E2K-DWRFID1202RFID 13.56MHz Wireless Module

Dell Latitude E6230/E6330 Setup and Features Information About Warnings WARNING: A WARNING indicates a potential for property damage, personal injury, or death. Latitude E6230 Front and Back View Figure 1. Front View 1. microphone 2. camera (optional) 3. camera status light (optional) 4. display 5. power button 6. HDMI connector 7. USB 3.0 connector 8. powered USB 3.0 connector Regulatory Model : P14T, P19S Regulatory Type : P14T001, P19S001 2011 - 9 9. wireless switch 10. ExpressCard slot 11. fingerprint reader 12. touchpad buttons (2) 13. touchpad 14. contactless smart-card reader 15. keyboard 16. volume control buttons (3) 17. device status lights Figure 2. Back View 1. network connector 2. device status lights 3. security cable slot 4. power connector 5. VGA connector 6. eSATA/USB 2.0 connector 7. audio connector 8. cooling vents 9. Secure Digital (SD) memory-card reader 10. smart card reader WARNING: Do not block, push objects into, or allow dust to accumulate in the air vents. Do not store your Dell computer in a low-airflow environment, such as a closed briefcase, while it is running. Restricting the airflow can damage the computer or cause a fire. The computer turns on the fan when the computer gets hot. Fan noise is normal and does not indicate a problem with the fan or the computer. 2 Latitude E6330 Front and Back View Figure 3. Front view 1. microphone 2. camera 3. camera status light 4. display 5. power button 6. eSATA/USB 2.0 connector 7. powered USB 3.0 connector 8. volume control buttons 9. wireless switch 10. optical drive 11. ExpressCard slot 12. fingerprint reader 13. contactless smart card reader 14. Secure Digital (SD) memory-card reader 15. touchpad buttons (2) 16. touchpad 17. trackstick buttons (3) 18. trackstick 19. keyboard 20. device status lights 3 Figure 4. Back view 1. security cable slot 2. network connector 3. mini HDMI connector 4. device status lights 5. USB 3.0 connector 6. power connector 7. VGA connector 8. audio connector 9. cooling vents 10. smart card slot WARNING: Do not block, push objects into, or allow dust to accumulate in the air vents. Do not store your Dell computer in a low-airflow environment, such as a closed briefcase, while it is running. Restricting the airflow can damage the computer or cause a fire. The computer turns on the fan when the computer gets hot. Fan noise is normal and does not indicate a problem with the fan or the computer. Quick Setup WARNING: Before you begin any of the procedures in this section, read the safety information that shipped with your computer. For additional best practices information, see www.dell.com/regulatory_compliance. 4 WARNING: The AC adapter works with electrical outlets worldwide. However, power connectors and power strips vary among countries. Using an incompatible cable or improperly connecting the cable to the power strip or electrical outlet may cause fire or equipment damage. CAUTION: When you disconnect the AC adapter cable from the computer, grasp the connector, not the cable itself, and pull firmly but gently to avoid damaging the cable. When you wrap the AC adapter cable, ensure that you follow the angle of the connector on the AC adapter to avoid damaging the cable. NOTE: Some devices may not be included if you did not order them. 1.Connect the AC adapter to the AC adapter connector on the computer and to the electrical outlet. Figure 5. AC Adapter 2.Connect the network cable (optional). Figure 6. Network Connector 3.Connect USB devices, such as a mouse or keyboard (optional). Figure 7. USB Connector 4.Open the computer display and press the power button to turn on the computer. 5 Figure 8. Power Button NOTE: It is recommended that you turn on and shut down your computer at least once before you install any cards or connect the computer to a docking device or other external device, such as a printer. Specifications NOTE: Offerings may vary by region. The following specifications are only those required by law to ship with your computer. For more information regarding the configuration of your computer, click Start → Help and Support and select the option to view information about your computer. Power AC Adapter65 W and 90 W NOTE: 65 W AC adapter is available only for computers with integrated video card. Input voltage100 VAC to 240 VAC Coin-cell battery3 V CR2032 lithium coin cell Physical Latitude E6230 Height22.40 mm to 24.70 mm (0.88 inch to 0.97 inch) Width309.00 mm (12.16 inches) Depth226.00 mm (8.89 inches) Weight1.70 kg (3.75 lbs) Latitude E6330 Height25.40 mm to 30.10 mm (1.00 inch to 1.19 inches) 6 Physical Width335.00 mm (13.19 inches) Depth223.00 mm (8.78 inches) Weight2.10 kg (4.63 lbs) Environmental Operating Temperature: Latitude E623010 °C to 35 °C (50 °F to 95 °F) Latitude E63300 °C to 35 °C (32 °F to 95 °F) Information para NOM (únicamente para México) Voltaje de alimentación 100 V CA – 240 V CA Frecuencia50 Hz – 60 Hz Consumo eléctrico1,50 A~2,50 A Voltaje de salida19,50 V de CC Intensidad de salida3,34 A/4,62 A Finding More Information and Resources See the safety and regulatory documents that shipped with your computer and the regulatory compliance website at www.dell.com/regulatory_compliance for more information on: •Safety best practices •Regulatory certification •Ergonomics See www.dell.com for additional information on: •Warranty •Terms and Conditions (U.S. only) •End User License Agreement Additional information on your product is available at support.dell.com/manuals. 7 Information in this publication is subject to change without notice. © 2011 Dell Inc. All rights reserved. Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden. Trademarks used in this text: Dell ™ , the DELL logo, Dell Precision ™ , Precision ON ™ , ExpressCharge ™ , Latitude ™ , Latitude ON ™ , OptiPlex ™ , Vostro ™ , and Wi-Fi Catcher ™ are trademarks of Dell Inc. Intel ® , Pentium ® , Xeon ® , Core ™ , Atom ™ , Centrino …

Text truncated - open the document above for the full version.

Date:December 6, 2011 Federal Communications Commission Authorization and Evaluation Division FCC ID: E2K-DW RFID1202 Confidentiality Request To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until Increase from 180 days from the date of approval. External Photos Internal Photos Test Setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards Name/Title: Mrs. Fiona, Y Chen / Regulatory Compliance Assistance Manager Company Name: Dell Inc. Address: 11F,No.218,Sec.2, Tun Hua S.Road Taipei, Taiwan, R.O.C TEL: (886)2- 2736-6352 FAX: (886)2- 2736-9067 Email: [email protected]

Date: December 6, 2011 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 c.c. Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Jason Lin / Section Manager of Compliance Certification Services Inc. and hereafter referred to as CCS, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Mr. Stan Lin / Section Manager of Compliance Certification Services Inc. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing CCS as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Name/Title: Mrs. Fiona, Y Chen / Regulatory Compliance Assistance Manager Company Name: Dell Inc. Address: 11F, No.218, Sec.2, Tun Hua S. Road Taipei, Taiwan, R.O.C TEL: (886)2- 2736-6352 FAX: (886)2- 2736-9067 Email: [email protected] REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us. 3. Authorized signature must be in agreement with grantee code contact in FCC database.

Limited Module Approval Request Letter Subject: Limited Module Approval Date: 201 FCC I D: E2K-DWRFID1202 IC: 1514B-DWRFID1202 Please be notified that we, Dell Inc., apply for limited module approval for the product which bears the above FCC ID / IC. The requirements regulated in Public Notice DA00-1407 and RSS-GEN have been fulfilled and clearly explained below. 1 The requirement of RF shielding: Th 2 The requirement of buffered inputs: The EUT has buffered data inputs, it is integrated in chip. 3 The requirement of power supply regulation: The power regulator is in front of chip with 3.3VDC. 4 The requirements of section 15.203 and 15.204(C): The requirements of antenna connector and spurious emission have been fulfilled. Please reference the exhibition Test Report. This module is intended for OEM integrator only and limited to host with brand: DELL and model: P19S. There were including professional installation in antenna part. 5 The requirement of stand-alone test configuration: This is limited modular approval, the modular be installed by the OEM into the specific hosts. The test has combine modular and host. Please reference exhibition Test Configuration Photo. 6 The requirement of labeling: The FCC ID / IC will be display on device which referring to the enclosed module. The instruction on the labeling rule of the end product has been stated in the user’s manual of this module. Please also see the exhibition Label Sample. 7 The requirement of compliance on specific rule or operating requirements: The required FCC / IC rule has been fulfilled and all the instructions for maintaining compliance has been clearly stated in the User’s Manual. 8 The requirement of RF exposure: Not applicable since the integration operates under section 15.225 of the FCC rules. MPE evaluation not be required. Please do not hesitate to contact me for any questions of this request letter. Thank you. Signature: Name: Mrs. Fiona, Y Chen Title: Regulatory Compliance Assistance Manager Company Name: Dell Inc.

Compliance Certification Services Inc. Report No.: T111116001 Date of Issue: November 30, 2011 A1 - 1 / 21 APPENDIX 1 - PHOTOGRAPHS OF EUT EXTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: T111116001 Date of Issue: November 30, 2011 A1 - 2 / 21 Compliance Certification Services Inc. Report No.: T111116001 Date of Issue: November 30, 2011 A1 - 3 / 21 Compliance Certification Services Inc. Report No.: T111116001 Date of Issue: November 30, 2011 A1 - 4 / 21 Compliance Certification Services Inc. Report No.: T111116001 Date of Issue: November 30, 2011 A1 - 5 / 21

Compliance Certification Services Inc. Report No.: T111116001 Date of Issue: November 30, 2011 A1 - 6 / 21 INTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: T111116001 Date of Issue: November 30, 2011 A1 - 7 / 21 Compliance Certification Services Inc. Report No.: T111116001 Date of Issue: November 30, 2011 A1 - 8 / 21 Compliance Certification Services Inc. Report No.: T111116001 Date of Issue: November 30, 2011 A1 - 9 / 21 Module Compliance Certification Services Inc. Report No.: T111116001 Date of Issue: November 30, 2011 A1 - 10 / 21 Loop Antenna Compliance Certification Services Inc. Report No.: T111116001 Date of Issue: November 30, 2011 A1 - 11 / 21 Compliance Certification Services Inc. Report No.: T111116001 Date of Issue: November 30, 2011 A1 - 12 / 21 Compliance Certification Services Inc. Report No.: T111116001 Date of Issue: November 30, 2011 A1 - 13 / 21 Compliance Certification Services Inc. Report No.: T111116001 Date of Issue: November 30, 2011 A1 - 14 / 21 Compliance Certification Services Inc. Report No.: T111116001 Date of Issue: November 30, 2011 A1 - 15 / 21 Module Compliance Certification Services Inc. Report No.: T111116001 Date of Issue: November 30, 2011 A1 - 16 / 21 Compliance Certification Services Inc. Report No.: T111116001 Date of Issue: November 30, 2011 A1 - 17 / 21 Compliance Certification Services Inc. Report No.: T111116001 Date of Issue: November 30, 2011 A1 - 18 / 21 Compliance Certification Services Inc. Report No.: T111116001 Date of Issue: November 30, 2011 A1 - 19 / 21 Compliance Certification Services Inc. Report No.: T111116001 Date of Issue: November 30, 2011 A1 - 20 / 21 Compliance Certification Services Inc. Report No.: T111116001 Date of Issue: November 30, 2011 A1 - 21

Compliance Certification Services Inc. FCC ID: E2K-DWRFID1202 Report No.: T111116001-RP Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 / 29 FCC 47 CFR PART 15 SUBPART C TEST REPORT For RFID 13.56MHz Wireless Module Model: DWRFID1202 Trade Name: DELL Issued to Dell Inc. One Dell Way Round Rock Texas 78682 United States Issued by Compliance Certification Services Inc. No.11, Wu-Gong 6th Rd., Wugu Industrial Park, New Taipei City 248, Taiwan (R.O.C.) http://www.ccsrf.com [email protected] Issued Date: November 25, 2011 Compliance Certification Services Inc. FCC ID: E2K-DWRFID1202 Report No.: T111116001-RP Page 2 Revision History Rev. Issue Date Revisions Effect Page Revised By 00 November 25, 2011 Initial Issue ALL Jessica Ho Compliance Certification Services Inc. FCC ID: E2K-DWRFID1202 Report No.: T111116001-RP Page 3 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION............................................................................................. 4 2. EUT DESCRIPTION .................................................................................................................... 5 3. TEST METHODOLOGY ............................................................................................................. 6 3.1 EUT CONFIGURATION.............................................................................................................. 6 3.2 EUT EXERCISE......................................................................................................................... 6 3.3 GENERAL TEST PROCEDURES.................................................................................................. 6 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS .............................................. 7 3.5 DESCRIPTION OF TEST MODES................................................................................................. 8 4. INSTRUMENT CALIBRATION................................................................................................. 9 4.1 MEASURING INSTRUMENT CALIBRATION........................................................................... 9 4.2 MEASUREMENT EQUIPMENT USED .............................................................................. 9 4.3 MEASUREMENT UNCERTAINTY .................................................................................. 10 5. FACILITIES AND ACCREDITATIONS ................................................................................. 11 5.1 FACILITIES............................................................................................................................ 11 5.2 EQUIPMENT........................................................................................................................... 11 5.3 TABLE OF ACCREDITATIONS AND LISTINGS.......................................................................... 12 6. SETUP OF EQUIPMENT UNDER TEST ................................................................................ 13 6.1 SETUP CONFIGURATION OF EUT............................................................................................ 13 6.2 SUPPORT EQUIPMENT..................................................................................................... 13 7. FCC PART 15.225 REQUIREMENTS...................................................................................... 14 7.1 20 DB BANDWIDTH .......................................................................................................... 14 7.2 RADIATED EMISSIONS........................................................................................................... 16 7.3 F REQUENCY STABILITY........................................................................................................ 21 7.4 POWERLINE CONDUCTED EMISSIONS.................................................................................... 23 APPENDIX I PHOTOGRAPHS OF TEST SETUP ....................................................................... 26 APPENDIX 1 - PHOTOGRAPHS OF EUT Compliance Certification Services Inc. FCC ID: E2K-DWRFID1202 Report No.: T111116001-RP Page 4 1. TEST RESULT CERTIFICATION Applicant: Dell Inc. One Dell Way Round Rock Texas 78682 United States Equipment Under Test: RFID 13.56MHz Wireless Module Tr a d e N a m e : DELL Model: DWRFID1202 Date of Test: November 17 ~ 21, 2011 APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4: 2003 and the energy emitted by the sample tested as described in this report is in compliance with the requirements of FCC Rules Part 15.225. The test results of this report relate only to the tested sample identified in this report. Approved by: Reviewed by: Jason Lin Gina Lo Section Manager Section Manager Compliance Certification Services Inc. Compliance Certification Services Inc. Compliance Certification Services Inc. FCC ID: E2K-DWRFID1202 Report No.: T111116001-RP Page 5 2. EUT DESCRIPTION Product RFID 13.56MHz Wireless Module Trade Name DELL Model Number DWRFID1202 Model Difference N/A Received Date November 16, 2011 Power Supply 1. Power Adapter Dell Inc. Model: AA65NM121 I/P: 100-240V, 1.7A, 50-60Hz O/P: 19.5V, 3.34A 2. Rechargeable Li-ion Battery: DELL / J79X4 Rating: 58Wh, 11.1V Frequency Range 13.56MHz Modulation Technique ASK Number of Channels 1 Channel Antenna Specification Gain: 0 dBi Antenna Designation Loop Antenna Note Product name: Notebook Computer / Brand name: DELL Model: P19S Remark: 1. The sample selected for test was enginee…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. FCC ID: E2K-DWRFID1202 Report No.: T111116001-RP Page 26 APPENDIX I PHOTOGRAPHS OF TEST SETUP Conducted Emission Set Up Photo Compliance Certification Services Inc. FCC ID: E2K-DWRFID1202 Report No.: T111116001-RP Page 27 Radiated Emission Set up Photos Compliance Certification Services Inc. FCC ID: E2K-DWRFID1202 Report No.: T111116001-RP Page 28 Compliance Certification Services Inc. FCC ID: E2K-DWRFID1202 Report No.: T111116001-RP Page 29 Powerline Conducted Emissions Setup Photos
