full version.

Test setup photo of EUT Photo of Test setup
