E2XCEMF11G01G0101LTE Full Mini card Module

CEMF11G01G0101 User manual REV 0.1 Samsung Electro-Mechanics Proprietary and Confidential 1/8 CEMF11G01G0101 User Manual GCT GDM7240R1 LTE Solution REV 0.1 Samsung Electro-Mechanics 2011-11-11 Summary This description presents the general specifications of CEMF11G01G0101 which designed for 3GPP LTE Band 13. © 2011 Samsung Electro-Mechanics. All rights reserved The names of actual companies and products mentioned herein may be the trademarks of their respective owners. No part of this document may be reproduced, stored in a retrieval system, or transmitted in any form or by any means without the express written consent of Samsung Electro-Mechanics. This document is subject to change without notice. CEMF11G01G0101 User Manual REV 0.1 Samsung Electro-Mechanics Proprietary and Confidential 2/8 1 Electrical Characteristics 1.1 Power Supply The CEMF 11G01G0101 must be connected to a 3.3V power supply by PCI Express® Mini Card Electromechanical Specification Revision 1.2 Compliant. Requirement type Value Power Supply 3.3V Voltage range 3.1 ~ 3.6V Maximum Current (Max Power +23dBm) 850mA Table 1-1. Power Supply Requirements 1.2 General Characteristics Item LTE Remark Current consumption Typ. 180mA Connect with PC, With Test JIG Radio Frequency Tx : 777 ~ 787MHz Rx : 746 ~ 756MHz Band 13 Bandwidth 10MHz Frequency Type Earcfn DL : 5230 / UL : 23230 Maximum Throughput DL : 100Mbps UL : 50Mbps Category 3 Modulation Format DL : QPSK, 16QAM, 64QAM UL : QPSK, 16QAM Antenna Configuration 2 Rx Diversity 1 Tx - Main 2 Rx – Main, Diversity Table 1-2. General Characteristics M & SOFT AMERICA MAP CENTER TEL : 888-757-0010 WEBSITE : www.mapnsoft.com MAP DATABASE HOTLINE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ˍ Reorient or relocate the receiving antenna. ˍ Increase the separation between the equipment and receiver. ˍ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ˍ Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.               !   "# $     %&    $' (    $'    $    $      )*   $+,   "        ),    *      %&,    "  ' (,  ,  "   * - " ' . "      ",$   This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum 20 cm between the radiator and your body. This transmitter must not be collocated or operating in conjunction with any other antenna or transmitter unless authorized to do so by the FCC. M & SOFT AMERICA MAP CENTER TEL : 888-757-0010 WEBSITE : www.mapnsoft.com MAP DATABASE HOTLINE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ˍ Reorient or relocate the receiving antenna. ˍ Increase the separation between the equipment and receiver. ˍ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ˍ Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.               !   "# $     %&    $' ( …

Text truncated - open the document above for the full version.

Applicant/Grantee Samsung Electro-Mechanics FCC ID: E2XCEMF11G01G0101 Section 15.212 Modular Transmitters Request for Modular Approval Request for Limited Modular Approval Requirements EUT Conditions Comply (Y/N) Single Modular Approval Requirements 1 The radio elements of the modular transmitter must have their own shielding. The physical crystal and tuning capacitors may be located external to the shielded radio elements. Refer to external photos. Shield is over the radio circuit module. Y 2 The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. All inputs to the modules are buffered through logic or microprocessor inputs. Refer to schematics. Y 3 The modular transmitter must have its own power supply regulation. Internal 5V power regulator.Refer to schematics Y 4 The modular transmitter must comply with the antenna and transmission system requirements of Sections 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of Section 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. PATCH Antenna. The module will go inside final product where the antenna(s) will be integral to the end product, which can be considered permanently attached. Y 5 The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing for compliance with Part 15 requirements. Unless the transmitter module will be battery powered, it must comply with the AC line conducted requirements found in Section 15.207. AC or DC power lines and data input/output lines connected to the module must not contain ferrites, unless they will be marketed with the module (see Section 15.27(a)). The length of these lines shall be the length typical of actual use or, if that length is unknown, at least 10 centimeters to insure that there is no coupling between the case of the module and supporting Module was tested outside. Refer to test setup photos in test report Y equipment. Any accessories, peripherals, or support equipment connected to the module during testing shall be unmodified and commercially available (see Section 15.31(i)). 6 The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number. (A) If using a permanently affixed label, the modular transmitter must be labeled with its own FCC identification number, and, if the FCC identification number is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. (B) If the modular transmitter uses an electronic display of the FCC identification number, the information must be readily accessible and visible on the modular transmitter or on the device in which it is installed. If the module is installed inside another device, then the outside of the device into which the module is installed must display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains FCC certified transmitter module(s).” Any similar wording that expresses the same meaning may be used. The user manual must include instructions on how to access the electronic display. A copy of these instructions must be included in the application for equipment authorization. Refer to label provided. Y 7 The modular transmitter must comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. Refer to manual. Y 8 The modular transmitter must comply with any applicable RF exposure requirements in its final configuration. Refer to MPE calculation in the Test report. Y A limited modular approval may be granted for single or split modular transmitters that do not comply with all of the above requirements, e.g., shielding, minimum signaling amplitude, buffered modulation/data inputs, or power supply regulation, if the manufacturer can demonstrate by alternative means in the application for equipment authorization that the modular transmitter meets all the applicable Part 15 requirements under the operating conditions in which the transmitter will be used. Limited modular approval also may be granted in those instances where compliance with RF exposure rules is demonstrated only for particular product configurations. The applicant for certification must state how control of the end product into which the module will be installed will be maintained such that full compliance of the end product is always ensured.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 Revised wording (current) 1.0 2.0 Sept–25-2007 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 Samsung Electro-Mechanics November 25, 2011 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Samsung Electro-Mechanics hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): LTE Full Mini card Module , SCF-G7 We affirm that between SIEMIC and Samsung Electro-Mechanics, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Jun-Hwan Lim/ Manager Samsung Electro-Mechanics 314,Maetan 3-Dong, Yeongtong-Gu, Suwon-Si, Gyeonggi-Do 443-73, Korea FCC ID : E2XCEMF11G01G0101

FCC ID: E2XCEMF11G01G0101 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １ of 3 EXTERNAL PHOTOGRAPHS FCC ID: E2XCEMF11G01G0101 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ２ of 3 ■ EXTERNAL PHOTO FCC ID: E2XCEMF11G01G0101 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ３ of 3 ■ EXTERNAL PHOTO

CEMF11G01G0101 Label Information REV 0.1 Samsung Electro-Mechanics Proprietary and Confidential 1/1 1 Label Information 1.1 Label Information The Label contains Model Name, Product Code, FCC ID, IMEI and Serial Number. Figure 1-1. Label Information 1.1.1 S/N(Serial Number) Ex) S N F B 000001
    S N F B 000001
    Company S: Samsung Custom Model N : CEMF11G01G0101 Year F:2011 G:2012 Month 1~9:Jan~SEP A:OCT, B:Nov, C:Dec 000001~FFFFFF Serial No(Hex) Table 1-1. Serial Number Information

FCC ID: E2XCEMF11G01G0101 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １ of 3 INTERNAL PHOTOGRAPHS FCC ID: E2XCEMF11G01G0101 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ２ of 3 ■ INTERNAL PHOTO FCC ID: E2XCEMF11G01G0101 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ３ of 3 ■ INTERNAL PHOTO

FCC ID:E2XCEMF11G01G0101 HCT CO., LTD 1 of 2 RF Exposure Statement 1. LIMITS According to §1.1310 and §2.1091 RF exposure is calculated. (B) Limits for General Population/Uncontrolled Exposures Frequency range (MHz) Electric field Strength (V/m) Magnetic field Strength (A/m) Power density (mW/cm²) Averaging time (minutes) 0.3 - 1.34....................................... 1.34 - 30....................................... 30 - 300....................................... 300 - 1500.................................... 1500 - 100.000................................. 614 824/f 27.5 ............... ............... 1.63 2.19/f 0.073 ............... ............... *(100) *(180/ f²) 0.2 f/1500 1.0 30 30 30 30 30 F = frequency in MHz * = Plane-wave equivalent power density 2. MAXIMUM PERMISSIBLE EXPOSURE Prediction Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S = PG/4πR² S = Power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna FCC ID:E2XCEMF11G01G0101 HCT CO., LTD 2 of 2 2-1. LTE BAND Max Peak output Power at antenna input terminal (dBm) 23.420 Max Peak output Power at antenna input terminal (mW) 219.786 Prediction distance (cm) 20.000 Prediction frequency (MHz) 782.000 Antenna Gain(typical) (dBi) -0.420 Antenna Gain(numeric) 0.908 Power density at prediction frequency (mW/cm²) 0.03969 MPE limit for uncontrolled exposure at prediction frequency (mW/cm²) 0.521 3. RESULTS The power density level at 20 cm is 0.03969 mW/cm², which is below the uncontrolled exposure limit of 0.521 mW/cm² at LTE band.

FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1111FR17-1 Date of Issue: November 28, 2011 EUT Type: LTE Full Mini card Module FCC ID: E2XCEMF11G01G0101 Page 2 of 42 Version TEST REPORT NO. DATE DESCRIPTION HCTR1111FR17 November 18, 2011 First Approval Report HCTR1111FR17-1 November 28, 2011 Adding test plot FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1111FR17-1 Date of Issue: November 28, 2011 EUT Type: LTE Full Mini card Module FCC ID: E2XCEMF11G01G0101 Page 3 of 42 Table of Contents 1. GENERAL INFORMATION ........................................................................................................................... 4 2. INTRODUCTION ........................................................................................................................................... 5 2.1. EUT DESCRIPTION............................................................................................................................ 5 2.2. MEASURING INSTRUMENT CALIBRATION .................................................................................... 5 2.3. TEST FACILITY .................................................................................................................................. 5 3. DESCRIPTION OF TESTS ........................................................................................................................... 6 3.1 EFFECTIVE RADIATED POWER/EQUIVALENT ISOTROPIC RADIATED POWER........................ 6 3.2 OCCUPIED BANDWIDTH................................................................................................................... 7 3.3 BLOCK FREQUENCY RANGE ........................................................................................................... 8 3.4 SPURIOUS AND HARMONIC EMISSIONS AT ANTENNA TERMINAL............................................ 9 3.5 RADIATED SPURIOUS AND HARMONIC EMISSIONS .................................................................. 10 3.6 FREQUENCY STABILITY / VARIATION OF AMBIENT TEMPERATURE .......................................11 4. LIST OF TEST EQUIPMENT ...................................................................................................................... 12 5. SUMMARY OF TEST RESULTS ................................................................................................................ 13 6. SAMPLE CALCULATION ........................................................................................................................... 14 7. TEST DATA ................................................................................................................................................. 15 7.1 CONDUCTED OUTPUT POWER ......................................................................................................15 7.2 OCCUPIED BANDWIDTH ................................................................................................................. 16 7.3 CONDUCTED SPURIOUS EMISSIONS ........................................................................................... 17 7.3.1 BAND EDGE............................................................................................................................ 17 7.3.2 EMISSION MASK .................................................................................................................... 17 7.4 RADIATED SPURIOUS EMISSIONS ................................................................................................18 7.4.1 RADIATED SPURIOUS EMISSIONS...................................................................................... 18 7.4.2 RADIATED SPURIOUS EMISSIONS (1559 ~ 1610 MHz Band) ........................................... 19 7.5 FREQUENCY STABILITY / VARIATION OF AMBIENT TEMPERATURE ...................................... 20 7.5.1 FREQUENCY STABILITY (LTE)............................................................................................. 20 8. TEST PLOTS............................................................................................................................................... 21 FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1111FR17-1 Date of Issue: November 28, 2011 EUT Type: LTE Full Mini card Module FCC ID: E2XCEMF11G01G0101 Page 4 of 42 MEASUREMENT REPORT 1. GENERAL INFORMATION Applicant Name: Samsung Electro-Mechanics Address: 314, Maetan 3-Dong, Yeongtong-Gu, Suwon-Si, Gyeonggi-Do 443-743, Korea FCC ID: E2XCEMF11G01G0101 Application Type: Certification FCC Classification: PCS Licensed Transmitter (PCB) FCC Rule Part(s): §2 , §27 EUT Type: LTE Full Mini card Module FCC Model(s): SCF-G7 Tx Frequency: 782 MHz (LTE – Band 13) Max. RF Output Power: 0.220 W (23.42 dBm) ERP (QPSK) 0.176 W (22.45 dBm) ERP (16-QAM) Emission Designator(s): 8M95G7D (QPSK) / 8M95W7D (16-QAM) Antenna Specification Manufacturer: SAMSUNG ELECTOR-MECHANICS Antenna type: PATCH Antenna Peak Gain: - 0.42 dBi Date(s) of Tests: November 10, 2011 ~ November 14, 2011 FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1111FR17-1 Date of Issue: November 28, 2011 EUT Type: LTE Full Mini card Module FCC ID: E2XCEMF11G01G0101 Page 5 of 42 2. INTRODUCTION 2.1. EUT DESCRIPTION The Samsung Electro-Mechanics SCF-G7 LTE Full Mini card Module consists of LTE Band 13. 2.2. MEASURING INSTRUMENT CALIBRATION The measuring equipment, which was utilized in performing the tests documented herein, has been calibrated in accordance with the manufacturer's recommendations for utilizing calibration equipment, which is traceable to recognized national standards. 2.3. TEST FACILITY The SAC(Semi-Anechoic Chamber) and conducted measurement facility used to collect the radiated data are located at the 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, 467-811, Korea. The site is constructed in conformance with the requirements of ANSI C63.4 and CISPR Publication 22. Detailed description of test facility was submitted to the Commission and accepted dated March 02…

Text truncated - open the document above for the full version.

FCC ID: E2XCEMF11G01G0101 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １ of 5 TEST SETUP PHOTOGRAPHS FCC ID: E2XCEMF11G01G0101 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ２ of 5 ■ Test Setup Photo FCC ID: E2XCEMF11G01G0101 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ３ of 5 ■ Test Setup Photo FCC ID: E2XCEMF11G01G0101 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ４ of 5 ■ Test Setup Photo FCC ID: E2XCEMF11G01G0101 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ５ of 5 ■ Test Setup Photo
