E2K-DWRFID1502RFID 13.56MHz Wireless Module

OEM Installation Guidance For Dell RFID 13.56MHz Wireless Module, FCC ID: E2K‐DWRFID1502, IC: 1514B‐DWRFID1502 ‐ OEM integrators must ensure that its product is electrically identical to Dell’s reference designs. Any modifications to Dell’s reference designs may invalidate regulatory approvals in relation to the product, or may necessitate notifications to the relevant regulatory authorities. ‐ OEM integrators are responsible for regression testing to accommodate changes to designs, new antennas, and host and submit for C2PC filings. Colocation with other transmitter modules will be addressed through filings for those co‐located transmitters when necessary or that colocation of other transmitters will be according to applicable KDB guidelines including those for RF exposure ‐The final system integrator must ensure there is no instruction provided in the user manual or customer documentation indicating how to install or remove the transmitter ‐ Appropriate labels must be affixed to the product that complies with applicable regulations in all respects. The regulatory label on the final system must include the statement: “Contains FCC ID: E2K‐DWRFID1502 and/or IC: 1514B‐DWRFID1502”. ‐ A user’s manual or instruction manual must be included with the product that contains the text as required by applicable law shall be provided to OEM integrators. They may include: 1. USA—Federal Communications Commission (FCC) FCC COMPLIANCE STATEMENT: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. INFORMATION TO USER: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy. If not installed and used in accordance with the instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by tuning the equipment off and on, the user is encouraged to try and correct the interference by one or more of the following measures: ‐Reorient or relocate the receiving antenna ‐Increase the distance between the equipment and the receiver. ‐Connect the equipment to outlet on a circuit different from that to which the receiver is connected. ‐Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. The final host manual shall include the following regulatory statement: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy. If not installed and used in accordance with the instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by tuning the equipment off and on, the user is encouraged to try and correct the interference by one or more of the following measures: ‐Reorient or relocate the receiving antenna ‐Increase the distance between the equipment and the receiver. ‐Connect the equipment to outlet on a circuit different from that to which the receiver is connected. ‐Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 2. Canada ‐ Industry Canada (IC) This device complies with Industry Canada licence‐exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. French: Cet appareil est conforme avec Industrie Canada exempts de licence standard RSS (s). L‘utilisation de ce dispositif est autorisée seulement aux conditions suivantes : (1) il ne doit pas produire de brouillage et (2) l’ utilisateur du dispositif doit étre prêt à accepter tout brouillage radioélectrique reçu, même si ce brouillage est susceptible de compromettre le fonctionnement du dispositif.

FCC Radiation Exposure Statement WARNING: The radiated output power of this device is below the FCC radio frequency exposure limits. Nevertheless, this device should be used in such a manner that the potential for human contact during normal operation is minimized. This device has been evaluated for and shown compliant with the FCC RF Exposure limits under mobile exposure conditions (antennas are greater than 20cm from a person’s body). This device has also been evaluated for and shown compliant with the FCC RF exposure limits under portable exposure conditions (antennas are within 20 cm of a person's body) when installed in certain specific configurations. Details of the authorized configurations can be found at https://fjallfoss.fcc.gov/oetcf/eas/reports/GenericSearch.cfm by entering the FCC ID number on the device. Interference Statement These devices comply with Part 15 of the FCC Rules. Operation of the devices is subject to the following two conditions: (1) The devices may not cause harmful interference, and (2) The devices must accept any interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy. If the equipment is not installed and used in accordance with the instructions, the equipment may cause harmful interference to radio communications. There is no guarantee, however, that such interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception (which can be determined by turning the equipment off and on), the user is encouraged to try to correct the interference by taking one or more of the following measures:  Relocate this device.  Increase the separation between the device and the receiver.  Connect the device into an outlet on a circuit different from that of other electronics.  Consult the dealer or an experienced radio technician for help. NOTE: Dell RFID devices must be installed and used in strict accordance with the manufacturer’s instructions as described in the user documentation that comes with the product. Any other installation or use will violate FCC Part 15 regulations. Modifications not expressly approved by Dell could void your authority to operate the equipment.

DELL CONFIDENTIAL Dell Mobile Precision Workstation - 7510 Quick Start Guide Language: ENGLISH Regulatory Model: P53F Regulatory Type: P53F001 This document is for regulatory purpose only. 1 | P a g e This document is for regulatory purpose only. Warnings WARNING: A WARNING indicates a potential for property damage, personal injury, or death. CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem. NOTE: A NOTE indicates important information that helps you make better use of your computer. Copyright © 2015 Dell Inc. All rights reserved. This product is protected by U.S. and international copyright and intellectual property laws. Dell™ and the Dell logo are trademarks of Dell Inc. in the United States and/or other jurisdictions. All other marks and names mentioned herein may be trademarks of their respective companies. Rev: A01 2 | P a g e This document is for regulatory purpose only. Setting up Your Computer This section provides information about setting up your Dell computer. Before Setting up Your Computer When positioning your computer, ensure that you allow easy access to a power source, adequate ventilation, and a level surface to place your computer. Restricting airflow around your computer may cause it to overheat. To prevent overheating ensure that you leave at least 10.2 cm (4 inches) at the back of the computer and a minimum of 5.1 cm (2 inches) on all other sides. You should never place your computer in an enclosed space, such as a cabinet or drawer when it is powered on. WARNING: Do not block, push objects into, or allow dust to accumulate in the air vents. Do not store your Dell™ computer in a low-airflow environment, such as a closed briefcase, while it is powered on. Restricting the airflow can damage the computer or cause a fire. The computer turns on the fan when the computer gets hot. Fan noise is normal and does not indicate a problem with the fan or the computer. CAUTION: Placing or stacking heavy or sharp objects on the computer may result in permanent damage to the computer. Icons, Status Lights and Indicators Icons are used to label all connectors and buttons on Dell computers. Check the following table for a description of those found on your computer. Power/battery status light – Indicates the power state and battery status. AC adapter connector - Connects to the AC adapter to power the computer and charge the battery when the computer is not in use. Battery status light – if the power status light does not provide information on battery charge status, this light provides information on charge status. Wireless switch - used to either turn wireless communication on or off. -Or- used to scan the local area for available wireless signals. Network connector – Connects your computer to a network or a broadband device if you are using a wired network. VGA connector – Connects to a monitor or projector. USB 2.0 connector – Connects to USB devices, such as a mouse, keyboard, printer, external drive, or MP3 player. Eject the disc 3 | P a g e This document is for regulatory purpose only. Audio out/Headphone connector – Connects one pair of headphones, or sends audio to a powered speaker or sound system. Audio in/Microphone connector – Connects to a microphone or input signal for use with audio programs. Turn up the volume Mute the sound Turn down the volume Play or pause Play the next track or chapter Play the previous track or chapter HDMI connector – connects to a monitor, projector, or television. eSATA – connects to external devices such as hard drives and media bays, this connector also supports standard USB devices. ExpressCard slot – Supports one 34 mm wide ExpressCard. The computer ships with a plastic blank installed in the slot. NOTE: Blanks protect unused slots from dust and other particles. Save the blank for use when no ExpressCard is installed in the slot; blanks from other computers may not fit your computer. Display Port - connects to a monitor or projector or Provides a fast and convenient way to view and share digital photos, music, videos, and documents stored on digital memory cards. 1394 Firewire – used for high-speed data connections to external storage and digital media devices, such as still- and video cameras. Line in – connects to audio devices such as receivers and MP3 players Line out – connects to audio devices such as stereos and speakers USB connector – connects to peripheral devices such as printers, mice, and keyboards. Wireless sync – used to synchronize connections with wireless input devices such as keyboards and mice (for select systems only). DVI connector – used to connect monitors, projectors, and televisions. 4 | P a g e This document is for regulatory purpose only. HD activity light – lights when the hard drive is writing or reading data. Removing and Replacing a Laptop Computer Battery If your Dell laptop computer is shipped without the battery, install the battery before your proceed. WARNING: Before you begin any of the procedures in this section, follow the safety instructions that shipped with your computer. WARNING: Using an incompatible battery may increase the risk of fire or explosion. This computer should only use a battery purchased from Dell. Do not use batteries from other computers. WARNING: Before removing the battery, shut down the computer, and remove external cables (including the AC adapter). To install the battery 1. Slide the battery into the battery bay until it clicks into place. For some computers, this requires that the battery be inserted at a 45-degree angle. To remove the battery 1. Turn off the computer and turn it over. 2. Slide the battery release latch or latches to the unlock position until it clicks into place. 3. Slide the battery out. 5 | P a g e This document is for regulatory purpose only. Connecting the Power Supply Computers With External AC Adapters (Notebooks and All-in-One Models) Connect the AC adapter to the computer and t…

Text truncated - open the document above for the full version.

Dell Inc. Richard Worley, NCE MS: PS4-30 EMC, Global Regulations and Standards One Dell Way Telephone 512.728.1081 Round Rock, Texas 78682 Telefax 512.283.9268 www.dell.com e-mail [email protected] Worldwide Regulatory Compliance Engineering & Environmental Affairs Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 May 5, 2015 FCC authorization letter for Dell Regulatory employees To whom it may concern, I, the undersigned, as the authorized signatory for the Dell Inc. grantee code E2K, hereby authorize the following EMC & Wireless Regulatory Engineers of Dell Inc., to act on my behalf as our agent in all manners relating to processes required according to FCC rules for equipment authorization: Adele Huang Alden Neilson Angelica Chang Don Bobo Fiona Y Chen James Carrillo Jane YC Chen Jason KP Lee Rex Wan Rick Linford Steve L Williams Thanh Nguyen Zenon Wang This authorization shall be sent along with application when filing with the FCC Certification Division and is valid until further written notice from the applicant. If you have any questions or need additional information, please feel free to contact me at 512-728-1081 or 512-431-1084. Sincerely, Richard Worley Dell Inc. FRN: 0008359580

Applicant/Grantee Dell Inc./ E2K FCC ID: E2K-DWRFID1502 Section 15.212 Modular Transmitters Request for Modular Approval Request for Limited Modular Approval Requirements EUT Conditions Comply (Y/N) Single Modular Approval Requirements 1 The radio elements of the modular transmitter must have their own shielding. The physical crystal and tuning capacitors may be located external to the shielded radio elements. The module has no shield, limited modular approval is being requested (see item 5 below). N 2 The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. The modular transmitter had buffer on (BCM58102) chip Y 3 The modular transmitter must have its own power supply regulation. The modular transmitter had its own power supply regulation on (BCM58102) chip (3.3VDC) Y 4 The modular transmitter must comply with the antenna and transmission system requirements of Sections 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of Section 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. The requirements of antenna connector and spurious emission have been fulfilled. Please reference the exhibition Test Report. This module is intended for OEM integrator only and limited to host with brand: DELL and model: P53F. There were including professional installation in antenna part. Y 5 The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing for compliance with Part 15 requirements. Unless the transmitter module will be battery powered, it must comply with the AC line conducted requirements found in Section 15.207. AC or DC power lines and data input/output lines connected to the module must not contain ferrites, unless they will be marketed with the module (see Section 15.27(a)). The length of these lines shall be the length typical of actual use or, if that length is unknown, at least 10 centimeters to insure that there is no coupling between LOOP antenna had fixed on PCB board. Y the case of the module and supporting equipment. Any accessories, peripherals, or support equipment connected to the module during testing shall be unmodified and commercially available (see Section 15.31(i)). 6 The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number. (A) If using a permanently affixed label, the modular transmitter must be labeled with its own FCC identification number, and, if the FCC identification number is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. (B) If the modular transmitter uses an electronic display of the FCC identification number, the information must be readily accessible and visible on the modular transmitter or on the device in which it is installed. If the module is installed inside another device, then the outside of the device into which the module is installed must display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains FCC certified transmitter module(s).” Any similar wording that expresses the same meaning may be used. The user manual must include instructions on how to access the electronic display. A copy of these instructions must be included in the application for equipment authorization. The FCC ID / IC will be display on device which referring to the enclosed module. The instruction on the labeling rule of the end product has been stated in the user’s manual of this module. Please also see the exhibition Label Sample. Y 7 The modular transmitter must comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the Y application for equipment authorization. 8 The modular transmitter must comply with any applicable RF exposure requirements in its final configuration. Y A limited modular approval may be granted for single or split modular transmitters that do not comply with all of the above requirements, e.g., shielding, minimum signaling amplitude, buffered modulation/data inputs, or power supply regulation, if the manufacturer can demonstrate by alternative means in the application for equipment authorization that the modular transmitter meets all the applicable Part 15 requirements under the operating conditions in which the transmitter will be used. Limited modular approval also may be granted in those instances where compliance with RF exposure rules is demonstrated only for particular product configurations. The applicant for certification must state how control of the end product into which the module will be installed will be maintained such that full compliance of the end product is always ensured. Signature____ ________________ Name/Title: Jane …

Text truncated - open the document above for the full version.

Date: November 2, 2015 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 c.c. Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Mr. Sam Chuang / Manager of Compliance Certification Services Inc. and hereafter referred to as CCS, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Mr. Miller Lee / Manager of Compliance Certification Services Inc. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing CCS as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) do cument the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Name/Title: Jane YC Chen / Regulatory Compliance Manager Company Name: Dell Inc. Address: One Dell Way Round Rock, TX78682, USA TEL: +886 2 2376 6599 FAX: +886 2 2736 9067 Email: [email protected] REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us. 3. Authorized signature must be in agreement with grantee code contact in FCC database.

Compliance Certification Services Inc. Report No.: T150423W02 Date of Issue: May 5, 2015 A1 - 1 / 13 Rev. 00 APPENDIX 1 - PHOTOGRAPHS OF EUT EXTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: T150423W02 Date of Issue: May 5, 2015 A1 - 2 / 13 Rev. 00 Compliance Certification Services Inc. Report No.: T150423W02 Date of Issue: May 5, 2015 A1 - 3 / 13 Rev. 00 Compliance Certification Services Inc. Report No.: T150423W02 Date of Issue: May 5, 2015 A1 - 4 Rev. 00 Adapter Compliance Certification Services Inc. Report No.: T150423W02 Date of Issue: May 5, 2015 A1 - 5 Rev. 00

DWRFID1502 module label document DWRFID1502 label drawing DWRFID1502 label location Note: As the module size is < 4x4”, FCC statement won’t be placed in the module label.

Label location P53F BOTTOM DOOR DWRFID1502 label drawing in P53F system

Compliance Certification Services Inc. FCC ID: E2K-DWRFID1502 Report No.: T150423W02-RP Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 / 31 FCC 47 CFR PART 15 SUBPART C TEST REPORT For RFID 13.56MHz Wireless Module Model: DWRFID1502 Trade Name: DELL Issued to Dell Inc. One Dell Way Round Rock Texas 78682 United States Issued by Compliance Certification Services Inc. No.11, Wugong 6th Rd., Wugu Dist., New Taipei City 24891, Taiwan. (R.O.C.) http://www.ccsrf.com [email protected] Issued Date: May 5, 2015 Compliance Certification Services Inc. FCC ID: E2K-DWRFID1502 Report No.: T150423W02-RP Page 2 Revision History Rev. Issue Date Revisions Effect Page Revised By 00 May 5, 2015 Initial Issue ALL Doris Chu Compliance Certification Services Inc. FCC ID: E2K-DWRFID1502 Report No.: T150423W02-RP Page 3 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION ............................................................................................. 4 2. EUT DESCRIPTION .................................................................................................................... 5 3. TEST METHODOLOGY ............................................................................................................. 6 3.1 EUT CONFIGURATION .............................................................................................................. 6 3.2 EUT EXERCISE ......................................................................................................................... 6 3.3 GENERAL TEST PROCEDURES .................................................................................................. 6 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS .............................................. 7 3.5 DESCRIPTION OF TEST MODES ................................................................................................. 7 4. INSTRUMENT CALIBRATION ................................................................................................. 8 4.1 MEASURING INSTRUMENT CALIBRATION ........................................................................... 8 4.2 MEASUREMENT EQUIPMENT USED .............................................................................. 8 4.3 MEASUREMENT UNCERTAINTY .................................................................................... 9 5. FACILITIES AND ACCREDITATIONS ................................................................................. 10 5.1 FACILITIES ............................................................................................................................ 10 5.2 EQUIPMENT ........................................................................................................................... 10 5.3 TABLE OF ACCREDITATIONS AND LISTINGS .......................................................................... 11 6. SETUP OF EQUIPMENT UNDER TEST ................................................................................ 12 6.1 SETUP CONFIGURATION OF EUT ............................................................................................ 12 6.2 SUPPORT EQUIPMENT ..................................................................................................... 12 7. FCC PART 15.225 REQUIREMENTS ...................................................................................... 13 7.1 20 DB BANDWIDTH .......................................................................................................... 13 7.2 RADIATED EMISSIONS ........................................................................................................... 15 7.3 FREQUENCY STABILITY ........................................................................................................ 22 7.4 POWERLINE CONDUCTED EMISSIONS .................................................................................... 25 APPENDIX I PHOTOGRAPHS OF TEST SETUP ....................................................................... 28 APPENDIX 1 - PHOTOGRAPHS OF EUT Compliance Certification Services Inc. FCC ID: E2K-DWRFID1502 Report No.: T150423W02-RP Page 4 1. TEST RESULT CERTIFICATION Applicant: Dell Inc. One Dell Way Round Rock Texas 78682 United States Equipment Under Test: RFID 13.56MHz Wireless Module Trade Name: DELL Model: DWRFID1502 Date of Test: April 27 ~ 30, 2015 APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in acc…
