CWTWC1U326Passive Entry System (Tuner)

User’s Manual MODEL No.: TWC1U326 The radio frequency keyless entry system has the following functions. 1. Locking and unlocking the doors without mechanical key. 2. Sounding a panic alarm during vehicle is not running. This system consists of RF Tuner, transmitters, and BCM. The RF Tuner (EUT) is supplied 5V from BCM. It is designed to operate on a single fixed frequency RF 433.92MHz by amplitude modulation. It receives unique identification code and function code transmitted from transmitters. After receiving RF signal, demodulation IC in Tuner demodulates RF signal from transmitters. And then driving circuit in Tuner outputs the demodulated signal to BCM. .Basic specifications  Operating supply voltage 4.5V ~ 5.5V  Operating supply current < 12mA  Stand-by current < 1.0mA  Operating ambient temperature -45 o C to +85 o C FCC This device complies with Part 15 of the FCC Rules and RSS-Gen of IC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC WARNING Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

TWC1U326 CWTWC1U326 CAN RSS-Gen/CNR-Gen

Test report No. : 32EE0264-HO-02-B-R1 Page : 2 of 12 Issued date : April 4, 2012 Revised date : April 13, 2012 FCC ID : CWTWC1U326 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 CONTENTS PAGE SECTION 1: Customer information ...................................................................................... 3 SECTION 2: Equipment under test (E.U.T.) ........................................................................ 3 SECTION 3: Test specification, procedures & results ......................................................... 4 SECTION 4: Operation of E.U.T. during testing ................................................................. 6 SECTION 5: Radiated Emission ............................................................................................ 7 APPENDIX 1: Data of EMI test ............................................................................................. 8 Radiated Emission ............................................................................................................................ 8 APPENDIX 2: Test instruments ........................................................................................... 10 APPENDIX 3: Photographs of test setup............................................................................. 11 Radiated Emission .......................................................................................................................... 11 Worst Case Position (Horizontal: X-axis/ Vertical:Y-axis) ........................................................ 12 Test report No. : 32EE0264-HO-02-B-R1 Page : 3 of 12 Issued date : April 4, 2012 Revised date : April 13, 2012 FCC ID : CWTWC1U326 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 SECTION 1: Customer information Company Name : Alps Electric Co., Ltd. Address : 6-3-36, Nakazato, Furukawa, Osaki-city, Miyagi-pref, 989-6181, Japan Telephone Number : +81-229-23-5111 Facsimile Number : +81-229-22-3755 Contact Person : Toru Kinoshita SECTION 2: Equipment under test (E.U.T.) 2.1 Identification of E.U.T. Type of Equipment : Passive Entry System (Tuner) Model No. : TWC1U326 (Tuner) Serial No. : Refer to Section 4, Clause 4.2 Receipt Date of Sample : January 28, 2012 Country of Mass-production : Japan Condition of EUT : Production prototype (Not for Sale: This sample is equivalent to mass-produced items.) Modification of EUT : No Modification by the test lab 2.2 Product description Model No: TWC1U326 (referred to as the EUT in this report) is the Passive Entry System (Tuner). General Specification Feature of EUT : The Tuner receives RF signal from a remote control, and performs locking and unlocking of a door and an engine start. Clock frequency in the system : 40.66027MHz (Oscillator circuit) Radio Specification Frequency of operation : 433.92MHz Oscillator Frequency : 40.66027MHz Local Oscillator Frequency : 433.7MHz Intermediate Frequency : 220kHz Type of modulation : FSK Operating voltage : DC 4.5 to 5.5V Antenna Type : Internal Antenna (Monopole) Operating Temperature : -40 to +85 deg. C FCC15.111(b) The receiving antenna (of this EUT) is installed inside the EUT and cannot be removed (permanently attached). Therefore, Radiated emission test was performed. Test report No. : 32EE0264-HO-02-B-R1 Page : 4 of 12 Issued date : April 4, 2012 Revised date : April 13, 2012 FCC ID : CWTWC1U326 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 SECTION 3: Test specification, procedures & results 3.1 Test specification Test Specification : FCC Part 15 Subpart B: 2012, final revised on February 1, 2012 Title : FCC 47CFR Part15 Radio Frequency Device Subpart B Unintentional Radiators 3.2 Procedures and results Item Test Procedure Limits Deviation Worst margin Result Conducted emission FCC: ANSI C63.4: 2003 7. AC powerline conducted emission measurements FCC: Part 15 Subpart B 15.107(a) N/A *1) N/A N/A IC: RSS-Gen 7.2.4 IC: RSS-Gen 7.2.4 Radiated emission FCC: ANSI C63.4: 2003 8. Radiated emission measurements FCC: Part 15 Subpart B 15.109(a) N/A 18.5dB 867.44MHz Vertical, QP Complied IC: RSS-Gen 4.10 IC: RSS-Gen 6.1 *Note: UL Japan, Inc’s EMI Work Procedure 13-EM-W0420. *1) The test is not applicable since the EUT is not the device that is designed to be connected to the public utility (AC) power line. 3.3 Addition to standard No addition, exclusion nor deviation has been made from the standard. 3.4 Uncertainty EMI The following uncertainties have been calculated to provide a confidence level of 95% using a coverage factor k=2. Test room (semi- anechoic chamber) Radiated emission (3m*)(+dB) (1m*)(+dB) (0.5m*)(+dB) 9kHz -30MHz 30MHz -300MHz 300MHz -1GHz 1GHz -10GHz 10GHz -18GHz 18GHz -26.5GHz 26.5GHz -40GHz No.1 4.2dB 5.0dB 5.1dB 4.7dB 5.7dB 4.4dB 4.3dB No.2 4.1dB 5.2dB 5.1dB 4.8dB 5.6dB 4.3dB 4.2dB No.3 4.5dB 5.0dB 5.2dB 4.8dB 5.6dB 4.5dB 4.2dB No.4 4.7dB 5.2dB 5.2dB 4.8dB 5.6dB 5.1dB 4.2dB *3m/1m/0.5m = Measurement distance Radiated emission test(3m) The data listed in this test report has enough margin, more than the site margin. Test report No. : 32EE0264-HO-02-B-R1 Page : 5 of 12 Issued date : April 4, 2012 Revised date : April 13, 2012 FCC ID : CWTWC1U326 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 3.5 Test Location UL Japan, Inc. Head Office EMC Lab. *NVLAP Lab. code: 200572-0 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 FCC Registration Number IC Registration Number Width x Depth x Height (m) Size of reference ground plane (m) / horizontal conducting plane Other rooms No.1 semi-anechoic chamber 313583 2973C-1 19.2 x 11.2 x 7.7m 7.0 x 6.…
