Dell Latitude E6230/E6330 Setup and Features Information About Warnings WARNING: A WARNING indicates a potential for property damage, personal injury, or death. Latitude E6230 Front and Back View Figure 1. Front View 1. microphone 2. camera (optional) 3. camera status light (optional) 4. display 5. power button 6. HDMI connector 7. USB 3.0 connector 8. powered USB 3.0 connector Regulatory Model : P14T, P19S Regulatory Type : P14T001, P19S001 2011 - 9 9. wireless switch 10. ExpressCard slot 11. fingerprint reader 12. touchpad buttons (2) 13. touchpad 14. contactless smart-card reader 15. keyboard 16. volume control buttons (3) 17. device status lights Figure 2. Back View 1. network connector 2. device status lights 3. security cable slot 4. power connector 5. VGA connector 6. eSATA/USB 2.0 connector 7. audio connector 8. cooling vents 9. Secure Digital (SD) memory-card reader 10. smart card reader WARNING: Do not block, push objects into, or allow dust to accumulate in the air vents. Do not store your Dell computer in a low-airflow environment, such as a closed briefcase, while it is running. Restricting the airflow can damage the computer or cause a fire. The computer turns on the fan when the computer gets hot. Fan noise is normal and does not indicate a problem with the fan or the computer. 2 Latitude E6330 Front and Back View Figure 3. Front view 1. microphone 2. camera 3. camera status light 4. display 5. power button 6. eSATA/USB 2.0 connector 7. powered USB 3.0 connector 8. volume control buttons 9. wireless switch 10. optical drive 11. ExpressCard slot 12. fingerprint reader 13. contactless smart card reader 14. Secure Digital (SD) memory-card reader 15. touchpad buttons (2) 16. touchpad 17. trackstick buttons (3) 18. trackstick 19. keyboard 20. device status lights 3 Figure 4. Back view 1. security cable slot 2. network connector 3. mini HDMI connector 4. device status lights 5. USB 3.0 connector 6. power connector 7. VGA connector 8. audio connector 9. cooling vents 10. smart card slot WARNING: Do not block, push objects into, or allow dust to accumulate in the air vents. Do not store your Dell computer in a low-airflow environment, such as a closed briefcase, while it is running. Restricting the airflow can damage the computer or cause a fire. The computer turns on the fan when the computer gets hot. Fan noise is normal and does not indicate a problem with the fan or the computer. Quick Setup WARNING: Before you begin any of the procedures in this section, read the safety information that shipped with your computer. For additional best practices information, see www.dell.com/regulatory_compliance. 4 WARNING: The AC adapter works with electrical outlets worldwide. However, power connectors and power strips vary among countries. Using an incompatible cable or improperly connecting the cable to the power strip or electrical outlet may cause fire or equipment damage. CAUTION: When you disconnect the AC adapter cable from the computer, grasp the connector, not the cable itself, and pull firmly but gently to avoid damaging the cable. When you wrap the AC adapter cable, ensure that you follow the angle of the connector on the AC adapter to avoid damaging the cable. NOTE: Some devices may not be included if you did not order them. 1.Connect the AC adapter to the AC adapter connector on the computer and to the electrical outlet. Figure 5. AC Adapter 2.Connect the network cable (optional). Figure 6. Network Connector 3.Connect USB devices, such as a mouse or keyboard (optional). Figure 7. USB Connector 4.Open the computer display and press the power button to turn on the computer. 5 Figure 8. Power Button NOTE: It is recommended that you turn on and shut down your computer at least once before you install any cards or connect the computer to a docking device or other external device, such as a printer. Specifications NOTE: Offerings may vary by region. The following specifications are only those required by law to ship with your computer. For more information regarding the configuration of your computer, click Start → Help and Support and select the option to view information about your computer. Power AC Adapter65 W and 90 W NOTE: 65 W AC adapter is available only for computers with integrated video card. Input voltage100 VAC to 240 VAC Coin-cell battery3 V CR2032 lithium coin cell Physical Latitude E6230 Height22.40 mm to 24.70 mm (0.88 inch to 0.97 inch) Width309.00 mm (12.16 inches) Depth226.00 mm (8.89 inches) Weight1.70 kg (3.75 lbs) Latitude E6330 Height25.40 mm to 30.10 mm (1.00 inch to 1.19 inches) 6 Physical Width335.00 mm (13.19 inches) Depth223.00 mm (8.78 inches) Weight2.10 kg (4.63 lbs) Environmental Operating Temperature: Latitude E623010 °C to 35 °C (50 °F to 95 °F) Latitude E63300 °C to 35 °C (32 °F to 95 °F) Information para NOM (únicamente para México) Voltaje de alimentación 100 V CA – 240 V CA Frecuencia50 Hz – 60 Hz Consumo eléctrico1,50 A~2,50 A Voltaje de salida19,50 V de CC Intensidad de salida3,34 A/4,62 A Finding More Information and Resources See the safety and regulatory documents that shipped with your computer and the regulatory compliance website at www.dell.com/regulatory_compliance for more information on: •Safety best practices •Regulatory certification •Ergonomics See www.dell.com for additional information on: •Warranty •Terms and Conditions (U.S. only) •End User License Agreement Additional information on your product is available at support.dell.com/manuals. 7 Information in this publication is subject to change without notice. © 2011 Dell Inc. All rights reserved. Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden. Trademarks used in this text: Dell ™ , the DELL logo, Dell Precision ™ , Precision ON ™ , ExpressCharge ™ , Latitude ™ , Latitude ON ™ , OptiPlex ™ , Vostro ™ , and Wi-Fi Catcher ™ are trademarks of Dell Inc. Intel ® , Pentium ® , Xeon ® , Core ™ , Atom ™ , Centrino …

Text truncated - open the document above for the full version.

FCC Radiation Exposure Statement WARNING: The radiated output power of this device is below the FCC radio frequency exposure limits. Nevertheless, this device should be used in such a manner that the potential for human contact during normal operation is minimized. This device has been evaluated for and shown compliant with the FCC RF Exposure limits under mobile exposure conditions (antennas are greater than 20cm from a person’s body). This device has also been evaluated for and shown compliant with the FCC RF exposure limits under portable exposure conditions (antennas are within 20 cm of a person's body) when installed in certain specific configurations. Details of the authorized configurations can be found at https://fjallfoss.fcc.gov/oetcf/eas/reports/GenericSearch.cfm by entering the FCC ID number on the device. Interference Statement These devices comply with Part 15 of the FCC Rules. Operation of the devices is subject to the following two conditions: (1) The devices may not cause harmful interference, and (2) The devices must accept any interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy. If the equipment is not installed and used in accordance with the instructions, the equipment may cause harmful interference to radio communications. There is no guarantee, however, that such interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception (which can be determined by turning the equipment off and on), the user is encouraged to try to correct the interference by taking one or more of the following measures:  Relocate this device.  Increase the separation between the device and the receiver.  Connect the device into an outlet on a circuit different from that of other electronics.  Consult the dealer or an experienced radio technician for help. NOTE: Dell RFID devices must be installed and used in strict accordance with the manufacturer’s instructions as described in the user documentation that comes with the product. Any other installation or use will violate FCC Part 15 regulations. Modifications not expressly approved by Dell could void your authority to operate the equipment.

Date:December 6, 2011 Federal Communications Commission Authorization and Evaluation Division FCC ID: E2K-P14T Confidentiality Request To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until Increase from 180 days from the date of approval. External Photos Internal Photos Test Setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards Name/Title: Mrs. Fiona, Y Chen / Regulatory Compliance Assistance Manager Company Name: Dell Inc. Address: 11F, No.218, Sec.2, Tun Hua S. Road Taipei, Taiwan, R.O.C TEL: (886)2- 2736-6352 FAX: (886)2- 2736-9067 Email: [email protected]

Date: December 6, 2011 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 c.c. Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Jason Lin / Section Manager of Compliance Certification Services Inc. and hereafter referred to as CCS, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Mr. Stan Lin / Section Manager of Compliance Certification Services Inc. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing CCS as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Name/Title: Mrs. Fiona, Y Chen / Regulatory Compliance Assistance Manager Company Name: Dell Inc. Address: 11F, No.218, Sec.2, Tun Hua S. Road Taipei, Taiwan, R.O.C TEL: (886)2- 2736-6352 FAX: (886)2- 2736-9067 Email: [email protected] REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us. 3. Authorized signature must be in agreement with grantee code contact in FCC database.

Compliance Certification Services Inc. Report No.: T111116002 Date of Issue: November 30, 2011 A1 - 1 / 19 APPENDIX 1 - PHOTOGRAPHS OF EUT EXTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: T111116002 Date of Issue: November 30, 2011 A1 - 2 / 19 Compliance Certification Services Inc. Report No.: T111116002 Date of Issue: November 30, 2011 A1 - 3 / 19 Compliance Certification Services Inc. Report No.: T111116002 Date of Issue: November 30, 2011 A1 - 4 / 19 Compliance Certification Services Inc. Report No.: T111116002 Date of Issue: November 30, 2011 A1 - 5 / 19

P14T RFID label location P14T RFID Label Drawing.

System Label: Label location:

Compliance Certification Services Inc. Report No.: T111116002 Date of Issue: November 30, 2011 A1 - 6 / 19 INTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: T111116002 Date of Issue: November 30, 2011 A1 - 7 / 19 Compliance Certification Services Inc. Report No.: T111116002 Date of Issue: November 30, 2011 A1 - 8 / 19 Compliance Certification Services Inc. Report No.: T111116002 Date of Issue: November 30, 2011 A1 - 9 / 19 Compliance Certification Services Inc. Report No.: T111116002 Date of Issue: November 30, 2011 A1 - 10 / 19 Compliance Certification Services Inc. Report No.: T111116002 Date of Issue: November 30, 2011 A1 - 11 Compliance Certification Services Inc. Report No.: T111116002 Date of Issue: November 30, 2011 A1 - 12

Compliance Certification Services Inc. Report No.: T111116002 Date of Issue: November 30, 2011 A1 - 13 Antenna Location Compliance Certification Services Inc. Report No.: T111116002 Date of Issue: November 30, 2011 A1 - 14 Compliance Certification Services Inc. Report No.: T111116002 Date of Issue: November 30, 2011 A1 - 15 Antenna Compliance Certification Services Inc. Report No.: T111116002 Date of Issue: November 30, 2011 A1 - 16 Compliance Certification Services Inc. Report No.: T111116002 Date of Issue: November 30, 2011 A1 - 17 Compliance Certification Services Inc. Report No.: T111116002 Date of Issue: November 30, 2011 A1 - 18 Compliance Certification Services Inc. Report No.: T111116002 Date of Issue: November 30, 2011 A1 - 19

Compliance Certification Services Inc. FCC ID: E2K-P14T Report No.: T111116002-RP Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 / 29 FCC 47 CFR PART 15 SUBPART C TEST REPORT For Notebook Computer (with RFID radios) Model: P14T Trade Name: DELL Issued to Dell Inc. One Dell Way Round Rock Texas 78682 United States Issued by Compliance Certification Services Inc. No.11, Wu-Gong 6th Rd., Wugu Industrial Park, New Taipei City 248, Taiwan (R.O.C.) http://www.ccsrf.com [email protected] Issued Date: November 28, 2011 Compliance Certification Services Inc. FCC ID: E2K-P14T Report No.: T111116002-RP Page 2 Revision History Rev. Issue Date Revisions Effect Page Revised By 00 November 28, 2011 Initial Issue ALL Jessica Ho Compliance Certification Services Inc. FCC ID: E2K-P14T Report No.: T111116002-RP Page 3 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION............................................................................................. 4 2. EUT DESCRIPTION .................................................................................................................... 5 3. TEST METHODOLOGY ............................................................................................................. 6 3.1 EUT CONFIGURATION.............................................................................................................. 6 3.2 EUT EXERCISE......................................................................................................................... 6 3.3 GENERAL TEST PROCEDURES.................................................................................................. 6 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS .............................................. 7 3.5 DESCRIPTION OF TEST MODES................................................................................................. 8 4. INSTRUMENT CALIBRATION................................................................................................. 9 4.1 MEASURING INSTRUMENT CALIBRATION........................................................................... 9 4.2 MEASUREMENT EQUIPMENT USED .............................................................................. 9 4.3 MEASUREMENT UNCERTAINTY .................................................................................. 10 5. FACILITIES AND ACCREDITATIONS ................................................................................. 11 5.1 FACILITIES............................................................................................................................ 11 5.2 EQUIPMENT........................................................................................................................... 11 5.3 TABLE OF ACCREDITATIONS AND LISTINGS.......................................................................... 12 6. SETUP OF EQUIPMENT UNDER TEST ................................................................................ 13 6.1 SETUP CONFIGURATION OF EUT............................................................................................ 13 6.2 SUPPORT EQUIPMENT..................................................................................................... 13 7. FCC PART 15.225 REQUIREMENTS...................................................................................... 14 7.1 20 DB BANDWIDTH .......................................................................................................... 14 7.2 RADIATED EMISSIONS........................................................................................................... 16 7.3 F REQUENCY STABILITY........................................................................................................ 21 7.4 POWERLINE CONDUCTED EMISSIONS.................................................................................... 23 APPENDIX I PHOTOGRAPHS OF TEST SETUP ....................................................................... 26 APPENDIX 1 - PHOTOGRAPHS OF EUT Compliance Certification Services Inc. FCC ID: E2K-P14T Report No.: T111116002-RP Page 4 1. TEST RESULT CERTIFICATION Applicant: Dell Inc. One Dell Way Round Rock Texas 78682 United States Equipment Under Test: Notebook Computer (with RFID radios) Tr a d e N a m e : DELL Model: P14T Date of Test: November 17 ~ 21, 2011 APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4: 2003 and the energy emitted by the sample tested as described in this report is in compliance with the requirements of FCC Rules Part 15.225. The test results of this report relate only to the tested sample identified in this report. Approved by: Reviewed by: Jason Lin Gina Lo Section Manager Section Manager Compliance Certification Services Inc. Compliance Certification Services Inc. Compliance Certification Services Inc. FCC ID: E2K-P14T Report No.: T111116002-RP Page 5 2. EUT DESCRIPTION Product Notebook Computer (with RFID radios) Trade Name DELL Model Number P14T Model Difference N/A Received Date November 16, 2011 Power Supply 1. Power Adapter Dell Inc. Model: AA65NM121 I/P: 100-240V, 1.7A, 50-60Hz O/P: 19.5V, 3.34A 2. Rechargeable Li-ion Battery: DELL / 7FF1K Rating: 32Wh, 11.1V Frequency Range 13.56MHz Modulation Technique ASK Number of Channels 1 Channel Antenna Specification Gain: 0 dBi Antenna Designation Loop Antenna Remark: 1. The sample selected for test was engineering sample that approximated to production product and was provided by manufacturer. 2. This s…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. FCC ID: E2K-P14T Report No.: T111116002-RP Page 26 APPENDIX I PHOTOGRAPHS OF TEST SETUP Conducted Emission Set Up Photo Compliance Certification Services Inc. FCC ID: E2K-P14T Report No.: T111116002-RP Page 27 Radiated Emission Set up Photos Compliance Certification Services Inc. FCC ID: E2K-P14T Report No.: T111116002-RP Page 28 Compliance Certification Services Inc. FCC ID: E2K-P14T Report No.: T111116002-RP Page 29 Powerline Conducted Emissions Setup Photos
