CW21100-5Carriage Control Transmitter used to remotely control a carriage used in high-lead logging operations

TALKIE TOOTER 1100 USER MANUAL The information contained in this document is subject to change without notice. In no event shall Rothenbuhler Engineering Company be liable for errors contained herein or for special, indirect, or consequential damages or injuries of any nature resulting from use of information in this document. ROTHENBUHLER ENGINEERING P.O. BOX 708 524 RHODES ROAD SEDRO WOOLLEY, WA 98284 1100-A19 2/12/2015 ©2015 Rothenbuhler Engineering All Rights reserved Talkie Tooter 1100 User Manual 2 TABLE OF CONTENTS TABLE OF CONTENTS ............................................................................................................................................2 SAFETY WARNINGS ................................................................................................................................................3 LIMITED WARRANTY.............................................................................................................................................4 REGULATORY INFORMATION ............................................................................................................................5 FCC Notice ...................................................................................................................................................................5 RADIATION HAZARD WARNING .........................................................................................................................5 TRANSMITTER OPERATION.................................................................................................................................7 EAGLE VI HYDRAULIC OR SUPER EAGLET SLACKPULLER .............................................................................7 EAGLE SLACKPULLER ...........................................................................................................................................8 EAGLE V & D7 DRUM CARRIAGE .........................................................................................................................9 EAGLE VI WINCH ..................................................................................................................................................10 ACME 3 SPEED SLACKPULLER...........................................................................................................................11 BATTERY CHARGING...........................................................................................................................................12 TRANSMITTER SPECIFICATIONS .....................................................................................................................13 AUTHORIZED TALKIE TOOTER SALES AND SERVICE CENTERS .........................................................14 CALIFORNIA..........................................................................................................................................................14 IDAHO.....................................................................................................................................................................14 MONTANA...............................................................................................................................................................14 OREGON.................................................................................................................................................................14 WASHINGTON........................................................................................................................................................15 AUSTRALIA.............................................................................................................................................................15 CANADA..................................................................................................................................................................15 CANADA (continued)..............................................................................................................................................16 CHILE......................................................................................................................................................................16 NEW ZEALAND.......................................................................................................................................................16 Chapter Page Talkie Tooter 1100 User Manual 3 SAFETY WARNINGS 1) Always follow your local safety regulations. This manual and its procedures are secondary to governmental regulations, local regulations or company safety regulations and procedures. The operation procedures in this manual are only suggestions and should be checked against the above safety regulations and procedures. Company training should include the proper use of this equipment and only trained personnel should use it. 2) Never rely on this equipment or any equipment totally for your safety. All mechanical and electronic equipment can fail. Always have a safety procedure that will protect you and minimize hazards of such failure. 3) This Talkie Tooter® Radio Equipment should be installed by a Factory Authorized installer. Improper installation may result in Safety Hazards, Poor Performance and/or Damage to Equipment, which may not be covered by warranty. 4) The 1059-4 Battery Chargers is for dry indoor use only. Only use a manufacturer authorized battery charger. Attempting to use an unauthorized battery charger may result in a safety hazard and equipment damage may occur. Disconnect the battery charger from the unit when charging has completed. 5) Do not connect the 1100-5 Yarder Transmitter to a battery charger. The Yarder Transmitter does not have a battery and may be damaged if connected to a battery charger. 6) This equipment does not include any internal user serviceable items. Opening the internal cases is strictly p…

Text truncated - open the document above for the full version.

Nonconformities FCC ID: CW21100 ‐ 5 (CKC CS Ref # 96354 ‐ 17 ‐ FCC) The items listed below represent requests for information following review of this application for certification under United States (FCC) regulations. Further question may arise pending review of responses to these items. OK ID # Non ‐ Conformity or Comment Submitted Response Respondent / Date of Response x 1 FCC and IC ITEM: The transmitter information cannot be located on the schematics provided. Please explain and/or provide updated schematics showing the transmitter circuitry. Please see attached transmitter schematic exhibits. Rothenbuhler Engineering 2/13/2015 x 2 Please provide the equipment’s emissions designator. (see similar IC item). 9K00F2D Maximum Modulation (M), kHz = 2.4 Maximum Deviation (D), kHz = 2.1 Constant Factor (K) = 1 Necessary Bandwidth (BN) , kHz = (2 x M) + (2 x D x K) = 9.00 Necessary Bandwidth = 9K00 Frequency Modulation = F Single Channel digital information with modulating sub ‐ carrier = 2 Data transmission = D Rothenbuhler Engineering 2/13/2015 x 3 The power output listed in the application form is 0.5 W, however the operational description indicates power output is configurable to 6W [operational description pages 4 and 6]. CKC CS noted that changes could be made to frequency assignments by an authorized, licensed service shop; does the also extend to power output settings? Please clarify how equipment is controlled such that the transmitter power cannot exceed the power certified. NOTICE: If equipment is certified for 0.5W, a request for equipment authorization for higher power cannot be performed via PCII; a new The transceiver module is capable of power output levels of ½ watt to 6 watts. These applications (1100 ‐ 3 Carriage Transmitter & 1100 ‐ 5 Yarder Transmitter) limit the power output level to ½ watt. Adjustments to the power output level to obtain ½ watt are limited to factory authorized & trained service shops ‐ as are frequency assignments. The power output level is controlled Rothenbuhler Engineering 2/13/2015 equipment certification would be required. If equipment certification is sought during this evaluation for output power >0.5W, then updated test data will be required demonstrating compliance with emissions limitations at the higher output power. with a digital potentiometer and active circuit feedback. The value for the digital potentiometer is stored in non ‐ volatile memory and automatically loaded each time the transmitter transmits. Factory and authorized service center personnel are trained to adjust the power output level to ½ watt conducted via adjustments to the digital potentiometer value using factory software and instructions. Please see attached updated “1100 Talkie Tooter Factory Configuration and Alignment Procedures” exhibit. x 4 Please clarify frequency deviation shown in test report 96354 ‐ 8 on pages 36 ‐ 39; the report does not indicate frequency deviation limits. Limits are set for 12.5 kHz Channels CKC (SP) 2/13/15 x 5 The operational description (page 4) states that the equipment supports both data and voice communications. Furthermore, the operational description states that the equipment operates on 6.25 and 12.5 kHz channel bandwidths. However, the data provided in the test report seems to indicate testing only on the 6.25kHz bandwidth using one modulation type. Please clarify operational modes and configurations. If equipment is able to operate with wider bandwidths, please provided updated test data demonstrating compliance with emissions limitations in that operational mode. While the transceiver module is capable of 6.25 kHz and 12.5 kHz channel bandwidths with data and voice communications, these applications (1100 ‐ 3 Carriage Transmitter & 1100 ‐ 5 Yarder Transmitter) only operate on 12.5 kHz bandwidth channels and only with data communications. These applications do not incorporate a microphone and are not voice capable. All submitted test data is for 12.5 kHz bandwidth channels. Rothenbuhler Engineering 2/13/2015 Please see attached updated operational descriptions. x 6 Please provide attestation in accordance with 90.203(j)(1) regarding voice operation on public safety frequencies; clarify whether equipment is capable of operation on nationwide interoperability channel(s) within this band. Please provide attestation in accordance with 90.203(j)(5) regarding spectrum efficient of one voice channel per 6.25kHz of channel bandwidth, or clarify operational frequency ranges with the business/industrial pool. And any other applicable provisions of part 90 related to operation in the 150 ‐ 174 MHz bands and/or clarify requested certification of frequency range(s). This equipment (1100 ‐ 3 Carriage Transmitter & 1100 ‐ 5 Yarder Transmitter) is not designed to, nor is it capable of transmitting voice. This equipment’s output level is not greater than 500 mW. However, the equipment does have a data rate of 9600 bits per second and operates on 12.5 kHz bandwidth channels. Thus it meets 90.203(j)(5) requirement of a minimum data rate of 4800 bits per second per 6.25 kHz of channel bandwidth. Rothenbuhler Engineering 2/13/2015

TYPE OF EXHIBIT: Photographs – External MANUFACTURER: Rothenbuhler Engineering, Inc. 524 Rhodes Road Sedro Woolley, WA 98284-0708 MODEL: 1100-3 FCC ID: CW21100-5 IC: 2758A-110005 TYPE OF UNIT: Carriage Transmitter DATE: December 30, 2014 External Photographs follow: Picture 1 1100-3 Side View Picture 2 1100-3 Side View 2 Picture 3 1100-3 Top View Picture 4 1100-3 Bottom View Picture 5 1100-3 Charge End View Picture 6 1100-3 Antenna End View Picture 7 1100-3 Ortho View Picture 8 1100-3 Barrel Picture 9 1100-3 Internal Assembly Into Barrel

TYPE OF EXHIBIT: Photographs – External MANUFACTURER: Rothenbuhler Engineering, Inc. 524 Rhodes Road Sedro Woolley, WA 98284-0708 MODEL: 1100-5 FCC ID: CW21100-5 IC: 2758A-110005 TYPE OF UNIT: Yarder Transmitter DATE: December 30, 2014 External Photographs follow: Picture 1 1100-5 Top View Picture 2 1100-5 Side View Picture 3 1100-5 External Power Connector Side View Picture 4 1100-5 External Antenna Connector (TNC) End View Picture 5 1100-5 Programmer Interface End View Picture 6 1100-5 Programmer Interface View Close Up Picture 7 1100-5 Bottom View Picture 8 1100-5 Barrel Picture 9 Internal Assembly into Barrel

TYPE OF EXHIBIT: Equipment Label - Location MANUFACTURER: Rothenbuhler Engineering, Inc. 524 Rhodes Road Sedro Woolley, WA 98284-0708 MODEL: 1100-3 FCC ID: CW21100-5 IC: 2758A-110005 TYPE OF UNIT: Carriage Transmitter DATE: December 30, 2014 Photograph of unit showing location of equipment label follows: Picture 1 1100-3 Label Location

TYPE OF EXHIBIT: Equipment Label - Sample MANUFACTURER: Rothenbuhler Engineering, Inc. 524 Rhodes Road Sedro Woolley, WA 98284-0708 MODEL: 1100-3 FCC ID: CW21100-5 IC: 2758A-110005 TYPE OF UNIT: Carriage Transmitter DATE: December 30, 2014 Sample of equipment label follows: Equipment Label Size: 0.47” x 2.4” TALKIE TOOTER S/N: 1100-3-S00103 SYSTEM: 0000000001 FCC ID: CW21100-5 IC: 2758A-110005

TYPE OF EXHIBIT: Equipment Label - Location MANUFACTURER: Rothenbuhler Engineering, Inc. 524 Rhodes Road Sedro Woolley, WA 98284-0708 MODEL: 1100-5 FCC ID: CW21100-5 IC: 2758A-110005 TYPE OF UNIT: Yarder Transmitter DATE: December 30, 2014 Photograph of unit showing location of equipment label follows: Picture 1 1100-5 Label Location

TYPE OF EXHIBIT: Equipment Label - Sample MANUFACTURER: Rothenbuhler Engineering, Inc. 524 Rhodes Road Sedro Woolley, WA 98284-0708 MODEL: 1100-5 FCC ID: CW21100-5 IC: 2758A-110005 TYPE OF UNIT: Yarder Transmitter DATE: December 30, 2014 Sample of equipment label follows: Equipment Label Size: 1.88” x 3.25”

TYPE OF EXHIBIT: Photographs - Internal MANUFACTURER: Rothenbuhler Engineering, Inc. 524 Rhodes Road Sedro Woolley, WA 98284-0708 MODEL: 1100-3 FCC ID: CW21100-5 IC: 2758A-110005 TYPE OF UNIT: Carriage Transmitter DATE: December 30, 2014 Digital Control Board Photographs follow: Picture 1 1100-3 Digital Board Top View Picture 2 1100-3-2 Digital Board Bottom View Picture 3 1100-3-2 Digital Board Antenna Interface End View Picture 4 1100-3-2 Digital Board Side View Picture 5 1100-3-2 Internal Assembly Top View Picture 6 1100-3-2 Internal Assembly Bottom View Picture 7 1100-3-2 Internal Assembly Antenna Interface Top View Picture 8 1100-3-2 Internal Assembly Antenna Interface End View Picture 9 1100-3-2 Internal Assembly Charger Interface End View Picture 10 1100-3-2 Internal Interface Battery Block / Charge Board Picture 11 Battery Block With O-Ring Gasket Picture 12 1100-3-2 Internal Assembly Side View Picture 13 1100-3-2 Internal Assembly Side View Picture 14 1100-3-2-4 Charge Interface Board Top View Picture 15 1100-3-2-4 Charge Interface Board Bottom View Picture 16 1100-2-6 Battery Pack, 14.4V 350mAH NiMH

TYPE OF EXHIBIT: Photographs - Internal MANUFACTURER: Rothenbuhler Engineering, Inc. 524 Rhodes Road Sedro Woolley, WA 98284-0708 MODEL: 1100-3 FCC ID: CW21100-5 IC: 2758A-110005 TYPE OF UNIT: Carriage Transmitter DATE: December 30, 2014 RF Transceiver Board Photographs follow: RF Transceiver Board – Top RF Transceiver Board – Shield Removed (Optional BNC connector shown instead of MMCX Cable) RF Transceiver Board - Bottom

TYPE OF EXHIBIT: Photographs - Internal MANUFACTURER: Rothenbuhler Engineering, Inc. 524 Rhodes Road Sedro Woolley, WA 98284-0708 MODEL: 1100-5 FCC ID: CW21100-5 IC: 2758A-110005 TYPE OF UNIT: Yarder Transmitter DATE: December 30, 2014 Digital Control Board Photographs follow: Picture 1 1100-3-2 Digital Board Top View Picture 2 1100-3-2 Digital Board Bottom View Picture 3 1100-3-2 Antenna Interface End View Picture 4 1100-3-2 Digital Board Side View Picture 5 1100-5-2 Internal Assembly Top View Picture 6 1100-5-2 Internal Assembly Bottom View Picture 7 1100-5-2 Internal Assembly Side View Picture 8 1100-5-2 Internal Assembly Side View 2 Picture 9 1100-5-2 Internal Assembly End View Picture 10 1100-5-2 Internal Assembly Interface Board Connections Picture 11 1100-5-2-1 Voltage Regulator Board Top View Picture 12 1100-5-2-1 Voltage Regulator Board Bottom View

TYPE OF EXHIBIT: Photographs - Internal MANUFACTURER: Rothenbuhler Engineering, Inc. 524 Rhodes Road Sedro Woolley, WA 98284-0708 MODEL: 1100-5 FCC ID: CW21100-5 IC: 2758A-110005 TYPE OF UNIT: Yarder Transmitter DATE: December 30, 2014 RF Transceiver Board Photographs follow: RF Transceiver Board – Top RF Transceiver Board – Shield Removed (Optional BNC connector shown instead of MMCX Cable) RF Transceiver Board - Bottom

This report contains a total of 42 pages and may be reproduced in full only. Partial reproduction may only be done with the written consent of CKC Laboratories, Inc. Rothenbuhler Engineering TEST REPORT FOR Carriage Transmitter, Model: 1100-3 Yarder Transmitter, Model: 1100-5 Tested To The Following Standards: FCC Part 90I Report No.: 96354-8 Date of issue: January 23, 2015 This test report bears the accreditation symbol indicating that the testing performed herein meets the test and reporting requirements of ISO/IEC 17025 under the applicable scope of EMC testing for CKC Laboratories, Inc. We strive to create long-term, trust based relationships by providing sound, adaptive, customer first testing services. We embrace each of our customers’ unique EMC challenges, not as an interruption to set processes, but rather as the reason we are in business. Page 2 of 42 Report No.: 96354-8 TABLE OF CONTENTS Administrative Information .......................................................................................................................... 3 Test Report Information ............................................................................................................................................ 3 Report Authorization ................................................................................................................................................. 3 Test Facility Information ............................................................................................................................................ 4 Software Versions ...................................................................................................................................................... 4 Site Registration & Accreditation Information .......................................................................................................... 4 Summary of Results ................................................................................................................................................... 5 Modifications During Testing ..................................................................................................................................... 5 Conditions During Testing.......................................................................................................................................... 5 Equipment Under Test ............................................................................................................................................... 6 Peripheral Devices ..................................................................................................................................................... 6 FCC Part(s) 2 / 90I ......................................................................................................................................... 7 2.1046 / 90.205(d) RF Power Output......................................................................................................................... 7 2.1049 / 90.209(b)(5) Bandwidth Limitations.......................................................................................................... 15 2.1051 / 90.210(d) Spurious Emissions at Antenna Terminals ................................................................................ 19 2.1053 / 90.210(d) Field Strength of Spurious Radiation ........................................................................................ 28 2.1055 / 90.213 Frequency Stability ........................................................................................................................ 32 2.1055 / 90.214 Transient Frequency Behavior....................................................................................................... 36 Supplemental Information .......................................................................................................................... 41 Measurement Uncertainty ...................................................................................................................................... 41 Emissions Test Details .............................................................................................................................................. 41 Page 3 of 42 Report No.: 96354-8 ADMINISTRATIVE INFORMATION Test Report Information REPORT PREPARED FOR: REPORT PREPARED BY: Rothenbuhler Engineering 524 Rhodes Rd. Sedro Woolley, WA 98284-0708 Morgan Tramontin CKC Laboratories, Inc. 5046 Sierra Pines Drive Mariposa, CA 95338 Representative: Tom Jacobson Project Number: 96354 Customer Reference Number: 25535 DATE OF EQUIPMENT RECEIPT: December 10, 2014 DATE(S) OF TESTING: December 10, 2014 - January 9, 2015 Report Authorization The test data contained in this report documents the observed testing parameters pertaining to and are relevant for only the sample equipment tested in the agreed upon operational mode(s) and configuration(s) as identified herein. Compliance assessment remains the client’s responsibility. This report may not be used to claim product endorsement by A2LA or any government agencies. This test report has been authorized for release under quality control from CKC Laboratories, Inc. Steve Behm Director of Quality Assurance & Engineering Services CKC Laboratories, Inc. Page 4 of 42 Report No.: 96354-8 Test Facility Information Our laboratories are configured to effectively test a wide variety of product types. CKC utilizes first class test equipment, anechoic chambers, data acquisition and information services to create accurate, repeatable and affordable test results. TEST LOCATION(S): CKC Laboratories, Inc. 22116 23rd Drive S.E., Suite A Bothell, WA 98021-4413 Software Versions CKC Laboratories Proprietary Software Version EMITest Emissions 5.00.14 Immunity 5.00.07 Site Registration & Accreditation Information Location CB # TAIWAN CANADA FCC JAPAN Bothell US0081 SL2-IN-E-1145R 3082C-1 318736 A-0148 Page 5 of 42 Rep…
