E2X-ESL-BP102Gen3 Gateway

1 Samsung Electro-Mechanics ESEL User Manual (SLG-BP102) 2 Document Summary Author: WS3 G, CDS Division, Samsung Electro-Mechanics Distributor: Samsung Electro-Mechanics Tel.: 031-300-4913 www.sem.samsung.com Ed itor Information - Tel.: +82-31-300-4913 - Address: 314, Maetan3-Dong, Yeongtong-Gu, Suwon, Gyunggi-Do, Korea 443-743 Copyright Notification Sams ung Electro-Mechanics Co., Ltd. Copyright @2009 SEMCO INC. All trademarks used are properties of their respective owners. The content of this document is subject to change without prior notice. The content of this document is intellectual property of Samsung Electro-Mechanics. This document may not be reproduced or published without prior consent from Samsung Electro-Mechanics. No part may be reproduced except as authorized by written permission. The copyright and the foregoing restriction extend to reproduction in all media. © 2008, SEMCO INC. All rights reserved. 3 Revision History Rev. Date Remark 1.0 22.04.2014 First Edition. 4 Contents 1. P recautions .............................................................................................................................. 5 2. Overview ................................................................................................................................... 6 3. Product Specifications ...................................................................................................... 7 3.1 General Specifications ..................................................................... 7 3.1.1 Gateway 3.2 RF Specifications .............................................................................. 8 3.2.1 Gateway 4. Product Description ........................................................................................................... 9 4.1 Extei or ............................................................................................... 9 4.1.1 Gateway 5. Product Installation .......................................................................................................... 10 5.1 Gateway ....................................................................................... 10 5 1. Precautions “This RF device operates on the 2.4GHz frequency band and can produce radio interference. The device, therefore, may not be used for applications where safety of human lives is concerned.” 1) Usage Environment Take extra caution when using this RF device in the vicinity of other electronic devices and appliances. Most electronic devices and appliances use electromagnetic waves. Electromagnetic waves emitted by this RF device can affect other electronic devices and appliances. If using the device in an explosion hazard area, follow all safety regulations, instructions, and signals. 2) Storage and Use Moisture and liquids can damage internal parts and circuit boards if allowed to enter into the device itself. Do not place or store the product on a sloped surface. The product may slide and fall off the surface and damage. Use the product in temperatures ranging from 0°C to +60°C. Parts and circuits may damage if used or stored under temperature extremes. Avoid areas with strong magnetism or subject to magnetism. Contact between the device and a magnetic object can lead to malfunctions. Do not place the product near heat-producing kitchen appliances like a stove or a microwave or in the vicinity of highly pressurized containers. External impact to the product, such as from being dropped, can damage the screen. Twisting and bending the product can damage the exterior casing and the internal components. 6 2. Overview Gateway make up a system the electronically displays price and other product information that are traditionally shown printed or written on paper in places like the supermarket. Here, S-Label Gateway receives product price updates from the server and uploads the new data to the applicable electronic tags (S-Label Tag), changing the displayed price information. <Diagram 1> S-Label System 7 3. Product Specifications 3.1 General Specifications 3.1.1. Gat eway General Communication Ethernet (10/100Mbps) Zigbee RF(based on IEEE 802.15.4) Dimension (W*H*D) 215 * 215 * 44 (mm) Weight (g) 1,385g Enclosure Plastic (ABS) Power DC Adaptor(5V,2A) or PoE (Power over Ethernet(IEEE802.3af)) Caution : DC Power Supply or PoE(Power over Ethernet) using one 8 3. 2 RF Specifications 3.2.1 Gateway Category Specification Note Antenna Type Internal Antenna 2ea Transmit Frequency 2405MHz ~ 2480MHz Receive Frequency 2405MHz ~ 2480MHz Antenna gain SAC0 : 0.99dBi SAC3 : 1.57dBi Modulation O-QPSK Channels 16ch Power █ DC Adapter (5V, 2A) █ PoE (Power over Ethernet (IEEE802.3af)) 1) Input Voltage Range :36~57VDC 2) Nominal Input Voltage : 48VDC 2) Output Voltage : 5VDC±3% 9 4. Product Description 4-1 Exterior 4.1.1 Gateway < top><bottom > Status LED 10 5. Product Installation 5-1 Gateway - Components (includes installation accessories – adapter, bracket, screws) Installation a) Drill 4 holes on the wall or ceiling to align with mounting Plates (1). Refer to the attached diagram. b) Drill two Ф10 holes on the wall or ceiling for SMPS Adapter and Ethernet Cable.(2) Refer to the attached diagram. c) Align the mounting bracket#2 holes to the holes drilled through the wall or ceiling from step a) and temporarily secure the bracket in place. (3) d) Use Screws to completely secure the mounting bracket and Wall or Ceiling. (4) e) Sliding gateway to mounting bracket#2 (5) Gypsum board Plate Screw (4ea) Bracket#2 1)Mounting Plate 2)Drilling hole for ADT,LAN cable 3)Attach Bracket#2 4)Screw 5)Sliding Gateway 11 f) SMPS Adapter and Ethernet Cable through the two Ф10 holes made from step b). Operati on Check < Connect E thernet Cable with PoE or Connect SMPS adapter and Ethernet cable first . > 1) Power : Always ON after connecting to Ethernet Cable with PoE or SMPS adapter 2) Ethernet : ON if Ethernet link is connected - Check every 1sec whether Ethernet link is connected. 3) Data : ON when d…

Text truncated - open the document above for the full version.

314 Maetan-3 Dong Pal Dal-Ku Kyungki-Do, Suwon-City, Korea, 442-743 Date: October 20, 2014 Letter of Authorization We, the undersigned, hereby authorize Harvey Sung of DT&C Co., Ltd. to act on our behalf in all manners relating to application for equipment authorization for FCCID: E2X-ESL-BP102 including signing of all documents relating to these matters. Any and all acts carried out by Harvey Sung of DT&C Co., Ltd. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from Samsung Electro Mechanics “I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a).” Sincerely, Jin Hwan, Lim Assistant Manager

DT&C Co., Ltd. 42, Yurim-ro, 154beon-gil, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea 449-935 Date: October 20, 2014 UL Verification Services Inc. 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Ms. Claire Hoque/Application Examiner of Compliance Engineering Services, Inc., d.b.a. Compliance Certification Services and hereafter referred to as CCS, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Ms. Claire Hoque of CCS on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing CCS as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards;

Samsung Electro Mechanics 314, Maethan-3 Dong, Paldal-Ku, Kyungki-Do, Suwon-City, Korea, 442-743 Date: October 20, 2014 UL Verification Services Inc. 47173 Benicia Street Fremont, CA 94538, USA RE: Request of Confidentiality for FCCID: E2X-ESL-BP102 To Whom It may Concern: Pursuant to Sections 0.457 and 0.459 of the Commission`s Rules(CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, Samsung Electro Mechanics hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give Samsung Electro Mechanics temporary confidentiality of commercially sensitive information prior to product release. The requested permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT & SHORT-TERM CONFIDENTIAL LIST Exhibit Description PERMANENT 1 Block Diagram 2 Schematics 3 Part Lists 4 Operation Description SHORT-TERM 5 Internal Photos 6 External Photos 7 Test-Setup Photos 8 User Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be public before the date of the Grant for this application. Sincerely, Jin Hwan, Lim Manager

FCCID: E2X-ESL-BP102 Copyright Ⓒ 2014, DT&C Co., Ltd. View 1 FCCID: E2X-ESL-BP102 Copyright Ⓒ 2014, DT&C Co., Ltd. View 2 FCCID: E2X-ESL-BP102 Copyright Ⓒ 2014, DT&C Co., Ltd. View 3 FCCID: E2X-ESL-BP102 Copyright Ⓒ 2014, DT&C Co., Ltd. View 4

FCC ID: E2X-ESL-BP102 Copyright Ⓒ 2014, DT&C Co., Ltd. FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase - The FCC label shown is representative of the label that will appear on the radio when in production. Other information may also be included on this user manual.

FCCID: E2X-ESL-BP102 Copyright Ⓒ 2014, DT&C Co., Ltd. Page1 / 5 View 1 FCCID: E2X-ESL-BP102 Copyright Ⓒ 2014, DT&C Co., Ltd. Page2 / 5 View 2 FCCID: E2X-ESL-BP102 Copyright Ⓒ 2014, DT&C Co., Ltd. Page3 / 5 View 3 FCCID: E2X-ESL-BP102 Copyright Ⓒ 2014, DT&C Co., Ltd. Page4 / 5 View 4 SAC 0(Transceiver 1) SAC 0(Transceiver 1) FCCID: E2X-ESL-BP102 Copyright Ⓒ 2014, DT&C Co., Ltd. Page5 / 5 View 5 SAC 3(Transceiver 2) SAC 3(Transceiver 2)

Portable device Movile device Simultaneous Transmitting MHzmm dBi =( ) [Th h ld t50 (t t ti dit 50 )X10] W 10.00 dBm Note. dBm November 18, 2014 FCC ID : E2X-ESL-BP102 KDB 447498 D01 clasue 4.3.1 Step 2- 2) SAR test exclusion thres holds for 1500MHz to 6GHz at test separationn distances > 50 mm - Device category = Standalone SAR test exclusion considerations 200 - Max. power with turn-up tolerance = 10.0 2480 - Min. test separ ation distance = mW 10.00 - Max. transmitting frequency = Single Transmitting This device does not transmit simultaneously. Max. Typical Power = - Transmitting mode = - Max. Antenna Gain = 1.57 = [ 0.08 + ( 200mm - 50 mm X 10 ) ] = 1500.1 Note. The calculation result was rounded to one decimal place f or comparison. Maximum power density Numeric power gain of the antenna Maximum power with turn-up toler ance Distance from transmitting antenna 2 G = R = = ) Copyright ⓒ 2014 DT&C Co Ltd 1.000000 ㎽/㎝ G → SAR evaluation for general population exposure conditions by measurement or numerical simulation is not required. The limit for maximum permissible exposure = 0.002856 2 ㎽/㎝ /( 4R Conclusion: The exposure condition of this device is compliant with FCC rul es. S = P = Maximum Permissible Exposure(MPE) evaluation for mobile device [ Th res h o ld a t 50 mm + ( t es t separa ti on di s t ance - 50 mm ) X 10 ] m W 2 S = 2 P , ㎽/㎝ π Copyright ⓒ 2014 , DT&C Co ., Ltd .

FCCID: E2X-ESL-BP102 DEMC1405-01910 Report No.: DRTFCC1411-1421(1) TRF-RF226(00)140710 Page 2 / 48 Copyright ○ C 2014, DT&C Co., Ltd. Test Report Version Test Report No. Date Description DRTFCC1411-1421 Nov. 11, 2014 Initial issue DRTFCC1411-1421(1) Nov. 18, 2014 Update Duty Cycle information FCCID: E2X-ESL-BP102 DEMC1405-01910 Report No.: DRTFCC1411-1421(1) TRF-RF226(00)140710 Page 3 / 48 Copyright ○ C 2014, DT&C Co., Ltd. Table of Contents 1. EUT DESCRIPTION ................................................................... 4 2. SUMMARY OF TESTS ............................................................... 5 3. TEST METHODOLOGY ............................................................. 6 3.1 EUT Configuration ............................................................................................ 6 3.2 EUT Exercise ..................................................................................................... 6 3.3 General Test Procedures ................................................................................. 6 3.4 Description of Test Modes ............................................................................... 6 4. INSTRUMENT CALIBRATION ................................................... 7 5. FACILITIES AND ACCREDITATIONS ........................................ 7 5.1 Facilities ............................................................................................................ 7 5.2 Equipment ......................................................................................................... 7 6. ANTENNA REQUIREMENTS ..................................................... 7 7. TEST RESULT ........................................................................... 8 7.1 6dB Bandwidth ................................................................................................. 8 7.2 Maximum Peak Conducted Output Power .................................................... 13 7.3 Maximum Power Spectral Density. ................................................................ 18 7.4 Out of Band Emissions in non-restricted frequency band .......................... 23 7.5 Out of Band Emissions in restricted frequency band .................................. 36 7.6 AC Power-line Conducted Emissions ........................................................... 40 7.7 Occupied Bandwidth ...................................................................................... 45 8. LIST OF TEST EQUIPMENT .................................................... 46 APPENDIX I ................................................................................. 47 APPENDIX II ................................................................................ 48 FCCID: E2X-ESL-BP102 DEMC1405-01910 Report No.: DRTFCC1411-1421(1) TRF-RF226(00)140710 Page 4 / 48 Copyright ○ C 2014, DT&C Co., Ltd. 1. EUT DESCRIPTION Product Gen3 Gateway Model Name SLG-BP102 Power Supply AC 120V / 60Hz Frequency Range 2405 ~ 2480MHz(16 channels) Modulation Type OQPSK(ZIGBEE) Antenna Specification Antenna Type: Internal Antenna Antenna gain ▪ Transceiver 1(SAC 0): 0.99 dBi(PK) ▪ Transceiver 2(SAC 3): 1.57 dBi(PK) Note: This device has 2 transceivers.(SAC 0 and SAC 3) FCCID: E2X-ESL-BP102 DEMC1405-01910 Report No.: DRTFCC1411-1421(1) TRF-RF226(00)140710 Page 5 / 48 Copyright ○ C 2014, DT&C Co., Ltd. 2. SUMMARY OF TESTS FCC Part Section(s) RSS Section(s) Parameter Limit Test Condition Status Note 1 I. Transmitter Mode (TX) 15.247(a) RSS-210 [A8.2] 6 dB Bandwidth > 500 kHz Conducted C 15.247(b) RSS-210 [A8.4] Transmitter Output Power < 1Watt C 15.247(d) RSS-210 [A8.5] Out of Band Emissions / Band Edge 20dBc in any 100kHz BW C 15.247(e) RSS-210 [A8.2] Transmitter Power Spectral Density < 8dBm / 3kHz C - RSS Gen [4.6.1] Occupied Bandwidth (99%) RSS-Gen(4.6.1) NA 15.205 15.209 RSS-210 [A8.5] General Field Strength Limits (Restricted Bands and Radiated Emission Limits) < FCC 15.209 limits Radiated C Note2 15.207 RSS-Gen [7.2.4] AC Conducted Emissions < FCC 15.207 limits AC Line Conducted C 15.203 - Antenna Requirements FCC 15.203 - C Note 1: C=Comply NC=Not Comply NT=Not Tested NA=Not Applicable Note 2: This test item was performed in each axis and the worst case data was reported. FCCID: E2X-ESL-BP102 DEMC1405-01910 Report No.: DRTFCC1411-1421(1) TRF-RF226(00)140710 Page 6 / 48 Copyright ○ C 2014, DT&C Co., Ltd. 3. TEST METHODOLOGY Generally the tests were performed according to the KDB558074 v03r02. And ANSI C63.10-2009 was used to reference appropriate EUT setup and maximizing procedures of radiated spurious emission and AC line conducted emission testing. 3.1 EUT Configuration The EUT configuration for testing is installed on RF field strength measurement to meet the Commissions requirement and operating in a manner that intends to maximize its emission characteristics in a continuous normal application. 3.2 EUT Exercise The EUT was operated in the engineering mode to fix the TX frequency that was for the purpose ofthe measurements. According to its specifications, the EUT must comply with the requirements ofthe Section 15.207, 15.209 and 15.247 under the FCC Rules Part 15 Subpart C. 3.3 General Test Procedures Conducted Emissions According to therequirements in Section 6.2 of ANSI C 63.10, the EUT is placed on the turntable, which is 0.8 m above ground plane and the conducted emissions from the EUT are measured in the frequency range between 0.15 MHz and 30MHz using CISPR Quasi-peakand Average detector. Radiated Emissions The EUT is placed on a turntable, which is 0.8 m above ground plane. The turntable shall rotate 360 degrees to determine the position of maximum emission level. EUT is set 3 m away from the receiving antenna, which varied from 1 m to 4 m to find out the highest emission. And also, each emission was to be maximized by changing the polarization of receiving antenna both horizontal and vertical. In order to find out the highest emission, the relative positions of this hand-hel…

Text truncated - open the document above for the full version.

FCC ID: E2X-ESL-BP102 Copyright Ⓒ 2014, DT&C Co., Ltd. Test Setup photographs EUT Position: X-axis EUT Position: Y-axis EUT Position: Z-axis FCC ID: E2X-ESL-BP102 Copyright Ⓒ 2014, DT&C Co., Ltd. Test Setup Photo of Radiated Measurement (0.009 ~ 30MHz) FCC ID: E2X-ESL-BP102 Copyright Ⓒ 2014, DT&C Co., Ltd. Test Setup Photo of Radiated Measurement (below 1000MHz) FCC ID: E2X-ESL-BP102 Copyright Ⓒ 2014, DT&C Co., Ltd. Test Setup Photo of Radiated Measurement (Above 1GHz) FCC ID: E2X-ESL-BP102 Copyright Ⓒ 2014, DT&C Co., Ltd. Test Setup Photo of Conducted Emissions
