DEO-MT-BCM01Unit Assy Body control

MOTOTECH CO., LTD. Title Certification Request Document Project Name X100 Drawn 2014-05-16 Released 2014-05-16 Made by J.H.An 1 PRODUCT SPECIFICATION AND MANUAL 2014.05 BUYER / PROJECT SYMC / X100 / MT-BCM-01 BUYER MODEL Unit Ass’y Body control COMPANY Mototech Co,. MAKER/NATION Mototech Co,./Republic of Korea DRAFT PART Research Center DRAFTER J.H.An MOTOTECH CO., LTD. Title Certification Request Document Project Name X100 Drawn 2014-05-16 Released 2014-05-16 Made by J.H.An 2 Table of Contents 1. CONTENTS ............................................................................................................ 3 2. ELECTRONIC SPEC.............................................................................................. 3 3. SPECIFICATION .................................................................................................... 4 4. CIRCUIT EXPLAINATION ...................................................................................... 4 MOTOTECH CO., LTD. Title Certification Request Document Project Name X100 Drawn 2014-05-16 Released 2014-05-16 Made by J.H.An 3 1. Contents Type Weak Signal Equip. Name Unit Ass’y Body Control Use Utilizing the frequency of 134.2kHz RFID vehicle anti-theft device Summary 1. This Equip is designed to prevent car theft. 2. This Equip & Transponder communicate encryption algorithm mutually for User Authentication. 3. This equipment uses semiconductors and integrated circuits that are designed to have a high reliability. 4. Main Power use Regulator VCC of BCM. Composition 1. LF Base Station 2. Bobbin Antenna 2. ELECTRONIC SPEC. UNIT item Unit Ass’y Body Control Rated Voltage DC 13.5V (TMS3705 DC 5.0V) Operating Voltage Range DC 9.0V ~ 16.0V (TMS3705 DC 4.5V~5.5V) Operating Temp. Range -30°C ~ +80°C Storage Temp. Range -40°C ~ +85°C COIL INDUCTANCE 420uH ± 20(WITH KEY LOCK BODY) COIL TURNS 95T MOTOTECH CO., LTD. Title Certification Request Document Project Name X100 Drawn 2014-05-16 Released 2014-05-16 Made by J.H.An 4 3. SPECIFICATION Type Unit Ass’y Body Control Name Weak Signal Equip. Equipment List LF Transmitter-Receiver Frequency 134.200KHz Antenna Type Type : BOBBIN COIL ANTENNA Oscillation Method Crystal oscillation Local clock frequency 4MHz Modulation Method FSK Communication Scheme Two-Way Communication Equipment use Vehicle Antitheft Equip. Operating Temp. DC 13.5V (TMS3705 DC 5.0V) Operating Voltage -30°C ~ +80°C Weight BCM : 580g, IMMO ANTENNA : 37g Dimension Antenna : External diameter 45mm 4. CIRCUIT EXPLAINATION 1. After IGNITION, When EMS Data transmitted to the receiver, the received Data is analyzed. 2. After data analyzing, When EMS need to order Write key or Challenge service, U1 send data to U10 3. U10 what are transmitted data by U1 modulate FSK way, and then it transmit transponder via Antenna. 4. Transponder what receive data from U10 reply information what U10 is ordered after processing data 5. Data received from the transponder to reply with U1 and U10 after the demodulation. U1 verify data from U10, and then the results are sent back to EMS. MOTOTECH CO., LTD. Title Certification Request Document Project Name X100 Drawn 2014-05-16 Released 2014-05-16 Made by J.H.An 5 FCC (Federal Communications Commission) WARNING: This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made. This device complies with Part 15 of the FCC`s Rules. Operation is subject to the following two Conditions: 1. This device may not cause harmful interference, and 2. This device must accept ant interference received, including interference that may cause undesirable operation.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 3 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (current) 3.0 4.0 May-23-2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 3 Rev 4.0 Sep. 26, 2014 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, MOTOTECH Co., Ltd. hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): (Unit Ass’y Body control, MT BCM 01) Sincerely, Ban-seok Choi Research Engineer MOTOTECH Co., Ltd. #68-26, Mannyeon-ro, Jeongnam-myeon, Hwasong-si, Gyeonggi-do, Korea

SCS-F19: Confidentiality Request Letter Page 1 of 3 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 3 Rev 3.0 Sep. 26, 2014 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: DEO-MT-BCM01 We hereby request confidential treatment of information accompanying this application as outlined below: - e.g. Block Diagram - e.g. Schematics - e.g. Operational Description - e.g. Part List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : Client’s name / title : Ban-seok Choi / Research Engineer Contact information / address: 031-305-0682 / #68-26, Mannyeon-ro, Jeongnam-myeon, Hwaseong-si, Gyeonggi-do, Korea SCS-F19: Confidentiality Request Letter Page 3 of 3 Rev 3.0 Sep. 26, 2014 To: Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Short Term Confidentiality Request for FCC ID: DEO-MT-BCM01 To Whom It May Concern: Pursuant to sections 0.457 and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 45 or 180 days (please check one). - e.g. User Manual - e.g. Ext Photo - e.g. Int Photo - e.g. Test Photo The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, Client’s signature : Client’s name / title : Ban-seok Choi / Research Engineer Contact information / address: 031-305-0682 / #68-26, Mannyeon-ro, Jeongnam-myeon, Hwaseong-si, Gyeonggi-do, Korea

MOTOTECH Co., Ltd. #68-26, Mannyeon-ro, Jeongnam-myeon, Hwaseong-si, Gyeonggi-do, Korea Date: Sep. 26, 2014 SIEMIC 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Letter of Authorization We, the undersigned, hereby authorize Harvey Sung of DT&C Co., Ltd. to act on our behalf in all manners relating to application for equipment authorization for FCCID: DEO- MT-BCM01 including signing of all documents relating to these matters. Any and all acts carried out by Harvey Sung of DT&C Co., Ltd. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from MOTOTECH Co., Ltd. “I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a).” Sincerely, Ban-seok Choi Research Engineer

FCCID: DEO-MT-BCM01 Copyright Ⓒ 2014, DT&C Co., Ltd. Page 1 / 3 View 1 FCCID: DEO-MT-BCM01 Copyright Ⓒ 2014, DT&C Co., Ltd. Page 2 / 3 View 2 FCCID: DEO-MT-BCM01 Copyright Ⓒ 2014, DT&C Co., Ltd. Page 3 / 3 View 3

FCCID: DEO-MT-BCM01 Copyright Ⓒ 2014, DT&C Co., Ltd. Page 1 / 4 View 1 FCCID: DEO-MT-BCM01 Copyright Ⓒ 2014, DT&C Co., Ltd. Page 2 / 4 View 2 FCCID: DEO-MT-BCM01 Copyright Ⓒ 2014, DT&C Co., Ltd. Page 3 / 4 View 3 FCCID: DEO-MT-BCM01 Copyright Ⓒ 2014, DT&C Co., Ltd. Page 4 / 4 View 4

FCC ID : DEO-MT-BCM01 DEMC1407-03029 Report No.: DRTFCC1409-1240 TRF-RF-204(01)110221 Page 2 / 13 Copyright ○ C 2014, DT&C Co., Ltd. Test Report Version Test Report No. Date Description DRTFCC1409-1240 Sep. 29, 2014 Initial issue FCC ID : DEO-MT-BCM01 DEMC1407-03029 Report No.: DRTFCC1409-1240 TRF-RF-204(01)110221 Page 3 / 13 Copyright ○ C 2014, DT&C Co., Ltd. CONTENTS 1. Equipment information ............................................................. 4 1.1 Equipment description ............................................................ 4 1.2 Support equipments ............................................................... 4 2. Information about test items .................................................... 5 2.1 Operating mode ..................................................................... 5 2.2 Tested frequency .................................................................... 5 2.3 Auxiliary equipment ................................................................ 5 2.4 Tested environment ................................................................ 5 2.5 EMI Suppression Device(s)/Modifications .............................. 5 3. FACILITIES AND ACCREDITATIONS ........................................ 6 3.1 FACILITIES ............................................................................ 6 3.2 EQUIPMENT .......................................................................... 6 4. Test Report ................................................................................ 7 4.1 Summary of tests ................................................................... 7 4.2 Transmitter requirements........................................................ 8 4.2.1 20dB Bandwidth ................................................................. 8 4.2.2 Radiated Emissions ........................................................... 9 4.2.3 AC Line Conducted Emissions .......................................... 11 APPENDIX I ................................................................................. 12 FCC ID : DEO-MT-BCM01 DEMC1407-03029 Report No.: DRTFCC1409-1240 TRF-RF-204(01)110221 Page 4 / 13 Copyright ○ C 2014, DT&C Co., Ltd. 1. Equipment information 1.1 Equipment description FCC Equipment Class Part 15 Low Power Transmitter Below 1705 kHz (DCD) Equipment type Unit Ass’y Body control Equipment model name MT BCM 01 Equipment add model name N/A Equipment serial no. Identical prototype Frequency 134.2kHz Power DC 12 V(Car Battery) Antenna type Fixed type(Low frequency Antenna) 1.2 Support equipments Equipment Model No. Serial No. Manufacturer Note - - - - - - - - - - - - - - - - - - - - Note: The above equipments were supported by manufacturer. FCC ID : DEO-MT-BCM01 DEMC1407-03029 Report No.: DRTFCC1409-1240 TRF-RF-204(01)110221 Page 5 / 13 Copyright ○ C 2014, DT&C Co., Ltd. 2. Information about test items 2.1 Operating mode Operating Mode Continuous transmitting mode 2.2 Tested frequency Item TX RX Frequency 134.20 kHz 134.20 kHz 2.3 Auxiliary equipment Equipment Model No. Serial No. Manufacturer Note - - - -. - 2.4 Tested environment Temperature : 23 ~ 24 o C Relative humidity content : 39 ~ 53 % R.H. Details of power supply : DC 12 V(Car Battery) 2.5 EMI Suppression Device(s)/Modifications EMI suppression device(s) added and/or modifications made during testing → None FCC ID : DEO-MT-BCM01 DEMC1407-03029 Report No.: DRTFCC1409-1240 TRF-RF-204(01)110221 Page 6 / 13 Copyright ○ C 2014, DT&C Co., Ltd. 3. FACILITIES AND ACCREDITATIONS 3.1 FACILITIES The semi anechoic chamber and conducted measurement facility used to collect the radiated and conducted test data are located at the 42, Yurim-ro, 154beon-gil, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea 449-935. The site is constructed in conformance with the requirements. - Semi anechoic chamber registration Number: 596748 3.2 EQUIPMENT Radiated emissions are measured with one or more of the following types of antennas: loop, tuned dipole, bi-conical, log periodic, bi-log, and/or ridged waveguide horn. Spectrum analyzers with pre-selectors and peak, quasi-peak detectors are used to perform radiated measurements. Conducted emissions are measured with Line Impedance Stabilization Networks and EMI Test Receivers. Calibrated wideband preamplifiers, coaxial cables, and coaxial attenuators are also used for making measurements. All receiving equipment conforms to CISPR Publication 16-1, “Radio Interference Measuring Apparatus and Measurement Methods.” FCC ID : DEO-MT-BCM01 DEMC1407-03029 Report No.: DRTFCC1409-1240 TRF-RF-204(01)110221 Page 7 / 13 Copyright ○ C 2014, DT&C Co., Ltd. 4. Test Report 4.1 Summary of tests FCC Part Section(s) RSS Section(s) Parameter Limit Test Condition Status Note 1 Test Items 2.1049 N/A 20 dB Bandwidth N/A Radiated C 15.209 RSS-Gen [7.2.5] Radiated Emission FCC 15.209 limits C 15.207 RSS-Gen [7.2.4] AC Conducted Emissions FCC 15.207 limits AC Line Conducted NA Note 1: C=Comply NC=Not Comply NT=Not Tested NA=Not Applicable The sample was tested according to the following specification: ANSI C-63.4 2009 FCC ID : DEO-MT-BCM01 DEMC1407-03029 Report No.: DRTFCC1409-1240 TRF-RF-204(01)110221 Page 8 / 13 Copyright ○ C 2014, DT&C Co., Ltd. 4.2 Transmitter requirements 4.2.1 20dB Bandwidth - Procedure: The 20 dB bandwidth is measured with a spectrum analyzer connected via a receiving antenna placed near the EUT while the EUT is operating. Tested Frequency(kHz) Test Results(kHz) 134.20 4.265 FCC ID : DEO-MT-BCM01 DEMC1407-03029 Report No.: DRTFCC1409-1240 TRF-RF-204(01)110221 Page 9 / 13 Copyright ○ C 2014, DT&C Co., Ltd. 4.2.2 Radiated Emissions - Limit: FCC Part 15.209(a) & RSS-GEN, section 7.2.5 Frequency [MHz] Field Strength [uV/m] Measurement Distance [Meters] 0.009 ~ 0.490 2400/F(kHz) 300 0.490 ~ 1.705 24000/F(kHz) 30 1.705 ~ 30 30 30 30 ~ 88 100 3 88 ~ 216 150 3 216 ~ 960 200 3 Above 960 500 3 ** Except as provided in 15.209(g), fundamental emissions from intentional radiators operating under this Sec…

Text truncated - open the document above for the full version.

FCC ID: DEO-MT-BCM01 Copyright Ⓒ 2014, DT&C Co., Ltd. Test Setup photographs EUT Position: X-axis FCC ID: DEO-MT-BCM01 Copyright Ⓒ 2014, DT&C Co., Ltd. Test Setup Photo of Radiated Measurement (0.009 ~ 30MHz) FCC ID: DEO-MT-BCM01 Copyright Ⓒ 2014, DT&C Co., Ltd. Test Setup Photo of Radiated Measurement (below 1000MHz)
