SAMSUNG MagicLAN SWL-2300U User Manual (Rev. 2.0) Table of Contents 1. MagicLAN Installation ................................................................................8 1.1 Introduction .......................................................................................8 1.2 Technical Background ..........................................................................8 1.3 MagicLAN Overview............................................................................10 2. Before the Installation ...............................................................................12 2.1 What is in your Package ......................................................................12 2.2 System Requirement ...........................................................................12 2.3 Preparations For Installation.........................................................12 3. MagicLAN Installation for Windows 98SE/ME/2000/XP .......................13 3.1 Installation Overview ..........................................................................13 3.2 Installation Procedure of Windows 98SE ..............................................13 3.3 Installation Procedure of Windows ME ..............................................21 3.4 Installation Procedure of Windows 2000 ..........................................27 3.5 Installation Procedure of Windows XP .........................................32 3.6 Update of MagicLAN Wireless LAN Card Driver........................................38 3.7 Removal of MagicLAN Wireless LAN Card Driver .......................................38 4. The Program for setting MagicLAN................................................................40 4.1 The concept of Profile.........................................................................40 4.2 Installation Procedure....................................................................40 5. The main configuration of Program................................................................46 5.1 Profile.............................................................................................47 5.1.1 The ‘New’ button......................................................................47 5.1.2 The ‘Apply’ button....................................................................47 5.1.3 The ‘Edit’ button......................................................................48 5.1.4 The ‘Delete’ button....................................................................51 5.2 Status..............................................................................................51 5.2.1 The ‘Current Status’ button..........................................................51 5.2.2 The ‘AP Status’ button...............................................................52 5.2.3 The ‘Site Survey’ button............................................................53 5.2.4 Statistics.................................................................................53 5.3 General Settings...................................................................................54 5.3.1 The ‘DHCP’ button.................................................................54 5.3.2 The ‘Options’ button................................................................54 5.4 Version........................................................................................55 6. Troubleshooting ....................................................................................56 Notice 1 This manual cannot be reproduced in any form without the prior written permission of SAMSUNG Electro-Mechanics Co., Ltd. SAMSUNG Electro-Mechanics Co., Ltd. reserves the right to change this manual and the specifications to improve products without prior notice. So you can get the most recent software and user documentation for all MagicLAN products on our web site. The users manual or instruction manual for an intentional or unintentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. All other brand and product names are trademarks of registered trademarks of their respective holders. http://www.MagicLAN.com Service Dept. Tel : +82-31-218-2416,8,9,20 Fax : +82-31-218-2431 Sales Dept. <America> Tel : +82-31-218-2407,9,11 Fax : +82-31-210-5996 <Europe> Tel : +82-31-218-2409 Fax : +82-31-210-5996 <Asia> Tel : +82-31-210-5603 Fax : +82-31-218-2414 Japan Tel : +82-31-210-5706 Fax : +82-31-210-5996 China Tel : +82-31-210-5703 Fax : +82-31-210-5996 Copyright © 1999 - 2003 SAMSUNG Electro-Mechanics Co., Ltd. All rights reserved. Notice 2 WARNING While installing and operating this transmitter and antenna combination the radio frequency exposure limit of 1mW/cm 2 may be exceeded at distances close to the antennas installed. Therefore, the user must maintain a minimum distance of 20 cm from the antenna. Important Safety Information z Read these simple guidelines. Breaking the rules may be dangerous or illegal. SAMSUNG will not be responsible for any damages caused by breaking the rules. z WLAN Card described in this document is approved for use in a wireless local area network. z Remember to make backup copies of important data. z When you are transferring data, keep your laptop computer stationary. Roaming between access points (APs) may break the connection. z Only qualified service personnel must repair the equipment. z All wireless devices may get interference, which could affect performance. z Use approved accessories only. Do not connect incompatible products. z Use only accessories approved by the WLAN Card manufacturer for use with this particular W LAN Card. The use of any other types will invalidate any approval or warranty applying to the WLAN Card, and may be dangerous. z Use only the region settings appropriate for the area where the WLAN Card is used at the present time. Using the card in any other region or with an incorrec…
Text truncated - open the document above for the full version.
1 SAMSUNG MagicLAN Quick Installation Guide (Wireless LAN Card) Rev 2.1 . This manual supports English and Korean. 2 SAMSUNG MagicLAN English Manual 3 Notice 1 This manual cannot be reproduced in any form without the prior written permission of SAMSUNG Electro-Mechanics Co., Ltd. SAMSUNG Electro-Mechanics Co., Ltd. reserves the right to change this manual and the specifications to improve products without prior notice. So you can get the most recent software and user documentation for all MagicLAN products on our web site. The users manual or instruction manual for an intentional or unintentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. All other brand and product names are trademarks of registered trademarks of their respective holders. http://www.MagicLAN.com Service Dept. Tel : +82-31-218-2416,8,9,20 Fax : +82-31-218-2431 Sales Dept. <America> Tel : +82-31-218-2407,9,11 Fax : +82-31-210-5996 <Europe> Tel : +82-31-218-2409 Fax : +82-31-210-5996 <Asia> Tel : +82-31-210-5603 Fax : +82-31-218-2414 Japan Tel : +82-31-210-3122 Fax : +82-31-210-5996 China Tel : +82-31-210-5703 Fax : +82-31-210-5996 Copyright © 1999 - 2003 SAMSUNG Electro-Mechanics Co., Ltd. All rights reserved. 4 Notice 2 Important Safety Information z Read these simple guidelines. Breaking the rules may be dangerous or illegal. SAMSUNG will not be responsible for any damages caused by breaking the rules. z WLAN Card described in this document is approved for use in a wireless local area network. z Remember to make backup copies of important data. z When you are transferring data, keep your laptop computer stationary. Roaming between access points (APs) may break the connection. z Only qualified service personnel must repair the equipment. z All wireless devices may get interference, which could affect performance. z Use approved accessories only. Do not connect incompatible products. z Use only accessories approved by the WLAN Card manufacturer for use with this particular WLAN Card. The use of any other types will invalidate any approval or warranty applying to the WLAN Card, and may be dangerous. z Use only the region settings appropriate for the area where the WLAN Card is used at the present time. Using the card in any other region or with an incorrect region setting is prohibited and may be illegal. z Operation of any radio transmitting equipment, including a WLAN Card, may cause interference with the functionality of inadequately protected medical devices. z Do not use the WLAN Card on aircraft. z Do not use the WLAN Card at a refueling point. z Do not use the WLAN Card near inflammable materials or chemicals. z Do not use the WLAN Card where blasting is in progress. z Do not use the WLAN Card when the use of wireless device may cause interference or danger. z Do not use the WLAN Card where the use of cellular terminals is prohibited. z Microwave oven degrades the performance of wireless LAN drastically. So do not use the WLAN card in the environment where Microwave oven is being used. z CardBus Card supports a 3.3-volt slot only. If a CardBus Card is inserted in a 5- volt only PC Card slot, the card can be damaged due to electrical overload. 5 Notice 3 FCC Statement and Warnings : This device complies with Part 15 rules of the FCC and RSS-210 of Industry of Canada. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Manufacturers Federal Communications Commission Declaration of Conformity Statement: This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential environment. This equipment generates, uses, and radiates radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference. However, there is no guarantee that interference will not occur. If this equipment does cause interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to correct the interference by one of the following measures: z REORIENT OR RELOCATE THE RECEIVING ANTENNA. z INCREASE SEPARATION BETWEEN THE EQUIPMENT AND RECEIVER. z CONNECT THE EQUIPMENT TO AN OUTLET ON A CIRCUIT DIFFERENT FROM WHICH THE RECEIVER IS CONNECTED. z CONSULT THE DEALER OR AN EXPERIENCED RADIO/TV TECHNICIAN. Caution The Part 15 radio device operates on a non-interference basis with other devices operating at this frequency when using the listed antenna. Any changes or modifications to product not expressly approved by Samsung Electro-Mechanics could void the user's authority to operate this device. 6 Declaration of Conformity for RF Exposure: The radio module has been evaluated under FCC Bulletin OET 65C and found compliant to the requirements as set forth in CFR 47 Sections 2.1091, 2.1093, and 15.247 (b) (4) addressing RF Exposure from radio frequency devices. For the listed antenna, the equipment should be positioned more than 2.5cm(USB/PCMCIA, PCI : 20cm) from your body or nearby persons. Collocation Statement for CardBus WLAN Product : This device must not be collocated with any other antenna or transmitters. 7 EMC Warning(French) CE Statement and Warnings : Information Importante de Sécurité • Lisez ces simples directives. La violation des règles peut être dangereuse ou illégale. SAMSUNG ne sera pas responsable pour des dommages causés par la …
Text truncated - open the document above for the full version.
11Mbps High Rate 802.11b WLAN USB Adapter Low Cost & High Performance! ■ Specifications Model NameSWL-2300U System InterfaceUSB Spec 1.1 Compliant Frequency Band2.400 ~ 2.4835GHz(Subject to local regulations) Operating Voltage5V±5% from Host PC Data Receiving : 220mA (Typical) Data Transmitting : 350mA (Typical) Power Save : 20mA (Typical) Data Rate1, 2, 5.5 ,11 Mbps SpreadingDSSS(Direct Sequence Spread Spectrum) Output Power40mW(16dBm) for 22MHz Bandwidth, 7mW/MHz Receive Sensitivity -87dBm(Typical) at 11Mbps Security40-bit/104(128)-bit WEP Encryption Antenna2 Printed Antennas on PCB(supporting Rx Diversity) Available DriversMicrosoft Windows 98SE/ME/2000/XP/XPSP1 StandardsIEEE 802.11b Media Access ProtocolCSMA/CA Temperature Range Operating : 0~45(32~113), Storage : -25~70(-13~158) Humidity10% to 90% Non-condensing Operating RangeOpen Space : 150m(500ft) over at 11Mbps, 200m(660ft) over at 2Mbps (1024 bytes file transfer)Closed Office: 30m(100ft) over at 11Mbps, 50m(160ft) over at 2Mbps Dimensions114mm×52mm×15mm & 1.2M Cable with USB A-type Connector Weight40g(Except 1.2m Cable) Certifications & Regulatory Approvals Wi-Fi certified, Korea, USA(FCC), Canada(IC), R&TTE Approval(CE) and 15 EU & 4 EFTA Countries Notifications The Spec can be changed without notice. CopyrightSamsung Electro-Mechanics Co., Ltd. All Rights Reserved. Current Consumption
3.6 Installation Procedure of Windows XP Please follow the following steps one by one in order to install the USB Adapter successfully. < Method 1 - Inserting card first > 1. Insert the USB Adapter into USB slot of your computer. 2. “Found New Hardware Wizard ” appeared and the system looks for “USB Device”. Insert the MagicLAN Installation CD into the CD-ROM Drive. 3. You can find the “SAMSUNG WLAN USB Adapter(SWL-2300)” and system will copy driver files. You can click Continue Anyway in the 'Hardware Installation' Message box. 4. Now driver files are fully installed to start the Wireless LAN Card’s operation. 5. Check for the SAMSUNG WLAN USB Adapter(SWL-2300) on Computer Management in the Administrative Tools of the Control Panel . If you find the Yellow sign on the adapter, it shows the installation is not successful. In this case, select the adapter and click on Remove . Restart your computer after uninstalling the driver to make the changes effective. (See the Adapter Removal in section 3.7) 6. Of the icons displayed on the right bottom of desktop, click on icon stated Wireless Network Connection . 7. When you are using DHCP, just select the AP that you want to connect in the Connect to Wireless Network above. 8. To manually set your IP address, WEP and some other configuration, click on Advanced of the above picutre and then click Configure Available networks on the Wireless Networks Tab . Set the SSID and parameters to be needed to modify and then clicking on OK. The AP that you selected will be displayed on the Preferred Networks. 9. Next, move to the General Tab. After the double click the “ Internet Protocol(TCP/IP) ”, set the IP value, Gateway value and DNS value and click on OK. All will be done by clicking on OK once more. < Method 2 – Installing software first > 1. If you insert the MagicLAN Installation CD into the CD-ROM drive, software will launch automatically. Then, click on the ‘Install MagicLAN Driver’. 2. You can see the pictures of Wireless LAN Cards by model name.(SWL-2300U USB Adapter). Click on the model name to install it’s driver. 3. Click on Operating System in the right screen in which you want to install driver. 4.After installing driver, insert Wireless LAN card. You can click Continue Anyway in the “‘Hardware Installation’ Message box. 5.The system recognize the Wireless LAN Card. If Found New Hardware Wizard appears, just click Next to install the driver files. 6.The other procedures are same to 5~9 of < Method 1 - Inserting card first > . Cf.) The third method : You can combine ‘Method 1’ with ‘Method 2’. In other words, after inserting card into the computer, you can install driver and utility by using the installshield instead, not by the inf file. In case of Windows 2000 and Windows XP, system will recognize the card automatically during installation . Notice that if you install a card after removing it in a Device Manager, you have to mark the check box(“Do you want to scan for hardware changes?”). The function is same to the “Refresh” in ther Device Manager. [ Use of Our company’s Utility in Windows XP ] You can also set up the Wireless LAN by the our company’s utility program instead of Windows XP’ utility program. After booting the computer, you have to draw out and re-insert the MagicLAN Installation CD to be automatically installed. You can click “Install Configuration Utility” to install our utility. Choose the appropriate language when a context box appeared to choose utility’s language. You should reboot the computer to use our utility properly in the NT-based OSs(Winows 2000, Windows XP). - If you click the icon on the right bottom of the desktop, you can see the current state of the Wireless LAN. - Click on Option of the General settings on the bottom of the Utility and mark “Manage the Wireless Control by this utility under WinXP”. For more details, refer to ‘Chapter 4’ in this manual. - If you want to use Wireless LAN Utility in the system of Windows XP , be sure that the mark of “Manage the Wireless Control by this utility under WinXP” of the our company’s utility program is removed. 3.6 Update of MagicLAN Wireless LAN Card Driver 1. After inserting the MagicLAN Installation CD, click the Install MagicLAN Driver and select the Card and Operationg System that you want to update in. 2. If selection box appears, select ‘Reinstall MagicLAN Software’ between ‘Remove’ and ‘Reinstall’. 3.7 Removal of MagicLAN Wireless LAN Card Driver (Adapter Removal) Click like followings : -> All Programs -> MagicLAN -> MagicLAN Driver -> Remove USB adapter. Select ‘Remove all MagicLAN Software’ and click Next. (Utility Removal) Click like followings : -> All Programs -> MagicLAN -> MagicLAN Utility -> Remove Utility Uninstall. Select ‘Remove Configuration Utility Software’ and click Next . (cf) If you want to just remove the WLAN Card from the PC, click and Stop SAMSUNG WLAN USB Adapter(SWL-2300) icon the right bottom of your computer screen. Then you remove the WLAN Card after clicking the OK button on the message, ‘SAMSUNG WLAN USB Adapter(SWL-2300) can now be safely removed from the system’ ** - ‘Safely remove hardware’ icon (Windows ME , 2000, XP) 4. The Program For Setting MagicLAN 4.1 The concept of Profile - TCP/IP settings for the fixed networks/Wired LAN have no problems, as they do not deal with the mobility. But in case of mobile equipments such as WLAN card, when WLAN client has moved from home to Office or vice-versa, the difficulty for using the old TCP/IP settings arises. - The concept of profile makes it easy to use the same TCP/IP settings for WLAN cards regardless of the movement. - Profile can be selected again with ease if it were saved. Saving the settings for WLAN and TCP/IP as a Profile, it is easy for user to select and use one of the saved profiles, especially, it can be used quickly without rebooting your computer while the settings for TCP/IP is updated. 4.2 Installation Procedure First time use of WLAN on your computer needs the…
Text truncated - open the document above for the full version.
Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Rd. Columbia, MD 21406 USA Subject: FCC ID: E2XSWL-2300U June 10, 2003 Gentlemen, Samsung Electro-Mechanics hereby requests that the following items be kept confidential under sections 0.457 and 0.459 of the CFR. If this information was to be made public record it would adversely affect the core business. I would like to request the following items be confidential (1) Schematics (2) Block Diagram (3) Part List (Bill of Material) (4) Operational Description Sincerely, John K. Seo Senior Manager Network Division R&D Lab. 2 nd , Wireless LAN ELECTRO-MECHANICS 31 4,Maetan 3-Dong, Paldal-ku, Suwoni, Kyung ki-Do,Korea,441- 743 TEL 82 -31 -2 10- 57 12 FAX 82-31 -21 0-552 9
Declaration on radiation safety standard conformance Samsung Electro-Mechanics Co., LTD 314, Maetan 3 –Dong, Paldal-Gu, Suwon, Gyunggi-Do Suwon Korea declares that the following product: Description: 2.4 GHz Direct Sequence Spread Spectrum Transceiver Manufacturer: Samsung Brand: Samsung Type/model number: SWL-2300U FCC ID: E2XSWL-2300U has a maximum e.i.r.p. of 14.8 dBm (30.2 mW, including a maximum antenna gain of +0 dBi); the worst case prediction of power density (100% reflection) at 20 cm distance (S) can be calculated as follows: S = EIRP / 4*pi*R² : (power density without reflection) S = 2² * EIRP / 4*pi*R² : (power density with 100% reflection) S = 2² * EIRP / 4*pi*R² = 30.2 mW / pi*(20cm)² = 0.024 mW/cm (limit = 1.0 mW/cm) This means that according to OET Bulletin 65 (Edition 97-01), Supplement C (Edition 01-01), the equipment fulfills the requirements on power density for general population/uncontrolled exposure and therefore fulfills the requirements of CFR 47 Part 15.247(b)(4).
Radio Test Report: 99393321 Applicant: Samsung Electro-Mechanics Co., LTD. 314, Maetan 3-Dong, Paldal-Gu, Suwon, Gyunggi-Do Suwon Korea Equipment Under Test: SWL-2300U Direct Sequence Spread Spectrum Transceiver (E.U.T.) FCC ID: E2XSWL-2300U In Accordance With: FCC Part 15, Subpart C (10-1-02 Edition) Direct Sequence Transmitters 2400 - 2483.5 MHz Tested By: Telefication bv Edisonstraat 12A 6902 PK Zevenaar Authorized By: J.P. van de Poll Co-ordinator Test Group Date: 15 July 2003 Total Number of Pages: 43 Telefication FCC PART 15, SUBPART C DIRECT SEQUENCE TRANSMITTERS PROJECT NO.:99393321 EQUIPMENT: SWL-2300U Spread Spectrum Direct Sequence Transceiver FCC ID: E2XSWL-2300U Page 2 of 43 Table of Contents Section 1 Summary of Test Results ...................................................................................................... 3 Section 2 Equipment Under Test (E.U.T.)........................................................................................... 5 Section 3 Powerline conducted emissions ............................................................................................ 9 Section 4 Minimum 6 dB bandwidth ................................................................................................. 16 Section 5 Peak Power Output ............................................................................................................. 20 Section 6 Peak power spectral density ............................................................................................... 21 Section 7 Spurious Emissions (Preliminary radiated)...................................................................... 25 Section 8 Spurious Emissions (Radiated) .......................................................................................... 32 Section 9 Spurious Emissions (restricted bands, radiated) .............................................................. 33 Section 10 Photographs ........................................................................................................................ 36 Section 11 Test equipment List............................................................................................................40 ANNEX A TEST METHODOLOGIES................................................................................................. 41 Telefication FCC PART 15, SUBPART C DIRECT SEQUENCE TRANSMITTERS PROJECT NO.:99393321 EQUIPMENT: SWL-2300U Spread Spectrum Direct Sequence Transceiver FCC ID: E2XSWL-2300U Page 3 of 43 Section 1 Summary of Test Results Manufacturer: Samsung Electro-Mechanics Co.,LTD Model No.: SWL-2300U Serial No.: Not applicable Date Received In Laboratory: 5 June 2003 These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with Part 15, Subpart C, Paragraph 15.247 for Direct Sequence Spread Spectrum devices. Radiated tests were conducted in accordance with ANSI C63.4-1992 New Submission Production Unit Class II Permissive Change Pre-Production Unit D T S Equipment Code Family Listing THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. See “ Summary of Test Data”. TESTED BY: _____________________________________ DATE: 15 July 2003 ing. P.A. Suringa, Senior engineer Radio/EMC Telefication authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Telefication accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. Telefication complies with the accreditation criteria for test laboratories as laid down in ISO/IEC 17025:1999. The accreditation covers the quality system of the laboratory as well as the specific activities as described in the authorized annex bearing the accreditation number L021 and is granted on 30 November 1990 by the Dutch Council For Accreditation (RvA: Raad voor Accreditatie). Telefication FCC PART 15, SUBPART C DIRECT SEQUENCE TRANSMITTERS PROJECT NO.:99393321 EQUIPMENT: SWL-2300U Spread Spectrum Direct Sequence Transceiver FCC ID: E2XSWL-2300U Page 4 of 43 Summary Of Test Data NAME OF TEST PARA. NO. SPEC. MEAS. RESULT Powerline conducted emissions 15.207(a) 64 dBμV 40.7 dBμV Complies Minimum 6 dB bandwidth 15.247(a)(2) 500 kHz 12.7 MHz Complies Maximum Peak Power Output 15.247(b) (3) 1 Watt 20.3 dBm E.I.R.P. Complies Peak Power Spectral Density 15.247(d) 8 dBm/3 kHz -19 dBm Complies Spurious Emissions (Radiated) 15.247(c) > 20 dB below fundamental > 20 dB Complies Test Conditions: Indoor Temperature: __22________ °C Humidity: __45________% Telefication FCC PART 15, SUBPART C DIRECT SEQUENCE TRANSMITTERS PROJECT NO.:99393321 EQUIPMENT: SWL-2300U Spread Spectrum Direct Sequence Transceiver FCC ID: E2XSWL-2300U Page 5 of 43 Section 2 Equipment Under Test (E.U.T.) General Equipment Information Equipment class Class B digital device (computer peripheral) Type of equipment Data transmission equipment in the 2.4 GHz ISM band using spread spectrum techniques Frequency Range: 2412 – 2462 MHz Number of Channels: 11 Emissions Designator: 22M0G1D Telefication FCC PART 15, SUBPART C DIRECT SEQUENCE TRANSMITTERS PROJECT NO.:99393321 EQUIPMENT: SWL-2300U Spread Spectrum Direct Sequence Transceiver FCC ID: E2XSWL-2300U Page 6 of 43 Description of Modification for Modification Filing Not applicable Family List Rationale Not applicable Telefication FCC PART 15, SUBPART C DIRECT SEQUENCE TRANSMITTERS PROJECT NO.:99393321 EQUIPMENT: SWL-2300U Spread Spectrum Direct Sequence Transceiver FCC ID: E2XSWL-2300U Page 7 of 43 Theory of Operation The SWL-2300U is a spread spectrum direct sequence transceiver and is de…
Text truncated - open the document above for the full version.
Testing and certification of, consultancy and research concerning, electronic and electric appliances, systems, installations and telecommunication systems TEST REPORT OF A 2.4 GHZ LOW POWER WLAN USB DEVICE, BRAND SAMSUNG, TYPE SWL-2300U, IN CONFORMITY WITH 47 CFR PART 15 (2003-03-13). FCC listed Industry Canada : : 90828 IC3501 TNO Electronic Products & Services (EPS) B.V. P.O. Box 15 9822 ZG Niekerk (NL) Smidshornerweg 18 9822 TL Niekerk (NL) Telephone: +31 594 505005 Telefax: +31 594 504804 E-mail: [email protected] Project number: 03081901.r01 Page 1 of 17 Test specification(s): Description of EUT: Manufacturer: Brand mark: Type: FCC ID: 47 CFR Part 15 (2003-03-13) 2.4 GHz low power WLAN USB Device Samsung Samsung SWL-2300U E2XSWL2300U MEASUREMENT/TECHNICAL REPORT SAMSUNG Model : SWL-2300U FCC ID: E2XSWL-2300U August 22, 2003 This report concerns: Original grant/certification Class 2 change Verification Equipment type: Direct Sequence Spread Spectrum Transceiver Deferred grant requested per 47 CFR 0.457(d)(1)(ii) ? Yes No Report prepared by: Name : J. Schuurmans, B.Sc.E.E. Company name : TNO Electronic Products & Services (EPS) B.V. Address : Smidshornerweg 18 Postal code/city : 9822 ZG Niekerk Mailing address : P.O. Box 15 Postal code/city : 9822 TL Niekerk Country : The Netherlands Telephone number : + 31 594 505 005 Telefax number : + 31 594 504 804 E-mail : [email protected] The data taken for this test and report herein was done in accordance with 47 CFR Part 15 and the measurement procedures of ANSI C63.4-1992. TNO Electronic Products & Services (EPS) B.V. at Niekerk, The Netherlands, certifies that the data is accurate and contains a true representation of the emission profile of the Equipment Under Test (EUT) on the date of the test as noted in the test report. I have reviewed the test report and find it to be an accurate description of the test(s) performed and the EUT so tested. Date: August 22, 2003 P. de Beer TNO Electronic Products & Services (EPS) B.V. Project number: 03081901.r01 Page 2 of 17 Test specification(s): Description of EUT: Manufacturer: Brand mark: Type: FCC ID: 47 CFR Part 15 (2003-03-13) 2.4 GHz low power WLAN USB Device Samsung Samsung SWL-2300U E2XSWL2300U Description of test item Test item : 2.4 GHz low power WLAN USB device Manufacturer : SAMSUNG Brand : SAMSUNG Type : SWL-2300U Serial numbers : TUKRAA – 230015119 Revision : n.a. Receipt number : n.a. Receipt date : August 14, 2003 Applicant information Applicant's representative : Company : TELEFICATION BV Address : Edisonstraat 12a Postal code : 6902 PK City : Zevenaar PO-box : - Postal code : - City : - Country : Netherlands Telephone number : Telefax number : Test(s) performed Location : Niekerk Test(s) started : August 18, 2003 Test(s) completed : August 22, 2003 Purpose of test(s) : Type approval / certification Test specif…
Text truncated - open the document above for the full version.
314, Maetan-3Dong, Paldal-Gu · Suwon, Kyunggi-Do · South Korea
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.41 GHz - 2.46 GHz | 30.20 mW |
