DO4CONDOR24PORTABLE ELECTRONIC ARTICLE SURVEILLANCE VERIFIER

PSE Letterhead.dot 1 of 1 June 01, 2004 Federal communications Commission EQUIPMENT APPROVAL SERVICES P.O. Box 358315 Pittsburgh, PA 15251-5315 Subject: User’s Manual for Condor Plus with TR4024 PCB Control Board Dear Sir/Madam, Checkpoint Systems Inc., the manufacturer of the Condor Plus with a TR4024 PCB Control Board, FCC ID: DO4CONDOR24, normally does not supply a User’s or Operator’s Manual with this product. Customers are provided with on-site training in the general use and operation of the device during the installation of the equipment. Regards, Steven Hoke EMC Site Manager

Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 TEST EQUIPMENT CALIBRATION INFORMATION Manufacturer Hewlett Packard Hewlett Packard Hewlett Packard Hewlett Packard Hewlett Packard Hewlett Packard Hewlett Packard Hewlett Packard Hewlett Packard Hewlett Packard Hewlett Packard Hewlett Packard Eaton Electro-Metrics Electro-Metrics Electro-Metrics Electro-Mechanics Electro-Metrics Solar Solar Solar Schwartzbeck Leader IFR Systems Electro-Metrics Antenna Research Radio Shack Radio Shack Model 8566B 85662A 85650A 8447D 8568B 85662A 85650A 8447D 8447D 8449B 8648B 8672A 96005 LPA 30 BIA 30 BIA 25 3115 ALR30M 8012 8028 8028 MDS-21 LFG1310 A-8000 EMC-30 ALA-130/A 63-867 63-867A Description Spectrum Analyzer Display Quasi-Peak Adapter Preamp 0.1 - 1,000 MHz Spectrum Analyzer Display Quasi-Peak Adapter Preamp 0.1 - 1,000 MHz Preamp 0.1 - 1,000 MHz Preamp 1 - 26.5 GHz Signal Generator Signal Generator Log Periodic Antenna Log Periodic Antenna Biconical Antenna Biconical Antenna Double Ridge Guide Ant. Magnetic Loop Antenna LISN LISN LISN Absorbing Clamp Function Generator Spectrum Analyzer EMI Receiver Loop Antenna Temp/Hygrometer Temp/Hygrometer Serial Number 2421A00526 2403A07352 2043A00209 2944A06832 2407A03213 2340A05806 2043A00358 2944A06901 1937A03247 3008A00320 3443U00312 2211A02426 1099 2280 3852 4283 3810 824 924840 829012/809022 903725/903726 02581 8060233 1306 191 106 N/A N/A Cal Due 08/14/04 08/14/04 08/14/04 12/10/04 08/14/04 08/14/04 08/14/04 08/14/04 07/17/04 12/02/04 05/04/05 10/17/04 02/05/05 01/12/05 01/13/05 02/04/05 11/25/05 01/12/05 12/24/04 12/12/04 12/01/04 09/18/04 05/04/05 12/08/04 05/04/05 03/14/05 05/04/05 05/04/05 Page A2 of A___ Radiated Emissions Measurements (1.705 - 10.0) MHz Intentional Radiator Fundamental Per 15.223 Freq. (MHz) Amplitude (dBuV) Peak Antenna Correction Factor Cable Loss Amplitude (dBuV/m) Peak Average Correction Factor (dB) Field Strength (dBuV/m) FCC Limit dBuV/m Delta Limit (dB) 7.462.8-6.90.556.4-2036.440.0-3.6 8.264.8-6.30.559.0-2039.040.0-1.0 8.964.5-5.60.559.4-2039.440.0-0.6 Measurements were all performed at a distance of (30) meters. Average correction factor reflects adjustment in amplitude based on calculated effect of duty cycle. (See duty cycle calculation) Measurements were also performed up to the tenth harmonic and no emissions were observed. Operation in Restricted Bands per 15.205: The Direct Digital Synthesizer (DDS) generates a sequence of (16) discrete frequencies. The transmitter is not capable of hopping into, or operating in, the restricted bands and therefore, complies with the restriction. The tuning table attached to the theory of operation defines each possible operating frequency. The restricted frequency bands (per FCC Part 15.205) in the operating frequency band of the EUT are as follows: 8.291 - 8.294 MHz 8.362 - 8.366 MHz 8.37625 - 8.38675 MHz 8.41425 - 8.41475 MHz
