E2K-DWRFID2406RFID 13.56MHz Wireless Module

Quick Start 快速入门 | 快速啟動 | Démarrage rapide | Quick Start Dell Pro Rugged 10 Tablet RA00260 Mulai Cepat | クイックスタート | 빠른 시작 | Início rápido Руководство по быстрому началу работы | Початок роботи Brzi početak | Brzo pokretanje | Inicio rápido التشغيل السريع | התחלה מהירה Regulatory Model/Type 管制型号/类型 | 管制型號/類型 | Type/Modèle réglementaire | Vorschriftenmodell/-Typ | Tipe/Model Resmi 規制モデル / タイプ | 규정 모델/유형 | Tipo ou modelo de normalização Нормативная модель/тип | Модель/тип за нормативами | Regulatorni model/tip Regulatorni model/tip Modelo/tipo regulatorio النوع/الطراز الرقابي | דגם/סוג תקינה T19G / T19G 001 Información para NOM, o Norma Oficial Mexicana La información que se proporciona a continuación se mostrará en los dispositivos que se describen en este documento, en conformidad con los requisitos de la Norma Oficial Mexicana (NOM): Importador: Dell México, S.A. de C.V Av. Javier Barros Sierra, no 540, Piso 10, Col. Lomas de Santa Fe Delegación Á lvaro Obregón, Ciudad de México. C.P. 01219 R.F.C: DME9204099R6 País de origen: Hecho en China MCMC certification mark Windows In Windows Search, type System. In the search results, click System. Ubuntu On the desktop, click → About This Computer. Di impor oleh: PT Dell Indonesia Menara BCA Lantai 48 Unit 4804 Jalan M.H Thamrin No. 1 Jakarta Pusat, 10310 Indonesia Connection and use of this communications equipment is permitted by the Nigerian Communications Commission. La operación de este equipo está sujeta a las siguientes dos condiciones: (1) es posible que este equipo o dispositivo no cause interferencia perjudicial y (2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar su operación no deseada 商品名稱：平板 型號： Tablet (T19G) 額定電壓： 100-240 伏特 額定頻率： 50-60 赫茲 額定輸入電流： 1.5 or 1.7 安培 製造年份：參考外箱標示或條碼標籤 製造號碼：參考條外箱條碼標籤 生產國別：參考外箱標示 注意事項：參考使用手冊 產品功能：參考使用手冊 緊急處理方法：參考使用手冊 進口商/委製商：荷蘭商戴爾企業股份有限公司台灣分公司 進口商/委製商地址：台北市敦化南路二段 218 號 20 樓 進口商/委製商電話：00801-861-011 本產品符合臺灣RoHS標準CNS15663, 請見 http://www.dell.com/learn/tw/zh/twcorp1/envt-info-materials Read the safety information that shipped with your computer. For additional safety best practices information, see the Regulatory Compliance Homepage at Dell.com/regulatory_compliance. 请阅读您计算机随附的安全信息。有关其他安全方面的最佳实践信息，请参阅 Dell.com/regulatory_compliance 上的“合规性”主页。 請閱讀電腦隨附的安全資訊。 關於其他最佳安全實作的資訊，請參閱 Regulatory Compliance Homepage (法規遵循首頁) 於 Dell.com/regulatory_compliance。 Lisez les consignes de sécurité livrées avec votre ordinateur. Pour des informations supplémentaires sur les pratiques d'excellence, reportez-vous à la page d'accueil de la conformité aux réglementations sur Dell.com/regulatory_compliance. Weitere Informationen bieten die im Lieferumfang des Computers enthaltenen Sicherheitshinweise. Um zusätzliche Informationen zur bestmöglichen Einhaltung der Sicherheitsrichtlinien zu erhalten, sehen Sie die dazugehörige Homepage unter Dell.com/regulatory_compliance. Lihat informasi keselamatan yang disertakan dengan komputer Anda. Untuk informasi praktik keselamatan tambahan, kunjungi Laman Pemenuhan Peraturan di Dell.com/regulatory_compliance. コンピュータに同梱の安全に関する注意事項をお読みください。安全にお使いいただくためのベストプラクティスの追加情報に関しては、Dell.com/regulatory_compliance の規制順守に関するホームペ ージを参照してください。 컴퓨터와 함께 제공된 안전 정보를 읽으십시오. 안전 우수사례와 관련한 추가 정보는, Dell.com/regulatory_compliance 의 규정 준수(Regulatory Compliance) 웹 사이트를 참조하십시오. Leia as informações de segurança fornecidas com o seu computador. Para obter mais informações sobre as boas práticas de segurança, consulte o site de conformidade normativa em Dell.com/regulatory_compliance. Ознакомьтесь с информацией о безопасности, поставляемой с вашим компьютером. Для получения дополнительных сведений о передовых практических методах по технике безопасности посетите домашнюю страницу соответствия нормативным требованиям на веб-узле Dell.com/regulatory_compliance. Ознайомтеся з паспортом безпеки, що входить до комплекту постачання комп'ютера. Додаткові відомості про техніку безпеки див. на головній сторінці розділу про відповідність нормативам за веб-адресою Dell.com/regulatory_compliance. Pročitajte bezbednosne informacije koje ste dobili uz računar. Za dodatne informacije o najboljoj bezbednosnoj praksi pogledajte početnu stranicu za usklađenost sa odredbama na adresi Dell.com/regulatory_compliance. Pročitajte bezbednosne informacije koje ste dobili uz računar. Za dodatne informacije o najboljim bezbednosnim praksama, pogledajte početnu stranicu za usklađenost sa propisima na Dell.com/regulatory_compliance. Lea la información de seguridad enviada con el equipo. Para obtener información adicional sobre las mejores prácticas de seguridad, consulte la Página principal de conformidad reglamentaria en Dell.com/regulatory_compliance. اقرأ معلومات الأمان الواردة مع الكمبيوتر. لإيجاد معلومات إضافية حول أفضل ممارسات السلامة، انظر انظر الصفحة الرئيسية لقسم Regulatory Compliances علي الموقع Dell.com/regulatory_compliance. קרא את המידע בנושא בטיחות המצורף למחשב .לעיון במידע על נהלים מומלצים נוספים בנושא בטיחות ,ראה את דף הבית בנושא תאימות תקינה בכתובת Dell.com/regulatory_compliance. Do not remove the computer cover unless you need to install internal accessories for your computer. For instructions on removing and replacing parts, see the Owner’s or Service Manual at Dell.com/support. 除非您需要安装计算机内部附件，否则请勿卸除计算机主机盖。有关卸除和更换部件的说明，请参阅位于Dell.com/support 上的《用户手册》或《服务手册》。 除非您需要為您的電腦安裝內部配件，否則請勿拆卸電腦外蓋。有關拆卸和更換零件的說明，請參閱Dell.com/support 上的擁有者手冊或維修手冊。 Ne retirez pas le capot de l'ordinateur à moins que vous ne deviez installer des accessoires internes à votre ordinateur. Pour obtenir des instructions sur le remplacement des pièces, reportez-vous au Guide de l'utilisateur ou au Guide de maintenance à l'adresse Dell.com/support. Entfernen Sie die Computerabdeckung nur dann, wenn Sie das interne Zubehör für Ihren Computer einbauen müssen. Weitere Informationen zum Entfernen und Austauschen von Komponenten finden Sie im Benutzer- oder Service-Handbuch unter Dell.com/support. Jangan lepaskan penutup komputer kecuali …

Text truncated - open the document above for the full version.

Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. FOR PORTABLE DEVICE USAGE (<20m from body/SAR needed) Radiation Exposure Statement: The product comply with the FCC portable RF exposure limit set forth for an uncontrolled environment and are safe for intended operation as described in this manual. The further RF exposure reduction can be achieved if the product can be kept as far as possible from the user body or set the device to lower output power if such function is available. KDB 996369 D03 OEM Manual rule sections: 2.2 List of applicable FCC rules This module has been tested for compliance to FCC Part 15.225 2.3 Summarize the specific operational use conditions This module is exclusively for use in the host device T19G T19G incorporates this module (module model name DWRFID2406) and the antenna certified for use with this module. Incorporating this module into a host device other than T19G will require a separate reassessment through a class II permissive change or new certification. Full testing for the new specific host is required. 2.4 Limited module procedures This module is certified as limited modular approval under the conditions integrated within the host product T19G. 2.5 Trace antenna designs Not applicable. 2.6 RF exposure considerations This equipment complies with FCC mobile radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the radiator & your body. If the module is installed in a portable host, a separate SAR evaluation is required to confirm compliance with relevant FCC portable RF exposure rules. 2.7 Antennas The following antennas have been certified for use with this module; antennas of the same type with equal or lower gain may also be used with this module, except as described below. The antenna must be installed such that 20 cm can be maintained between the antenna and users. Antenna Manufacturer Hong Bo Antenna Model PW6T2(DC330030R0L) Antenna Type Loop Antenna Antenna Gain (dBi) N/A 2.8 Label and compliance information The final end product must be labeled in a visible area with the following: “Contains FCC ID: E2K-DWRFID2406”. The grantee's FCC ID can be used only when all FCC compliance requirements are met. The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user’s manual of the end product which integrates this module. The end product user manual shall include all required regulatory information/warning as shown in this manual. 2.9 Information on test modes and additional testing requirements This transmitter is tested in a standalone mobile RF exposure condition and any co-located or simultaneous transmission with other transmitter(s) or portable use will require a separate class II permissive change re-evaluation or new certification. 2.10 Additional testing, Part 15 Subpart B disclaimer This transmitter module is tested as a subsystem and its certification does not cover the FCC Part 15 Subpart B (unintentional radiator) rule requirement applicable to the final host. The final host will still need to be reassessed for compliance to this portion of rule requirements if applicable. OEM/Host manufacturers are ultimately responsible for the compliance of the Host and Module. The final product must be reassessed against all the essential requirements of the FCC rule such as FCC Part 15 Subpart B before it can be placed on the US market. This includes reassessing the transmitter module for compliance with the Radio and EMF essential requirements of the FCC rules. This module must not be incorporated into any other device or system without retesting for compliance as multi-radio and combined equipment. As long as all conditions above are met, further transmitter test will not be required. However, the OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed. 2.11 Note EMI Considerations Please follow the guidance provided for host manufacturers in KDB publications 996369 D02 and D04. 2.12 How to make changes Only Grantees are permitted to make permissive changes. Please contact us should the host integrator expect the module to be used differently than as granted: Don Bobo, Title: Distinguished Member…

Text truncated - open the document above for the full version.

Reference No.: BEDW-WTW-P24120944_INT Page No. 18/32 Reference No.: BEDW-WTW-P24120944_INT Page No. 19/32 Reference No.: BEDW-WTW-P24120944_INT Page No. 20/32 Reference No.: BEDW-WTW-P24120944_INT Page No. 21/32 Reference No.: BEDW-WTW-P24120944_INT Page No. 22/32 Reference No.: BEDW-WTW-P24120944_INT Page No. 23/32 Loop Antenna Reference No.: BEDW-WTW-P24120944_INT Page No. 24/32 Reference No.: BEDW-WTW-P24120944_INT Page No. 25/32 Brand: DELL, Model: DWRFID2406 Reference No.: BEDW-WTW-P24120944_INT Page No. 26/32 Reference No.: BEDW-WTW-P24120944_INT Page No. 27/32 Reference No.: BEDW-WTW-P24120944_INT Page No. 28/32 Reference No.: BEDW-WTW-P24120944_INT Page No. 29/32 Reference No.: BEDW-WTW-P24120944_INT Page No. 30/32 Reference No.: BEDW-WTW-P24120944_INT Page No. 31/32 Reference No.: BEDW-WTW-P24120944_INT Page No. 32/32

Photographs of EUT Setup and Antenna Location The photographs of EUT and setup for SAR testing are shown as follows. Report No.: SFBEDW-WTW-P24120944 To Top Side To Baseline To Left Side To Right Side (mm) (mm) (mm) (mm) 60.00 85.00 163.00 59.00 <Front Face View>Laptop Mode (180°) Antenna Support Band RFID RF ID Top Side Bottom Side Right Side Left Side LCD Keyboard Baseline RFID Report No.: SFBEDW-WTW-P24120944 Rear Face (mm) 85.00 <Right Side View> Laptop Mode(90°) Su pport Band RFID RF ID Antenna RFID Report No.: SFBEDW-WTW-P24120944 To Top Side To Bottom Side To Left Side To Right Side (mm) (mm) (mm) (mm) 60.00 85.00 163.00 59.00 Antenna RFID RFID Support Band <Fr ont Face View> Tablet Top Side Bottom Side Right Side Left Side LCD RFID Report No.: SFBEDW-WTW-P24120944 To Front Side To Rear Side (mm)(mm) 18.002.15 Antenna <Rear Face View> Tablet Support Band RFIDRFID LCD Side FrontSide Rear Side Bottom Side TopSide RFID Report No.: SFBEDW-WTW-P24120944 Bottom of Laptop Tested at 0 mm <Photographs of Body SAR Test Setup> Report No.: SFBEDW-WTW-P24120944 Top Side of Tablet Tested at 0 mmBottom Side of Tablet Tested at 0 mm Left Side of Tablet Tested at 0 mmRight Side of Tablet Tested at 0 mm <Photographs of Body SAR Test Setup> Front Face of Tablet Tested at 0 mmRe ar Face of Tablet Tested at 0 mm Report No.: SFBEDW-WTW-P24120944 Rear Face of Tablet Handle w/ Tested at 0 mm <Photographs of Body SAR Test Setup> Report No.: SFBEDW-WTW-P24120944

Reference No.: BEDW-WTW-P24120944 _TSup Page No. 1/3 PHOTOGRAPHS OF THE TEST CONFIGURATION Conducted Emission Test Reference No.: BEDW-WTW-P24120944 _TSup Page No. 2/3 Radiated Emission Test (9kHz ~ 30MHz) Reference No.: BEDW-WTW-P24120944 _TSup Page No. 3/3 Radiated Emission Test (30MHz ~ 1GHz)

Please refer to Appendix A 2Broadcom Limited Proprietary and Confidential. © 2016 Broadcom Limited. All rights reserved. | INTRODUCTION Citadel chipset for RFID based secure login and NFC features NFC/RFID implementation in these products requires an effective Antenna Match and NFC functionality verification The primary scope of this document is limited to evaluating the antenna matching circuit. Scope also covers signal integrity/waveform measurements, field strength validation and Critical card functional tests. Implementation has an LC EMI filter on the Citadel Module containing 58202. The rest of match is on Antenna Module and is subject to tuning adjustment based on antenna and related design AFE3 Antenna Interface Circuit Topology 3Broadcom Limited Proprietary and Confidential. © 2016 Broadcom Limited. All rights reserved. | ANTENNA DETAILS: BlueRidge 10(1/6) ParameterItemLimitDetail Product Info Vendor Name HongBo Date 2025/03/13 Sample Part Number Mechanical Design Coil outer Size (mm*mm)40 x 35 x 0.5 mm 38 mm x 33 mm Coil area (mm 2 )N/A 1254 mm 2 Number of turns3-6 4 Inductance<1.5uH 1.43 uH Antenna PCB Copper Thickness 1/2 oz. Trace Width (mm)>0.6mm 0.7 mm Trace Gap(mm)>0.4mm 0.5 mm Ferrite magnetic permeability(u')>120 130 ± 20% magnetic loss(u")<3 3 ± 10% Thickness (mm) 0.2 mm Ferrite size (mm*mm) 40 x 35 mm 2 10Broadcom Limited Proprietary and Confidential. © 2016 Broadcom Limited. All rights reserved. | Resonant Frequencies and other parameters Field Strength Measurements (A/m) ParameterRecommendedValue R/W Resonant Frequency (MHz) 13.56MHz +/- 0.10MHz13.57 CE Resonant Frequency (MHz)15.00MHz +/- 1.00MHz15.14 System Q17 19 (+/- 2)17.92 System Impedance as seen across TX1 and TX2 pins 8 +/-MHz7.88 NFC HW PERFORMANCE Distance from landing plane On-axis to Antenna90-deg to Antenna axis 0mm 3.093.11 5mm 3.123.14 10mm 2.862.93 15mm 2.212.22 20mm 1.731.89 25mm 1.521.25 30mm 1.141.06 35mm 0.830.84

Report No.: RFBEDW-WTW-P24120944 Page No. 1 /34Report Format Version: 7.1.0 TEST REPORT CERTIFICATE OF CONFORMITY Standard: 47 CFR FCC Part 15, Subpart C (Section 15.225) Report No.: RFBEDW-WTW-P24120944 FCC ID: E2K-DWRFID2406 Product: RFID 13.56MHz Wireless Module Brand: DELL Model No.: DWRFID2406 Received Date: 2025/2/25 Test Date: 2025/4/30 Issued Date: 2025/5/20 Applicant: Dell Inc. Address: One Dell Way, Round Rock, Texas 78682, USA Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lin Kou Laboratories Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan Test Location: No. 19, Hwa Ya 2nd Rd., Wen Hwa Vil., Kwei Shan Dist., Taoyuan City 33383, Taiwan FCC Registration / Desi gnation Number: 788550 / TW0003 Approved by: , Date:2025/5/20 Jeremy Lin / Project Engineer This test report consists of 34 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The test results in the report only apply to the tested sample. The test results in this report are traceable to the national or international standards. Prepared by : Celine Chou / Senior Specialist This report is governed by, and incorporates by reference, the Conditions of Testing as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our- business/cps/about-us/terms-conditions/ and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. Statements of conformity are based on simple acceptance criteria without taking measurement uncertainty into account, unless otherwise requested in writing. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Report No.: RFBEDW-WTW-P24120944 Page No. 2 /34Report Format Version: 7.1.0 Table of Contents Release Control Record ....................................................................................................................................................... 3 1 Certificate .................................................................................................................................................................... 4 2 Summary of Test Results .......................................................................................................................................... 5 2.1 Measurement Uncertainty ........................................................................................................................................ 5 2.2 Supplementary Information ...................................................................................................................................... 5 3 General Information ................................................................................................................................................... 6 3.1 General Description .................................................................................................................................................. 6 3.2 Antenna Description of EUT ..................................................................................................................................... 7 3.3 Channel List .............................................................................................................................................................. 8 3.4 Test Mode Applicability and Tested Channel Detail .................................................................................................. 9 3.5 Test Program Used and Operation Descriptions .................................................................................................... 10 3.6 Connection Diagram of EUT and Peripheral Devices ............................................................................................ 10 3.7 Configuration of Peripheral Devices and Cable Connections ................................................................................ 10 4 Test Instruments ...................................................................................................................................................... 11 4.1 AC Power Conducted Emissions ........................................................................................................................... 11 4.2 Radiated Emissions below 30 MHz ........................................................................................................................ 12 4.3 Radiated Emissions above 30 MHz ....................................................................................................................... 12 4.4 Frequency Stability ................................................................................................................................................. 13 4.5 20 dB Bandwidth ...................................…

Text truncated - open the document above for the full version.

Plots of System Verification Appendix A. Plots of System Verification The plots for system verification are shown as follows. Report No.: SFBEDW-WTW-P24120944 Plots of System Verification Measurement Report S01 System Check_H13MHz_250428 Device under Test Properties Model, Manufacturer Dimensions [mm] IMEI DUT Type CLA13, 240.0 x 240.0 x 95.0 Exposure Conditions Phantom Section, TSL Position, Test Distance [mm] Band Group, UID Frequency [MHz], Channel Number Conversion Factor TSL Conductivity [S/m] TSL Permittivity Flat, FRONT, 0.00 Custom Band CW, 0-- 13.000, 13000 15.75 0.759 55.7 Hardware Setup Phantom TSL, Measured Date Probe, Calibration Date DAE, Calibration Date ELI V8.0 (20deg probe tilt) - 2118 250MHz , 2025-Apr-28 EX3DV4 - SN7797, 2024-11-20 DAE4 Sn1585, 2024-05-16 Scan Setup Area Scan Zoom Scan Grid Extents [mm] 270.0 x 270.0 36.0 x 40.0 x 30.8 Grid Steps [mm] 10.0 x 10.0 4.0 x 4.0 x 1.4 Sensor Surface [mm] 3.0 1.4 Measurement Results Area Scan Zoom Scan Date 2025-04-28 2025-04-28 psSAR1g [W/kg] 0.029 0.027 psSAR10g [W/kg] 0.021 0.016 Power Drift [dB] 0.06 0.07 Report No.: SFBEDW-WTW-P24120944 Plots of Measurement Appendix B. Plots of Measurement The SAR plots for highest measured SAR in each exposure configuration, wireless mode and frequency band combination are shown as follows. Report No.: SFBEDW-WTW-P24120944 Plots of Measurement Measurement Report P01 RFID_ASK_Rear Face of Tablet_0mm_13.56MHz_Handle_w_o Device under Test Properties Model, Manufacturer Dimensions [mm] IMEI DUT Type P24120944, 260.0 x 187.0 x 25.0 Tablet Exposure Conditions Phantom Section, TSL Position, Test Distance [mm] Band Group, UID Frequency [MHz], Channel Number Conversion Factor TSL Conductivity [S/m] TSL Permittivity Flat, Rear Face of Tablet, 0.00 Custom Band CW, 0-- 13.600, 15.75 0.753 55.3 Hardware Setup Phantom TSL, Measured Date Probe, Calibration Date DAE, Calibration Date ELI V8.0 (20deg probe tilt) - 2118 250MHz , 2025-Apr-28 EX3DV4 - SN7797, 2024-11-20 DAE4 Sn1585, 2024-05-16 Scan Setup Area Scan Zoom Scan Grid Extents [mm] 240.0 x 320.0 Grid Steps [mm] 10.0 x 10.0 Sensor Surface [mm] 3.0 Measurement Results Area Scan Zoom Scan Date 2025-04-28 psSAR1g [W/kg] 0 psSAR10g [W/kg] 0 Power Drift [dB] 0 M2/M1 [%] Dist 3dB Peak [mm] Report No.: SFBEDW-WTW-P24120944 Appendix Z. Calibration Certificate for Probe and Dipole The SPEAG calibration certificates are shown as follows. Report No.: SFBEDW-WTW-P24120944 Report No.: SFBEDW-WTW-P24120944 Report No.: SFBEDW-WTW-P24120944 Report No.: SFBEDW-WTW-P24120944 Report No.: SFBEDW-WTW-P24120944 Report No.: SFBEDW-WTW-P24120944 Report No.: SFBEDW-WTW-P24120944 Report No.: SFBEDW-WTW-P24120944 Report No.: SFBEDW-WTW-P24120944 Report No.: SFBEDW-WTW-P24120944 Report No.: SFBEDW-WTW-P24120944 Report No.: SFBEDW-WTW-P24120944 Report No.: SFBEDW-WTW-P24120944 Report No.: SFBEDW-WTW-P24120944 Report No.: SFBEDW-WTW-P24120944 Report No.: SFBEDW-WTW-P24120944 Report No.: SFBEDW-WTW-P24120944 Report No.: SFBEDW-WTW-P24120944 Report No.: SFBEDW-WTW-P24120944 Report No.: SFBEDW-WTW-P24120944 Report No.: SFBEDW-WTW-P24120944 Report No.: SFBEDW-WTW-P24120944 Report No.: SFBEDW-WTW-P24120944 Report No.: SFBEDW-WTW-P24120944 Report No.: SFBEDW-WTW-P24120944 Report No.: SFBEDW-WTW-P24120944 Report No.: SFBEDW-WTW-P24120944 Report No.: SFBEDW-WTW-P24120944 Report No.: SFBEDW-WTW-P24120944

SAR Test Report Report Format Version 8.0.0 Page No. : 1 of 26 Report No. : SFBEDW-WTW-P24120944 Issued Date : May 21, 2025 SAR Test Report FCC Rule Part : CFR §2.1093 Standards : IEEE Std 1528:2013, KDB 865664 D01 v01r04, KDB 865664 D02 v01r02, KDB 447498 D01 v06, KDB 616217 D04 v01r02 Report No. : SFBEDW-WTW-P24120944 Applicant : Dell Inc. Address : One Dell Way, Round Rock, Texas 78682, USA Product : RFID 13.56MHz Wireless Module FCC ID : E2K-DWRFID2406 Brand : DELL Model No. : DWRFID2406 Sample Received Date : Feb. 25, 2025 Date of Testing : Apr. 28, 2025 Lab Address : No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan TEST LOCATION : No. 19, Hwa Ya 2nd Rd., Wen Hwa Vil., Kwei Shan Dist., Taoyuan City, Taiwan FCC Accredited No. : TW0003 CERTIFICATION: The above equipment have been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch–Lin Kou Laboratories, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s SAR characteristics under the conditions specified in this report. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF or any government agencies. Prepared By : Lena Wang / Specialist Approved By : Gordon Lin / Manager This report is governed by, and incorporates by reference, the Conditions of Testing as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our-business/cps/about-us/terms-conditions/ and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. Statements of conformity are based on simple acceptance criteria without taking measurement uncertainty into account, unless otherwise requested in writing. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. SAR Test Report Report Format Version 8.0.0 Page No. : 2 of 26 Report No. : SFBEDW-WTW-P24120944 Issued Date : May 21, 2025 Table of Contents Release Control Record ............................................................................................................................................................... 3 1. Test Reference Guidance ...................................................................................................................................................... 4 2. Summary of Maximum SAR Value ....................................................................................................................................... 5 3. Description of Equipment Under Test ................................................................................................................................. 6 4. SAR Measurement System ..............................................................................................................…

Text truncated - open the document above for the full version.
