1 SAMSUNG MagicLAN Quick Installation Guide (Wireless LAN Card) 삼성 매직랜 무선랜 카드 설치 설명서 Rev 2.0 이 설명서는 영문과 국문이 동시에 기재되어 있습니다. This manual supports English and Korean. 2 SAMSUNG MagicLAN English Manual 3 Notice 1 This manual cannot be reproduced in any form without the prior written permission of SAMSUNG Electro-Mechanics Co., Ltd. SAMSUNG Electro-Mechanics Co., Ltd. reserves the right to change this manual and the specifications to improve products without prior notice. So you can get the most recent software and user documentation for all MagicLAN products on our web site. The users manual or instruction manual for an intentional or unintentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. All other brand and product names are trademarks of registered trademarks of their respective holders. http://www.MagicLAN.com Service Dept. Tel : +82-31-218-2416,8,9,20 Fax : +82-31-218-2431 Sales Dept. <America> Tel : +82-31-218-2407,9,11 Fax : +82-31-210-5996 <Europe> Tel : +82-31-218-2409 Fax : +82-31-210-5996 <Asia> Tel : +82-31-210-5603 Fax : +82-31-218-2414 Japan Tel : +82-31-210-3122 Fax : +82-31-210-5996 China Tel : +82-31-210-5703 Fax : +82-31-210-5996 Copyright © 1999 - 2003 SAMSUNG Electro-Mechanics Co., Ltd. All rights reserved. 4 Notice 2 Important Safety Information z Read these simple guidelines. Breaking the rules may be dangerous or illegal. SAMSUNG will not be responsible for any damages caused by breaking the rules. z WLAN Card described in this document is approved for use in a wireless local area network. z Remember to make backup copies of important data. z When you are transferring data, keep your laptop computer stationary. Roaming between access points (APs) may break the connection. z Only qualified service personnel must repair the equipment. z All wireless devices may get interference, which could affect performance. z Use approved accessories only. Do not connect incompatible products. z Use only accessories approved by the WLAN Card manufacturer for use with this particular WLAN Card. The use of any other types will invalidate any approval or warranty applying to the WLAN Card, and may be dangerous. z Use only the region settings appropriate for the area where the WLAN Card is used at the present time. Using the card in any other region or with an incorrect region setting is prohibited and may be illegal. z Operation of any radio transmitting equipment, including a WLAN Card, may cause interference with the functionality of inadequately protected medical devices. z Do not use the WLAN Card on aircraft. z Do not use the WLAN Card at a refueling point. z Do not use the WLAN Card near inflammable materials or chemicals. z Do not use the WLAN Card where blasting is in progress. z Do not use the WLAN Card when the use of wireless device may cause interference or danger. z Do not use the WLAN Card where the use of cellular terminals is prohibited. z Microwave oven degrades the performance of wireless LAN drastically. So do not use the WLAN card in the environment where Microwave oven is being used. 5 Notice 3 FCC Statement and Warnings : This device complies with Part 15 rules of the FCC and with RSS-210 of Industry of Canada. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Manufacturers Federal Communications Commission Declaration of Conformity Statement: This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential environment. This equipment generates, uses, and radiates radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference. However, there is no guarantee that interference will not occur. If this equipment does cause interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to correct the interference by one of the following measures: z REORIENT OR RELOCATE THE RECEIVING ANTENNA. z INCREASE SEPARATION BETWEEN THE EQUIPMENT AND RECEIVER. z CONNECT THE EQUIPMENT TO AN OUTLET ON A CIRCUIT DIFFERENT FROM WHICH THE RECEIVER IS CONNECTED. z CONSULT THE DEALER OR AN EXPERIENCED RADIO/TV TECHNICIAN. Caution The Part 15 radio device operates on a non-interference basis with other devices operating at this frequency when using the listed antenna. Any changes or modifications to product not expressly approved by Samsung Electro-Mechanics could void the user's authority to operate this device. 6 Declaration of Conformity for RF Exposure: The radio module has been evaluated under FCC Bulletin OET 65C and found compliant to the requirements as set forth in CFR 47 Sections 2.1091, 2.1093, and 15.247 (b) (4) addressing RF Exposure from radio frequency devices. For the listed antenna, the equipment should be positioned more than 2.5cm(USB/PCMCIA, PCI : 20cm) from your body or nearby persons. Collocation Statement: This device must not be collocated with any other antenna or transmitters. 7 EMC Warning(French) CE Statement and Warnings : Information Importante de Sécurité • Lisez ces simples directives. La violation des règles peut être dangereuse ou illégale. SAMSUNG ne sera pas responsable pour des dommages causés par la violation des règles. • La carte WLAN décrite dans ce document a été approuvée pour utilisation dans un réseau local (local area network) sans fil. • N’oubliez pas de faire des copies de sécurité de toute information importante. • Pendant la transmission de données, ne déplaçez pas votre laptop. Le déplaçement entre access po…
