E2KCS1A13Thin Client Terminal

Cloud Connect Setup and Features Information Model CSx, Product ID: CS1A13 To find the latest Quick-Start Guide, go to http://www.dellwyse.com/manuals and click on the name of your product. Important: The license at http://www.dellwyse.com/license as of the purchase date is the controlling licensing agreement. By copying, using, or installing the software or the product, you agree to be bound by those terms. Setting Up Your Cloud Connect Be sure you have read all safety guidelines before setting up and operating this product. Refer to the figures and proceed as follows: 1. Connecting Your Cloud Connect to the Monitor HDMI Connection — Plug your Cloud Connect into the HDMI port on the monitor. (If your monitor/TV has multiple video ports, verify that you select the correct video port to display the information from the Cloud Connect.) Connect the Micro end of the provided USB cable to the Cloud Connect’s Micro USB On- The-Go (OTG) port, and connect the standard end of the USB cable to a powered USB port or use a standard USB power adapter for smartphones. The Power status indicator will light blue when connected. As the Cloud Connect starts up, the Activity status indicator will light amber. Note: If you cannot plug in Cloud Connect due to mechanical interference, use the HMI extension cable. MHL Connection — Plug your Cloud Connect into the MHL port on the monitor; no external adapter power is required. The Power status indicator will light blue when connected. As the Cloud Connect starts up, the Activity status indicator will light amber. 2. Pairing Your Bluetooth Keyboard and Bluetooth Mouse Press and hold the Bluetooth pairing button, and then follow the on-screen steps to complete the Bluetooth setup for your Bluetooth keyboard and mouse. 3. Turning Off Your Cloud Connect It is strongly recommend to use the on-screen button to power off your Cloud Connect. For more information, locate your product and download the Fact Sheet using the Cloud clients tab at: http://www.dellwyse.com/products Safety Guidelines Improper connection or use of this product could result in component failure or undesired interference. Read the following guidelines before setting up and operating the device. Setup •Do not force a connector into its socket. If any undue resistance is encountered, ensure that the connector is correctly oriented to the receptacle. •The main unit is not user serviceable; opening or accessing the case will void your warranty. Care •To clean your device, first disconnect it from all connections, and then use a soft cloth dampened with water for cleaning. Do not use liquid or aerosol cleaners. Power Sources •The Cloud Connect product requirements are a minimum of 5.0 V, 0.5 mA. If a USB port is not available on the monitor, you can use a standard USB 2.0 power adapter. •Surge protectors for electrical devices are recommended in areas of lightning. However, when lightning is occurring, your equipment should be properly shut down and unplugged from AC power until the storm has passed. Views * Not all USB devices are supported; check with Dell Wyse or your Dell Wyse representative to find out if a particular device is supported on your product. Need More Information? Dell Wyse Reference Guides - Related documentation is available at: http://www.dellwyse.com/manuals Dell Wyse-Approved Accessories - Information about approved accessory options are available at: http://www.dellwyse.com/products/accessories Dell Wyse Service and Support - Latest software images are available at: http://www.dellwyse.com/downloads Dell Wyse and the Environment - Information about Wyse compliance with RoHS and with the Waste Electrical and Electronic Equipment (WEEE) is available at: http://www.dellwyse.com/green Dell Wyse and E-Recycling - Information about recycling unwanted Wyse product available within the United States is available at: http://www.dellwyse.com/erecycling Dell Wyse Warranty Registration* - Register your product at: http://www.dellwyse.com/registration * The standard warranty is one year from the date of purchase. 1Bluetooth pairing button7Power/Activity status indicators 2Micro SD slot8Micro USB OTG* port/power input for 3HDMI/MHL connectorHDMI connection 4Cap 9Micro USB to Standard USB 2.0* cable 5Mini USB 2.0* host port 10HDMI extension cable 6Wrist strap slot Wyse Technology LLC 5455 Great America Parkway Santa Clara, CA 95054 USA ©2013 Wyse Technology LLC. All rights reserved. This product and/or associated software are protected by copyright international treaties, and various patents, including the following U.S. patents: 6,836,885 and 5,918,039. 883958-01L Rev. A August 2013 Printed in USA Printed on 50% post-consumer recycled paper Federal Communications Commission Notice This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1.This device may not cause harmful interference, and 2.This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee this equipment does not cause harmful interference to radio or TV reception. This can be determined by turning the equipment on and off. The user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experie…

Text truncated - open the document above for the full version.

Date 2013-08-15 BABT TCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Confidentiality Request FCC ID: E2KCS1A13 Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, Dell Inc. hereby requests permanent confidential treatment of information accompanying this application as outlined below: Schematics Block Diagrams Operational Description Tune-Up Procedure Antenna Specification The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Company Officer: Benton Ng Telephone Number: 1-408-473-1938 Email: [email protected]

Dell Inc. Richard Worley, NCE MS: PS4-30 EMC, Global Regulations and Standards One Dell Way Telephone 512.728.1081 Round Rock, Texas 78682 Telefax 512.283.9268 www.dell.com e-mail [email protected] Worldwide Regulatory Compliance Engineering & Environmental Affairs Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 March 27, 2013 FCC authorization letter for Dell Regulatory employees To whom it may concern, I, the undersigned, as the authorized signatory for the Dell Inc. grantee code E2K, hereby authorize the following EMC & Wireless Regulatory Engineers of Dell Inc., to act on my behalf as our agent in all manners relating to processes required according to FCC rules for equipment authorization: Thanh Nguyen Chase Berry Fiona Y Chen Hank Liu Don Bobo Steve L Williams Rick Linford James Carrillo Benton S Ng Alden Neilson Angelica Chang This authorization shall be sent along with application when filing with the FCC Certification Division and is valid until further written notice from the applicant. If you have any questions or need additional information, please feel free to contact me at 512-728-1081 or 512-431-1084. Sincerely, Richard Worley Dell Inc. FRN: 0008359580

Dell Inc. . One Dell Way, Round Rock, Texas USA 78682 Date: Aug. 15, 2013 Subject: DoC declaration To Whom it may concern, We, as the grantee of this project FCC ID: E2KCS1A13, would like to declare that the composite portion categorized as computer peripheral has been authorized under the Declaration of Conformity procedures. Brand Name and Model Name of the specified radio equipment: Dell / CSxyyyy(x and y= 0-9, A-Z, a-z or blank), CSx FCC ID: E2KCS1A13 Product Name: Thin Client Terminal Regards, Signature___________________________________ Name/Title: Benton Ng / Regulatory Engineer Company Name: Dell Inc.

Date:2013/8/15 BABT TCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Dear Sir or Madam, We, Dell Inc., address: One Dell Way, Round Rock, Texas USA 78682, hereby authorize A Test Lab Techno Corp., address: No. 140-1, Changan Street, Bade City, Taoyuan County 334, Taiwan R.O.C., phone: +886-3-2710188 to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. This authorization expires on 2014.02.08. Sincerely, ___________________________________ Benton Ng. / Regulatory Engineer Tel: 1-408-473-1938 Email: [email protected]

1 of 7 External Photos Model Number: CS1A13 FCC ID: E2KCS1A13 2 of 7 EUT Photo 1 ) EUT Photo 2 ) 3 of 7 EUT Photo 3 ) EUT Photo 4 ) 4 of 7 EUT Photo 5 ) EUT Photo 6 ) 5 of 7 EUT Photo 7 ) EUT Photo 8 ) 6 of 7 EUT Photo 9 ) EUT Photo 10 ) 7 of 7 EUT Photo 11 )

Ink, Pantone 428 C (TBD) Option A.Option B. FCC ID: E2KCS1A13 Artwork (For America) Artwork (For EURO) Artwork (For Australia) 顏色(Color): Pantone 428 M 表面處理(Finish): 平光(Matte) 顏色(Color): Pantone 424 M 表面處理(Finish): 平光(Matte) 雷射雕刻(Laser Engraving) 雷射雕刻(Laser Engraving) W/ Top Case 顏色(Color): Pantone 428 M 表面處理(Finish): 平光(Matte) 顏色(Color): Pantone 424 M 表面處理(Finish): 平光(Matte) 雷射雕刻(Laser Engraving) 雷射雕刻(Laser Engraving) W/ Top CaseW/O Top Case 顏色(Color): Pantone 428 M 表面處理(Finish): 平光(Matte) 顏色(Color): Pantone 424 M 表面處理(Finish): 平光(Matte) 雷射雕刻(Laser Engraving) 雷射雕刻(Laser Engraving) W/O Top Case W/ Top Case

1 of 4 Internal Photos Model Number: CS1A13 FCC ID: E2KCS1A13 2 of 4 EUT Photo 1 ) EUT Photo 2 ) 3 of 4 EUT Photo 3 ) EUT Photo 4 ) 4 of 4 EUT Photo 5 ) EUT Photo 6 )

A Test Lab Techno Corp. Changan Lab：No. 140 -1, Changan Street, Bade City, Taoyuan County, Taiwan R.O.C. Te l：886-3-271-0188 / Fax：886-3-271-0190 SAR EVALUATION REPORT Test Report No. ： 1308FS12-01 Applicant ： Dell Inc. Product Type ： Thin Client Terminal Trade Name ： Dell Model Number ： CSxyyyy(x and y= 0-9, A-Z, a-z or blank), CSx Date of Received ： Jul. 09, 2013 Test Period ： Jul. 31 ~ Sep. 25, 2013 Date of Issued ： Sep. 30, 2013 Test Environment ： Ambient Temperature： 22 ± 2 ° C Relative Humidity：40 - 70 % Standard ： ANSI/IEEE C95.1-1999 IEEE Std. 1528-2003 IEEE Std. 1528a-2005 47 CFR Part §2.1093; KDB 865664 D01 SAR Measurement 100 MHz to 6 GHz v01r01 KDB 865664 D02 RF Exposure Reporting v01r01 Max. Reported SAR ： 0.960 W/kg Body SAR Test Lab Location ： Chang-an Lab Report Number: 1308FS12-01Page 1 of 156 ©2013 A Test Lab Techno Corp. 1. The test operations have to be performed with cautious behavior, the test results are as attached. 2. The test results are under chamber environment of A Test Lab Techno Corp. A Test Lab Techno Corp. does not assume responsibility for any conclusions and generalizations drawn from the test results with regard to other specimens or samples. 3. The measurement report has to be written approval of A Test Lab Techno Corp. It may only be reproduced or published in full. This report shall not be reproduced except in full, without the written approval of A Test Lab Techno Corp. The test results in the report only apply to the tested sample. Approved By ： Tested By ： (Bill Hu) (Sky Chou) Contents 1. Description of Equipment under Test (EUT) .................................................................................................. 3 2. Introduction..................................................................................................................................................... 4 2.1 SAR Definition ..................................................................................................................................... 4 3. SAR Measurement Setup .............................................................................................................................. 5 3.1 DASY E-Field Probe System............................................................................................................... 6 3.2 Data Acquisition Electronic (DAE) System .......................................................................................... 9 3.3 Robot ................................................................................................................................................... 9 3.4 Measurement Server........................................................................................................................... 9 3.5 Device Holder .................................................................................................................................... 10 3.6 Phantom - SAM v4.0 ......................................................................................................................... 10 3.7 Oval Flat Phantom - ELI 4.0 .............................................................................................................. 11 3.8 Data Storage and Evaluation............................................................................................................. 11 4. Tissue Simulating Liquids............................................................................................................................. 14 4.1 Ingredients......................................................................................................................................... 15 4.2 Recipes.............................................................................................................................................. 15 4.3 Liquid Depth ...................................................................................................................................... 16 5. SAR Testing with RF Transmitters ............................................................................................................... 17 5.1 Power reduction ................................................................................................................................ 17 5.2 SAR Testing with 802.11 Transmitters............................................................................................... 17 5.3 General Device Setup ....................................................................................................................... 17 5.4 Conducted Power .............................................................................................................................. 19 5.5 Antenna location................................................................................................................................ 24 5.6 Stand-alone SAR Evaluate................................................................................................................ 25 5.7 Simultaneous Transmitting Evaluate ................................................................................................. 25 5.8 SAR test reduction according to KDB ............................................................................................... 26 6. System Verification and Validation ............................................................................................................... 27 6.1 Symmetric Dipoles for System Verification ....................................................................................... 27 6.2 Liquid Parameters ............................................................................................................................. 28 6.3 Verification Summary ........................................................................................................................ 31 6.4 Validation Summary ...........................................................................................…

Text truncated - open the document above for the full version.

SAR Test Setup Photographs EUT Side Definition Item Side 1 Side 1 2 Side 2 3 Side 3 4 Side 4 5 Side 5 6 Side 6 n o p q rs Report Number: 1308FS12-01Page 1 of 5 ©2013 A Test Lab Techno Corp. Draft Report Phantom Position： Flat EUT side：Side 1 Spacing to phantom： 5 mm Accessory：N/A EUT Side 1 Report Number: 1308FS12-01Page 2 of 5 ©2013 A Test Lab Techno Corp. Draft Report Phantom Position： Flat EUT side：Side 2 Spacing to phantom： 5 mm Accessory：N/A EUT Side 2 Report Number: 1308FS12-01Page 3 of 5 ©2013 A Test Lab Techno Corp. Draft Report Phantom Position： Flat EUT side：Side 3 Spacing to phantom： 5 mm Accessory：N/A EUT Side 3 Report Number: 1308FS12-01Page 4 of 5 ©2013 A Test Lab Techno Corp. Draft Report Phantom Position： Flat EUT side：Side 4 Spacing to phantom： 5 mm Accessory：N/A EUT Side 4 Report Number: 1308FS12-01Page 5 of 5 ©2013 A Test Lab Techno Corp. Draft Report

FCC 47 CFR PART 15 SUBPART C Product Type ： Thin Client Terminal Applicant ： Dell Inc. Address ： One Dell Way, Round Rock, Texas USA 78682 Trade Name ： Dell Model Numbers ： CSxyyyy(x and y= 0-9, A-Z, a-z or blank), CSx Test Specification ： FCC 47 CFR PART 15 SUBPART C: Oct., 2012 ANSI C63.4-2009 Receive Date ： Jul. 09, 2013 Test Period ： Jul. 17 ~ Jul. 24, 2013; Sep. 10, 2013 Issue Date ： Oct. 01, 2013 Issue by A Test Lab Techno Corp. No. 140-1, Changan Street, Bade City, Taoyuan County 334, Taiwan R.O.C. Te l：+886-3-2710188 / Fax：+886-3-2710190 T aiwan Accreditation Foundation accreditation number: 1330 Note: This report shall not be reproduced except in full, without the written approval of A Test Lab Techno Corp. This document may be altered or revised by A Test Lab Techno Corp. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by TAF, or any government agencies. The test results in the report only apply to the tested sample. A Test Lab Techno Corp. Report Number: 1307FR16-02 1 of 87 Revision History Rev. Issue Date Revisions Revised By 00 Aug. 02, 2013 Initial Issue 01 Aug. 12, 2013 Change Antenna type Gili Huang 02 Oct. 01, 2013 Re-test middle and high channel. Joyce Liao A Test Lab Techno Corp. Report Number: 1307FR16-02 2 of 87 Verification of Compliance Issued Date: 10/01/2013 Product Type : Thin Client Terminal Applicant : Dell Inc. Address : One Dell Way, Round Rock, Texas USA 78682 Trade Name : Dell Model Number : CSxyyyy(x and y= 0-9, A-Z, a-z or blank), CSx FCC ID : E2KCS1A13 EUT Rated Voltage : DC 5.0V, 0.5A Test Voltage : 120 Vac / 60 Hz Applicable Standard : FCC 47 CFR PART 15 SUBPART C: Oct., 2012 ANSI C63.4-2009 Test Result : Complied Performing Lab. : A Test Lab Techno Corp. No. 140-1, Changan Street, Bade City, Taoyuan County 334, Taiwan R.O.C. Te l：+886-3-2710188 / Fax：+886-3-2710190 T aiwan Accreditation Foundation accreditation number: 1330 http://www.atl-lab.com.tw/e-index.htm The above equipment was tested by A Test Lab Techno Corp. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4: 2009 and the energy emitted by the sample tested as described in this report is in compliance with the requirements of FCC Rules Part 15.207, 15.209, 15.247 . The test results of this report relate only to the tested sample identified in this report. Approved By ： Reviewed By ： (Manager) (Cran Yang) (Testing Engineer) (Fly Lu) A Test Lab Techno Corp. Report Number: 1307FR16-02 3 of 87 TABLE OF CONTENTS 1 General Information .........................................................................................................6 2 EUT Description................................................................................................................7 3 Test Methodology.............................................................................................................8 3.1. Mode of Operation......................................................................................................8 3.2. EUT Exercise Software ..............................................................................................9 3.3. Configuration of Test System Details..........................................................................9 3.4. Test Site Environment.................................................................................................9 4 Conducted Emission Measurement..............................................................................10 4.1. Limit..........................................................................................................................10 4.2. Test Instruments .......................................................................................................10 4.3. Test Setup ................................................................................................................10 4.4. Test Procedure ......................................................................................................... 11 4.5. Test Result................................................................................................................11 5 Radiated Emission Measurement .................................................................................12 5.1. Limit..........................................................................................................................12 5.2. Test Instruments .......................................................................................................12 5.3. Setup ........................................................................................................................13 5.4. Test Procedure .........................................................................................................14 5.5. Test Result................................................................................................................16 6 Maximum Conducted Output Power Measurement.....................................................27 6.1. Limit..........................................................................................................................27 6.2. Test Setup ................................................................................................................27 6.3. Test Instruments .......................................................................................................27 6.4. Test Procedure .........................................................................................................27 6.5. Test Result................................................................................................................28 7 6dB RF Bandwidth & 99 % Occupied Bandwidth Measurement ................................32 7.1. Limit................................................................................…
