DO4AMBERPart 15 Anti-Pilferage Device

SIDEP Page 1 of 19 Boulevard BoulevardBoulevard Boulevard Mono Mono Mono Mono System SystemSystem System Installation Manual Installation ManualInstallation Manual Installation Manual Document Version Rev2. Document Version Rev2.Document Version Rev2. Document Version Rev2.6 66 6 PN: 7961668 SIDEP Page 2 of 19 Transceiver MONO system Installation Manual Document revision information Rev Description Date Author 2.4 Released by Sidep Electronic 11/01/07 Sidep electronic Co., Ltd. 2.5 Updated by Shanghai R&D 05/07/10 Jean Long 2.6 Updated by Shanghai R&D 04/21/11 Cucumber Huang Trademarks Sidep is a registered trademark of Sidep, Inc. All rights reserved. Information in this document is subject to change without notice. Other products © or ® their respective manufacturers or copyright holders. Companies, names and data used in examples herein are fictitious unless otherwise noted. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the written permission of the publisher. Copyright and Warranty Information The information in this document is subject to change without notice. Because of the changing nature of this product information presented in the Transceiver MONO system Installation Manual, Sidep, Inc. is not liable for any omissions, misstatements, or other errors of information. The information presented in this document may not be copied, used or disclosed to others for the purpose of procurement or manufacturing without the written permission of Sidep, Inc. This guide and the products discussed in this guide are the exclusive property of Sidep Inc. Copyright laws of the United States protect all information and products. Copyright© 2010 Sidep, Inc. All rights reserved. SIDEP Page 3 of 19 Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. for Canada: This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. SIDEP Page 4 of 19 Table of Contents 1. GENERAL INFORMATION 5 1.1 ANTENNA TYPES 5 1.2 BOARD INTRODUCTION 6 1.3 POWER SUPPLY 7 1.4 TEST RANGE 8 2. GENERAL INSTALLATION 9 2.1 IMPLEMENTING ANTENNAS 9 2.2 INTERFERENCE SOURCES 9 3. SELECTION OF FUNCTIONING MODES WITH DIP SWITCH 11 4. BASIC ADJUSTMENT PROCEDURE 12 4.1 SINGLE SYSTEM ADJUSTMENT 12 5. MULTIPLE SYSTEM SYNCHRONIZATION 13 5.1 EXTERNAL SYNCHRONIZATION MODE WITH CABLE (UP TO 25 SYSTEMS BY 230V 50HZ MAIN POWER OR UP TO 25 SYSTEMS 120V 60HZ MAIN POWER) 13 5.2 SUPPLY SYNCHRONIZATION MODE WITH (UP TO 4 SYSTEMS BY 230V 50HZ MAIN POWER OR UP TO 4 SYSTEMS 120V 60HZ MAIN POWER) 13 5.3 DEACTIVATOR SYNCHRONISATION 13 6. TROUBLE SHOOTING 14 7. ADVANCED ADJUSTMENT OF SYSTEM PARAMETERS 15 7.1 LEDS DS11-18 15 8. CONNECTIONS FROM MONO BOARD TO ANTENNA 16 9. MECHANICAL INSTLLATION 17 SIDEP Page 5 of 19 1.GENERAL INFORMATION 1.1 ANTENNA TYPES. The installation manual is applied in boulevard antenna. The TX loop of antenna is O-loop and the RX loop of antenna is 2-loop. Figure 1.1 Boulevard Antenna 1.2 BOARD INTRODUCTION. Figure 1.2 SIDEP Page 6 of 19 SW1 DS3 DS2 VR5 SW2 VR4 VR3 VR2 VR1 VR6 DS1 TX power SIDEP Page 7 of 19 SYN Trim:VR1 Synchronization B-TMP Trim:VR2 Alarm sound time: long time in clockwise direction B-MOD Trim: VR3 Buzzer frequency: low frequency in clockwise direction L-TMP Trim:VR4 Alarm light time: long time in clockwise direction RX GAIN Trim:VR5 Sensitivity: high sensitivity in clockwise direction VOLUME Trim:VR6 Buzzer volume: low volume in clockwise direction SW1 Reset system SW2 Test function DS1 Work display DS2 Synchronization display DS3 Alarm display Firmware version : AMBER_FW_1.0 1.3 POWER SUPPLY The basic system incorporates a transceiver Antenna, power supply adapter (PSA). Both 230VAC 50Hz and 120VAC 60Hz main power can be used. For 230VAC 50Hz main line, input power should be 150mA, and for 120VAC 60Hz main line, input power should be 250mA. Make sure your anti theft system is connected to an electrical system complying with the national regulations in force. Recommended input power of MONO system is 15 VAC 800mA. Only 1 antenna can be connected to the PSA provided. Figure 1.3 Cabling shall always be running on the floor inside embedded ducts or in a groove under the rugs, under floating flooring, in tiling joints or under a sill nosing, as required. Cabling acts as an antenna. Under no circumstances shall the cable be allowed to run through the ceiling or along antennas. SIDEP Page 8 of 19 1.4 TEST RANGE The type of antenna to be selected is a function of size of the tag and antenna spacing. The table provides a reference for tag size versus maximum allowable spacing. However, the spacing values shown on this table will significantly decrease as the operating environment becomes harsher or surrounded with such interfering environment as steel structures, power lines located close to the antennas. A walkabout on site test (installation procedures refer) will testify of the maximum allowable spacing. Figure 1.4 Tag Type MONO 410 tag 0.75 m Mini Hard tag 1.0 m 410tag 0.75M 410tag 0.75M Mini HT 1.0M Mini HT 1.0M SIDEP Page 9 of 19 2. GENERAL INSTALLATION 2.1 IMPLEMENTING ANTENNAS. The Transceiver antenna (MONO) selection of location shall be a function of the stores layout. The rear field is wider on transceiver system therefore removes all furniture and hang…
