TLM Touch Light On/Off Remote Control INSTALLATION AND OPERATING INSTRUCTIONS This wireless wall on/off/ remote control – system provides a safe, reliable, and user-friendly remote control for millivolt valve gas appliances. The system can be manually turned on and off with the transmitter. Always check the appliance home owner’s manual for additional information, or warnings regarding accessory instal- lation before connecting this remote control system. Carefully inspect the contents for shipping damage. If any parts are missing or damaged, immediately contact the dealer from whom you purchased the kit. Do not attempt to install any part of the kit unless all parts are in good condition. Please keep this booklet for future reference. CONTENTS OF KIT DescriptionQty Touch Light Transmitter1 Battery Alkaline AA (for Transmitter and receiver)6 Receiver (Assembly) consists of :1 Receiver Box Slide Button-Black (On/RS/Off) L-Bracket (Floor Mount) Wall Cover Plate-Black1 Wall Cover Plate-White1 Slide Button-White (On/RS/Off)1 Screws (for Wall Cover Plate)2 Plug-In Wiring Assembly – 18" Inches1 Velcro (Loop and Hook)1 Wall Anchor Screws2 Wall Anchor2 Installation Instructions1 Screws (for fireplace system control covers)2 Wall Bracket1 FEATURES/SPECIFICATIONS • Contemporary Ergonomic Table Top or Wall Mount Transmitter with Large LCD Display • Battery Powered Transmitter and Receiver • Easy Access Battery Door • Pre-Programmed for Quick Installation • Low battery Indication • Child Proof Lock-out • 128 Security Codes • 2 hour Shut Down (Optional) • Thermal Safety Shutdown (Transmitter Only) • Quick Disconnect Wiring Assembly • Reset Button WARNING Important Safety Information • Read this manual thoroughly prior to installing, programming or operating any remote control. • This remote control system is designed for use with a milli volt gas valve system. Do not use this remote control system on applications with voltages above 24 Volts DC and 1 amp current. • This remote control system requires two (2) "AA" alkaline batteries for the transmitter and four (4) "AA" alkaline batteries for the receiver. • Wiring must conform to appliance requirement and building codes/ordinances as required by local and national code authorities having jurisdiction. • Do not short (or jumper) across the gas valve terminals to test the remote control installation. This could damage the unit and void the warranty. • This remote control system should only be used as described in this manual. Any other use is not recommended and will void the warranty. Due to the sensitive temperature monitoring components in the transmitter, it is necessary to allow the transmitter to stabilize to room temperature before accurate room temperatures are displayed. If the transmitter is activated from a severe cold condition, allow 15 minutes for accurate temperature readings to appear on the LCD. Turn appliance OFF and allow to cool before installing or servicing. DO NOT connect 110-120 VAC wiring to the milli-volt gas control valve. The remote operator must be installed exactly as outlined in these instructions. Read all instructions completely before attempting installation. Follow instructions carefully during installation. Any modification of components will void the warranty and may cause a fire hazard. Turn appliance OFF (at the appliance or remote receiver) if you are away from your house for a long period of time. Never leave anything on top of the surface on the touch light transmitter. INSTALLATIONS Remote Receiver: The remote receiver may be wall mounted or installed in the appli- ance per the appliance homeowner’s manual. Refer to the Homeowner’s Manual for special installation instructions. If wall mounted, the remote receiver must be installed in a junction box with cover plate provided. Failure to follow the installation instructions found in the appropriate Homeowner’s Manual will void the warranty and may cause a fire hazard. Installing Batteries: The remote receiver uses four (4) "AA"- size batteries. To install batteries, 1. Remove the slide switch by gently pulling straight out. 2. Use your thumb and index finger to gently pull down the L-bracket. 3. Open the battery door by pressing the two tabs located on the door. 4. Install the batteries as indicated in the receiver cover. 5. Close the battery door until the door tab snaps in place. 6. To install the receiver into a wall junction box, install the receiver with the screws provided . 7. If you decided to install the receiver into the appliance, reinstall the L-bracket. 8. Gently, install the slide switch back to the receiver stem. 9. The batteries should be replaced at least once every 6 months or when the battery indicator flashes. Connecting the Receiver to your appliance: This system comes with an 18 inch wire assembly. Insert the white terminal to the back of the receiver. The terminal wire block can only be installed one way. Do not force the terminal plug onto the receiver. Connect the wiring terminal two (2) 1/4" female spade terminals to the appliance. Refer to the appropriate Homeowner’s Manual for proper wiring connections to the appliance. Your appliance may have other options to connect wiring from receiver. For applications longer than 18 inches, use 18 gauge wire, 105ºC rated, with no splices. Connect to the two (2) 1/4" female spade wiring terminals. Wire can be no longer than 20 feet. Make sure that the wires do not contact the appliances any place other than at the terminals. Exposure to temperatures higher than 105ºC (250ºF) may cause the receiver to malfunction or fire hazard. Touch Light Transmitter: Installing Batteries: The Touch Light transmitter uses two (2) "AA"- size batteries. To install batteries, 1. Press down the battery door tab and lift up and remove the battery door. 2. Install the battery. 3. Close the battery door by snapping in place 4. Repeat the above step for the other battery. 5. When both batteries are installed, the transmi…

Text truncated - open the document above for the full version.

Test Setup FCC ID : DI2TLM-TX External Photo - Front External Photo - Rear

Critical Component of MHNTLM(TX) Component Part Number Description Antenna Printed on-board PCB 2N3904 Q1, Q2 Low battery detection. Generate about 1.5Hz wave for low battery circuitry THERMISTOR 103AT-2 TH1 TH1 works with R4, R9 as temperature sensor Touch PAD On/off Input command DIP switch (4) SW1 Generate different address code RF transistor 2SC3838 Q3 Modulator SAW RESONATOR NMR350 (350MHz) Y3 Generate oscillation of RF frequency 350MHz

• The test results reported in this test report shall refer only to the sample actually tested and shall not refer or be deemed to refer to bulk from which such a sample may be said to have been obtained. • This report shall not be reproduced except in full without prior authorization from Intertek Testing Services Hong Kong Limited. • For Terms And Conditions of the services, it can be provided upon request. • The evaluation data of the report will be kept for 3 years from the date of issuance. Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2371 0521 Website: www.hk.intertek-etlsemko.com Computime Ltd. Application For Certification (FCC ID: DI2TLM-TX) Transmitter 0501666 DL/ Sandy Lee March 7, 2005 INTERTEK TESTING SERVICES FCC ID: DI2TLM-TX i LIST OF EXHIBITS INTRODUCTION EXHIBIT 1: General Description EXHIBIT 2: System Test Configuration EXHIBIT 3: Emission Results EXHIBIT 4: Equipment Photographs EXHIBIT 5: Product Labelling EXHIBIT 6: Technical Specifications EXHIBIT 7: Instruction Manual EXHIBIT 8: Miscellaneous Information INTERTEK TESTING SERVICES FCC ID: DI2TLM-TX ii MEASUREMENT/TECHNICAL REPORT Computime Ltd. - MODEL: Ambient TLM-TX FCC ID: DI2TLM-TX March 7, 2005 This report concerns (check one:) Original Grant X Class II Change Equipment Type: Low Power Transmitter (example: computer, printer, modem, etc.) Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? Yes No X If yes, defer until: date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37? Yes No X If no, assumed Part 15, Subpart C for intentional radiator - the new 47 CFR [12-08-03 Edition] provision. Report prepared by: Derek Leung Intertek Testing Services 2/F., Garment Center, 576, Castle Peak Road, Kowloon, Hong Kong. Phone: 852-2173-8539 Fax: 852-2371-0521 INTERTEK TESTING SERVICES FCC ID: DI2TLM-TX iii Table of Contents 1.0 General Description..............................................................................................2 1.1 Product Description ..............................................................................................2 1.2 Related Submittal(s) Grants .................................................................................2 1.3 Test Methodology.................................................................................................3 1.4 Test Facility ..........................................................................................................3 2.0 System Test Configuration ...................................................................................5 2.1 Justification ..........................................................................................................5 2.2 EUT Exercising Software .....................................................................................5 2.3 Special Accessories .............................................................................................5 2.4 Equipment Modification ........................................................................................6 2.5 Measurement Uncertainty ....................................................................................6 2.6 Support Equipment List and Description ..............................................................6 3.0 Emission Results ..................................................................................................8 3.1 Field Strength Calculation ....................................................................................9 3.2 Radiated Emission Configuration Photograph ....................................................11 3.3 Radiated Emission Data.....................................................................................12 4.0 Equipment Photographs .....................................................................................15 5.0 Product Labelling ................................................................................................17 6.0 Technical Specifications ....................................................................................19 7.0 Instruction Manual ..............................................................................................21 8.0 Miscellaneous Information .................................................................................23 8.1 Measured Bandwidth .........................................................................................24 8.2 Discussion of Pulse Desensitization ...................................................................25 8.3 Calculation of Average Factor ............................................................................26 8.4 Emissions Test Procedures................................................................................27 INTERTEK TESTING SERVICES FCC ID: DI2TLM-TX iv List of attached file Exhibit type File Description filename Test Report Test Report report.pdf Operation Description Technical Description descri.pdf Test Setup Photo Radiated Emission radiated photos.doc Test Report Bandwidth Plot bw.pdf External Photo External Photo external photos.doc Internal Photo Internal Photo internal photos.doc Block Diagram Block Diagram block.pdf Schematics Circuit Diagram circuit.pdf ID Label/Location Label Artwork and Location label.pdf User Manual User Manual manual.pdf Test Report Timing Diagram timing.pdf INTERTEK TESTING SERVICES FCC ID: DI2TLM-TX 1 EXHIBIT 1 GENERAL DESCRIPTION INTERTEK TESTING SERVICES FCC ID: DI2TLM-TX 2 1.0 General Description 1.1 Product Description The Equipment Under Test (EUT) is a Transmitter operating at 350MHz. The EUT is powered by 3V d.c. (2 x 1.5V “AA” battery). It transmits control signal to receiver. The fireplace associated with the receiver will be turned on/off accordingly if the dip switches setting of both units are…
