FCC ID: DKN-301LM Model: ID 084 SAR Exclusion Justification KDB 447498 has the following exclusion for portable devices (devices that may be used within 20cm of a person): The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where  f(GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation  The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. For small devices and for devices used close to the body the enclosure-to-person separation distance is used rather than the antenna-to-person separation distance. For this device, which is hand-operated and so could be within 20cm of persons when in use:  f = 2.45 GHz  distance = 0 mm from the hand (so we will use 5 mm in the calculation)  the maximum output power declared by the manufacturer is the measured power +1.5dB. This is 5dBm (3.2 mW) The calculated value = [ 3.0 / 5 ]. √ 2.45 = 0.94. As this is below both 7.5 and 3.0, there is no need for SAR evaluation of this device.

FCC 47 CFR PART 15 SUBPART C CERTIFICATION TEST REPORT FOR EUT LIGHTSWITCH COVER MODULE MODEL NUMBER: ID:084 FCC ID: DKN-301LM REPORT NUMBER: 14M18734-2 ISSUE DATE: 2014-10-02 Prepared for ECHOSTAR 90 INVERNESS CIRCLE EAST ENGLEWOOD, CO 80112 Prepared by UL LLC INC. 1285 WALT WHITMAN RD MELVILLE, NY 11747, U.S.A. TEL: (631) 271-6200 FAX: (877) 854-3577 REPORT NO: 14M18734-1 DATE: 2014-10-02 FCC ID: DKN-301LM Page 2 of 39 UL LLC. INC. FORM NO: CCSUP4701I 1285 WALT WHITMAN RD, MELVILLE, NY 11747, USA TEL: (631) 271-6200 FAX: (877) 854-3577 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. Revision History Rev. Issue Date Revisions Revised By -- 2014-10-02 Initial Issue Joseph Danisi 1 2014-10-07 Correct antenna calibration date, added clarification on emissions from 2390 to 2400MHz. Joseph Danisi 2 2014-10-08 Add calculation in section 8.1.2 and analyzer settings Joseph Danisi REPORT NO: 14M18734-1 DATE: 2014-10-02 FCC ID: DKN-301LM Page 3 of 39 UL LLC. INC. FORM NO: CCSUP4701I 1285 WALT WHITMAN RD, MELVILLE, NY 11747, USA TEL: (631) 271-6200 FAX: (877) 854-3577 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS ................................................................................. 4 2. TEST METHODOLOGY ..................................................................................................... 5 3. FACILITIES AND ACCREDITATION ................................................................................. 5 4. CALIBRATION AND UNCERTAINTY ................................................................................ 5 4.1. MEASURING INSTRUMENT CALIBRATION .............................................................. 5 4.2. SAMPLE CALCULATION ............................................................................................ 5 4.3. MEASUREMENT UNCERTAINTY ............................................................................... 5 5. EQUIPMENT UNDER TEST ............................................................................................... 6 5.1. DESCRIPTION OF EUT .............................................................................................. 6 5.2. MAXIMUM OUTPUT POWER...................................................................................... 6 5.3. DESCRIPTION OF AVAILABLE ANTENNAS .............................................................. 6 5.4. SOFTWARE AND FIRMWARE .................................................................................... 6 5.5. WORST-CASE CONFIGURATION AND MODE .......................................................... 6 5.6 DESCRIPTION OF TEST SETUP ................................................................................ 7 6. TEST AND MEASUREMENT EQUIPMENT ....................................................................... 9 7. ON TIME, DUTY CYCLE AND MEASUREMENT METHODS ...........................................11 7.1. ON TIME AND DUTY CYCLE RESULTS ....................................................................11 7.2. DUTY CYCLE PLOTS ................................................................................................11 8. ANTENNA PORT TEST RESULTS ...................................................................................12 8.1. 802.15.4 MODE IN THE 2.4 GHz BAND .....................................................................12 8.1.1. 6 dB BANDWIDTH ...............................................................................................12 8.1.2 OUTPUT POWER ...............................................................................................15 8.1.3 POWER SPECTRAL DENSITY ...........................................................................16 8.1.4 CONDUCTED SPURIOUS EMISSIONS ..............................................................17 9. RADIATED TEST RESULTS .............................................................................................23 9.1. LIMITS AND PROCEDURE ........................................................................................23 9.2 TRANSMITTER ABOVE 1 GHz ..................................................................................24 9.2.1 TX ABOVE 1 GHz FOR 802.15.4 MODE IN THE 2.4 GHz BAND ........................24 9.2.2 WORST-CASE BELOW 1 GHz ...............................................................................31 10. AC POWER LINE CONDUCTED EMISSIONS ..............................................................33 11. SETUP PHOTOS ...........................................................................................................34 REPORT NO: 14M18734-1 DATE: 2014-10-02 FCC ID: DKN-301LM Page 4 of 39 UL LLC. INC. FORM NO: CCSUP4701I 1285 WALT WHITMAN RD, MELVILLE, NY 11747, USA TEL: (631) 271-6200 FAX: (877) 854-3577 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. 1. ATTESTATION OF TEST RESULTS COMPANY NAME: ECHOSTAR 90 INVERNESS CIRCLE EAST ENGLEWOOD, CO 80112 EUT DESCRIPTION: LIGHTSWITCH COVER MODULE MODEL: ID:084 SERIAL NUMBER: Non serialized sample DATE TESTED: 2014-08-25 to 2014-10-02 APPLICABLE STANDARDS STANDARD TEST RESULTS CFR 47 Part 15 Subpart C Pass UL LLC. tested the above equipment in accordance with the requirements set forth in the above standards. All indications of Pass/Fail in this report are opinions expressed by UL LLC. based on interpretations and/or observations of test results. Measurement Uncertainties were not taken into account and are published for informational purposes only. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Note: The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. This document may not b…
