DKNFSK03Remote Control

EchoStar Technologies Corporation 94 Inverness Circle East Englewood, CO 80112 (303) 723-1000 April 20, 2004 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 We the undersigned, hereby certify that, in the case of individual applicant, he or she is not subject to a denial of federal benefits pursuant to section 5301 of the Anti-Drug Abuse Act of 1988, 21 USC 853a or in the case of non-individual applicant (e.g. corporation, partnership or other unincorporated association), no party to the applicant is subject to a denial of federal benefit pursuant to that action. Sincerely, Mathew Aschenberg, Agency Engineer

EchoStar Technologies Corporation 94 Inverness Circle East Englewood, CO 80112 (303) 723-1000 April 20, 2004 To whom it may concern: We the undersigned, hereby authorize CKC Laboratories, Inc., to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by CKC Laboratories, Inc., on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from EchoStar Technologies. Sincerely, Mathew Aschenberg, Agency Engineer

EchoStar Technologies Corporation 94 Inverness Circle East Englewood, CO 80112 (303) 723-1000 April 20, 2004 To whom it may concern: We the undersigned, hereby authorize International Approvals Laboratories, LLC, to act on our behalf in all manners relating to application for equipment authorization to include the transfer the information contained herein to a TCB or regulatory agency, and sign all documents relating to these matters. Any and all acts carried out by International Approvals Laboratories, LLC, on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from Echostar Technologies Corporation. Sincerely, Mathew Aschenberg, Agency Engineer

Scale: 200% Use this image to create label Scale: 100% Use this image to create label TITLE SCALE 1:1 SIZE DWG. NO A SHEET 1 of 1 REV 01 APPROVALS DATE UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE DRAWN CHECKED REVISIONS ECOITEM MASTER DESCRIPTION REVDATEB TOLERANCES: 0.000 +/- .125 0.00 +/- .25 0.0 +/- .4 0. +/- .7 HOLE DIA: +/- .075 ANGLES: +/- .5 C14178132615 Initial Release @ Development 0 1 07/01/04 RP RYAN PRAST07/01/04 132615 LABEL / ART, BOTTOM CASE, 1ST MASK REMOTE 4.0, IR/FSK (PHASE II), MEXICO FCC ID: DKNFSK03 132577 NOTES: 1. ALL DIMENSIONS ARE IN MILLIMETERS, UNLESS OTHERWISE NOTED. 2. PLACE ARTWORK AT LOCATION SHOWN. 3. COLOR OF PRINTING TO BE LIGHT GRAY, Pantone 427. 4. MATERIAL: POLYCARBONATE .010" THICK, Pantone BLACK LIGHT SATIN TEXTURE WITH PERMANENT PRESSURE- SENSITIVE BACKING. UL/CSA APPROVED. 5. COVER ADHESIVE WITH PROTECTIVE BACKING 6. QUALITY ASSURANCE PROVISIONS: IN ADDITION TO MEETING ALL REQUIREMENTS OUTLINED IN THIS SPECIFICATION, ALL REQUIREMENTS IN THE FOLLOWING ECHOSTAR QUALITY ASSURANCE DOCUMENTS AND THEIR REFERENCES MUST BE MET OR EXCEEDED. A) 124214 SUPPLIER AQL REQUIREMENTS B) 105450 SUPPLIER QA REQUIREMENTS C) 123473765-AA COSMETIC PROVISIONS

22.4 35.0 Scale: 200% Use this image to create label Scale: 100% Use this image to create label TITLE SCALE 1:1 SIZE DWG. NO A SHEET 1 of 1 REV 01 APPROVALS DATE UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE DRAWN CHECKED REVISIONS ECOITEM MASTER DESCRIPTION REVDATEBY TOLERANCES: 0.000 +/- .125 0.00 +/- .25 0.0 +/- .4 0. +/- .7 HOLE DIA: +/- .075 ANGLES: +/- .5 C14263133084Initial Release @ Development 0 107/19/04RP RYAN PRAST07/19/04 133084 LABEL / ART, BOTTOM CASE, 1ST MASK REMOTE 6.2, IR/UHF PRO, MEXICO, EXPRESS VU NOTES: 1. ALL DIMENSIONS ARE IN MILLIMETERS, UNLESS OTHERWISE NOTED. 2. PLACE ARTWORK AT LOCATION SHOWN. 3. COLOR OF PRINTING TO BE BLACK 4. MATERIAL: POLYCARBONATE .010" THICK, Pantone 423U LIGHT SATIN TEXTURE WITH PERMANENT PRESSURE-SENSITIVE BACKING. UL/CSA APPROVED. 5. COVER ADHESIVE WITH PROTECTIVE BACKING. 6. QUALITY ASSURANCE PROVISIONS: IN ADDITION TO MEETING ALL REQUIREMENTS OUTLINED IN THIS SPECIFICATION, ALL REQUIREMENTS IN THE FOLLOWING ECHOSTAR QUALITY ASSURANCE DOCUMENTS AND THEIR REFERENCES MUST BE MET OR EXCEEDED. A) 124214 SUPPLIER AQL REQUIREMENTS B) 105450 SUPPLIER QA REQUIREMENTS C) 123473765-AA COSMETIC PROVISIONS 133082 IC: 1707A-DKNFSK03 6.2 Made in Mexico Patent Pending

2.1093 Radiofrequency radiation exposure evaluation: portable devices According to 2.1093 (a) and 1.1307(b)(1) our UHF remote control is excluded from making such studies or preparing EA as our remote control is not listed in Table 1 of 1.1037(b)

EMC EMISSIONS - TEST REPORT (Full) Test Report No. BC400286-1 Issue Date: June 28, 2004 Model / Serial No. MN: REMOTE 10.0 / SN: FCC1 Product Type 9 Channel FSK/OOK remote Client Echostar Manufacturer Echostar License holder Echostar 9601 S. Meridian Blvd Address Englewood, CO 80112 Test Criteria Applied FCC CFR47 Part 15.231 Test Result PASS Test Project Number References BC400286-1 Total Pages Including Appendices: 39 Title 47 CFR 15.231: RADIO FREQUENCY DEVICES operating in the frequency range of 40.66-40.70MHz and above 70MHz (including 15.205, 15.207, 15.209 where applicable) Reviewed By : Approved By : INTERNATIONAL APPROVALS LABORATORIES (IAL) reports apply only to the specific samples tested under stated test conditions. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. IAL have no liability for any deductions, inferences or generalizations drawn by the client or others from IAL issued reports. This report is the confidential property of the client. As a mutual protection to our clients, the public and ourselves, extracts from the test report shall not be reproduced except in full without our written approval of IAL. This report shall not be used by the client to claim product endorsement by NVLAP (No. 200624- 0) or any agency of the US government. International Approval Laboratories and its professional staff hold government and professional organization certifications and are members of IEEE, NVLAP, and VCCI. Project File: BC400286 Page 2 of 39 International Approvals Laboratories, LLC 5541 Central Avenue, Suite 110 Boulder, Colorado 80301 Voice: 303 786 7999 Fax: 303 449 6160 Rev.No 1 D I R E C T O R Y Documentation Page(s) Test report 1 - 39 Directory 2 Test Regulations 3 General Remarks 5 Test-setup Photographs 7 - 9 Appendix A Test Data Sheets and Test Equipment Used 10 - 33 Appendix B Test Plan/Constructional Data Form 34 - 34 Appendix C Measurement Protocol/Test Procedures 35 - 39 STATEMENT OF MEASUREMENT UNCERTAINTY The data and results referenced in this document are true and accurate. The measurement uncertainty for Conducted Emissions in the frequency range of 150kHz – 30MHz is calculated to be ±2.30dB and for Radiated Emissions is calculated to be ±3.60dB in the frequency range of 30MHz – 200MHz and ±3.38dB in the frequency range of 200MHz – 1000MHz. EUT Received Date: 14-June-2004 Testing Start Date: 14-June-2004 Testing End Date: 16-June-2004 Project File: BC400286 Page 3 of 39 International Approvals Laboratories, LLC 5541 Central Avenue, Suite 110 Boulder, Colorado 80301 Voice: 303 786 7999 Fax: 303 449 6160 Rev.No 1 The tests were performed according to following regulations : 1. FCC CFR47 Part 15.205 2. FCC CFR47 Part 15.207 3. FCC CFR47 Part 15.209 4. FCC CFR47 Part 15.231 5. ICES-003 Emission Test Results: Conducted Emissions, Powerline (15.207) - Not Applicable Test Result Minimum limit margin 00.00 dB at 000.00 MHz Maximum limit exceeding dB at MHz Remarks: Battery Powered Device Radiated Emissions (15.209) / 15.231(b)(3) - PASS Test Result Minimum limit margin -19.6 dB at 4000.00 MHz Maximum limit exceeding dB at MHz Remarks: Emissions testing for 15.209 started at 4MHz Radiated Emissions (15.205) / 15.231(b)(2) - PASS Test Result Minimum limit margin -9.62 dB at 1151.89 MHz Maximum limit exceeding dB at MHz Remarks: Emissions is from the On/Off key Radiated Emissions 15.231(a)(1)&(2) - PASS Test Result Remarks: Required measurement for manually and automatic operated transmitter equipment. <5 Sec. after activation Radiated Emissions 15.231(b)(1) - PASS Test Result Minimum limit margin -0.52 dB at 376.83 MHz Maximum limit exceeding dB at MHz Remarks: Measurements were taken utilizing the methods dictated by Part 15.35 for averaging pulsed emissions and for limiting peak emissions. Emission is from FSK channel 4 Project File: BC400286 Page 4 of 39 International Approvals Laboratories, LLC 5541 Central Avenue, Suite 110 Boulder, Colorado 80301 Voice: 303 786 7999 Fax: 303 449 6160 Rev.No 1 Radiated Emissions 15.231(c) - PASS Test Result Remarks: Devices operated within the frequency band of 70 – 900MHz: -20dBc Bandwidth maximum of 0.25% of the center frequency Devices operated within the frequency band of >900MHz: -20dBc Bandwidth maximum of 0.50% of the center frequency Radiated Emissions 15.231(d) - Not Applicable Test Result Remarks: Devices operated within the frequency band of 40.66 – 40.70MHz: -20dBc Bandwidth maximum of 0.01% of the center frequency as measured through the temp range of -20 to +50 deg. C, and at 85 - 115% of the nominal supply voltage at 20 deg. C “a new battery would be used in cases where the device is powered from a battery” Radiated Emissions 15.231(e) - Not Applicable Test Result Minimum limit margin 00.00 dB at 0000.00 MHz Maximum limit exceeding dB at MHz Remarks: Measurements were taken utilizing the methods dictated by Part 15.35 for averaging pulsed emissions and for limiting peak emissions Project File: BC400286 Page 5 of 39 International Approvals Laboratories, LLC 5541 Central Avenue, Suite 110 Boulder, Colorado 80301 Voice: 303 786 7999 Fax: 303 449 6160 Rev.No 1 GENERAL REMARKS: The following remarks are to be considered as “where applicable“ and are taken into account while completing any FCC/IC/ETSI radio tests at International Approvals Laboratories, LLC. Testing was performed in 3 different orthogonal axis to determine the worst case emissions from the device. The worst case emissions measurements are shown in this report. FCC CFR47 Part 15.31: Measurement Standards: In any case where the device is powered off a battery, a fresh battery was used during test. In cases where the device is powered off an AC supply, voltage was varied per Part 15.31 to find worst case emissions. FCC CFR47 Part 15.35: Measurement Detector Functions and Bandwidths: FCC Part 15.35 was utilized when performing the measurement…
