From: Generic Office of Engineering Technology [[email protected]] Sent: Friday, June 29, 2007 12:13 PM To: Ollie Moyrong ES-MPK Subject: Response to Inquiry to FCC (Tracking Number 235259) Inquiry: The device falls under the scope of Permit But Ask list for Category 1 ? 15.239 FM transmitter. Inquiry: New Application Grantee: Navico, Inc. FCC ID: D6NLOWFMMOD2V1 EUT Description: GPS Product with built in FM Transmitter Below are the answers for the following FCC questions: i. Describe the operation of the device. This device is an FM Stereo Modulator that creates a wireless audio link for a GPS navigation device. It links pre-recorded music or turn-by-turn directions to the user?s FM car radio. No additional wiring is necessary. The broadcast frequency is fully adjustable throughout the FM band in 200 kHz steps from 88.1 to 107.9 MHz. The user is instructed to tune their FM radio to a vacant FM radio frequency and then manually tune the device to the same frequency. ii. Provide information on the device and its antenna. The device is a GPS Navigation System/MP3 player intended for use in cars. · Power consumption: 22mA@ 5V · RF Output: Loop Antenna Radiation Output · Audio Input: Cable Internal to the Host Board · Carrier Frequency: Frequency Modulated · Transmission Frequency: Tunable from 88.1 to 107.9 MHz in 0.2 MHz steps. · Physical dimension: 34.19x33.19x8.07mm · Weight: 10 g (.022 lb) · Main Functions: Provides the full FM band tuning range in 0.2 MHz steps. · Antenna: Built-in internal antenna. iii. How is it installed? i. Install the mounting bracket of the device to the vehicle and place the device on the mount. ii. Plug the power cable of the device into the vehicle?s light socket. iii. Tune the FM radio to a vacant FM radio frequency and then manually tune the device to the same frequency. iv. Describe the test procedure used. The test procedure used was ANSI C63.4 following the requirements in 15.239. v. If tested in a car, describe how it was it configured and tested. It was not tested in a car. Testing was performed on an Open Area Test Site and a semi-anechoic chamber. vi. Was the tuning range properly verified? Yes, the lowest channel is 88.1 and the highest channel is 107.9. The tuning controls were manually adjusted to verify maximum tuning range. Refer to page 9 of the Test Report for more details. vii. Was the bandwidth properly tested with maximum audio input? It was determined that the highest OBW was produced by playing the following MP3 file: Do Me Like 3- 15.mp3. This file was continuously playing through all testing. The volume control was set to maximum level. viii. Provide a test report. The test report is attached. Response: The data looks good, and passes the permit but ask. Do not reply to this message. Please select the Reply to an Inquiry Response link from the OET Inquiry System to add any additional information pertaining to this inquiry.

27611 La Paz Road Suite C Laguna Niguel, CA 92677 Tel 949-448-4100 Fax 949-448-4111 Navico Inc., Model: LOWFMMOD2V1 FCC ID: D6NLOWFMMOD2V1 FCC Part 15.239 EXTERNAL PHOTOGRAPHS GPS unit with FM Modulator inside 27611 La Paz Road Suite C Laguna Niguel, CA 92677 Tel 949-448-4100 Fax 949-448-4111 Navico Inc., Model: LOWFMMOD2V1 FCC ID: D6NLOWFMMOD2V1 FCC Part 15.239 Front and Rear view

XXXX 051-2958-00 010-4276-00 FCC ID: D6NLOWFMMOD2V1 IC: 978B-FMMOD2V1 XXXX FCC ID: D6NLOWFMMOD2V1 IC: 978B-FMMOD2V1 3 3

27611 La Paz Rd., Suite C, Laguna Niguel, CA 92677 Date of Test: March 12 – May 29, 2007 FCC ID: D6NLOWFMMOD2V1 Test Report for Navico Inc. on the LOWFMMOD2V1 TEST REPORT Report Number: 3104630LAX-017 Project Number: 3104630 May 30, 2007 Testing performed on the FM Modulator FCC ID: D6NLOWFMMOD2V1 Model: LOWFMMOD2V1 to FCC Part 15.239 RSS-210 part A2.8 For Navico Inc. Test Performed by: Test Authorized by: Intertek 27611 La Paz Road., Suite C Laguna Niguel, CA 92677 Navico Inc. 2601 Industry Street Oceanside, CA 92054 Prepared by: Date:May 30, 2007 Sergey Marker Reviewed by: Date:May 31, 2007 Suresh Kondapalli This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to copy or distribute this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. A2LA Certificate Number: 2085-01 File: 3104630LAX-017 Page 1 of 31 27611 La Paz Rd., Suite C, Laguna Niguel, CA 92677 Date of Test: March 12 – May 29, 2007 FCC ID: D6NLOWFMMOD2V1 Test Report for Navico Inc. on the LOWFMMOD2V1 File: 3104630LAX-017 Page 2 of 31 Table of Contents 1.0 Summary of Test Results............................................................................................................... 4 2.0 General Description ....................................................................................................................... 5 2.1 Product Description ............................................................................................................5 2.2 Related Submittal(s) Grants ................................................................................................ 6 2.3 Test Methodology ...............................................................................................................6 2.4 Test Facility ........................................................................................................................ 6 3.0 System Test Configuration............................................................................................................ 7 3.1 Justification ......................................................................................................................... 7 3.2 EUT Exercising Software ................................................................................................... 7 3.3 System Test Configuration ................................................................................................. 7 3.3.1 Block Diagram of Test Setup................................................................................. 9 3.3.2 EUT........................................................................................................................ 9 3.3.3 Support Equipment ........................................................................9 3.4 Equipment Modification ..................................................................................................... 9 3.5 Mode(s) of operation .......................................................................................................... 9 4.0 Field Strength of Emission .......................................................................................................... 10 4.1 Test Description ................................................................................................................10 4.1.1 Test Procedure ..................................................................................................... 10 4.1.2 Field Strength Calculation ................................................................................... 10 4.1.3 Radiated Emission Data....................................................................................... 11 4.2 Test Description ................................................................................................................13 4.2.1 Test Procedure ..................................................................................................... 13 4.2.2 Field Strength Calculation ................................................................................... 13 4.2.3 Radiated Emission Data....................................................................................... 14 4.3 Test Description ................................................................................................................17 4.3.1 Test Procedure ..................................................................................................... 17 4.3.2 Field Strength Calculation ................................................................................... 17 4.3.3 Radiated Emission Data....................................................................................... 18 5.0 Occupied Bandwidth ................................................................................................................... 19 5.1 Test Descrition ...................................................................................................................... 19 5.1.1 Test Procedure ..................................................................................................... 19 5.1.2 Test Results.......................................................................................................... 19 5.2 Test Descrition ...........................…

Text truncated - open the document above for the full version.

27611 La Paz Road Suite C Laguna Niguel, CA 92677 Tel 949-448-4100 Fax 949-448-4111 Navico Inc., Model: LOWFMMOD2V1 FCC ID: D6NLOWFMMOD2V1 FCC Part 15.239 TEST SETUP PHOTOGRAPHS OBW measurements (15.239a). 27611 La Paz Road Suite C Laguna Niguel, CA 92677 Tel 949-448-4100 Fax 949-448-4111 Navico Inc., Model: LOWFMMOD2V1 FCC ID: D6NLOWFMMOD2V1 FCC Part 15.239 Field Strength emission measurements (15.239 b/c, 15.109, 15.209) 27611 La Paz Road Suite C Laguna Niguel, CA 92677 Tel 949-448-4100 Fax 949-448-4111 Navico Inc., Model: LOWFMMOD2V1 FCC ID: D6NLOWFMMOD2V1 FCC Part 15.239 . Line Conducted Emission (15.107, 15.207)
