Dell Latitude E6320/E6420 ATG Setup and Features Information About Warnings WARNING: A WARNING indicates a potential for property damage, personal injury, or death. Front And Back View Figure 1. Latitude E6320 1. microphone 2. camera 3. camera status light 4. display 5. power button 6. eSata/USB connector 7. USB 2.0 connector 8. volume control buttons 9. wireless switch 10. optical drive 11. PC card or Express card slot 12. fingerprint reader Regulatory Model: P12S, P15G Regulatory Type: P12S001, P15G002 February 2011 13. contactless smart card reader 14. Secure Digital (SD) memory-card reader 15. touchpad buttons 16. touchpad 17. trackstick buttons 18. trackstick 19. keyboard 20. device status lights 21. Latitude ON button 1. network connector 2. mini HDMI connector 3. power and battery status lights 4. security cable slot 5. AC adapter connector 6. video connector (VGA) 7. audio connector 8. cooling vents 9. smart card slot WARNING: Do not block, push objects into, or allow dust to accumulate in the air vents. Do not store your Dell computer in a low-airflow environment, such as a closed briefcase, while it is running. Restricting the airflow can damage the computer or cause a fire. The computer turns on the fan when the computer gets hot. Fan noise is normal and does not indicate a problem with the fan or the computer. 2 Front And Back View Figure 2. Latitude E6420 ATG 1. microphone 2. display release latch 3. camera 4. camera status light 5. display latch 6. display 7. Latitude ON button 8. power button 9. eSata/USB connector 10. USB 2.0 connectors (2) 11. volume control buttons 12. wireless switch 13. optical drive 14. PC card or Express card slot 15. fingerprint reader 16. Secure Digital (SD) memory-card reader 17. contactless smart card reader 18. touchpad buttons 19. touchpad 20. trackstick buttons 21. trackstick 22. keyboard 23. device status lights 3 1. HDMI connector 2. security cable slot 3. modem connector 4. power and battery status lights 5. AC adapter connector 6. network connector 7. video connector (VGA) 8. USB 2.0 connector 9. audio connector 10. cooling vents 11. smart card slot WARNING: Do not block, push objects into, or allow dust to accumulate in the air vents. Do not store your Dell computer in a low-airflow environment, such as a closed briefcase, while it is running. Restricting the airflow can damage the computer or cause a fire. The computer turns on the fan when the computer gets hot. Fan noise is normal and does not indicate a problem with the fan or the computer. Latitude E6420 ATG Handle Assembly 1. Insert a paper clip into the release hole to unlock and remove the covering plugs from their hollow. 4 2. Place the handle assembly into the hollow as shown. Use the two screws to tighten and secure the handle assembly to the computer. Quick Setup WARNING: Before you begin any of the procedures in this section, read the safety information that shipped with your computer. For additional best practices information, see www.dell.com/regulatory_compliance. WARNING: The AC adapter works with electrical outlets worldwide. However, power connectors and power strips vary among countries. Using an incompatible cable or improperly connecting the cable to the power strip or electrical outlet may cause fire or equipment damage. CAUTION: When you disconnect the AC adapter cable from the computer, grasp the connector, not the cable itself, and pull firmly but gently to avoid damaging the cable. When you wrap the AC adapter cable, ensure that you follow the angle of the connector on the AC adapter to avoid damaging the cable. NOTE: Some devices may not be included if you did not order them. 5 1. Connect the AC adapter to the AC adapter connector on the computer and to the electrical outlet. Figure 3. AC Adapter 2. Connect the network cable (optional). Figure 4. Network Connector 3. Connect USB devices, such as a mouse or keyboard (optional). Figure 5. USB Connector 4. Connect IEEE 1394 devices, such as a 1394 hard drive (optional). Figure 6. 1394 Connector 5. Open the computer display and press the power button to turn on the computer. 6 Figure 7. Power Button NOTE: It is recommended that you turn on and shut down your computer at least once before you install any cards or connect the computer to a docking device or other external device, such as a printer. Specifications NOTE: Offerings may vary by region. The following specifications are only those required by law to ship with your computer. For more information regarding the configuration of your computer, click Start → Help and Support and select the option to view information about your computer. System Information ChipsetIntel Mobile Express Series 6 chipset ProcessorIntel Core i5 or Intel Core i7 (2nd generation) Video Video typeintegrated on system board Data busintegrated video Video controller memory512 MB Memory Memory connectortwo SODIMM slots Memory capacity1 GB, 2 GB, 4 GB, or 8 GB Memory typeDDR3 SDRAM (1333 MHz) Minimum memory1 GB Maximum memory8 GB Battery Type 7 Battery Latitide E6320 • 3-cell “smart” Lithium ion • 6-cell “smart” Lithium ion Latitude E6420 ATG • 4-cell “smart” Lithium ion • 6-cell “smart” Lithium ion • 9-cell “smart” Lithium ion Dimensions: 3-cell battery Latitide E6320 Depth29.87 mm (1.18 inches) Height19.80 mm (0.78 inch) Width208.00 mm (8.03 inches) 6-cell battery Latitide E6320 Depth54.00 mm (2.13 inches) Height20.85 mm (0.82 inch) Width214.00 mm (8.43 inches) Latitude E6420 ATG Depth48.08 mm (1.89 inches) Height20.00 mm (0.79 inch) Width208.00 mm (8.19 inches) 9-cell battery Latitude E6420 ATG Depth71.79 mm (2.83 inches) Height20.00 mm (0.79 inch) Width214.00 mm (8.43 inches) Weight Latitide E6320 3-cell174.00 g (0.38 lb) 8 Battery 6-cell335.90 g (0.74 lb) Latitude E6420 ATG 4-cell240.00 g (0.53 lb) 6-cell343.00 g (0.76 lb) 9-cell510.00 g (1.12 lb) Voltage 3-cell, 6-cell, and 9-cell11.10 VDC 4-cell14.80 VDC Temperature range: Operating0 °C to 35 °C (32 °F to 95 °F) Non-Operating–40 °C …

Text truncated - open the document above for the full version.

Date: Nov. 02, 2010 Federal Communications Commission Authorization and Evaluation Division FCC ID: E2K-P12S Confidentiality Request To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until Increase from 180 days from the date of approval. External Photos Internal Photos Test Setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards Name/Title: Mrs. Fiona, Y Chen / Sr. Regulatory Compliance Engineer Company Name: Dell Inc. Address: 11F, No. 218,Sec.2, Tun Hua S. Road Taipei, Taiwan, R.O.C TEL: (886)2-2736-6352 FAX: (886)2-2736-9067 Email: [email protected]

1 of 2 Date: Nov. 02, 2010 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 c.c. Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize (Miller Lee /Measurement Center Manger) of (A Test Lab Techno Corp.) and hereafter referred to as (ATL), to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by (Miller Lee /Measurement Center Manger) of (A Test Lab Techno Corp.) on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing (ATL) as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; 2 of 2 e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Name/Title: Mrs. Fiona, Y Chen / Sr. Regulatory Compliance Engineer Company Name: Dell Inc. Address: 11F, No. 218,Sec.2, Tun Hua S. Road Taipei, Taiwan, R.O.C TEL: (886)2-2736-6352 FAX: (886)2-2736-9067 Email: [email protected] REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us. 3. Authorized signature must be in agreement with grantee code contact in FCC database.

Dell Inc. Richard Worley, NCE MS: PS4-30 EMC, Global Regulations and Standards One Dell Way Telephone 512.728.1081 Round Rock, Texas 78682 Telefax 512.283.9268 www.dell.com e-mail [email protected] Worldwide Regulatory Compliance Engineering & Environmental Affairs November 08, 2010 To whom it may concern, I, the undersigned, as the authorized signatory for the Dell Inc grantee code E2K, hereby authorize Fiona Y Chen, EMC & Wireless Regulatory Engineering of Dell Inc., to act on my behalf in all manners relating to application (FCC ID: E2K-P12S) for equipment authorization, including signing of all documents relating to this application. Any and all acts carried out by Fiona Y Chen of Dell Inc. on our behalf shall have the same effects as acts of our own. This authorization shall be sent along with application when filing with the FCC Certification Division and is valid until further written notice from the applicant. If you have any questions or need additional information, please feel free to contact me at 512-728-1081 or 512-431-1084. Sincerley, Richard Worley Dell Inc. FRN: 0008359580

1 Lucy Tsai From: ATL-Joyce [[email protected]] Sent: Thursday, November 11, 2010 7:16 PM To: Lucy Tsai Cc: [email protected]; [email protected]; [email protected]; [email protected] Subject: FW : Dell Inc., FCC ID: E2K-P12S, Assessment NO.: AN10T1117, Notice#1 Dear Lucy, Q#1: Label location, block diagram and schematics also included the location for WLAN/WiMAX, WWAN/UWB and BT other three transmitters. Please be noted that this filing will is only for the certification of RFID. Other transmitters are also required to get FCC certification and meet the RF exposure requirements. ATL ‐‐> The FCC ID only applies RFID function of system. Other transmitters will be submitted by module manufacturers via other separate applications. Q#2: Please check again if the user manual uploaded is designated for this application. The EUT functional key and model number indicated inside the user manual do not agree with EUT external photos and label format. Moreover, please make sure all the related statements as 15.21, 15.105 and RF exposure statements have been included to the user manual. ATL ‐‐> a) The user manual's model number is show “ Regulatory Model: P12S”. The Regulatory Model: P12S is corresponding Latitude E6320. b) This user manual is P12S and P15G share. Latitude E6320 functional key is for P12S and Latitude E6420 ATG functional key is for P15G. c) The 15.21, 15.105 and RF exposure statements show on website. http://www.dell.com/downloads/global/corporate/environ/comply/united_states_rfid.pdf We've provide it. Best regards, 廖秋吟 Joyce Liao Measurement Center TEL : +886-3-2710188 ext: 200 Mobile : +886-935176076 Address :桃園縣八德市長安街140-1號 E-mail : [email protected] Website : http://www.atl-lab.com.tw ----- 轉呈者 miller/ATL 於 2010/11/11 上午 09:16 ----- <[email protected]> 收件人 <[email protected] > 副本抄送 <[email protected] > 2 2010/11/10 下午 03:18 主旨 Dell Inc., FCC ID: E2K-P12S, Assessment NO.: AN10T1117, Notice#1 Hi, Miller, Please address following issues. Q#1: Label location, block diagram and schematics also included the location for WLAN/WiMAX, WWAN/UWB and BT other three transmitters. Please be noted that this filing will is only for the certification of RFID. Other transmitters are also required to get FCC certification and meet the RF exposure requirements. Q#2: Please check again if the user manual uploaded is designated for this application. The EUT functional key and model number indicated inside the user manual do not agree with EUT external photos and label format. Moreover, please make sure all the related statements as 15.21, 15.105 and RF ex posure statements have been included to the user manual. Best Regards, Lucy Tsai/UL CCS

1 of 12 External Photos Model Number: P12S Regulatory Type: P12S001 FCC ID: E2K-P12S 2 of 12 EUT Photo 1 ) EUT Photo 2 ) 3 of 12 EUT Photo 3 ) EUT Photo 4 ) 4 of 12 EUT Photo 5 ) EUT Photo 6 ) 5 of 12 EUT Photo 7 ) EUT Photo 8 ) 6 of 12 EUT Photo 9 ) EUT Photo 10 ) 7 of 12 EUT Photo 11 ) EUT Photo 12 ) 8 of 12 EUT Photo 13 ) EUT Photo 14 ) 9 of 12 EUT Photo 15 ) EUT Photo 16 ) 10 of 12 EUT Photo 17 ) EUT Photo 18 ) 11 of 12 EUT Photo 19 ) EUT Photo 20 ) 12 of 12 EUT Photo 21 ) EUT Photo 22 )

ming_lin 10/26-10” PAL70-0FN LABEL 100% A4 00 00 SIZE 40 NOTE: 1. MATERIAL: WHITE POLYESTER FILM, T:0.05mm 2. COLOR: BACKGROUND: BLACK GE 701 CHARACTER: PMS431C 3. THICKNESS: T:0.075mm (INCLUDE SINGLE STICK) 4. MATERIAL NO.: XXXXXXXXXXX 5. SIZE: L40XW30MM, TOLERANCE: ±0.1MM 6. ADHESIVE: ACRYLIC ADHESIVE 7. USE WATER DISSOVING INK, INK CONTAINS HEAVY METAL IS PROHIBITED. 8. PIECE BY PIECE R0.5X3 C4(+0.1,-0) 30 2010 / 11 / 26 N889 Z233 E2K-PP12S001(B) P12S MOC: XX-XXXXX SUBTEL: 1453/DFRS00245/X-XX TRC/SS/2010/XX Complies with IDA standards DA XXXXXX 14875/POSTEL/2010 XXXX FCC ID: E2K-P12S: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Type Accepted No: ESD-XXXXXXXX NTC CCXXXXXXXXXXX DPN: XXXXX A00 IC: 1514B-P12S RFID Regulatory LABEL ming_lin 11/03-10” PAL70-0FN RATING LABEL RATING NP 0FN NBK WW E6320 4.62A RNGGR 100% A4 00 00 SIZE NOTE: 1. MATERIAL: WHITE POLYESTER FILM, T:0.05mm 2. COLOR: BACKGROUND: BLACK GE 701 CHARACTER: PMS431C 3. THICKNESS: 0.075MM (INCLUDE ADHESIVE) 4. MATERIAL NO.: EJ0FN000400 5. SIZE: L95XW10MM, TOLERANCE: +0.1/-0.2MM 6. ADHESIVE: ACRYLIC ADHESIVE 7. USE WATER DISSOVING INK, INK CONTAINS HEAVY METAL IS PROHIBITED. 8. PIECE BY PIECE 10 2010 / 12 / 03 95 R 0.5 x 4 7.838 5.593 筆記型電腦 www.dell.com Reg Model/型號: P12S Input/輸入/Daya: 19.5V 4.62A Reg Type No: P12S001 DPN:RNGGR A00CM-2 Dell Inc. N889 E2K-P12S001(B) DELL IC Class: B ICES-003 4.9 4.9

WLANlabel Artwork 40x30mm BT-label Artwork 40x30mm CTSClabel RFID Label Artwork 40x30mm WWANlabel Artwork 40x30mm Macallan_13_Base Door_Inside_Label_Proposal Macallan_13_Base Door_Inside_Label_Proposal ( Base Door ) 00 Keith_Ho Robert_Pai Rev. B.RD Phase 1:1mmUnit.Drawing No. Title THISSHEETOFENGINEERINGDRAWINGISTHEPROPRIETARYPROPERTYOFCOMPALELECTRONICS,INC. ANDCONTAINSCONFIDENTIALANDTRADESECRETINFORMATION.THISSHEETMAYNOTBETRANSFERRED FROMTHECUSTODYOFTHECOMPETENTDIVISIONOFR&DDEPARTMENTEXCEPTASAUTHORIZEDBY COMPALELECTRONICS,INC.NEITHERTHISSHEETNORTHEINFORMATIONITCONTAINSMAYBEUSEDBY ORDISCLOSEDTOANYTHIRDPARTYWITHOUTPRIORWRITTENCONSENTOFCOMPALELECTRONICS,INC. INDUSTRIAL DESIGNCENTER 2011/03/25 2010/10/13 Security classification Macallan_Base Door_Inside_Label Expiration Data Engineer Designer Approved Scale Date Sheet1 of 1 Regulatory Label 1 (only for Macallan 13) 95mm x 10mm Regulatory Label 2 (only for Macallan 13) 50mm x 10mm Microsoft COA Label 70mm x 23mm 00 Keith_Ho Robert_Pai Rev. B.RD Phase 1:1 1 of 1 mmUnit.Drawing No. Title THISSHEETOFENGINEERINGDRAWINGISTHEPROPRIETARYPROPERTYOFCOMPALELECTRONICS,INC. ANDCONTAINSCONFIDENTIALANDTRADESECRETINFORMATION.THISSHEETMAYNOTBETRANSFERRED FROMTHECUSTODYOFTHECOMPETENTDIVISIONOFR&DDEPARTMENTEXCEPTASAUTHORIZEDBY COMPALELECTRONICS,INC.NEITHERTHISSHEETNORTHEINFORMATIONITCONTAINSMAYBEUSEDBY ORDISCLOSEDTOANYTHIRDPARTYWITHOUTPRIORWRITTENCONSENTOFCOMPALELECTRONICS,INC. INDUSTRIAL DESIGNCENTER 2011/03/25 2010/10/13 Security classification Macallan_13_Base Lower_Label Macallan_13_Base Lower_Label Macallan_13_Base Lower_Label (Stick Labels on Logic Lower Core Side) Expiration Data Engineer Designer Approved Scale Date Sheet PPID Label 25.4mm X 9.5mm

1 of 29 Internal Photos Model Number: P12S Regulatory Type: P12S001 FCC ID: E2K-P12S 2 of 29 EUT Photo 1 ) EUT Photo 2 ) 3 of 29 EUT Photo 3 ) EUT Photo 4 ) 4 of 29 EUT Photo 5 ) EUT Photo 6 ) 5 of 29 EUT Photo 7 ) EUT Photo 8 ) 6 of 29 EUT Photo 9 ) EUT Photo 10 ) 7 of 29 EUT Photo 11 ) EUT Photo 12 ) 8 of 29 EUT Photo 13 ) EUT Photo 14 ) RFID Ant. 9 of 29 EUT Photo 15 ) EUT Photo 16 ) 10 of 29 EUT Photo 17 ) EUT Photo 18 ) 11 of 29 EUT Photo 19 ) EUT Photo 20 ) 12 of 29 EUT Photo 21 ) EUT Photo 22 ) 13 of 29 EUT Photo 23 ) EUT Photo 24 ) 14 of 29 EUT Photo 25 ) EUT Photo 26 ) 15 of 29 EUT Photo 27 ) EUT Photo 28 ) 16 of 29 EUT Photo 29 ) EUT Photo 30 ) 17 of 29 EUT Photo 31 ) EUT Photo 32 ) 18 of 29 EUT Photo 33 ) EUT Photo 34 ) 19 of 29 EUT Photo 35 ) EUT Photo 36 ) 20 of 29 EUT Photo 37 ) EUT Photo 38 ) 21 of 29 EUT Photo 39 ) EUT Photo 40 ) 22 of 29 EUT Photo 41 ) EUT Photo 42 ) 23 of 29 EUT Photo 43 ) EUT Photo 44 ) 24 of 29 EUT Photo 45 ) EUT Photo 46 ) 25 of 29 EUT Photo 47 ) EUT Photo 48 ) 26 of 29 EUT Photo 49 ) EUT Photo 50 ) 27 of 29 EUT Photo 51 ) EUT Photo 52 ) 28 of 29 EUT Photo 53 ) EUT Photo 54 ) 29 of 29 EUT Photo 55 )

FCC 47 CFR PART 15 SUBPART C Product Type ： Notebook Computer Applicant ： Dell Inc. Address One Dell Way, Round Rock City, Texas, United States Trade Name ： DELL Model Number ： P12S Regulatory Type ： P12S001 Test Specification ： FCC 47 CFR PART 15 SUBPART C: Oct., 2009 Canada RSS-210 ISSUE 7: Jun., 2007 Canada RSS-Gen ISSUE 2: Jun., 2007 ANSI C63.4-2003 Issue Date ： Nov. 03, 2010 Issue by A Test Lab Techno Corp. No. 140-1, Changan Street, Bade City, Taoyuan County 334, Taiwan R.O.C. Te l：+886-3-2710188 / Fax：+886-3-2710190 T aiwan Accreditation Foundation accreditation number: 1330 Note: This report shall not be reproduced except in full, without the written approval of A Test Lab Techno Corp. This document may be altered or revised by A Test Lab Techno Corp. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by TAF, or any government agencies. The test results in the report only apply to the tested sample. A Test Lab Techno Corp. Report Number: 1011FR11 1/26 Revision History Rev. Issue Date Revisions Revised By 00 Nov. 03, 2010 Initial Issue A Test Lab Techno Corp. Report Number: 1011FR11 2/26 Verification of Compliance Issued Date: 2010/11/03 Product Type : Notebook Computer Applicant : Dell Inc. Address : One Dell Way, Round Rock City, Texas, United States Trade Name : DELL Model Number : P12S Regulatory Type P12S001 FCC ID : E2K-P12S EUT Rated Voltage : DC 19.5 V, 3.34 A Test Voltage : 120 Vac / 60 Hz Applicable Standard : FCC 47 CFR PART 15 SUBPART C: Oct., 2009 Canada RSS-210 ISSUE 7: Jun., 2007 Canada RSS-Gen ISSUE 2: Jun., 2007 ANSI C63.4-2003 Test Result : Complied Performing Lab. : A Test Lab Techno Corp. No. 140-1, Changan Street, Bade City, Taoyuan County 334, Taiwan R.O.C. Te l：+886-3-2710188 / Fax：+886-3-2710190 T aiwan Accreditation Foundation accreditation number: 1330 http://www.atl-lab.com.tw/e-index.htm The above equipment was tested by A Test Lab Techno Corp. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4: 2003 and the energy emitted by the sample tested as described in this report is in compliance with the requirements of FCC Rules Part 15.207, 15.209, 15.225. The test results of this report relate only to the tested sample identified in this report. Approved By ： Reviewed By ： (Manager) (Miller Lee ) (Testing Engineer) (Gary Wu) A Test Lab Techno Corp. Report Number: 1011FR11 3/26 TABLE OF CONTENTS 1 General Information.......................................................................................................................... 5 2 EUT Description ............................................................................................................................... 6 3 Test Methodology ............................................................................................................................. 7 3.1. Mode of Operation .................................................................................................................. 7 3.2. EUT Exercise Software........................................................................................................... 7 3.3. Configuration of Test System Details......................................................................................8 3.4. Test Site Environment............................................................................................................. 8 4 Conducted Emission Measurement ................................................................................................. 9 4.1. Limit ........................................................................................................................................ 9 4.2. Test Instruments ..................................................................................................................... 9 4.3. Test Setup............................................................................................................................... 9 4.4. Test Procedure...................................................................................................................... 10 4.5. Test Result ............................................................................................................................ 11 5 Radiated Emissions Measurement ................................................................................................ 13 5.1. Limit ...................................................................................................................................... 13 5.2. Test Instruments ................................................................................................................... 14 5.3. Setup .................................................................................................................................... 15 5.4. Test Procedure...................................................................................................................... 16 5.5. Test Result ............................................................................................................................ 18 6 Frequency Stability Measurement.................................................................................................. 22 6.1. Limit ...................................................................................................................................... 22 6.2. Test Setup............................................................................................................................. 22 6.3. Test Instruments ................................................................................................................... 22 6.4. Test Procedure...................................................................................................................... 23 6.5. Test Result ................…
